ON LM258DMR2G, LM2904ADMG, LM2904ADMR2G, LM2904DMR2G, LM2904VDG Schematics

LM258, LM358, LM358A,
LM2904, LM2904A,
LM2904V, NCV2904,
NCV2904V

Single Supply Dual
Operational Amplifiers

http://onsemi.com

Utilizing the circuit designs perfected for Quad Operational
Amplifiers, these dual operational amplifiers feature low power drain,
a common mode input voltage range extending to ground/V

EE

, and
single supply or split supply operation. The LM358 series is
equivalent to one−half of an LM324.

These amplifiers have several distinct advantages over standard
operational amplifier types in single supply applications. They can
operate at supply voltages as low as 3.0 V or as high as 32 V, with
quiescent currents about one−fifth of those associated with the
MC1741 (on a per amplifier basis). The common mode input range
includes the negative supply, thereby eliminating the necessity for
external biasing components in many applications. The output voltage
range also includes the negative power supply voltage.

Features

• Short Circuit Protected Outputs

• True Differential Input Stage

• Single Supply Operation: 3.0 V to 32 V

• Low Input Bias Currents

• Internally Compensated

• Common Mode Range Extends to Negative Supply

• Single and Split Supply Operation

• ESD Clamps on the Inputs Increase Ruggedness of the Device

without Affecting Operation

• NCV Prefix for Automotive and Other Applications Requiring

Unique Site and Control Change Requirements; AEC−Q100
Qualified and PPAP Capable

• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS

Compliant

PDIP−8

N, AN, VN SUFFIX

8

1

8

1

8

1

PIN CONNECTIONS

1

Output A

2

Inputs A

VEE/Gnd

ORDERING INFORMATION

See detailed ordering and shipping information in the package
dimensions section on page 10 of this data sheet.

DEVICE MARKING INFORMATION

See general marking information in the device marking
section on page 11 of this data sheet.

−

+

3

4

(Top View)

CASE 626

SOIC−8

D, VD SUFFIX

CASE 751

Micro8]

DMR2 SUFFIX

CASE 846A

8

V

CC

7

Output B

6

−

Inputs B

+

5

© Semiconductor Components Industries, LLC, 2013

October, 2013 − Rev. 27

1 Publication Order Number:

LM358/D

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

3.0 V to V

CC(max)

Single Supply Split Supplies

Q19

1

2

Q16

V

CC

VEE/Gnd

Q15

Figure 1.

Q14

40 k

Q13

V

CC

1.5 V to V

1

CC(max)

2

1.5 V to V

V

EE

EE(max)

Bias Circuitry

Common to Both

Output

Amplifiers

Q22

V

CC

Inputs

Q2

Q18

Q17

Q3 Q4

5.0 pF

Q20

Q21

Q12

25

Q11

Q9

Q7

Q6

Q5

Q8

Q26

Figure 2. Representative Schematic Diagram

(One−Half of Circuit Shown)

Q10

Q1

Q24

Q23

Q25

2.4 k

2.0 k

VEE/Gnd

http://onsemi.com

2

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

MAXIMUM RATINGS (T

Power Supply Voltages

Single Supply
Split Supplies

Input Differential Voltage Range (Note 1) V

Input Common Mode Voltage Range (Note 2) V

Output Short Circuit Duration t

Junction Temperature T

Thermal Resistance, Junction−to−Air (Note 3) Case 846A

Storage Temperature Range T

ESD Protection at any Pin

Human Body Model
Machine Model

Operating Ambient Temperature Range

= +25°C, unless otherwise noted.)

A

Rating

LM2904/LM2904A

LM2904V, NCV2904 (Note 4)

NCV2904V (Note 4)

Case 751
Case 626

LM258

LM358, LM358A

Symbol Value Unit

Vdc

V

CC

VCC, V

IDR

ICR

SC

R



EE

J

JA

32

±16

±32 Vdc

−0.3 to 32 Vdc

Continuous

150 °C

238

°C/W
212
161

stg

V

esd

−65 to +150 °C

2000

200

T

A

−25 to +85
0 to +70

−40 to +105

−40 to +125

−40 to +150

V

°C

Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.

