Omega Products PX276 Installation Manual

Pressure Transducer

PX276 and PX279

M3505/0303

SPECIFICATIONS

Accur acy*: ± 1%

Overpressure: 10

Supply Voltage: 12 - 40

transducers only)

Supply Current: 10
20

M

maximum MA output tran sducers

A

Enclosure: 18 Ga. C.R. steel NEMA-4 (IP-65) 6061T aluminum
probe

Finish: Baked on enamel PMS2GR88B

Conformance: EMC standards EN50082-1(1992),

EN55014(1993)/EN60730-1(1992)

Compensated Temperature Range: 25°F to 150°F (4°C to

)

65°C

T. C . E rr o r: ± 0.0125%/°F (.02%/°C)

Media Compatibility: Clean dry air or any inert gas

Environmental: 10 to 90% RH non-condensing

Te rm in a ti o n: Unpluggable screw terminal block

Wire Size: 12 Ga. maximum

Load Impedance: 1.6K ohms maximum at 40

transducers); 1,000 ohms minimum (

Weight: 1.0 lb. (.45 kg)

*

Includes nonlinearity, hysteresis, and non-repeatability.

FS

PSID

M

A

VDC

maximum

; 12 - 35

VAC (VDC

output transd ucers;

VDC

output transducers)

VDC

(MA output

VDC

output

4. If using a controller/meter with an internal power
supply, connect the controller/meter input signal to
the [+] terminal. Connect the controller/meter
common to the [-] terminal.

5. Reinsert the terminal block onto the circuit board and
apply power to the transducer.

6. Check for the appropriate output signal using a digital
voltmeter set to DC milliamps connected in series to
the [-] term inal.

Wiring the PX-279:

1. Remove the blue terminal block by carefully pulling it

off the circuit board.

2. Note the block’s terminal markings on the circuit board.

3. Connect the power supply voltage wire to the [+]

terminal and the power sup ply common to the [-]
terminal.

4. Connect the controller/meter input wire to the [0]
terminal and the controller/meter common wire to the
[-] terminal.

CALIBRATION

All transducers are factory calibrated to meet or exceed
published specifications. If field adjustment is necessary,
follow these instructions:

1. Connect the [+ ] and [-] termina ls to the appropr iate
power source.

2. If calibrating an
voltmeter in series to the [-] terminal.

3. If calibrating a VDC output transducer, connect a digital
voltmeter on DC volts across the [0] and [-] terminals.

output transducer, connect a digital

M

A

INSTALLATION PRECAUTIONS

Do not use on oxygen service, in an explosive or hazardous
environment, or with flammable or combustible material.

Disconnect the power supply before installing the transducer.
Failure to do so can result in electrical shock and equipment
damage.

Make all connections in accordance with the job wiring
diagram and national and local electrical codes.

Use electrostatic discharge precautions such as wrist straps
when installing and wiring the transducer.

Do not exceed ratings for the transducer.

If using grounded AC, ensure that the hot wire is on the [+]
terminal. Also, if using a controller without built-in isolation,
use an isolation transformer to supply the transducer.

This transducer contains a half-wave rectifier power supply
and must not be powered from transformers powering other
devices with non-isolated full-wave rectifier power supplies.

When multiple transducers are powered from the same
transformer, damage will result unless all 24-gage power
leads are connected to the same power lead on all
transducers. Maintain the correct phasing when powering
more than one transducer from a single transformer.

WIRING

Use 12

The
power supply. The
for 0 - 5
either 12 - 40

Wiring the PX-276:

wire maximum for wiring terminals.

AWG

M

output transducer must be powered with a 12 - 40

A

or 0 - 10

VDC

output transducer is field selectable

VDC

output and can be powered with

VDC

or 12 - 35

VDC

VAC

.

VDC

5. Reinsert the terminal block onto the circuit board and
apply power to the transducer.

6. Check the appropriate VDC output using a di gital
voltmeter set to DC volts connected to the [0] and [-]
terminals.

PRESSURE RANGES AND JUMPER
CONFIGURATIONS

Jumper Configurations

Range A B C

05 0 - 5.0”w.c. 0 - 2.5”w.c. 0 - 1.25”w.c.

15 0 - 15”w.c. 0 - 7.5”w.c. 0 - 3.75”w.c.

Jumper Conf igurations for Pr essure Ranges

4. Apply low pressure to the transducer and carefully

adjust the zero tr immer [Z] to obtain the desired low
output pressure.

5. Apply high pressure to the transducer and adjust the
span trimmer [S] to obtain the desired high output
pressure.

6. Repeat steps 4 and 5 until the transducer is fully
calibrated.

DIMENSIONS

1. Remove the blue terminal block by carefully pulling it

off the circuit b oard.

2. Note the block’s terminal markings on the circuit board.

3. If using an external power supply, connect the supply

voltage wire to the [+] terminal. Connect the power
supply common to the common bus of the controller/
meter. Connect th e input signal of the controller/meter
to the [-] te rminal.

Jumper Configurati ons for VDC Output
