Page 1
Chapter 1: Introduction
OMEGAPHONE
®
OMA-P1108
Voice Synthesized Monitoring
& Alarm System
User’s Manual
Page 2
Page 3
IMPORTANT SAFETY INSTRUCTIONS
Your OMA-P1108 has been carefully designed to give you
years of safe, reliable performance. As with all electrical
equipment, however, there are a few basic precautions you
should take to avoid hurting yourself or damaging the unit:
• Read the installation and operating instructions in this
manual carefully. Be sure to save it for future reference.
• Read and follow all warning and instruction labels on
the product itself.
•To protect the OMA-P1108 from overheating, make sure
all openings on the unit are not blocked. Do not place on
or near a heat source, such as a radiator or heat register.
• Do not use your OMA-P1108 near water, or spill liquid
of any kind into it.
• Be certain that your power source matches the rating
listed on the AC power transformer. If you’re not sure of
the type of power supply to your facility, consult your
dealer or local power company.
• Do not allow anything to rest on the power cord. Do not
locate this product where the cord will be abused by
persons walking on it.
• Do not overload wall outlets and extension cords, as this
can result in the risk of fire or electric shock.
•Never push objects of any kind into this product through
ventilation holes as they may touch dangerous voltage
points or short out parts that could result in a risk of fire
or electric shock.
•To reduce the risk of electric shock, do not disassemble
this product, but return it to Omega Customer Service,
or other approved repair facility, when any service or
repair work is required. Opening or removing covers
may expose you to dangerous voltages or other risks.
Incorrect reassembly can cause electric shock when the
unit is subsequently used.
i
Page 4
Omegaphone® OMA-P1108 User’s Manual
• If anything happens that indicates that your OMAP1108 is not working properly or has been damaged,
unplug it immediately and follow the procedures in
Appendix C for having it serviced. Return the unit for
servicing under the following conditions:
1. The power cord or plug is frayed or damaged.
2. Liquid has been spilled into the product or it has been
exposed to water.
3. The unit has been dropped, or the cabinet is damaged.
4. The unit doesn’t function normally when you’re
following the operating instructions.
•Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote risk
of electric shock from lightning.
• Do not use the telephone to report a gas leak in the
vicinity of the leak.
CAUTION
To Reduce the Risk of Fire or Injury to Persons, Read and
Follow these Instructions:
1. Use only the following type and size batteries:
Alkaline, size D.
2. Do not dispose of the batteries in a fire. The cell may
explode. Check with local codes for possible special
disposal instructions.
3. Do not open or mutilate the batteries. Released electrolyte
is corrosive and may cause damage to the eyes or skin. It
may be toxic if swallowed.
4. Exercise care in handling batteries in order not to short
the battery with conducting materials such as rings,
bracelets, and keys. The battery or conductor may
overheat and cause burns.
5. Do not mix old and new batteries in this product.
ii
Page 5
FCC Requirements
Part 68: The OMEGAPHONE® OMA-P1108 complies with
Part 68 of the FCC rules. On the back of the unit there is a label
that contains, among other information, the FCC Registration
Number and the Ringer Equivalence Number (REN) for this
equipment. You must, upon request, provide this information to
your local telephone company.
The REN is useful to determine the quantity of devices that you
may connect to your telephone line and still have all of those
devices ring when your telephone number is called. In most,
but not all areas, the sum of the REN’s of all devices connected
to one line should not exceed five (5.0). To be certain of the
number of devices that you may connect to your line, you may
want to contact your local telephone company to determine the
maximum REN for your calling area.
This equipment may not be used on coin service provided by
the telephone company. Connection to party lines is subject to
state tariffs.
Should the OMA-P1108 cause harm to the telephone network,
the telephone company may discontinue your service temporarily. If possible, they will notify you in advance. But if
advance notice isn’t practical, the telephone company may
temporarily discontinue service without notice and you will be
notified as soon as possible. You will be informed of your right
to file a complaint with the FCC. The telephone company may
make changes in its facilities, equipment, operations, or
procedures where such action is reasonably required in the
operation of its business and is not inconsistent with the rules
and regulations of the FCC that could affect the proper functioning of your equipment. If they do, you will be notified in
advance to give you an opportunity to maintain uninterrupted
telephone service.