1. Split Power Supplies.

2. For supply voltages less than 32 V the absolute maximum input voltage is equal to the supply voltage.

3. All R

4. NCV2904 and NCV2904V are qualified for automotive use.

measurements made on evaluation board with 1 oz. copper traces of minimum pad size. All device outputs were active.



JA

http://onsemi.com

3

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

ELECTRICAL CHARACTERISTICS (V

= 5.0 V, VEE = GND, TA = 25°C, unless otherwise noted.)

CC

LM258 LM358 LM358A

Characteristic

Input Offset Voltage

= 5.0 V to 30 V, VIC = 0 V to VCC −1.7 V,

V

CC

] 1.4 V, RS = 0 

V

O

Symbol

V

Min Typ Max Min Typ Max Min Typ Max

IO

Unit

mV

TA = 25°C − 2.0 5.0 − 2.0 7.0 − 2.0 3.0
TA = T
TA = T

Average Temperature Coefficient of Input Offset

(Note 5) − − 7.0 − − 9.0 − − 5.0

high

(Note 5) − − 7.0 − − 9.0 − − 5.0

low

VIO/T

− 7.0 − − 7.0 − − 7.0 −

V/°C

Voltage

TA = T

Input Offset Current I

TA = T

Input Bias Current I

TA = T

Average Temperature Coefficient of Input Offset

high

high

high

to T

(Note 5)

low

to T

(Note 5) − − 100 − − 150 − − 75

low

to T

(Note 5) − −50 −300 − −50 −500 − −50 −200

low

IO

IB

IIO/T

− 3.0 30 − 5.0 50 − 5.0 30 nA

− −45 −150 − −45 −250 − −45 −100

− 10 − − 10 − − 10 − pA/°C

Current

TA = T

Input Common Mode Voltage Range (Note 6),

V

CC

VCC = 30 V, TA = T

Differential Input Voltage Range V

Large Signal Open Loop Voltage Gain A

RL = 2.0 k, VCC = 15 V, For Large VO Swing,
TA = T

high

= 30 V

high

to T

(Note 5)

low

high

to T

low

V

ICR

IDR

VOL

0 − 28.3 0 − 28.3 0 − 28.5 V

0 − 28 0 − 28 0 − 28

− − V

CC

− − V

CC

50 100 − 25 100 − 25 100 −

to T

(Note 5) 25 − − 15 − − 15 − −

low

− − V

CC

V

V/mV

Channel Separation CS − −120 − − −120 − − −120 − dB

1.0 kHz ≤ f ≤ 20 kHz, Input Referenced

Common Mode Rejection

CMR 70 85 − 65 70 − 65 70 − dB

RS ≤ 10 k

Power Supply Rejection PSR 65 100 − 65 100 − 65 100 − dB

Output Voltage−High Limit

= T

to T

T

A

high

(Note 5)

low

VCC = 5.0 V, RL = 2.0 k, TA = 25°C
VCC = 30 V, RL = 2.0 k
VCC = 30 V, RL = 10 k

Output Voltage−Low Limit V

V

OH

V

3.3 3.5 − 3.3 3.5 − 3.3 3.5 −
26 − − 26 − − 26 − −
27 28 − 27 28 − 27 28 −

OL

− 5.0 20 − 5.0 20 − 5.0 20 mV

VCC = 5.0 V, RL = 10 k,

high

to T

(Note 5)

low

O+

mA

TA = T

Output Source Current I

VID = +1.0 V, VCC = 15 V 20 40 − 20 40 − 20 40 −

high

to T

(LM358A Only) 10 − −

low

O−

TA = T

Output Sink Current I

VID = −1.0 V, VCC = 15 V 10 20 − 10 20 − 10 20 − mA

high

high

to T

(LM358A Only) 5.0 − − mA

low

− 40 60 − 40 60 − 40 60 mA

to T

(Note 5)

low

SC

I

CC

A

mA

TA = T
VID = −1.0 V, VO = 200 mV 12 50 − 12 50 − 12 50 −

Output Short Circuit to Ground (Note 7) I

Power Supply Current (Total Device)

