OM-CP-PR2000
Pressure Data Logger with LCD
OM-CP-PR2000
Product Notes
The OM-CP-PR2000 is a pressure data logger with LCD display. The device
features an IP rating of 65, which means it is dust proof, and splash proof
making it available to be used outdoors. The convenient LCD provides access to
the current pressure reading, as well as minimum, maximum and average
statistics. A trending graph is also displayed of the last 100 readings.
For additional information refer to your OM-CP-PR2000 manual and “Data
Logger & Software Operating Manual”.
Backlight
The backlight uses a significant amount of battery life. Refer to the manual to
configure the auto shut-off when not in use.
Submergibility
The OM-CP-PR2000 is rated IP65, which means it is dust tight and can withstand
water jets.
Set Password
To password protect the device so that others cannot start, stop or reset the
device:
- Click Identify Device and Read Status, then select the Device Detail Tab.
- Choose Set Password.
- Enter and confirm the password and click OK
Device Maintenance
Battery Replacement
Materials:
9/64” HEX Driver (Allen Key) and Replacement Batteries (Six AA)
- Remove the back cover from the device by unscrewing the four screws.
- Remove the batteries from the compartment.
- Insert the new batteries as indicated by the diagram on the battery holder.
- Replace the cover taking care not to pinch the wires. Screw the enclosure
back together securely.
Note: Be sure not to over tighten the screws or strip the threads.