If you experience trouble with this equipment, or you need
information on obtaining service or repairs, please contact:
OMEGA Customer Service
1-800-622-2378 (1-800-622-BEST)
iii
Page 6
Omegaphone® OMA-P1108 User’s Manual
The telephone company may ask that you disconnect this
equipment from the network until the problem has been
corrected or until you are sure that the equipment is not
malfunctioning.
Part 15: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits a designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television
technician for help.
OMEGAPHONE® is a registered trademark of Omega
Touch Tone™ is a registered trademark of AT&T.
iv
Page 7
Canadian Department of Communications Statement
Notice: The Canadian Department of Communications label
identifies certified equipment. This certification means that the
equipment meets certain telecommunications network protective operational and safety requirements. The Department does
not guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is
permissible to be connected to the facilities of the local
telecommunications company. The equipment must also be
installed using an acceptable method of connection. In some
cases, where the company’s inside wiring is associated with a
single line, individual service may be extended by means of a
certified connector assembly (telephone extension cord). The
customer should be aware that compliance with the above
conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier.
Any repairs or alterations made by the user to this equipment,
or equipment malfunctions, may give the telecommunications
company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical
ground connections of the power utility telephone lines and
internal metallic water pipe system, if present, are connected
together. This precaution may be particularly important in rural
areas.
CAUTION: Users should not attempt to make such connections
themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate.
The Load Number (LN) assigned to each terminal device
denotes the percentage of the total load to be connected to a
telephone loop which is used by the device to prevent overloading. The termination on loop may consist of any combination of
devices subject only to the requirement that the total of the
Load Numbers of all the devices does not exceed 100. For the
Omegaphone
®
OMA-P1104, the Load Number is 8.
v
Page 8
Omegaphone® OMA-P1108 User’s Manual
Unpacking Instructions
Remove the Packing List and verify that you have received all
equipment, including the following (quantities in parentheses):
• OMA-P1108 OMEGAPHONE® Voice Synthesized Monitoring and Alarm system (1)
• Operator’s Manual (1)
If you have any questions about the shipment, please call
OMEGA Customer Service Department.
When you receive the shipment, inspect the container and
equipment for signs of damage. Note any evidence of rough
handling in transit. Immediately report any damage to the
shipping agent.
Note: the carrier will not honor damge claims
unless all shipping material is saved for inspection. After examining and removing contents,
save packing material and carton in the event
reshipment is necessary.
vi
Page 9
Chapter 1: Introduction
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS ......................... i
FCC Requirements .........................................................iii
Canadian Department of Communications Statement ... v
Unpacking Instructions ........................................... vi
Chapter 1: Introduction................................................. 1
Technical Support ..................................................... 2
Chapter 2: Installation................................................... 3
2.1 Operating Environment .................................... 3
2.2 Mounting............................................................ 3
2.3 Power Surge Protection.................................... 4
2.4 Power Supply and Battery Backup.................. 4
2.5 Starting the OMA-P1108 ................................... 5
2.6 Run Mode and Standby Mode .......................... 5
2.7 Telephone Line .................................................. 6
2.8 The Microphone ................................................ 7
2.9 Alert Inputs ........................................................ 8
2.10 Installing the Sensor......................................... 9
2.11 Multiple Sensors ............................................. 11
2.12 Outdoor Wiring ................................................ 12
2.13 Disconnecting for Storage or Seasonal Use... 13
