Lifetime
OMG-USB-232-2, OMG-USB-232-4
and OMG-USB-232-8
Two, Four and Eight Port RS-232 to USB Adaptors
OMG-USB-232-4, $209,
Shown smaller than actual size
C
Starts at
$
159
⻬ Power Obtained from
USB Cable - No External
Power Required
⻬ “Hot swapping”/ Auto
Configuration
⻬ High Speed UART
with 128 byte TX
FIFO and 384 byte RX
⻬ FIFO Supporting
Standard PC Data
Rates up to 460.8K bps
⻬ 1.8 M (6') High
Quality USB
Cable Provided
⻬ Includes Driver
and Utility Software
The OMG-USB-232 USB to serial
I/O adaptors provide two, four or
eight RS-232 serial ports for USB
connectivity to legacy or non-USB
compliant devices. OMB-USB-232
adaptors support standard PC data
rates up to 460K bps.
Simply install the included software
and connect the OMB-USB-232
adaptor to your USB port. The
device is immediately recognized
by the system. At that point, simply
connect the adaptor to your target
device (i.e. modem, serial printer,
scale, bar code/mag stripe
reader, etc.).
Now your non-USB peripherals
can have the same connection
simplicity and ease of use as USB
aware peripherals. We include our
Windows 98/ME/2000/XP and Linux
drivers to simplify installation.
Specifications
Number of Ports: 2, 4 or 8
Max. Data Rate: 460K
Max. Data Distance:
up to 15 m (50')
Operating Temperature:
0 to 50°C (32 to 122°F)
Storage Temperature:
-50 to 105°C (-58 to 221°F)
Humidity Range: 10 to 90%
RH non-condensing
Power: USB cable
Connector(s): 2, 4 or 8 DB9P
(male)
Dimensions:
OMG-USB-232-2, -4;
17.78 L x 13.34 W x 3.81 cm H
(7.0 x 5.25 x 1.5"):
OMG-USB-232-8;
22.1 L x 15.5 W x 5.1 cm H
(8.7 x 6.1 x 2.0")
C-52
OMG-USB-232-4, $209,
Shown smaller than actual size
OMG-USB-232-2, $159,
Shown smaller than actual size
C
OMG-CA179 USB cable, $8
and software CD shown
smaller than actual size
OMG-USB-232-8, $399,
Shown smaller than actual size
IN STOCK FOR FAST DELIVERY!
To Order (Specify Model Number)
Model Number Price Description
OMG-USB-232-2 $159 2 port RS-232 to USB adaptor
OMG-USB-232-4 209 4 port RS-232 to USB adaptor
OMG-USB-232-8 399 8 port RS-232 to USB adaptor
OMG-CA177 8 DB9F/25M 1.8 m (6') cable
OMG-CA179 8 1.8 m (6') USB A to B cable
OMG-DR102 10 DIN rail mounting kit
All OMG-USB-232 converters include utility software and a complete user’s
manual on CD-ROM and an OMG-CA179 USB cable.
Ordering example: OMG-USB-232-2 2 port RS-232 to USB adaptor, $159.
D3-15