= T

T

A

VCC = 30 V, VO = 0 V, RL = ∞ − 1.5 3.0 − 1.5 3.0 − 1.5 2.0
VCC = 5 V, VO = 0 V, RL = ∞ − 0.7 1.2 − 0.7 1.2 − 0.7 1.2

5. LM258: T
LM2904/LM2904A: T
NCV2904 and NCV2904V are qualified for automotive use. NCV2904V: T

6. The input common mode voltage or either input signal voltage should not be allowed to go negative by more than 0.3 V. The upper end of
the common mode voltage range is V

7. Short circuits from the output to V
simultaneous shorts on all amplifiers.

= −25°C, T

low

= +85°C LM358, LM358A: T

high

= −40°C, T

low

= +105°C LM2904V & NCV2904: T

high

− 1.7 V.

CC

can cause excessive heating and eventual destruction. Destructive dissipation can result from

CC

low

= −40°C, T

low

= 0°C, T

= −40°C, T

low

high

= +70°C

high

= +150°C

= +125°C

high

http://onsemi.com

4

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

ELECTRICAL CHARACTERISTICS (V

= 5.0 V, VEE = Gnd, TA = 25°C, unless otherwise noted.)

CC

LM2904V, NCV2904

NCV2904V

Unit

mV

Characteristic

Input Offset Voltage

= 5.0 V to 30 V, VIC = 0 V to VCC −1.7 V,

V

CC

] 1.4 V, RS = 0 

V

O

Symbol

V

IO

LM2904 LM2904A

Min Typ Max Min Typ Max Min Typ Max

TA = 25°C − 2.0 7.0 − 2.0 7.0 − − 7.0
TA = T
TA = T

Average Temperature Coefficient of Input Offset

(Note 8) − − 10 − − 10 − − 13

high

(Note 8) − − 10 − − 10 − − 10

low

VIO/T

− 7.0 − − 7.0 − − 7.0 −

V/°C

Voltage

TA = T

Input Offset Current I

TA = T

Input Bias Current I

TA = T

Average Temperature Coefficient of Input Offset

high

high

high

to T

(Note 8)

low

to T

(Note 8) − 45 200 − 45 200 − 45 200

low

to T

(Note 8) − −50 −500 − −50 −250 − −50 −500

low

IO

IB

IIO/T

− 5.0 50 − 5.0 50 − 5.0 50 nA

− −45 −250 − −45 −100 − −45 −250

− 10 − − 10 − − 10 − pA/°C

Current

TA = T

Input Common Mode Voltage Range (Note 9),

V
VCC = 30 V, TA = T

Differential Input Voltage Range V

Large Signal Open Loop Voltage Gain A

RL = 2.0 k, VCC = 15 V, For Large VO Swing,
TA = T

CC

high

= 30 V

high

to T

(Note 8)

low

high

to T

low

V

ICR

IDR

VOL

0 − 28.3 0 − 28.3 0 − 28.3 V

0 − 28 0 − 28 0 − 28

− − V

CC

− − V

CC

25 100 − 25 100 − 25 100 −

to T

(Note 8) 15 − − 15 − − 15 − −

low

− − V

CC

V

V/mV

Channel Separation CS − −120 − − −120 − − −120 − dB

1.0 kHz ≤ f ≤ 20 kHz, Input Referenced

Common Mode Rejection

CMR 50 70 − 50 70 − 50 70 − dB

RS ≤ 10 k

Power Supply Rejection PSR 50 100 − 50 100 − 50 100 − dB

Output Voltage−High Limit

= T

to T

T

A

high

(Note 8)