Chapter 3: Quick Start ................................................ 15
3.1 The Local Keypad ........................................... 15
3.2 Preparation for Programming ........................ 15
3.3 Quick-Start Programming Steps
Step 1: Set Configuration of Inputs .............................. 16
vii
Page 10
Omegaphone® OMA-P1108 User’s Manual
Step 2: Set the ID Number ........................................... 17
Step 3: Set Dial-Out Telephone Numbers .................... 18
Step 4: Set Temperature Limits .................................... 19
3.4 Summary of the Alarm Dial-Out Process ...... 21
Chapter 4: Communications Programming ..............23
4.1 The Unit ID Number .......................................... 23
4.1.1 Programming the ID Number .............................. 24
4.1.2 Interrogating the ID Number ............................... 24
4.2 Dial-out Telephone Numbers........................... 25
4.2.1 Programming Dial-out Telephone Numbers ........ 25
4.2.2 Interrogating a Dial-out Telephone Number ........ 26
4.2.3 Erasing a Telephone Number.............................. 26
4.3 Tone or Pulse Dialing ....................................... 27
4.4 Special Dialing.................................................. 28
4.4.1 Special Dialing Keys ........................................... 28
viii
4.4.2 Incorporating a Pause......................................... 29
4.4.3 Incorporating a Pound (#) or Asterisk (*) ............ 30
4.4.4 Special Dialing to a Beeper or Pager.................. 31
4.5 Rings Until Answer .......................................... 34
4.5.1 Programming Rings Until Answer ....................... 34
4.5.2 Interrogating Rings Until Answer......................... 34
4.6 TAD (Telephone Answering Device).............. 35
4.6.1 TAD Enable/Disable ............................................ 35
4.6.2 Using the TAD Feature ........................................ 36
4.6.3 No TAD In Use .................................................... 37
4.7 Listen-in Time ................................................... 37
4.7.1 Programming the Listen-in Time ......................... 37
4.7.2 Interrogating the Listen-in Time .......................... 38
Page 11
Chapter 1: Introduction
4.8 Call Delay .......................................................... 38
4.8.1 Programming the Call Delay ............................... 39
4.8.2 Interrogating Call Delay....................................... 40
4.9 Local Voice Mute............................................... 40
4.9.1 Enable/Disable Local Voice Mute........................ 40
4.10 Voice Repetitions............................................ 41
4.10.1 Programming Voice Repetitions ........................ 41
4.10.2 Interrogating Voice Repetitions ......................... 42
4.11 Intercall Time................................................... 42
4.11.1 Programming Intercall Time .............................. 42
4.11.2 Interrogating Intercall Time ............................... 43
4.12 Maximum Number of Calls (Max Calls) ........ 44
4.12.1 Programming Max Calls.................................... 44
4.12.2 Interrogating Max Calls ..................................... 45
4.13 The Clock......................................................... 45
4.13.1 Setting the Clock............................................... 46
4.13.2 Interrogating for the Current Time ..................... 47
4.14 The Security Code .......................................... 47
4.14.1 Locking the Keypad........................................... 47
4.14.2 Unlocking the Keypad ....................................... 48
Chapter 5: Alarm Programming ................................. 49
5.1 Input Configuration ......................................... 49
5.1.1 Programming Input Configuration ....................... 50
5.1.2 Verifying Input Configuration ............................... 51
5.2 Enab le/Disable Inputs ..................................... 51
5.2.1 Changing Enabled/Disabled Input Status ........... 51
5.2.2 Verifying Enabled/Disabled Input Status ............. 52
5.3 Input Recognition Time................................... 52
ix
Page 12
Omegaphone® OMA-P1108 User’s Manual
5.3.1 Programming Input Recognition Time................. 53
5.3.2 Interrogating Input Recognition Time.................. 54
5.4 Establishing High and Low Temperature
Limits ............................................................ 54
5.4.1 Programming Temperature Limits
for a Selected Input ............................................. 55
5.4.2 Disabling Alarm Response to High or
