Digital Infrared Temperature Scanner
With Automatic Emissivity Compensation
OS91
Starts at
$
879
19
(0.75)
15
(0.6)
20
(0.8)
Dimensions: mm (in)
Applications
Research
Production
Quality Control
Maintenance
Energy Conservation
Automatic Emissivity
Compensation
Scans Temperature
Rapidly
-45 to 287°C
(-50 to 550°F) Range
0.1°C/°F Resolution with
Scan/Min/Max and
Audible Assist
OS91, $879, shown
actual size.
Carrying case included.
Spectral Response
from 2 to 20 Microns
Analog Output Optional
Fast 80 ms Time
Constant
High-Impact Housing
with Copper EMI Shield
Measures Relative
Humidity and Dew Point
J-37
AT A DISTANCE,
THE OS91 OPERATES AS
A HIGH-SPEED INFRARED
SCANNING DEVICE
WHEN THE NOSE PIECE OF
THE OS91 IS IN CONTACT WITH
A SURFACE, IT WILL DISPLAY AN
ACCURATE SURFACE TEMPERATURE
Extended Warranty
Program
SM
The OS91 infrared temperature
scanner is a general purpose
instrument that can measure
surface temperature quickly and
accurately. Because it is
microprocessor powered and
computer calibrated, the OS91 is
highly stable. It has a patented
automatic emissivity compensation
system for close-up measurements;
no emissivity adjustment is required.
The OS91 has a 0.1° resolution that
switches between °C and °F with
the push of a button. Instant lock,
max-reading lock, and min-reading
lock features offer the utmost in
speed and precision. An audible
assist feature beeps when a new
min or max reading is detected.
The OS91 updates its display every
100 ms. The copper-coated housing
shields against EMI/noises, which
makes this model attractive
in the medical field. The one-piece,
high-impact design eliminates
cable and probe failures and
provides unsurpassed durability.
A psychrometer kit (included) allows
measurements of wet and dry bulb
temperatures. The OS91 has a dial
indicator to translate scanned
temperatures into relative humidity
and dew point values.
OMEGACARESMextended warranty
program is available for models shown on
this page. Ask your sales representative
for full details when placing an order.
OMEGACARE
and equivalent loaners.
SM
covers parts, labor
Meaures Surface
Temperature in a
Fraction of a Second
Accurate Over a Wide Emissivity Range
Specifications
Temperature Range -45 to 287°C (-50 to 550°F)
Temperature Units °C/°F switchable
Linearity Error ±1% rdg + 1 digit
Emissivity Error ±1% of difference between target
Repeatability ±0.1°C or °F
Resolution 0.1°C or °F
LED Display Update 100 ms
Time Constant Approx 80 ms
Field of View Approx 1:1 (53°)
Minimum Spot Size 6.4 mm (0.25")
Spectral Response 2 to 20 microns
Power 9V alkaline battery (included)
Battery Life Approx 5000 readings
Dimensions 86 x 127 x 19 mm (3.375 x 5 x 0.75")
Weight 0.2 kg (7 oz)
temperature and instrument temperature
when touching surface ( 0.8 to 1.0
J
⑀)
AVAILABLE FOR FAST DELIVERY!
To Order (Specify Model Number)
Model No. Price Description
OS91 $879 Digital temperature scanner, 0.1° resolution
OS91-A 1079 OS91 with analog output
OS91-PEN 12 Spare marking pen
Comes complete with relative humidity kit, carrying pouch, marking pen, 9V alkaline battery
and operator’s manual.
Ordering Example: OS91, 0.1° resolution scanner, $879. OCW-2, OMEGACARESMextends
standard 2-year warranty to a total of 4 years ($158), $879 + 158 = $1037.
Recommended Reference Book: Practical Optics,
PE-1410, $70. See Section Y for Additional Books.