low

VCC = 5.0 V, RL = 2.0 k, TA = 25°C
VCC = 30 V, RL = 2.0 k
VCC = 30 V, RL = 10 k

Output Voltage−Low Limit V

V

OH

V

3.3 3.5 − 3.3 3.5 − 3.3 3.5 −
26 − − 26 − − 26 − −
27 28 − 27 28 − 27 28 −

OL

− 5.0 20 − 5.0 20 − 5.0 20 mV

VCC = 5.0 V, RL = 10 k,

= T

to T

T

A

high

Output Source Current I

(Note 8)

low

O+

20 40 − 20 40 − 20 40 − mA

VID = +1.0 V, VCC = 15 V

Output Sink Current I

O−

VID = −1.0 V, VCC = 15 V 10 20 − 10 20 − 10 20 − mA
VID = −1.0 V, VO = 200 mV − − − − − − − − −

Output Short Circuit to Ground (Note 10) I

Power Supply Current (Total Device)

= T

to T

T

A

high

(Note 8)

low

SC

I

CC

− 40 60 − 40 60 − 40 60 mA

A

mA

VCC = 30 V, VO = 0 V, RL = ∞ − 1.5 3.0 − 1.5 3.0 − 1.5 3.0
VCC = 5 V, VO = 0 V, RL = ∞ − 0.7 1.2 − 0.7 1.2 − 0.7 1.2

8. LM258: T
LM2904/LM2904A: T
NCV2904 and NCV2904V are qualified for automotive use. NCV2904V: T

9. The input common mode voltage or either input signal voltage should not be allowed to go negative by more than 0.3 V. The upper end of
the common mode voltage range is V

10.Short circuits from the output to V
simultaneous shorts on all amplifiers.

= −25°C, T

low

= +85°C LM358, LM358A: T

high

= −40°C, T

low

= +105°C LM2904V & NCV2904: T

high

− 1.7 V.

CC

can cause excessive heating and eventual destruction. Destructive dissipation can result from

CC

low

= −40°C, T

low

= 0°C, T

= −40°C, T

low

high

= +70°C

high

= +150°C

= +125°C

high

http://onsemi.com

5

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

CIRCUIT DESCRIPTION

The LM358 series is made using two internally
compensated, two−stage operational amplifiers. The first
stage of each consists of differential input devices Q20 and
Q18 with input buffer transistors Q21 and Q17 and the
differential to single ended converter Q3 and Q4. The first
stage performs not only the first stage gain function but also
performs the level shifting and transconductance reduction
functions. By reducing the transconductance, a smaller
compensation capacitor (only 5.0 pF) can be employed, thus
saving chip area. The transconductance reduction is
accomplished by splitting the collectors of Q20 and Q18.
Another feature of this input stage is that the input common
mode range can include the negative supply or ground, in
single supply operation, without saturating either the input
devices or the differential to single−ended converter. The
second stage consists of a standard current source load
amplifier stage.

Each amplifier is biased from an internal−voltage
regulator which has a low temperature coefficient thus
giving each amplifier good temperature characteristics as
well as excellent power supply rejection.

1.0 V/DIV

V
R
T

5.0 s/DIV

Figure 3. Large Signal Voltage

Follower Response

= 15 Vdc

CC

= 2.0 k

L

= 25°C

A

20

18

16

14

12

10

8.0

I

6.0

V , INPUT VOLTAGE (V)

4.0

2.0
0

0 2.0 4.0 6.0 8.0 10 12 14 16 18 20

Negative

Positive

V

POWER SUPPLY VOLTAGES (V)

CC/VEE,

Figure 4. Input Voltage Range Figure 5. Large−Signal Open Loop Voltage Gain

120

V

= 15 V

100

80

60

40

20

, OPEN LOOP VOLTAGE GAIN (dB)

0

VOL

A

-20

1.0 10 100 1.0 k 10 k 100 k 1.0 M

f, FREQUENCY (Hz)

CC

V

EE

T

= 25°C

A

= Gnd

http://onsemi.com

6

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

14

pp

12

10

8.0

RL = 2.0 k
V

= 15 V

CC

V

= Gnd

EE

Gain = -100

= 1.0 k

R

I

= 100 k

R

F

6.0

4.0

, OUTPUT VOLTAGE RANGE (V )

