OMRON G6RN-1A 12DC Datasheet

G6RN

■Application Examples

• Control equipments

■Characteristics

Note. The data given above are initial values.
*1. Measurement conditions: 5 VDC, 1 A, voltage drop

method.

*2. Measurement conditions: The insulation resistance

was measured with a 500 VDC megohmmeter at the
same locations as the dielectric strength was

measured.
*3. Test conditions: With diode
*4. This value was measured at a switching frequency of

120 operations/min.

Contact resistance *1 100 mΩ max.
Operate time 15 ms max.
Release time 5 ms max.
Insulation resistance *2 1,000 MΩ min.

Dielectric
strength

Between
coil and
contacts

4,000 VAC, 50/60 Hz for 1 min

Between
contacts of
the same
polarity

1,000 VAC, 50/60 Hz for 1 min

Impulse withstand
voltage (between coil
and contacts)

10,000 V (1.2 x 50

μ

s)

Insulation
distance

Between
coil and
contacts

Clearance: 8 mm,
Creepage: 8 mm

Vibration
resistance

Destruction

10 to 55 to 10 Hz, 0.75 mm
single amplitude
(1.5 mm double amplitude)

Malfunction

10 to 55 to 10 Hz
NO: 0.75 mm single amplitude
(1.5 mm double amplitude)
NC: 0.4 mm single amplitude
(0.8 mm double amplitude)

Shock
resistance

Destruction

1,000 m/s

2

Malfunction

NO: 100 m/s

2

NC:: 50 m/s

2

Durability

Mechanical

10,000,000 operations min.
(at 36,000 operations/hr)

Electrical *3

50,000 operations min.
(8 A at 250 VAC, resistive load)
50,000 operations min.
(5 A at 30 VDC, resistive load)
(at 360 operations/hr under

rated load)
Failure rate (P level)
(reference value) *4

10 mA at 5 VDC

Ambient operating
temperature

-40°C to 85°C (with no icing or

condensation)
Ambient operating
humidity

5% to 85%

Weight Approx. 9 g

■Model Number Legend

G6RN-@@

——

12

1. Number of Poles

1: 1-pole

2. Contact Form

None: SPDT (1c)
A: SPST-NO (1a)

■Ordering Information

■Ratings

● Coil

Note 1. The rated current and coil resistance are measured at a coil temperature of 23°C with a tolerance of

±10%.
*2. The operating characteristics are measured at a coil temperature of 23°C.
*3. The “Max. voltage” is the maximum voltage that can be applied to the relay coil.

● Contacts

Classification

Enclosure

rating

Contact form Terminal shape Model

Rated coil

voltage

Minimun

packing unit

Standard Fully sealed

SPST-NO (1a)

PCB

terminals

G6RN-1A

5, 6, 12 VDC

20 pcs/tube

24 VDC

SPDT (1c) G6RN-1

5, 6, 12 VDC

24 VDC

Item

Rated voltage

Rated

current

(mA)

Coil

resistance

(Ω)

Must operate

voltage

(V)

Must release

voltage

(V)

Max.

voltage

(V)

Power

consumption

(mW)

% of rated voltage

5 VDC 43.9 114

70% max. 10% min.

150%

(at 23°C)

Approx. 220

6 VDC 36.6 164
12 VDC 18.3 655
24 VDC 9.2 2,620

Load

Item

Resistive load

Contact type Single

Contact material

Ag-Alloy + gold plating
(Cd free)

Rated load

8 A at 250 VAC

5 A at 30 VDC
Rated carry
current

8 A

Max. switching
voltage

250 VAC, 30 VDC

Max. switching
current

8 A

Note. When ordering, add the rated coil voltage to the model number.

Example: G6RN-1A DC5

However, the notation of the coil voltage on the product case will be marked as @@VDC.

Rated coil voltage

PCB Power Relay

Miniature Power Relay for
Switching 8 A

• Low-profile height of 15 mm (approx. 60% the height of the Omron

G2R model).

• Capable of switching with 8 A at 250 VAC despite its small size.

• High sensitivity with 220mW power consumption.

• Offers high insulation with insulation distance of 8 mm and impulse

withstand voltage of 10kV between coil and contacts.

• Satisfies ambient operating temperature requirement of 85°C.

• Standard model conforms to VDE standards.

