Cat No. W15E-EN-01
Software
CX-Supervisor
Software Release 3.1
.NET Interface
Reference
Trademarks and copyrights Notice
Notice
OMRON products are manufactured for use by a trained operator and only for
the purposes described in this manual.
The following conventions are used to classify and explain the precautions in
this manual. Always heed the information provided with them.
Note: Indicates information of particular interest for efficient and convenient
operation of the product.
Caution:
Indicates information that, if not heeded, could possibly result in minor or
relatively serious injury, damage to the product, or faulty operation.
Warning:
Indicates information that, if not heeded, could possibly result in serious injury
or loss of life.
Trademarks and copyrights
CX-Supervisor is a registered trademark of OMRON.
All other product names, company names, logos or other designations
mentioned herein are trademarks of their respective owners.
Copyright
Copyright © 2010 OMRON
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form, or by any means, mechanical,
electronic, photocopying, recording, or otherwise, without the prior written
permission of OMRON.
No patent liability is assumed with respect to the use of the information
contained herein. Moreover, because OMRON is const antly striving to improve
its high-quality products, the information contained in this manual is subject to
change without notice. Every precaution has been taken in the preparation of
this manual. Nevertheless, OMRON assumes no responsibility for errors or
omissions. Neither is any liability assumed for damages resulting from the use
of the information contained in this publication.
1
Copyright Notice
2
Table of Contents
Notice................................................................................................1
Trademarks and copyrights..................................................................................................................1
Copyright..............................................................................................................................................1
SECTION 1
Introduction......................................................................................7
1-1 Who Should Read This Document ...................... .................................................... ............................7
1-2 Interface Overview ...............................................................................................................................7
1-3 Referencing the DLL ............................................................................................................................7
SECTION 2
Examples ..........................................................................................9
2-1 VB .NET ..............................................................................................................................................9
2-2 C# .NET ............. .... ............................................................................. ... .... ... ... ... .... ............................9
2-3 VB .NET and ASP.NET .......................................................................................................................9
SECTION 3
Class Reference.............................................................................11
3-1 PointMngt...........................................................................................................................................11
3-1-1 ListGroups.............................................................................................................................11
3-1-2 ListPoints ..............................................................................................................................11
3-1-3 SetValue ...............................................................................................................................11
3-1-4 GetValue...............................................................................................................................11
3-1-5 IsValidPoint... ........................................................................................................................12
3-1-6 IsValidGroup.........................................................................................................................12
3-1-7 GetPointData ........................................................................................................................12
3-1-8 BrowsePoints........................................................................................................................12
3-2 ApplicationMngt..................................................................................................................................13
3-2-1 GetErrorString.......................................................................................................................13
3-2-2 Restart ..................................................................................................................................13
3-2-3 GetProjectName ...................................................................................................................13
3-2-4 ListDevices............................................................................................................................14
3-2-5 GetDeviceStatus...................................................................................................................14
3-2-6 GetAppId...............................................................................................................................14
3-2-7 IsValidAppId..........................................................................................................................14
3-2-8 IsValidUser............................................................................................................................14
3-3 AlarmMngt..........................................................................................................................................15
3-3-1 ListAlarmGroups...................................................................................................................15
3-3-2 ListAlarms.............................................................................................................................15
3-3-3 GetAlarmData.......................................................................................................................15
3-3-4 AcknowledgeAlarm...............................................................................................................16
3-3-5 AcknowledgeAllAlarms .........................................................................................................16
3-3-6 BrowseAlarms.......................................................................................................................16
3-3-7 GetAlarmLog.........................................................................................................................16
3-3-8 GetActiveAlarms...................................................................................................................16
3
Table of Contents
3-4 ScriptMngt.......................................................................................................................................... 17
3-4-1 ExecuteScript ....................................................................................................................... 17
3-4-2 ListScripts............................................................................................................................. 17
3-4-3 GetScriptParameters............................................................................................................ 17
3-5 ErrorMngt........................................................................................................................................... 17
3-5-1 GetErrorLog.......................................................................................................................... 17
Revision history.............................................................................19
4
Table of Contents
5
Table of Contents
6
Who Should Read This Document SECTION 1 Introduction
SECTION 1
Introduction
The purpose of this document is to act as an introduction and reference guide
to the CX-Supervisor .NET interface introduced in V3.0.