2.0

OR

V

0

1.0 10 100 1000

f, FREQUENCY (kHz)

Figure 6. Large−Signal Frequency Response Figure 7. Small Signal Voltage Follower

2.4

2.1

1.8

1.5

1.2

0.9

0.6

0.3

CC

I , POWER SUPPLY CURRENT (mA)

0

0 5.0 10 15 20 25 30 35

, POWER SUPPLY VOLTAGE (V) VCC, POWER SUPPLY VOLTAGE (V)

V

CC

TA = 25°C
R

= R

L

550

500

450

400

Input

Output

350

300

, OUTPUT VOLTAGE (mV)

O

250

V

200

0

0 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0

t, TIME (ms)

Pulse Response (Noninverting)

90

80

IB

I , INPUT BIAS CURRENT (nA)

70

0 2.0 4.0 6.0 8.0 10 12 14 16 18 20

VCC = 30 V
V

= Gnd

EE

T

= 25°C

A

CL = 50 pF

Figure 8. Power Supply Current versus

Power Supply Voltage

Figure 9. Input Bias Current versus

Supply Voltage

http://onsemi.com

7

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

R1

50 k

V

V

CC

MC1403

R2

2.5 V

Figure 10. Voltage Reference

e

+

1

1/2

LM358

1

R

C

-

1/2

LM358

+

V

CC

= 2.5 V (1 +

O

10 k

CC

R1
R2

V

V

ref

ref

1

= V

2

V

O

)

Figure 11. Wien Bridge Oscillator

R

-

R1

a R1

-

1/2

LM358

e

o

+

b R1

-

1/2

LM358

e

2

+

1

R

C

R

R1

V

ref

V

in

eo = C (1 + a + b) (e2 - e1)

5.0 k

V

CC

-

1/2

LM358

+

R

R

C

C

R2

+

1/2

LM358

-

R1

V

=

inL

R1 + R2

R1

V

=

inH

R1 + R2

R1

H =

R1 + R2

V

- V

(V

OL

- V

(V

OH

(V

- VOL)

OH

V

O

1

fo =

2  RC

= 1.0 kHz

For: f

o

R = 16 k
C = 0.01 F

Hysteresis

V

OH

V

O

O

V

ref

ref

OL

)+ V

) + V

ref

V

inLVinH

V

ref

ref

Figure 12. High Impedance Differential Amplifier Figure 13. Comparator with Hysteresis

1

=

f

R

C1

V

in

R2

C

-

1/2

LM358

+

V

ref

R2

R1

R

V

ref

Bandpass

Output

-

1/2

LM358

+

R

100 k

C

100 k

R3

-

1/2

LM358

+

V

ref

Where:

-

1/2

LM358

+

V

ref

C1

TBP = Center Frequency Gain
T

= Passband Notch Gain

N

o

R1 = QR

R2 =

R3 = T

C1 = 10 C

For:

f

o

Q
T

BP

T

N

Notch Output

2 

RC

R1

T

BP

N R2

= 1.0 kHz
= 10
= 1
= 1

Figure 14. Bi−Quad Filter

V

ref

R

= 160 k

C

= 0.001 F

R1

= 1.6 M

R2

= 1.6 M

R3

= 1.6 M

1

=V

CC

2

http://onsemi.com

8

=V

V

ref

V

ref

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

V

CC

V

R1

in

C

R2

Given: fo = center frequency

Choose value f

1

CC

2

Triangle Wave

+

1/2

LM358

-

C

f =

Output

R1 + R
4 CRf R1

R2

300 k

R3

75 k

R1

V

R

f

C

100 k

ref

R2 R1

if,

R3 =

R2 + R1

+

1/2

LM358

-

Square
Wave
Output

Then: R3 =

R1 =

R2 =

For less than 10% error from operational amplifier.

