Page 1
NEMA TYPE 4X ENVIROLINE
SERIES 304 STAINLESS
STEEL ENCLOSURES
SCE-EL Series
®
l 0.075" Stainless Steel Type 304
l Seams Continuously Welded and
Ground Smooth
l Flange Trough Collar Around All
Sides of Door Opening
l Oil-Resistant Gasket
l Collar Studs Provided for Mounting
Optional Sub-Panels
l Stainless Steel Concealed Hinge
l Removable and Interchangeable Doors
l Black Quarter Turn Latches
l Latches Are Opened or Closed With a Screwdriver
(Optional Tamper-Resistant Inserts Are Available)
l Mounting Holes In Back of Enclosure
l Mounting Hardware, Sealing Washer and Hole Plug
Included
l Removable Print Pocket
l Ground Studs On Door and Body
l Optional Mounting Feet Available
l Door Hardware Available
l Panel Can Be Special Ordered in Stainless Steel Up
to 48P36 Size
SCE-12EL1206SSLP
shown smaller than actual size.
Application
Designed to house electrical and electronic controls, instruments
and components in areas which may be regularly hosed down or are
in very wet conditions. Provides protection from dust, dirt, oil and
water. For outdoor application a drip shield is recommended.
Finish
#4 brushed finish on all exterior surfaces. Optional panels are
powder coated white.
Industry Standards
NEMA Type 4, 4X, 12 & 13; UL Listed Type 4, 4X & 12;
CSA Type 4, 4X & 12; IEC 60529 IP 66
N-67
Page 2
A - 12.7 (.50)
DOOR
A - 63.5 (2.5)
OPENING
B
A - 177.8
(7)
AVAILABLE
DOOR SPACE
B - 136.3
(5.37)
82.6
(3.25)
27.9
(1.10)
SEE
SUB-PANEL
NOTES
C
A
A - 38.1
(1.50 )
D
31.8
(1.25)
B - 63.5 (2.5)
OPENING
B - 9.3 (.37)
DOOR
B - 38.1
(1.5)
E
82.6
(3.25)
31.8
(1.25)
11.1
(.44)
SUB-PANEL NOTES:
Dimensions are from the inside of the door
C + 8.1 (.32) for flat sub-panels
C - 4.5 (.18) for bent sub-panels
LATCH NOTE:
Enclosures > 609.4 (24) in height require
only one latch centered on door.
Enclosures ≥ 609.4 (24) and < 1016 (40)
in height require two latches on door.
Enclosures ≥ 1016 (40) require three latches
on door.
Doors ≥ 508 (20) in width require an additional
latch centered top and bottom in door.
38.9
(1.53)
Dimensions: mm (inch)
ø = diameter
A
38.9
(1.53)
SECTION A-A
To Order Visit omega.com/sce_el for Pricing and Details
TYPE 4X 304 STAINLESS STEEL ENVIROLINE® SERIES ENCLOSURES
ENCLOSURES (inch) SUB-PANEL (inch)
HEIGHT WIDTH DEPTH HEIGHT WIDTH
MODEL NO. (A) (B) (C) MODEL NO. (D) (E)
SCE-12EL1206SSLP 12.00 12.00 6.00 SCE-12DLP12 9.00 9.00
SCE-12EL2406SSLP 12.00 24.00 6.00 SCE-12P24 9.00 21.00
SCE-16EL1206SSLP 16.00 12.00 6.00 SCE-16P12 13.00 9.00
SCE-16EL1208SSLP 16.00 12.00 8.00 SCE-16P12 13.00 9.00
SCE-16EL1606SSLP 16.00 16.00 6.00 SCE-16P16 13.00 13.00
SCE-16EL1608SSLP 16.00 16.00 8.00 SCE-16P16 13.00 13.00
N-68
Page 3
To Order Visit omega.com/sce_el for Pricing and Details
TYPE 4X 304 STAINLESS STEEL ENVIROLINE® SERIES ENCLOSURES (CONTINUED)
ENCLOSURES (inch) SUB-PANEL (inch)
HEIGHT WIDTH DEPTH HEIGHT WIDTH
MODEL NO. (A) (B) (C) MODEL NO. (D) (E)