Low Temperature................................................. 56
5.4.3 Interrogating High and Low Temperature Limits.. 57
5.5 Temperature Scale............................................ 57
5.6 Temperature Calibration .................................. 58
5.6.1 Programming Temperature Calibration ............... 58
5.6.2 Interrogating Temperature Calibration................. 59
5.7 Obtaining Current Temperature ..................... 60
5.8 AC Power Monitoring Enable/Disable............ 60
5.8.1 Enabling/Disabling the AC Power Alarm ............. 61
5.9 AC Power Failure Recognition Time .............. 61
5.9.1 Programming Power Failure Recognition Time... 62
5.9.2 Interrogating Power Failure Recognition Time .... 63
5.10 Sound Alarm Monitoring .............................. 63
5.10.1 Programming Sound Alarm Sensitivity ............. 63
5.10.2 Interrogating Sound Sensitivity ......................... 64
5.10.3 Programming High Sound Alarm
Recognition Time .............................................. 65
5.11 High Sound Alarm Enable/Disable ................ 66
5.11.1 Changing Enabled/Disabled High Sound Alarm .. 66
5.12 Exit Delay ....................................................... 66
Chapter 6: Acknowledgment, Status Report,
and Remote Access ................................. 69
x
Page 13
Chapter 1: Introduction
6.1 Alarm Acknowledgment ................................. 69
6.1.1 Local Acknowledgment ....................................... 69
6.1.2 Touch-ToneTM Acknowledgment ........................ 69
6.1.3 Callback Acknowledgment.................................. 70
6.2 Status Report................................................... 71
6.2.1 Example: Status Report, No Alarms ................... 72
6.2.2 Example: Status Report, Existing Alarms ........... 73
6.2.3 Example: Status Report, Disabled Inputs ........... 74
6.2.4 Battery Condition ................................................ 75
6.2.5 Remote Access by Touch-Tone™ Telephone...... 75
Chapter 7: Operation................................................... 79
7.1 Alarm Detection, Dial-out and
Acknowledgment ............................................ 79
7.2 Example: A Dial-out Telephone Call .............. 84
Appendix A: Troubleshooting..................................... 79
Appendix B .................................................................. 87
xi
Page 14
Omegaphone® OMA-P1108 User’s Manual
xii
Page 15
Chapter 1: Introduction
The OMEGAPHONE® OMA-P1108 is a fully-programmable,
environmental monitoring system that offers extensive on-site
and remote monitoring capability to small businesses, private
homes, farms, greenhouses, computer rooms, and remote
facilities. Designed for desktop or wall mounting, the
OMA-P1108 is simple to install, program and operate; no
changes to standard electrical or telephone service are required.
Connected to a telephone line, it will respond to an alarm by
dialing up to eight separate telephone numbers. When the call
is answered, an “Alert Condition” message is delivered in
digitized speech.
The OMA-P1108 features built-in sensors to monitor a variety
of conditions:
•High sound level
•AC electric power failure
• Battery backup
•Temperature
Chapter 1: Introduction
Equipped with 8 alert inputs, additional sensors* can be added
for extended monitoring:
•Intrusion or unauthorized entry
•Water leaks and seepage
•Temperature
• Humidity
• Equipment operation
• Many other conditions that may require unique
monitoring solutions
* Refer to Appendix B for information on additional sensors
(available separately from Omega) that are best suited to your
application.
The status of each monitored condition is readily obtained at
the unit's installation site or remotely, by telephone. At the close
of every Status Report, time is provided for listening to on-site
sounds.
1
Page 16
Omegaphone® OMA-P1108 User’s Manual
To ensure reliable operation, the OMA-P1108 features power
backup capability; in the event of AC power failure,
six D-cell batteries (not included) will continue to power the
unit for approximately 10 hours.
This manual is comprised of the instructions and commands for
installing and operating the OMA-P1108. The Quick Start
chapter is included to speed understanding of programming and
operation. Communication and Alarm Programming chapters
demonstrate step-by-step methods for utilizing the full range of
available features. The Troubleshooting chapter provides
assistance in the event that problems are encountered.
Technical Support
If any questions arise upon installation or operation of the
OMA-P1108, please contact Omega Engineering Data Acquisition Group.
