RFID Smart Card Reader Technology
CardMan
®
5321 User's Manual
CardMan® 5321
User's Manual
English
If you have any technical problems or other questions please
contact our help desk:
For latest drivers, visit our homepage:
Copyright © OMNIKEY GmbH 2005 (Sept 2005)
Reproduction, adaptation or translation without prior written permission is prohibited,
except as allowed under the copyright laws.
The information contained in this document is subject to change without notice
support@omnikey.com
http://www.omnikey.com
User's Manual - English
Introduction
This manual describes the physical behaviour, short data sheet
and conformities of OMNIKEY's CardMan
contact and contactless smart card reader.
To install your CardMan
described in the “CardMan
If you are developing applications using CardMan
please refer to the “CardMan
®
5321 please follow the steps as
®
5321 Installation Guide”.
®
5321 Developer’s Guide”.
For other detailed information please contact the OMNIKEY
support: support@omnikey.com
Box content
• Smart card reader with fixed USB cable
• This manual
The required drivers for operating your reader can be found in
the internet at
http://www.omnikey.com
®
5321, a combined
®
5321,
Overview
The CardMan® 5321 is a dual interface PC-linked reader that
reads and writes both 13.56 MHz RFID contactless smart cards
and virtually any contact smart card. The dual interface feature
economically supports end-user environments where both
contactless and contact smart card technology may be in use.
The CardMan
cable is fixed to the reader. To connect the reader with your PC,
plug the USB connector to an unused USB port of your
computer.
When the reader is working the LED on the left is lighting up
green. If the reader is not working consult the “CardMan
Installation Manual” for driver setup.
®
5321 is a USB plug and play device. The USB
®
5321
2 RFID Smart Card Reader CardMan® 5321
User's Manual - English
For using a contact card, put the card with the contacts facing
up, in the reader. For contactless operation, hold the card next
to the logo on top of the reader.
When the reader is exchanging data with the card (reading or
writing) the red LED on the right side is on.
Short Data Sheet
Dimensions 115mm x 95.5mm x 25.5mm
Weight (including light base and
adapter)
Operating temperature 10-55°C (50-131°F)
Operating humidity 10-90% rH
Composition ABS
PC Connector cable 180 cm (71")
Contact Interface Durability 100,000 Insertions
Meantime between failure
(MTBF)
Host Interface USB 2.0 CCID
Host Data Transmission speed 12 Mbps (USB 2.0 Full
Power supply Bus powered
(4.53" x 3.8" x 1.0")
160 gr
(5.9 oz.)
500,000 Hours
(also supports 1.1)
Speed)
Conformance Information
CE Marking
The shipped version of this device complies with the
requirements of the directives 89/336/EWG,
73/23/EWG and 1999/5/EG.
RFID Smart Card Reader CardMan® 5321 3
User's Manual - English
Declaration of Conformity
FCC ID: SIYCM5321
IC ID: 5345A-CM5321
This device complies with Part 15 of the FCC Rules
and with Industry Canada Radio Standards
Specification RSS-210 Issue 5, Section 6.2.2(e)
(Category I Equipment).
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
This Class [B] digital apparatus complies with Canadian
ICES-003.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
4 RFID Smart Card Reader CardMan® 5321
User's Manual - English
• Consult the dealer or an experienced radio/TV technician
for help.
Warning: Changes or modifications made to this equipment not
expressly approved by Omnikey GmbH may void the FCC
authorization to operate this equipment.
Declaration of Conformity
This device complies with the Australian/New Zealand Standard
AS/NZS 4268:2003 “Radio equipment and systems – short
range devices – Limits and methods of measurement”.
RFID Smart Card Reader CardMan® 5321 5
