Pipe-Plug Thermistor Probes
TH-44004 Series
$
61
SST strain
relief spring
⻬ Ideal for Use in Pressure Vessel
Applications 2500 PSI (172 bar) Max
⻬ Max Temperature 150°C (302°F) or 75°C
(167°F) Depending on Option Selected
⻬ 6 mm Diameter Sheath with 1⁄4 or 1⁄8 NPT
Mounting Thread Standard; Sheath and
Plug are 300 Series Stainless Steel
⻬ 2 m (80") 26 AWG Stranded, PFA
Insulated and Jacketed, SST Braided
Cable with Stripped Leads Standard
⻬ Available in 5 Resistance Values and
2 Tolerances
TH-44004-1/4NPT-80,
$61, shown actual size.
14.2 mm (0.56") hex 1⁄4 NPT
6 mm
(0.24")
Dia.
13 mm
(0.5")
Standard Dimensions
1
⁄4 NPT
11 mm (0.43") hex 1⁄8 NPT
6 mm
(0.24")
Dia.
13 mm
(0.5")
1
⁄8 NPT
AVAILABLE FOR FAST DELIVERY!
To Order (Specify Model Number)
Model Resistance Tolerance Sheath Cable Lgth Cable
Number Price @ 25°C @ 0 to 70°C Dia. (mm) m (in) Termination
TH-44004-1/4NPT-80 $61 2252 Ω ±0.2°C 6 2 (80) Stripped
TH-44004-1/8NPT-80 61 2252 Ω ±0.2°C 6 2 (80) Stripped
Options: Other thermistors selections are available—select from the table below, insert the thermistor number into the model number and add
any additional price shown into the probe price. For phone plug option, add “-PP” to the model number and $7 to the price. For leads over
2 m (80"), change model number to required length and add $10/m to the price. For longer cable length, contact Sales.
Ordering Examples: TH-44004-1/4NPT-80,1⁄4 NPT pipe plug sensor, 2252 Ω at 25°C, interchangeability ±0.2°C, 2 m (80") of cable, $61.
TH-44033-1/8NPT-120-PP,1⁄8 NPT pipe plug sensor, 2252 Ω at 25°C, interchangeability ±0.1°C, 3 m (10') of cable with phone plug connector,
$61 + 11 + (1 x 10) + 7 = $89.
Thermistor Selection Table
Model Number Add’l Price Resistance @ 25°C Tolerance @ 25°C Max Temperature
44004 — 2252 Ω ±0.02°C 150°C
44005 — 3000 Ω
44007 — 5000 Ω
44006 — 10000 Ω
44008 — 30000 Ω
44033 $11 2252 Ω
44030 11 3000 Ω
44034 11 5000 Ω 0.01°C
44031 11 10000 Ω
44032 11 30000 Ω
±0.2°C
±0.1°C
150°C (302°F)
75°C (167°F)
D-33