2
Page 17
Chapter 2: Installation
Correctly installing the OMA-P1108 will ensure proper
functioning of the unit. Please read the entire chapter before
starting the installation process.
Within the packaging will be a Warranty Registration Card.
Please take the time to fill this out and mail. The One Year
Limited Warranty is explained in the back of this manual.
2.1 Operating Environment
The OMA-P1108 should be installed and operated in an area
that provides space for wiring sensors to the screw terminals,
near an AC power source and telephone line. Operating
temperature ranges from 32° Fahrenheit (0° Celsius) to +120°
Fahrenheit (+49° Celsius).
NOTE
The OMA-P1108 is a sensitive electronic device.
Do not install the OMA-P1108 near strong
electrostatic, electromagnetic or radioactive
fields. Do not expose to fumes or corrosive
vapors.
Chapter 2: Installation
2.2 Mounting
Flat Mount: Place the OMA-P1108 on top of a desk or other
horizontal surface. Wall Mount: Mount on a wall with two
screws using the keyholes on the back panel of the unit. Place
the screws or bolts 313/16" apart at the desired height from the
floor. Hook the unit over the screws and toward the floor. Refer
to Figure 2-1.
3
Page 18
Omegaphone® OMA-P1108 User’s Manual
"
13
16
3
Figure 2-1. Wall Mount
2.3 Power Surge Protection
The OMA-P1108 can be damaged by power surges and
lightning through the telephone line and the 120 VAC power
supply. Although the OMA-P1108 has built-in surge protection,
we recommend that ad ditional pr otection be obtained f or
the unit and f or an y electr onic equipment that is attac hed to
your po wer suppl y and telephone lines. Power sur ge protection is especiall y impor tant if y ou live in a lightning-pr one
area.
2.4 Power Supply and Battery Backup
The OMA-P1108 is provided with an AC power transformer
that will plug into any standard 120 VAC outlet and a battery
backup (batteries not included) that enables the unit to continue
functioning if AC power is removed (due to electric power
disruption or failure). The OMA-P1108 uses six, D-cell
alkaline batteries. Do not use rechargeable nicad batteries.
NOTE
Be sure that the AC transformer is plugged into
an outlet before installing batteries.
To install the batteries, open the battery compartment hatch
located underneath the unit, align batteries according to the
diagram shown in Figure 2-2, and replace the hatch.
4
Page 19
Chapter 2: Installation
---
2.5 Starting the OMA-P1108
When the AC power transformer is first plugged into the
electrical outlet, the OMA-P1108 automatically starts in RUN
mode. The red LED light will begin to glow. The unit will
respond with,“Hello, this is Sensaphone® 1108.”
2.6 Run Mode and Standby Mode
Pressing the RUN/STANDBY key on the OMA-P1108 keypad
will alternately activate or deactivate the unit. If the unit is
activated and in RUN mode, the red LED (small red light on
the upper right of the unit's front panel) glows steadily. In
STANDBY mode, the red LED goes out, but will blink every
few seconds to indicate that power is still supplied to the unit.
+++
Figure 2-2. Battery Installation
+++
---
In RUN mode, the OMA-P1108 is able to receive incoming
calls and to automatically dial out in the event of an alarm on
one of the monitored conditions. To enter STANDBY mode,
press RUN/STANDBY.
As soon as the OMA-P1108 enters STANDBY mode, it
responds with “Have a good day.” The red light immediately
goes out and then resumes with a blink every few seconds.
While in STANDBY mode, all functions are disabled, but
5
Page 20
Omegaphone® OMA-P1108 User’s Manual
programmed memory is preserved. Upon exiting STANDBY
mode, any currently existing alert conditions will be announced.
NOTE
STANDBY mode is not equivalent to “power
off”—an electrical source, such as the 120 VAC,
or the battery backup, continues to provide full
power to the unit. If the unit is placed in
STANDBY mode, unplugged from the 120 VAC
outlet, and placed in storage, the batteries will
continue to power the OMA-P1108, discharging
until they fail. Consequently, batteries should
always be removed from the unit following
disconnection from any 120 VAC outlet, prior to
storage.