SCE-16EL2008SSLP 16.00 20.00 8.00 SCE-20P16 17.00 13.00
SCE-20EL1606SSLP 20.00 16.00 6.00 SCE-20P16 17.00 13.00
SCE-20EL1608SSLP 20.00 16.00 8.00 SCE-20P16 17.00 13.00
SCE-20EL1610SSLP 20.00 16.00 10.00 SCE-20P16 17.00 13.00
SCE-20EL2006SSLP 20.00 20.00 6.00 SCE-20P20 17.00 17.00
SCE-20EL2008SSLP 20.00 20.00 8.00 SCE-20P20 17.00 17.00
SCE-20EL2010SSLP 20.00 20.00 10.00 SCE-20P20 17.00 17.00
SCE-20EL2408SSLP 20.00 24.00 8.00 SCE-24P20 21.00 17.00
SCE-24EL1608SSLP 24.00 16.00 8.00 SCE-24P16 21.00 13.00
SCE-24EL2006SSLP 24.00 20.00 6.00 SCE-24P20 21.00 17.00
SCE-24EL2008SSLP 24.00 20.00 8.00 SCE-24P20 21.00 17.00
SCE-24EL2010SSLP 24.00 20.00 10.00 SCE-24P20 21.00 17.00
SCE-24EL2012SSLP 24.00 20.00 12.00 SCE-24P20 21.00 17.00
SCE-24EL2408SSLP 24.00 24.00 8.00 SCE-24P24 21.00 21.00
SCE-24EL2410SSLP 24.00 24.00 10.00 SCE-24P24 21.00 21.00
SCE-24EL2412SSLP 24.00 24.00 12.00 SCE-24P24 21.00 21.00
SCE-24EL2416SSLP 24.00 24.00 16.00 SCE-24P24 21.00 21.00
SCE-24EL3008SSLP 24.00 30.00 8.00 SCE-30P24 27.00 21.00
SCE-24EL3010SSLP 24.00 30.00 10.00 SCE-30P24 27.00 21.00
SCE-30EL1606SSLP 30.00 16.00 6.00 SCE-30P16 27.00 13.00
SCE-30EL2008SSLP 30.00 20.00 8.00 SCE-30P20 27.00 17.00
SCE-30EL2010SSLP 30.00 20.00 10.00 SCE-30P20 27.00 17.00
SCE-30EL2408SSLP 30.00 24.00 8.00 SCE-30P24 27.00 21.00
SCE-30EL2410SSLP 30.00 24.00 10.00 SCE-30P24 27.00 21.00
SCE-30EL2412SSLP 30.00 24.00 12.00 SCE-30P24 27.00 21.00
SCE-30EL2416SSLP 30.00 24.00 16.00 SCE-30P24 27.00 21.00
SCE-30EL3008SSLP 30.00 30.00 8.00 SCE-30P30 27.00 27.00
SCE-30EL3010SSLP 30.00 30.00 10.00 SCE-30P30 27.00 27.00
SCE-30EL3012SSLP 30.00 30.00 12.00 SCE-30P30 27.00 27.00
SCE-30EL3608SSLP 30.00 36.00 8.00 SCE-36P30 33.00 27.00
SCE-36EL2408SSLP 36.00 24.00 8.00 SCE-36P24 33.00 21.00
SCE-36EL2410SSLP 36.00 24.00 10.00 SCE-36P24 33.00 21.00
SCE-36EL3008SSLP 36.00 30.00 8.00 SCE-36P30 33.00 27.00
SCE-36EL3010SSLP 36.00 30.00 10.00 SCE-36P30 33.00 27.00
SCE-36EL3012SSLP 36.00 30.00 12.00 SCE-36P30 33.00 27.00
SCE-36EL3608SSLP 36.00 36.00 8.00 SCE-36P36 33.00 33.00
SCE-36EL3612SSLP 36.00 36.00 12.00 SCE-36P36 33.00 33.00
SCE-42EL2410SSLP 42.00 24.00 10.00 SCE-42P24 39.00 21.00
SCE-42EL3010SSLP 42.00 30.00 10.00 SCE-42P30 39.00 27.00
SCE-42EL3612SSLP 42.00 36.00 12.00 SCE-42P36 39.00 33.00
SCE-42EL3616SSLP 42.00 36.00 16.00 SCE-42P36 39.00 33.00
SCE-48EL3612SSLP 48.00 36.00 12.00 SCE-48P36 45.00 33.00
SCE-48EL3616SSLP 48.00 36.00 16.00 SCE-48P36 45.00 33.00
SCE-60EL3612SSLP 60.00 36.00 12.00 SCE-60P36 57.00 33.00
SCE-60EL3616SSLP 60.00 36.00 16.00 SCE-60P36 57.00 33.00
SCE-72EL3016SSLP 72.00 30.00 16.00 SCE-72P30 69.00 27.00
SCE-72EL3612SSLP 72.00 36.00 12.00 SCE-72P36 69.00 33.00
SCE-72EL3616SSLP 72.00 36.00 16.00 SCE-72P36 69.00 33.00
Ordering Examples: SCE-12EL1206SSLP, Type 4X 304 stainless steel Enviroline® series enclosure.
SCE-24EL2008SSLP, Type 4 series Enviroline stainless steel enclosure, 24 H x 20 W x 8" D, SCE-24P20, sub-panel.
N-69
