omm Technology M2 User Manual
57mm
57mm
inchor-M2
TWS Bluetooth Earphone
Reject Call
Hold MFB for 1s to reject incoming call.
Hold
Answer Call
Tap MFB to answer incoming call and tap again to
end the call.
Tap
Overview
Change EarTip
Large
Multi-function Button(MFB)
Middle
Small
LED
Mic
Metal Contacts for Charging
Middle EarTip is strongly suggested to try first as it
fits most people.
Switch Audio Output Between Earphone and Cellphone
Hold MFB for 1s to switch audio output when answering
call.
Hold
Switch on Mute
Double tap MFB when answering call.
Double tap
How to wear
Adjust its end towards your mouth.
Play/Pause
Tap MFB to play or pause when playing music.
Skip Track Forward
Double tap MFB when playing music.
Tap
Double tap
Stereo Mode - Auto Pairing
(For maiden use)
Tear off Insulated Sticker
1. Tear off stickers on both units and plug units back to
charging dock so as to activate your earphone.
Notes: Supposing your earphones fail to be charged, please charge
the dock via USB cable(you may refer to below instructions for more
details).
Three-way Talking
Activate call waiting facility on your phone(for more details
please refer your phone's manual).
1. Whenever you are on the phone and there is an incoming
call at the same time, please press MFB to answer the
second one.
2. Supposing you have two incoming calls at the same time,
the first one is answering while the second is holding,
you may switch their statuses by double pressing MFB.
Voice Control
Hold MFB for 1s to activate voice assistant(like Siri).
Single Unit Reconnecting with Cellphone
Power on single unit(LED turns to white). Tap MFB to reconnect
with the last connected device(the unit was once connected
with this cellphone before).
a.m.
BLUETOOTH
Turn on Bluetooth
Visibility
Visible to all Bluetooth devices nearby
Device name MI
Available Devices
inchor-M2_R
Available Devices
2. Take out the master unit(R) . Hold MFB for 5s to enter
pairing mode. On cellphone, activate Bluetooth facility,
search for "inchor-M2_R" and tap to connect.
Charge for the Earphone
Low battery will be warned by voice prompt(LED will be solid
white when charging and turn off when fully charged)
Notes: LED will turn to red with voice prompt once the units
were plugged into charging dock. Later, LED will be solid
white.
Plug earphones into charging dock(make sure metal contacts
are connected properly).
3. Take out the slave unit(L), hold MFB for 5s to enter pairing
mode. Now please wait for them auto connecting with
each other(sharing audio/media).
Charge for the Dock
LED will be solid red when charging and turn to blue once
fully charged.
Charge the dock via USB cable.
Stereo Mode - Manual Pairing
connect with each other automatically)
1. At first, pair the master unit(R) with cellphone(for details
you may refer to "Mono Mode - Master Unit(R)").
(when two units fail to
a.m.
BLUETOOTH
Turn on Bluetooth
Visibility
Visible to all Bluetooth devices nearby
Device name MI
Available Devices
inchor-M2_R
Available Devices
Features
With the new 4.1 Bluetooth version, inchor
-M2 brings you more HD experience.
TWS style delivers true wireless stereo
sound effect.
Charging dock allows the device to be charged
even when stored.
Parameters
Model number: inchor-M2
Battery capacity:3.7V 45mAh
Stand-by time: approx.50hrs.
Input parameter: 5V 250mA
Battery type: Li-polymer
Operation range: 10m(no obstacle)
Bluetooth profile:HFP/HSP/A2DP/AVRCP
Bluetooth version:V4.1
Weight: 5.3g
Talking time: 2 or 3hrs
Size: 25.3×17.3×29mm
Hold for 3s
2. Once you finish the above process, please power off the
master unit(R)(LED turns to red).
After Service and Support
Warranty period:
12 months following the purchase date.
Free service:
Under warranty, if there is any breakdown caused
by manufacturing defects, please contact our dealers
to enjoy freemaintenance. You will always need this
Warranty Card and your receipt or other proof of
purchase to claim warranty.
Free maintenance won’t be available under the
followingcircumstances：
1.Without Warranty Card or intact maintenance label.
2.Damage caused by improper disassembly or repair.
3.Damage resulting from liquid or dropping, and
other artificial mechanical defects.
4.Damage caused by any force majeure.