Press the RUN/STANDBY key again to return to RUN mode.
RUN
STANDBY
Figure 2-3. The RUN/STANDBY Key
2.7 Telephone Line
The OMA-P1108 will operate with all standard telephone
systems that accept pulse or tone dialing. The OMA-P1108
cannot be used on an extension line to dial its own telephone
number. Also, it may not be installed on a party line or pay
telephone line.
Certain private telephone systems and public switching
equipment may not accept the OMA-P1108 dialing or may
generate an unacceptable ring signal. In those cases, a dedicated line may be required. Consult the supplier of your
telephone system if you encounter problems.
If you do not have a modular telephone extension at the
OMA-P1108’s location, you must contact your local telephone
company to have one installed (there is a charge for this
6
Page 21
Chapter 2: Installation
service). If you have four-pin jacks, adapters are available to
convert them to the modular plugs. Contact your local
telephone company or electronics parts store.
CAUTION
Never install telephone wiring during a lightning
storm. Never install telephone jacks in wet
locations unless the jack is specifically designed
for wet locations. Never touch uninsulated
telephone wires or terminals unless the telephone
line has been disconnected at the network
interface. Use caution when installing or
modifying telephone lines.
To install the telephone line, plug the modular telephone jack
provided into any standard RJ11 phone outlet. Refer to
Figure 2-4.
Figure 2-4. Installing the Telephone Line
On the back of the OMA-P1108 is a female telephone jack.
This is provided so that a telephone or other answering device
may be used on the same line as the unit. It is not necessary to
hook up a telephone for the OMA-P1108 to operate.
2.8 The Microphone
The OMA-P1108 is provided with a built-in microphone which
is used to monitor high sound levels produced near the installation site. The sensitivity of the microphone is configurable and
will detect a continuous as well as a beeping alarm.
Other programming options that apply to the microphone
include setting the length of time before a high sound causes an
GND 1 2 GND 3 4 GND 5 6 GND 7
8
7
Page 22
Omegaphone® OMA-P1108 User’s Manual
alarm.
If this sound level exists for 8 consecutive seconds (default) or
for the programmed length of time, the OMA-P1108 will dial
out with an alarm message.
NOTE
The proximity of the audible alarm to the
microphone is extremely important.
Normally, the OMA-P1108 and the audible
alarm must be in the same room. The maximum
distance can vary considerably depending on the
alarm, the acoustics, and the size of the room.
During an alarm dial-out, the microphone allows four-second
intervals to listen-in to sounds at the OMA-P1108’s location.
When calling for a Status Report, the microphone permits
listening to on-site sounds for a programmed time interval.
2.9 Alert Inputs
The OMA-P1108 can monitor up to 4 inputs (represented by
the numbered terminal screws shown in Figure 2-5, below).
Figure 2-5. Alert Inputs
Inputs are configured as either dry contact or temperature.
An input configured as dry contact can be used with any
normally open (N.O.) or normally closed (N.C.) device.
“Open” refers to an opened circuit path; if conditions cause the
8
Page 23
circuit to close, an alert condition occurs. “Closed” refers to a
continuous circuit path; if a closed circuit is opened, an alert
condition occurs. The OMA-P1108 determines the way inputs
are configured by the type of sensor connected to each alert
input (refer to Chapter 5, Section 5.1).
An input configured as “temperature” is designed to evaluate a
range of settings. The OMA-P1108 will read the temperature at
the sensor’s location and compare that value to programmed
high and low temperature limits. Temperature inputs must be
used with Phonetics Remote Temperature Sensor.
NOTE
Before wiring, it is advisable to disable the
inputs to prevent accidentally tripping an alarm.
See Chapter 5, Section 5.2.