RoHS Compliant

G

6
R
N

1

G6RN PCB Power Relay

0 3 5 10 30 50 100 250 500

Switching current (A)

Switching Voltage (V)

50

30

10

8

5

3

1

0.5

0.3

0.1

DC resistive load

AC resistive load

200

180

160

150

140

130

120

110

100

80

0

-40 20 23 30 40 50 60 70 80 90 100

Maximum coil voltage (%)

Ambient Temperature (°C)

100

80

60

40

20

0

-40 -20 0 20 40 60 80 100

Operate/Release voltage (percentage of rated value) (%)

Ambient Temperature (°C)

Must operate voltage
Must release voltage

Sample:
G6RN-1 12 VDC
Number of Relays:
5 pcs

max.

min.

X

max.

min.

X

Sample: G6RN-1 24 VDC
Number of Relays: 5 pcs
Test conditions: The value at which
malfunction occurred was measured
after applying shock to the test piece 3
times each in 6 directions along 3 axes.
Standard value: 100m/s

2

at contact A,

50m/s

2

at contact B

28.5

±0.5

10

±0.5

15

±0.5

3.2

3.219

3.5

7.62

0.5

21

453

(1.19)

7.62

±0.1

Five, 1.3-dia. holes

(1.19)

(1.5)

(1.6)

19

±0.1

3.2

±0.1

3.2

±0.1

G6RN-1

PCB Mounting Holes

(Bottom View)

Terminal Arrangement/
Internal Connections

(Bottom View)

(No coil polarity)

G6RN-1A

PCB Mounting Holes

(Bottom View)

Terminal Arrangement/
Internal Connections

(Bottom View)

(No coil polarity)

■Engineering Data

●Maximum Switching Capacity ●Durability ●Ambient Temperature vs.

Maximum Coil Voltage

●Ambient Temperature vs.
Maximum Coil Voltage

G

6
R
N

100

50

operations)

4

30

Durability (x 10

10

5

3

1

0 2 4 6 8 10

●Shock Malfunction
G6RN-1

Y

contact A

X

88.2

contact B

1,000

250 VAC resistive load
30 VDC resistive load

Switching Current (A)

Z

1,0001,000

Note. The maximum coil voltage refers to the

maximum value in a varying range of operating
power voltage, not a continuous voltage.

■Dimensions

Unit: m/s

1,000

X'

2

Y

Y'

Four, 1.3-dia. holes

±0.1

19

Shock direction

XX'

7.62

±0.1

(2.8)(1.6)

5.1

Z
Z'

(1.19)

±0.1

(1.19)

21

53

1,000

Z'

1,000

Y'

±0.5

±0.5

28.5

±0.5

15

19 5.1

10

3.5

0.5

7.62

2

G6RN PCB Power Relay

• Application examples provided in this document are for reference only. In actual applications, confirm equipment functions and safety before using the product.

• Consult your OMRON representative before using the product under conditions which are not described in the manual or applying the product to nuclear control systems, railroad

systems, aviation systems, vehicles, combustion systems, medical equipment, amusement machines, safety equipment, and other systems or equipment that may have a serious
influence on lives and property if used improperly. Make sure that the ratings and performance characteristics of the product provide a margin of safety for the system or
equipment, and be sure to provide the system or equipment with double safety mechanisms.

OMRON Corporation

Electronic and Mechanical Components Company

Contact: www.omron.com/ecb

Cat. No. J182-E1-04

1116(0207)(O)

Note: Do not use this document to operate the Unit.

■Approved Standards

●The rated values approved by each of the safety standards may be different from the performance characteristics individually defined

in this catalog.

UL Recognized (File No. E41515)
CSA Certified (File No. 31928)

Model

G6RN-1 1 5 to 24 VDC

EN/TÜV Certified

Model

G6RN-1
G6RN-1A

Creepage distance 8 mm
Clearance distance 8 mm
Insulation material group IIIa
Rated Insulation voltage 250 V
Pollution degree 2
Rated voltage system 250 V
Overvoltage category III
Tracking Index of relay base PTI 250 V min. (housing parts)
Flammability class according to UL94 V-0
Ball pressure test (IEC 60695-10-2) 160°C

Number of

poles

Coil ratings Contact ratings

(Certificate No. 6135)

Number of

poles

1 5, 6, 12, 24 VDC

Coil ratings Contact ratings

8 A, 250 VAC 85°C
8 A, 30 VDC 85°C

8 A, 250 VAC (Resistive)
85°C

■Precautions

●Please refer to “PCB Relays Common Precautions” for correct use.

Number of test

operations

6,000

Approved switching

operations

10,000

G

6
R
N

3