1-1 Who Should Read This Document
The target audience is application developers knowledgeable in the .NET
Framework and using external libraries. No attempt is made to teach .NET
practices or any programming language.
1-2 Interface Overview
The CX-Supervisor .NET interface allow external applications to access CXSupervisor using well defined interfaces to access specific areas of
functionality. The interface can be divided in to the following areas of
functionality:
• Point monitoring and data gathering
• Application/System management
• Alarm monitoring and control
• Script execution
• Error management
The reference section of th is document provides full details of the class es an d
methods which implement this functionality.
1-3 Referencing the DLL
The interface is exposed through the file SCSRUNLib.dll which is located in
the CX-Supervisor installation directory. In order to use the interface classes
you must first add a reference to it in your project and then insert an
appropriate using or Imports declaration in your class.
7
Referencing the DLL SECTION 1 Introduction
8
VB .NET SECTION 2 Examples
SECTION 2
Examples
These code snippets are provided as an example of how to use the CXSupervisor .NET Interface.
2-1 VB .NET
' declare variables
CErrorMngtClass errorMngr = new CErrorMngtClass();
object list;
' get list of errors
errorMngr.GetErrorLog(out list);
' convert list to string array
string[] errors = (string[])list;
' use error log…
2-2 C# .NET
// declare variables
CPointMngtClass pointMngr = new CPointMngtClass();
object list;
// get list of points
pointMngr.ListPoints(out list);
// convert list to string array
string[] points = (string[])list;
// use points list…
2-3 VB .NET and ASP.NET
The source code for the CX-Supervisor Standard Web Pages is installed along
with CX-Supervisor. It can be opened and run using Visual Web Developer
2008. The Express edition of this software is available as a free download
from Microsoft.
9
VB .NET and ASP.NET SECTION 2 Examples
10
PointMngt SECTION 3 Class Reference
SECTION 3
Class Reference
3-1 PointMngt
Allows the client to manage the acquisition of point information and the
reading and writing of point data.
3-1-1 ListGroups
Retrieves a list of all the point groups contained within a CX-Supervisor
application.
ListGroups(ByRef pGroups As Object)
Parameters Description
pGroups An array of strings representing the names of all the groups
3-1-2 ListPoints
Retrieves a list of all the points that are part of the given group.
ListPoints(ByVal szName As String, ByRef pPoints As
Object)
3-1-3 SetValue
3-1-4 GetValue
Parameters Description
szName Name of Group
pPoints Receives an array of strings representing the names of all the
points contained in the group
This method sets a point to a specified value. In circumstances where the
point can not be set to a value (i.e. More than allowed maximum) the value
returned in the retVal parameter will differ from that specified and represent
the actual value the point was set to.
SetValue(ByVal szName As String, ByVal varValue As Object,
ByRef retVal As Object)
Parameters Description
szName Name of Point
varValue Value the point is to be set to
retVal The actual value the point was set to
Reads the current value of a point.
GetValue(ByVal szName As String, ByRef retVal As Object)
Parameters Description
szName Name of Point
retVal Receives the current value of point
11
PointMngt SECTION 3 Class Reference
3-1-5 IsValidPoint
Determines whether the point is valid.
IsValidPoint(ByVal szName As String, ByVal szGroup As
String, ByRef retVal As Integer)
Parameters Description
szName Name of Point
szGroup Name of Group
retVal Receives true or false
3-1-6 IsValidGroup
Determines whether the group is valid.