Where f

and BW are expressed in Hz.

o

If source impedance varies, filter may be preceded with voltage
follower buffer to stabilize filter parameters.

R3

C

-

1/2

LM358

+

V

ref

A(f

) = gain at center frequency

o

, C

o

Q

 f

C

o

R3

2 A(f

)

o

R1 R3

2

4Q

R1 -R3

CO

CO = 10 C

1

=V

V

ref

2

Q

o fo

BW

< 0.1

V

O

CC

Figure 15. Function Generator

Figure 16. Multiple Feedback Bandpass Filter

http://onsemi.com

9

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

ORDERING INFORMATION

Device Operating Temperature Range Package Shipping

LM358ADR2G

LM358DG 98 Units / Rail

LM358DR2G 2500 / Tape & Reel

LM358DMR2G Micro8

LM358NG PDIP−8

LM258DG

LM258DR2G 2500 / Tape & Reel

LM258DMR2G Micro8

LM258NG PDIP−8

LM2904DG

LM2904DR2G 2500 / Tape & Reel

LM2904DMR2G Micro8

LM2904NG PDIP−8

LM2904ADMG

LM2904ADMR2G 4000 / Tape & Reel

LM2904ANG PDIP−8

LM2904VDG

LM2904VDR2G 2500 / Tape & Reel

LM2904VDMR2G Micro8

LM2904VNG PDIP−8

NCV2904DR2G* SOIC−8

NCV2904DMR2G* Micro8

NCV2904VDR2G* −40°C to +150°C SOIC−8

†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging

Specifications Brochure, BRD8011/D.

*NCV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q100 Qualified and PPAP

Capable.

0°C to +70°C

−25°C to +85°C

−40°C to +105°C

−40°C to +125°C

SOIC−8

(Pb−Free)

(Pb−Free)

(Pb−Free)

SOIC−8

(Pb−Free)

(Pb−Free)

(Pb−Free)

SOIC−8

(Pb−Free)

(Pb−Free)

(Pb−Free)

Micro8

(Pb−Free)

(Pb−Free)

SOIC−8

(Pb−Free)

(Pb−Free)

(Pb−Free)

(Pb−Free)

(Pb−Free)

(Pb−Free)

2500 / Tape & Reel

4000 / Tape & Reel

50 Units / Rail

98 Units / Rail

4000 / Tape & Reel

50 Units / Rail

98 Units / Rail

2500 / Tape & Reel

50 Units / Rail

4000 / Tape & Reel

50 Units / Rail

98 Units / Rail

4000 / Tape & Reel

50 Units / Rail

2500 / Tape & Reel

4000 / Tape & Reel

2500 / Tape & Reel

†

http://onsemi.com

10

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

MARKING DIAGRAMS

PDIP−8
N SUFFIX
CASE 626

8

LMx58N
AWL

YYWWG

1

8

LMx58

ALYW

G

1

x = 2 or 3
A = Assembly Location
WL, L = Wafer Lot
YY, Y = Year
WW, W = Work Week
G = Pb−Free Package
G = Pb−Free Package − (Note: Microdot may be in either location)

8

LM2904N
AWL

YYWWG

1

SOIC−8
D SUFFIX
CASE 751

8

LM358

ALYWA

G

1

8

x58

AYW G

G

1

8

1

8

2904

AYW G

G

1

2904

ALYW

G

Micro8

DMR2 SUFFIX

CASE 846A

8

904A

AYW G

1

PDIP−8

AN SUFFIX

CASE 626

8

LM2904AN

AWL

YYWWG

1

VD SUFFIX

CASE 751

8

1

G

SOIC−8

2904V
ALYW

G

8

904V

AYW G

1

PDIP−8

VN SUFFIX

CASE 626

8

LM2904VN

AWL

YYWWG

1

SOIC−8

VD SUFFIX

CASE 751

*

8

2904V

ALYWV

G

1

NCV2904V

*

G

*This diagram also applies to NCV2904

http://onsemi.com

11

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

PACKAGE DIMENSIONS

PDIP−8

N, AN, VN SUFFIX

CASE 626−05

ISSUE M

NOTE 5

D

D1

14

TOP VIEW

e/2

A1

e

SIDE VIEW

NOTES:

