OMNI TH
DIGITAL TISSUE HOMOGENIZER
USER MANUAL
Q
REV. B
03-225
WARRANTY INFORMATION
This manual is a guide for the use of the Omni International THQ, Digital Tissue Homogenizer and accessories.
Data herein has been veried and validated. It is believed adequate for the intended use of the instrument. If the instrument or procedures are used for purposes over and above the capabilities specied herein, conrmation of the validity and suitability should be obtained, other­wise Omni International does not guarantee results and assumes no obligation or liability. This publication is not a license to operate under, or a recommendation to infringe upon, any process patents.
Notes, cautions, and warnings within the text of this manual are used to emphasize important and critical instructions.
This Omni International product is warranted to be free from defects in material and workmanship for a period of THREE (3) YEARS from the date of delivery. Omni International will repair or replace and return free of charge any part which is returned to its factory within said pe­riod, transportation prepaid by user, and which is found upon inspec­tion to have been defective in materials or workmanship. For the rst 90 days, both parts and service are without charge. For the balance of the period, parts will be provided but service will be charged at established labor rates. This warranty does not include normal wear from use; it does not apply to any instrument or parts which have been altered by anyone other than an employee of Omni International nor to any instrument which has been damaged through accident, negligence, failure to follow operating instructions, the use of electric currents or circuits other than those specied on the plate axed to the instrument, misuse, or abuse. Omni International reserves the right to change, alter, modify, or improve any of its instruments without any obligation whatever to make corresponding changes to any instru­ment previously sold or shipped.
THE FORGOING OBLIGATION IS IN LIEU OF ALL OBLIGATIONS AND LIABILITIES IN­CLUDING NEGLIGENCE AND ALL WARRANTIES OF MERCHANTABILITY OR OTHERWISE, EXPRESSED OR IMPLIED IN FACT OR BY LAW, AND STATE OUR ENTIRE AND EXCLUSIVE LIABILITY AND BUYERS EXCLUSIVE REMEDY FOR ANY CLAIM OF DAMAGES IN CONNEC­TION WITH THE SALE OR FURNISHING OF GOODS OR PARTS, THEIR DESIGN, SUITABILI­TY FOR USE, INSTALLATION, OR OPERATION. OMNI INTERNATIONAL WILL IN NO EVENT BE LIABLE FOR ANY SPECIAL OR CONSEQUENTIAL DAMAGES WHATSOEVER, AND THEIR LIABILITY UNDER NO CIRCUMSTANCES WILL EXCEED THE CONTRACT PRICE FOR THE GOODS FOR WHICH LIABILITY IS CLAIMED.
2
IMPORTANT SAFEGUARDS
- READ ALL INSTRUCTIONS BEFORE USING.
- SAVE THIS OWNER’S MANUAL.
The Omni THQ has been engineered for economical functionality as well as safety; however, basic safety precautions and common sense must always be demonstrated when using any electrical product. DO NOT attempt to modify any part of the Omni THQ. If you experi- ence problems with or have questions about your Omni THQ, contact your authorized dealer or call Omni International at 800-776-4431 or 770-421-0058.
DANGER
- DO NOT allow the machine to be submerged in any liquid.
- DO NOT use in any setting other than an indoor laboratory.
- DO NOT plug power cord into an incorrect outlet.
WARNING
To reduce the risk of burns, electrocution, re, or injury:
- Use this product only for its intended purpose as described in this booklet. DO NOT use attachments not recommended by the manufacturer.
- DO NOT operate the product if it is damaged in any way.
- Keep this product away from heated surfaces.
3
TABLE OF CONTENTS
Warranty Information ....................................................................................... 2
Section 1 — Omni THQ, Digital Tissue Homogenizer
1.1 Device Layout ........................................................................................ 5
1.2 Buttons / Display .................................................................................. 6
1.3 Parts and Accessories ......................................................................... 6
1.4 Powering the Device ........................................................................... 7
1.5 Stand Mounting the Omni THQ ....................................................... 7
Section 2 — Rotor-Stator Generator Probes
2.1 Installing Rotor-Stator Generator Probes ................................... 8
2.2 Homogenization .................................................................................. 9
Section 3 — Motor Unit Maintenance
3.1 Specications .....................................................................................10
3.2 Stainless Steel Generator Probes .................................................10
3.3 Motor Drive Unit ................................................................................ 10
3.4 Motor Bearings ..................................................................................10
3.5 Storage ................................................................................................... 11
Section 4 — Troubleshooting ......................................................................12
Section 5 — Service
5.1 Assistance .............................................................................................13
5.2 Decontamination ............................................................................... 13
4
SECTION 1 — Omni TH
1.1 DEVICE LAYOUT
Power jack
DIGITAL TISSUE HOMOGENIZER
Q,
LED RPM display
Running LED
Stop LED
Power button
Run button
Stop button
Speed up button
Speed down button
Stand Arm cutout
Omni Tip™
coupling
5
SECTION 1 — Omni THQ, DIGITAL TISSUE HOMOGENIZER
1.2 BUTTONS / DISPLAY
The THQ is operated by means of a digital touch-pad.