IsValidPoint(ByVal szName As String, ByRef retVal As
Integer)
Parameters Description
szName Name of Group
retVal Receives true or false
3-1-7 GetPointData
3-1-8 BrowsePoints
Retrieves the metadata of a specific point
GetPointData(ByVal szName As String, ByRef vartype As
UShort, ByRef pDescription As Object, ByRef bReadOnly As
Integer, ByRef iArraySize As Integer, ByRef Value As
Object)
Parameters Description
szName Name of the Point
vartype The type of point
pDescription The description of the point
iArraySize Number of array elements (1 = non array point)
value The current value of the point
This method retrieves a filtered list of the points contained within a CXSupervisor application.
BrowsePoints(ByVal szFilter As String, ByVal szGroup As
String, ByVal vtDataTypeFilter As UShort, ByRef pPoints As
Object)
12
Parameters Description
szFilter Free format filter eg. “P*”
szGroup Group name filter
ApplicationMngt SECTION 3 Class Reference
Parameters Description
vtDataTypeF
ilter
pPoints Receives an array of strings representing the names of all the
3-2 ApplicationMngt
Allows the client to retrieve Application level information and manage the
running application.
3-2-1 GetErrorString
This method returns the error string corresponding to a specific error code
generated by CXSupervisor in response to a method call on the custom
interface.
GetErrorString(ByVal dwError As Integer, ByRef pString As
Object)
Parameters Description
Data type filter. One of:
0 - All types
11 - Boolean
3 - Integer
5 - Real
8 - String
points that pass the filters
dwError A valid component specific error code that the client had
pString Receives a string error message
3-2-2 Restart
Causes the CX-Supervisor runtime to be restarted. If a path to a .SR2 file is
specified then this is run upon restart.
Restart(ByVal szFile As String)
Parameters Description
szFile Optional path of the SCS application to run.
3-2-3 GetProjectName
Returns the name of the running CX-Super viso r app lica tion pr ojec t.
GetProjectName(ByRef pName As Object)
Parameters Description
pName Receives the name of the project
returned from an interface function from the component. For
which the client application is requesting the server’s textual
representation
13
ApplicationMngt SECTION 3 Class Reference
3-2-4 ListDevices
Retrieves a list of all the devices contained within a CX-Supervisor application.
ListDevices(ByRef pDevices As Object)
Parameters Description
pDevices An array of strings representing the names of all the devices
3-2-5 GetDeviceStatus
Retrieves the status of a device
GetDeviceStatus(ByVal szName As String, ByRef pOpen As
Integer, ByRef pCommsFailed As Integer, ByRef pInError As
Integer)
Parameters Description
szName Name of the device
pStatus Receives the status of the device
3-2-6 GetAppId
Returns a App ID string that can be used to identify the instance of this
runtime.
GetAppId(ByRef pAppId As Object)
3-2-7 IsValidAppId
3-2-8 IsValidUser
Parameters Description
pAppId Receives the App ID
This method determines whether the given App ID matches the current’s
instance’s App ID.
IsValidAppId(ByVal szAppId As String, ByRef retVal As
Integer)
Parameters Description
szAppId The App ID to validate
retVal Receives true or false
This method determines whether the given username and password matches
a configured CXSupervisor runtime user with web access enabled.
IsValidAppId(ByVal szUsername As String, ByVal szPassword
As String, ByRef retVal As Integer)
Parameters Description
szUsername A username to validate
14
szPassword A password to validate
retVal Receives true or false
AlarmMngt SECTION 3 Class Reference
3-3 AlarmMngt
Allows the client to view alarm state and history and acknowledge active
alarms.
3-3-1 ListAlarmGroups
Retrieves a list of all the alarm groups contained within a CX-Supervisor
application.
ListAlarmGroups(ByRef pGroups As Object)
Parameters Description
pGroups Receives an array of strings representing the names of all the
alarm groups
3-3-2 ListAlarms
Retrieves a list of all the alarm contained within the given alarm group.
ListAlarms(ByVal szName As String, ByRef pAlarms As
Object)
Parameters Description
szName Name of Alarm Group
3-3-3 GetAlarmData
pAlarms Receives an array of strings representing the names of all the
alarms
Retrieves the metadata of a specific alarm.