A

58

E

E1

F

c

E2

END VIEW

NOTE 3

A

1. DIMENSIONING AND TOLERANCING PER ASME
Y14.5M, 1994.

2. CONTROLLING DIMENSION: INCHES.

3. DIMENSION E IS MEASURED WITH THE LEADS RE­STRAINED PARALLEL AT WIDTH E2.

4. DIMENSION E1 DOES NOT INCLUDE MOLD FLASH.

5. ROUNDED CORNERS OPTIONAL.

DIM MIN NOM MAX

A −−−− −−−− 0.210

A1 0.015 −−−− −−−−

b 0.014 0.018 0.022
C 0.008 0.010 0.014
D 0.355 0.365 0.400

D1 0.005 −−−− −−−−

E 0.300 0.310 0.325
E1 0.240 0.250 0.280 6.10 6.35 7.11
E2
E3 −−−− −−−− 0.430 −−−− −−−− 10.92

e 0.100 BSC
L 0.115 0.130 0.150

INCHES

0.300 BSC 7.62 BSC

MILLIMETERS

MIN NOM MAX

−−−− −−−− 5.33

0.38 −−−− −−−−

0.35 0.46 0.56

0.20 0.25 0.36

9.02 9.27 10.02

0.13 −−−− −−−−

7.62 7.87 8.26

2.54 BSC

2.92 3.30 3.81

L

SEATING

C

PLANE

E3

8X

b

M

0.010 CA

END VIEW

http://onsemi.com

12

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

PACKAGE DIMENSIONS

SOIC−8 NB

CASE 751−07

ISSUE AK

NOTES:

1. DIMENSIONING AND TOLERANCING PER
ANSI Y14.5M, 1982.

2. CONTROLLING DIMENSION: MILLIMETER.

3. DIMENSION A AND B DO NOT INCLUDE
MOLD PROTRUSION.

4. MAXIMUM MOLD PROTRUSION 0.15 (0.006)
PER SIDE.

5. DIMENSION D DOES NOT INCLUDE DAMBAR
PROTRUSION. ALLOWABLE DAMBAR
PROTRUSION SHALL BE 0.127 (0.005) TOTAL
IN EXCESS OF THE D DIMENSION AT
MAXIMUM MATERIAL CONDITION.

6. 751−01 THRU 751−06 ARE OBSOLETE. NEW
STANDARD IS 751−07.

MILLIMETERS

DIMAMIN MAX MIN MAX

4.80 5.00 0.189 0.197

B 3.80 4.00 0.150 0.157
C 1.35 1.75 0.053 0.069
D 0.33 0.51 0.013 0.020
G 1.27 BSC 0.050 BSC
H 0.10 0.25 0.004 0.010

J 0.19 0.25 0.007 0.010

K 0.40 1.27 0.016 0.050

M 0 8 0 8

____

N 0.25 0.50 0.010 0.020
S 5.80 6.20 0.228 0.244

−Y−

−Z−

−X−

A

58

B

1

S

0.25 (0.010)

4

M

M

Y

K

G

C

SEATING
PLANE

0.10 (0.004)

H

D

0.25 (0.010) Z

M

Y

SXS

N

X 45

_

M

SOLDERING FOOTPRINT*

J

INCHES

1.52

0.060

7.0

0.275

0.6

0.024

4.0

0.155

1.270

0.050

SCALE 6:1

ǒ

inches

mm

Ǔ

*For additional information on our Pb−Free strategy and soldering

details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.

http://onsemi.com

13

LM258, LM358, LM358A, LM2904, LM2904A, LM2904V, NCV2904, NCV2904V

PACKAGE DIMENSIONS

Micro8t

CASE 846A−02

ISSUE H

SEATING
PLANE

−T−

0.038 (0.0015)

PIN 1 ID

DD

H

E

e

E

8 PL

b

0.08 (0.003) A

M

T

S

B

S

NOTES:

1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.