Hold MFBs for 8s
3. Hold MFBs of both units until LED turns to solid white(LED
may flash red and white before being solid white, ). Then
wait until LED flashes red and white again with voice
prompt, now you have paired two units with each other.
Hazardous substances and their contents in the item
Hazardous Substances
Part Name
Main body
Battery
Ear tips
Accessories
Charging cable
This form is made by SJ/T 11364 regulation.
O：means that hazardous substance content in the homogeneo
us materials of this part is within the limitsof GB/T 26572
regulation.
X ：means that hazardous substance content in, at least,one
certain homogeneous material of this part is beyond the
limits of GB/T 26572 regulation.
（Pb） （Hg）
（Cd） （Cr(VI)） （PBB）
（PBDE）
Facilities in Stereo Mode
Power-on
Hold MFB for 4s(LED turns to white).
Power-off
Supposing two units connect with each other and master
unit(R) connects with cellphone, hold MFB on any of them
for 5s(LED turns to red).
Connect Two Units with Each Other and Play Media in
both Units
1.Take out master unit(R) from charging dock and hold
MFB to enter pairing mode(LED will flash red and white),
refer to according steps for pairing with cellphone.
Then get out the slave unit(L) from the dock and hold
MFB to power on the unit(LED will be white for 1s).
Please wait for it auto re-connect with the master unit(R).
2.Supposing the master unit(R) and slave unit(L) fail to
connect with each other, you may connect the master
unit(R) to cellphone and try to play music. Please power
on the slave unit(L), then triple tap MFB on the master
unit(R) and the master unit(R) will re-connect with the
slave unit(L).
5
Lifespan:
As the booklet states, the eco-lifespan of the item is 5 years
while using it in normal ways. During the period, no dangerous
material will be leaked. The item must be recycled by the local law.
Tips
1.Before using the headset, please read the manual
carefully and keep it for future references.
2.The headset need to be fully charged prior to first-time
use.
3.If the headset is left unused for over two weeks, please
recharge it periodically.
4.Please use the chargers made by qualified manufacturer.
Play Media in Both Units
Play/pause
Supposing two units are connected with each other while the
master unit(R) is connected with cellphone, you may tap MFB
on any of two units to play or pause.
Skip track forward
Double tap MFB on any of two units.
Note: You can only use the master unit to answer incoming call
as you will hear nothing from the slave unit(L).
5.If the headset cannot be found by your phone, please
check whether it is in pairing mode; if left unconnected
for a long while, the headset will exit pairing mode,
please re-enter the mode; if a procedure error of your
phone occurs, reboot it ; if a procedure error of the
headsetoccurs, reboot or reset it.
6. If the two units can not connect with eachother
automatically when switched on. Please hold the MFB
of both units until the white light is on then move them
approaching each other andwait for the connection
completed.
Mono Mode - Master Unit(R)
1. Master unit will auto enter pairing mode once power-on
(LED flashes red and white slowly).
2. On cellphone, activate Bluetooth facility then search for
"inchor-M2_R" and tap to connect.
3. The connection is done.
Caveats
1.Never disassemble or modify your headset for any
reasons to avoid any damages and danger.
2.Do not store the headset in extreme temperatures
(under 0℃ or over 45℃).
3.Avoid using the indicator close to the eyes of children
or animals.
4.Do not use this headset during a thunderstorm to
avoid irregular function and increased risk of electric
shock.
5.Do not use harsh chemicals or strong detergents to
clean the headset.
6.Keep the headset dry.
Please arrange using time properly since
Notes:
your hearing may be damaged by using the device
for a long time.
Mono Mode - Slave Unit(L)
Hold for 5s
1. Switch off slave unit(L) then hold its MFB for 5s to enter
pairing mode(LED flashes red and white slowly).
2. On cellphone, activate Bluetooth facility then search for
"inchor-M2_L" and tap to connect.
3. The connection is done.
For any after service, please contact customer
-service
Perform standard: Q/HL 1-2016
www.inchor.cn
Web:
Manufacturer: Shenzhen Incomm Technology,CO.,Ltd.
Address:Second Industrial Zone A24,Fuyong Street,
Bao’an District, Shenzhen, City China.
2AHR6-M2
Facilities in Mono Mode
Power-on
Hold MFB for 4s(LED turns to white).
Hold
Power-off
Hold MFB for 5s(LED turns to red).
Hold
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving an tenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition
www.inchor.cn
without restriction.