The speed of the THQ is indicated on the LED display.
Press “RUN” to begin homogenization at indicated speed
Press “STOP” to end homogenization
Use the “+” & “-” arrow keys to change the speed of the motor
Press the power button to turn the motor on or o. The motor will store the last selected speed when powered o.
1.3 PARTS AND ACCESSORIES
Prior to operation, please remove all parts from the shipping container and inspect for damaged or missing parts. If any parts are found to be dam­aged or missing, please contact Omni International at 1-800-776-4431.
The Omni TH
Post Clamp Assembly
Omni Tip Plastic Probes
(Hard & Soft TIssue)
Digital Tissue Homogenizer Package consists of the following:
Q
Description Part Number Quantity
Motor Drive Unit
Tool Kit
Instruction Manual
Storage Case
12-200-1 1
12-118 1
30007L (Soft)
30007HT (Hard)
T1001 1
03-225 1
04-502 1
6 6
Also available, but not supplied with the instrument:
Description Part Number Quantity
Stand Assembly* S1000 1
6
SECTION 1 — Omni THQ, DIGITAL TISSUE HOMOGENIZER
1.4 POWERING DEVICE
Connect the included power supply to the Omni THQ motor unit and plug the power supply unit into an appropriate outlet.
STAND-MOUNTING THE OMNI TH
1.5
To mount the Omni THQ to a stand assembly, refer to the gure and follow these steps:
Q
1. Secure the 24” post by twisting it into the base plate until securely tightened.
2. Loosen the locking knob and slide the included post clamp assembly down over the end of the post until the clamp is at the desired height and lock in place.
3. Slide the TH
motor into the opening
Q
on the end of the post clamp assembly and push it down rmly. The unit will lock in place.
4. To remove the TH
, press the black
Q
button on the back of the opening of the post clamp assembly and lift the motor from the cradle.
7
SECTION 2 — ROTOR-STATOR GENERATOR PROBES
2.1 INSTALLING ROTOR-STATOR
GENERATOR PROBES
Stainless steel and plastic Omni Tip™ rotor­stator generator probes are easily installed to the Omni THQ motor by means of a quar­ter-turn bayonet mount. Simply push the generator probe into the motor housing as far as possible, turn clockwise, and release. The Omni THQ is ready to operate.
CAUTION: Remove the blue protective
cap from the stainless steel generator probes before processing. Replace the blue cap when not in use.
WARNING: The tip of the saw tooth
generator probe is sharp.
8
SECTION 2 — ROTOR-STATOR GENERATOR PROBES
2.2 HOMOGENIZATION
Insert the generator probe into the Omni THQ motor. The depth of the generator probe in the sample vessel can signicantly aect ow pat­terns within the vessel. This also aects process­ing eciency. As a rule of thumb, the generator probe usually operates most eciently at a depth of 1/3 (to 1/2) of the liquid height. Heavy sediments may require deeper immersion, and this processing depth can be optimized by observing ow patterns and related processing results. While processing, liquid can circulate through the two holes at the bottom of the gen­erator probe. The top hole of the stainless steel generator probe should not be immersed in the sample. Blocking the upper hole could result in liquid being drawn into the lower motor bear­ing.
CAUTION: When using glass-lled Teon lower
bearings, do not operate the unit for extended periods of time without immersing the bottom of the generator probe in liquid or the sample being processed in order to avoid premature failure of the lower bearing.
WARNING: Reduce the risk of unintentional
starting; make sure that the power switch is in the OFF position prior to plugging in the unit.
