5000 Series Multichannel SD MediaPort - MediaPort 5001 (Single Module)
MediaPort 5002 (Dual Module)
MediaPort 5001 Rear Panel Components
2 3
1
1/2 3 /4
6 7 9
1 Redundant Power Supplies
2 AES Input Group Channel A
3 AES Output Group Channels A-C
4 LTC (Timecode) Group
Channel A
A B C A/B CA
Channel B Channel CChannel A
(A) (B)
108
Module
5 Reference Loop
6 SD SDI Video IN Channel A
7 SD SDI Video OUT Channels A-C
8 RS-422 Ports A-C
Quick Reference Guide
4 5
IN OUT1/2 3/ 4 1/2 3/4 1/2 3/4
12 5
11
1
9 Ethernet
10 IEEE 1394b (to MediaDirectors 2100, 2101, or 2102B)
(to MediaDirectors 2201 or 2202)
11 Net Restart (left), Reset (right)
12 Wink LED
MediaPort 5002 Rear Panel Components
2 3
1
1/2 3/4
6 7 9
1 Redundant Power Supplies
2 AES Input Group Channel A
3 AES Output Group Channels A-C
4 LTC (Timecode) Group
Channel A
A B C A /B CA
Channel B Channel CChannel A
Left Module Right Module
5 Reference Loop
6 SD SDI Video IN Channel A
7 SD SDI Video OUT Channels A-C
8 RS-422 Ports A-C
(A) (B)
108
4 5
IN OUT1/2 3/4 1/2 3/4 1/2 3/4
12 5
11
1
Omneon Technical Support: 888 686-7781 (Americas), +65 6542 0050 (Asia Pacific), + 44 1256 347 401 (EMEA), +1 408 585-5200 (Other)
2 3
Channel A
1/2 3/4
A B C
A
6 7 9
9 Ethernet
10 IEEE 1394b (to MediaDirectors 2100, 2101, or 2102B)
Channel B Channel CChannel A
A/B C
(to MediaDirectors 2201 or 2202)
(A) (B)
108
11 Net Restart (left), Reset (right)
12 Wink LED
4 5
IN OUT1/2 3/4 1/2 3/4 1/2 3/4
12 5
11
28-0162 Rev. E
Page 2
Front Panel Status LEDs
*Left Module
(MediaPort 5002 only)
Channel A Channel A
Channel B
Channel C
For Output
Channel
* As view ed from t he f ront of t he unit
Rear Panel RS-422 Activity LEDs
Right Module
(MediaPorts
Channel B
Channel C
MediaPort Status
Green Record in progress
Blue
Black
Play in progres s
Stopped
5001 & 5002 )
Omneon Technical Support: 888 686-7781 (Americas), +65 6542 0050 (Asia Pacific), + 44 1256 347 401 (EMEA), +1 408 585-5200 (Other)
= Channel A
= Channel B
= Channel C
28-0162 Rev. E