2. CONTROLLING DIMENSION: MILLIMETER.

3. DIMENSION A DOES NOT INCLUDE MOLD FLASH, PROTRUSIONS OR GATE
BURRS. MOLD FLASH, PROTRUSIONS OR GATE BURRS SHALL NOT EXCEED

0.15 (0.006) PER SIDE.

4. DIMENSION B DOES NOT INCLUDE INTERLEAD FLASH OR PROTRUSION.
INTERLEAD FLASH OR PROTRUSION SHALL NOT EXCEED 0.25 (0.010) PER SIDE.

5. 846A-01 OBSOLETE, NEW STANDARD 846A-02.

DIMAMIN NOM MAX MIN

A1 0.05 0.08 0.15 0.002

b 0.25 0.33 0.40 0.010
c 0.13 0.18 0.23 0.005
D 2.90 3.00 3.10 0.114
E 2.90 3.00 3.10 0.114
e 0.65 BSC
L 0.40 0.55 0.70 0.016

H

E

MILLIMETERS

−− −− 1.10 −−

4.75 4.90 5.05 0.187 0.193 0.199

INCHES

NOM MAX

−− 0.043

0.003 0.006

0.013 0.016

0.007 0.009

0.118 0.122

0.118 0.122

0.026 BSC

0.021 0.028

A

A1

c

L

SOLDERING FOOTPRINT*

8X

1.04

0.041

3.20

0.126

0.38

0.015

8X

4.24

0.167

5.28

0.208

0.65

6X

0.0256

SCALE 8:1

ǒ

inches

mm

Ǔ

*For additional information on our Pb−Free strategy and soldering

details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.

Micro8 is a trademark of International Rectifier.

ON Semiconductor and are registered trademarks of Semiconductor Components Industries, LLC (SCILLC). SCILLC reserves the right to make changes without further notice
to any products herein. SCILLC makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor does SCILLC assume any liability
arising out of the application or use of any product or circuit, and specifically disclaims any and all liability, including without limitation special, consequential or incidental damages.
“Typical” parameters which may be provided in SCILLC data sheets and/or specifications can and do vary in different applications and actual performance may vary over time. All
operating parameters, including “Typicals” must be validated for each customer application by customer’s technical experts. SCILLC does not convey any license under its patent rights
nor the rights of others. SCILLC products are not designed, intended, or authorized for use as components in systems intended for surgical implant into the body, or other applications
intended to support or sustain life, or for any other application in which the failure of the SCILLC product could create a situation where personal injury or death may occur. Should
Buyer purchase or use SCILLC products for any such unintended or unauthorized application, Buyer shall indemnify and hold SCILLC and its officers, employees, subsidiaries, affiliates,
and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney fees arising out of, directly or indirectly, any claim of personal injury or death
associated with such unintended or unauthorized use, even if such claim alleges that SCILLC was negligent regarding the design or manufacture of the part. SCILLC is an Equal
Opportunity/Affirmative Action Employer. This literature is subject to all applicable copyright laws and is not for resale in any manner.

PUBLICATION ORDERING INFORMATION

LITERATURE FULFILLMENT:

Literature Distribution Center for ON Semiconductor
P.O. Box 5163, Denver, Colorado 80217 USA

Phone: 303−675−2175 or 800−344−3860 Toll Free USA/Canada
Fax: 303−675−2176 or 800−344−3867 Toll Free USA/Canada
Email: [e-mail]

N. American Technical Support: 800−282−9855 Toll Free

USA/Canada

Europe, Middle East and Africa Technical Support:

Phone: [phone]

Japan Customer Focus Center

Phone: 81−3−5817−1050

http://onsemi.com

ON Semiconductor Website: www.onsemi.com

Order Literature: http://www.onsemi.com/orderlit

For additional information, please contact your local
Sales Representative

LM358/D

14