WARNING: DO NOT process pathogenic
material in an open container, since aerosols created during normal processing could be inhaled by the operator. Please call for assistance in processing pathogens or other material which require sealed enclosures.
WARNING: DO NOT use the motor
in a dangerous environment.
9
SECTION 3 — MOTOR MAINTENANCE
3.1 SPECIFICATIONS
Motor Speed: 8,000 - 32,000 rpm Processing Capacity: 0.1-150 mL Height (motor only): 21.92 cm (8.63 in.) Weight (motor only): 340 g (11.99 oz.) Electrical Requirements: 115V, 60Hz or 220V, 50Hz
Standards Approval/Compliance: CE Certied (220V)
NOTE:
The THQ is equipped with a universal power supply which
works with an input voltage of 110V-230V at 50 or 60 Hz
3.2 STAINLESS STEEL GENERATOR PROBES
Stainless steel generator probes are also available for the Omni THQ, but are not supplied with the instrument.
Description Part Number
5 mm x 75 mm Stainless Steel Generator Probe
7 mm x 95 mm Stainless Steel Generator Probe B7-95ST
10 mm x 110 mm Stainless Steel Generator Probe
12 mm x 110 mm Stainless Steel Generator Probe
B5-75
B10-110ST
B12-110ST
3.3 MOTOR DRIVE UNIT
The Motor drive housing should be wiped o after use, especially when concentrated and potentially damaging liquids are used during processing. Never use solvents to clean unit or accessories.
3.4 MOTOR BEARINGS
The Omni THQ, Digital Tissue Homogenizer motor is equipped with sealed ball bearings. Under normal use they require no additional lubrication.
10
SECTION 3 — MOTOR MAINTENANCE
3.5 STORAGE
The unique design of the Omni THQ, Tissue Homogenizer allows the hand-held unit to stand vertically on a bench-top or shelf so that it can be stored in less than six square inches of space.
WARNING: Keep all housings in place and in working order.
WARNING: Remove all tools from the generator probe before turning
the motor on.
WARNING: Disconnect the motor before servicing, and when chang-
ing the generator probe.
WARNING: DO NOT modify the plug or cord that is provided. If the
plug will not t the outlet, have the proper outlet installed by a quali­ed electrician.
WARNING: Damaged or worn power cords should be repaired or
replaced immediately by a qualied electrician.
WARNING: Improper connection of the equipment can result in a risk
of electric shock.
11
SECTION 4 — TROUBLESHOOTING
Do not attempt to service the Omni THQ in a manner other than those discussed in this manual. For any issue that is unsuccessfully corrected using this guide, please contact your authorized dealer or call Omni International technical assistance at 1-800-776-4431 or 1-770-421-0058.
PROBLEM CORRECTIVE ACTION
The Omni TH
is plugged in and
Q
turned on but is not functioning.
Teon bearing wears quickly
Excessive splashing
in sample tube
Motor does not spin.
Green light ashes.
- Check power cord connectors
- Check wall socket for power to the outlet
- Fluid level may be too low in the tube.
- Immerse the probe deeper into the uid.
- Fluid level too low for tube size
Rotor is locked.
Remove the obstruction.
12
SECTION 5 — SERVICE
5.1 ASSISTANCE
Should this product ever require service, please contact Omni International at 1–800–776-4431.
5.2 DECONTAMINATION
Should an instrument or component that has been used with radioac­tive or pathogenic material require factory or eld service, comply with the following procedure to ensure the safety of service personnel:
Clean the parts to be serviced of all encrusted material and de­contaminate them. There must be no radioactivity detectable by survey equipment.
Obtain a Decontamination Certicate from Omni International. Complete the certicate and attach to the instrument or parts being returned.
If no Decontamination Certicate is attached, and a potential radioac­tive or biological hazard is detected or suspected by Omni Internation­al, the equipment will not be serviced until proper decontamination and certication is complete. The sender will be contacted for instruc­tions as to the disposition of the equipment. Disposition costs will be borne by the sender.
WARNING: It is a violation of federal law to transport biologically
hazardous or radioactive materials without proper packaging, labeling, and appropriate warnings.
13
NOTES
14
NOTES
15
OMNI TH
Q
DIGITAL TISSUE HOMOGENIZER
Omni International, Inc. 935C Cobb Place Blvd. Kennesaw, GA 30144
800.776.4431
770.421.0058
www.omni-inc.com