2.10 Installing the Sensor
After you have selected the sensor, loosen the screw of the alert
input and its corresponding ground. Two wire leads are used to
connect any monitoring sensor. Fasten one lead to the numbered screw and the other lead to GND. Tighten both screws. If
the input was not disabled, the OMA-P1108 may recite its
“Alert Condition Exists” message as you connect the sensor. If
it does, just press any key to stop it. Re-enable the input after
wiring. Refer to Figures 2-6 and 2-7 for connecting a sensor to
an alert input.
Chapter 2: Installation
9
Page 24
Omegaphone® OMA-P1108 User’s Manual
Figure 2-6. Sensor Connected to an Alert Input
Any sensor can be attached to the OMA-P1108 using 22-gauge
wire. The sensor can be several hundred feet from the unit, as
long as the total resistance of the circuit is not greater than 50
ohms. Use wire appropriate for the application.
10
Figure 2-7. Two Sensors Wired to Adjacent Inputs
Page 25
Do not use sensors, switches, or relays that
supply any voltage or current to the OMAP1108. Be aware of proximity to other electrical
wires or components when placing wires that
lead from the sensors to the unit. Avoid running
the wires near electrical devices that use high
voltage or current, such as motors, heavy
machinery, etc. This voltage may be inductively
coupled into the sensor wiring and could result in
damage to the the OMA-P1108’s circuitry. Try to
place wires at least 6 inches from other electrical
wiring or devices.
2.11 Multiple Sensors
The OMA-P1108 may have more than one sensor connected to
the same alert input, as long as the normal condition for each
sensor on the same alert input is identical (either all N.O. or all
N.C.). However, only one remote temperature sensor can be
used on each input.
Chapter 2: Installation
NOTE
When wiring several normally closed sensors on one input,
they must be connected in series. Connect one lead from the
first sensor to the numbered screw of the alert input. Next, take
the other lead from the first sensor and connect it to one lead
from the next sensor. Continue connecting sensors end-to-end
until you have connected all of your sensors. Take the second
lead from the last sensor and connect it to the ground screw on
the OMA-P1108. See Figure 2-8. Multiple N.C. sensors are
typically magnetic reed switches to monitor the security of
windows and doors.
11
Page 26
Omegaphone® OMA-P1108 User’s Manual
Figure 2-8. Multiple Normally Closed Sensors
To wire several normally open sensors to one alert input,
connect them in parallel. To do this, take one lead from each
sensor and attach it to the numbered terminal. Then, take the
second lead from each sensor and attach each to the corresponding ground screw. Refer to Figure 2-9.
Figure 2-9. Multiple Normally Open Sensors
2.12 Outdoor Wiring
When wiring sensors outdoors, DO NOT allow exposed wires
to run freely in open air; under such conditions, the OMAP1108 is susceptible to serious damage during a lightning
storm. Depending upon the distance outdoor wiring must
travel, consideration should be given to use of shielded wire
inside a metal conduit. Both shield and conduit should be
connected to earth ground. This prevents stray voltage from
entering the unit.
12
Page 27
Chapter 2: Installation
Figure 2-10. Potential Sensor Damage from Stray Electrical Noise
2.13 Disconnecting the OMA-P1108 for Storage or
Seasonal Use.
If you plan to emplo y the OMA-P1108 as a seasonal “watchdog” for a few months during the y ear, you m ust disconnect
all wires fr om the unit completel y to a void dama ge to the
circuitry when the unit is not in use . If the unit is unplugged
but left in place with all the sensors still connected, the wires
act as antennae that draw in any stray “electrical noise” from
such devices as fans, blowers, microwaves, etc.
Additionally, it is important to remove the batteries, or they will
discharge until they fail.
Preserve your OMA-P1108 during the off-season, or
when not in use:
• Remove the sensor wires at the screw terminals
• Remove the batteries
• Unplug the unit and store in a safe place
13
Page 28
Omegaphone® OMA-P1108 User’s Manual
NOTES
14
Page 29
Chapter 3: Quick Start
This section presents a useful guide for first-time programming
of the OMA-P1108. Follow instructions for installation before
attempting to program the OMA-P1108. Refer to
Chapter 2: Installation.