GetAlarmData(ByVal szName As String, ByRef pType As
Object, ByRef pAuto As Integer, ByRef pDescription As
Object, ByRef pPriority As Object, ByRef pStatus As
Object, ByRef pDateTime As Object, ByRef pMessage As
Object)
Parameters Description
szName Name of the Alarm
pType The type of Alarm “simple”, “deadband”, ”rateofchange”
pAuto Indicates Automatically acknowledged
pDescription The description of the alarm
pPriority The priority of the alarm
“Highest”, “High”, “Medium”, “Low”, “Lowest”
pStatus The current status of the alarm
“Inactive”, “Active”, “Acknowledged”
pDateTime The time and date the alarm entered it’s current state
pMessage The message shown
15
AlarmMngt SECTION 3 Class Reference
3-3-4 AcknowledgeAlarm
Acknowledge an alarm.
AcknowledgeAlarm(ByVal szName As String, ByVal szUser As String)
Parameters Description
szName Name of Alarm
szUser User who acknowledged alarm
3-3-5 AcknowledgeAllAlarms
Acknowledge all un-acknowledged, active alarms.
AcknowledgeAllAlarms(ByVal szUser As String)
Parameters Description
szName Name of Alarm
szUser User who acknowledged alarms
3-3-6 BrowseAlarms
This method retrieves a filtered list of the alarms contained within a CXSupervisor application.
BrowseAlarms(ByVal szFilter As String, ByVal
szPriorityFilter As String, ByRef pAlarms As Object)
Parameters Description
szFilter Free format filter eg. A*
szPriorityFilterAlarm priority filter. Eg. “High”. If string empty all types are
pAlarms Receives an array of strings represen tin g th e na m es of all the
3-3-7 GetAlarmLog
This method provides the ability to get a list of all the alarm log entries. The
returned array strings each delimitated by tabs will provide time, message and
status information. The list matches the order of entries in the log.
GetAlarmLog(ByRef pAlarmLogEntries As Object)
Parameters Description
pAlarmLogE
ntries
3-3-8 GetActiveAlarms
Retrieves a list of all the currently active alarms.
GetActiveAlarms(ByRef pAlarms As Object)
returned
alarms
Receives an array of strings representing the alarm log entries
16
Parameters Description
pAlarms Receives an array of strings represen tin g th e na m es of all the
alarms
ScriptMngt SECTION 3 Class Reference
3-4 ScriptMngt
Allows the client to execute scripts contained within a supervisor application.
3-4-1 ExecuteScript
Execute a project level script in the supervisor application.
ExecuteScript(ByVal varName As Object, ByRef pParamList As
Object, ByRef retVal As Object)
Parameters Description
varName Name of script
pParamList Array of objects representing the list of script arguments
retVal Returned output parameters
3-4-2 ListScripts
Retrieve a list of all the project level scripts contained within a CX-Supervisor
application.
ListScripts(ByRef pScripts As Object)
Parameters Description
pScripts Receives an array of strings representing the names of all the
3-4-3 GetScriptParameters
Retrieves the parameters associated with a script.
GetScriptParameters(ByVal szName As String, ByRef
pParamList As Object)
Parameters Description
szName The name of the script
pParamList Receives an array of strings representing the data types of the
3-5 ErrorMngt
Allows the client to access to the error log.
3-5-1 GetErrorLog
Get a list of all the error log entries.
GetErrorLog(ByRef pErrors As Object)
Parameters Description
scripts
parameters
pErrors Receives and array of strings representing the all of the error
log entries (date/time and message)
17
ErrorMngt SECTION 3 Class Reference
18
Revision history
Revision history
A manual revision code appears as a suffix to the catalog number on the front
cover of the manual.
Cat. No. W15E-EN-01
The following table lists the chan ges made to the manual during each revision.
The page numbers of a revision refer to the previous ver sio n.
Revision
code
01 Sept. 2010 First version in the standard Omron format.
Date Revised content
19
Revision history
20
Authorized Distributor:
Cat. No. W15E-EN-01 Note: Specif cations subject to change without notice.
Printed in Europe
Loading...