3.1 The Local Keypad
Programming is accomplished using the local keypad (shown
below, Figure 3-1). Notice that a single key has several functions assigned to it; programming results are determined by
the order in which keys are pressed.
Individual keystrokes are illustrated to show programming
steps in the correct order. If you make a mistake by entering the
wrong key, do not press another key until you hear the message,
“Error 1.” Then, start over with the first key in the
programming sequence.
Chapter 3: Quick Start
Figure 3-1. The OMA-P1108 Keypad
3.2 Preparation for Programming
Read complete instructions in Chapter 2: Installation, and make
sure to follow these steps first:
1. Plug the AC adaptor into the 120 VAC outlet.
15
Page 30
Omegaphone® OMA-P1108 User’s Manual
2. Install the batteries.
3. Connect the OMA-P1108 to a telephone line.
When these steps are completed, the OMA-P1108 is fully
operational and able to monitor temperature, high sound,
AC power failure and battery backup condition; it can also be
called on the telephone for a Status Report or used for listening
to on-site sounds from any remote location. Now, the unit is
ready for programming.
3.3 Quick-Start Programming Steps
Step 1: Set Configuration of Inputs
The OMA-P1108 will scan the 8 external inputs and determine
if they are N.O. (normally open), N.C. (normally closed), or
Temperature. If external sensors are added, make sure they are
in their normal positions before proceeding—refer to
Chapter 5, Section 5.1.
1. Press STANDBY to place the OMA-P1108 in Standby
mode.
16
2. If you have external sensors available, wire the sensors to
the inputs on the back of the OMA-P1108 (see Chapter 2,
Section 2.10). Otherwise, skip this step and move to
step 3.
3. Press RUN. The red light glows when the OMA-P1108
returns to Run mode.
4. Press SET.
Page 31
5. Press CONFIGURE.
6. The OMA-P1108 will audibly recite the new configuration for each of the eight inputs, responding with “OK,” if
it detects N.O . (normall y open), “beep-OK,” if it detects
N.C (normally closed) or “Temperature,” if it detects
temperature (regardless of whether all the inputs have
attached sensors or not). If an input is unused, it is treated
as normally open.
Step 2: Set the ID Number
It is recommended that you set the ID number to reflect the
telephone number on which the OMA-P1108 is installed.
1. Press SET.
Chapter 3: Quick Start
2. Press ID NUMBER.
3. Using the number keys, enter the digits (up to 16 are
permitted) for the ID number. The OMA-P1108 will recite
the digits as they are pressed.
1
CALL
DELAY
4
MAX CALLS
7
RECOGNITION
TIME
VOICE
REPS
TEMP LIMITS
CLOCK
ID NUMBER
POWER
3
2
INTERCALL
TIME
6
5
CALIBRATE
9
8
LISTEN TIME
SOUND
0
4. Press ENTER. The 1108 will respond: “Enter.”
17
Page 32
Omegaphone® OMA-P1108 User’s Manual
Step 3: Set Dial-Out Telephone Numbers
To program dial-out telephone numbers:
1. Press SET.
2. Press PHONE NUMBER.
3. Select which telephone number to program. Press any
unassigned number key (from 1 to 8) to represent the new
telephone number entry . OMA-P1108 will respond:
“Enter number.”
18
4. Enter the complete telephone number using the number
keys. The OMA-P1108 will recite the digits as they are
pressed.
5. Press ENTER. The unit will respond: “Enter.”
6. Repeat above procedure to program up to eight separate
telephone numbers.
Page 33
Step 4: Set Temperature Limits
High and low temperature limits can be separately programmed
for each input that is configured as temperature. Limits can
range from –20° to +150° Fahrenheit, or from –30
Celsius. Default settings are: 10
°
100
F for high temperature. Do not set temperature limits too
close to normal room temperature, since minor fluctuations
could result in frequent and unnecessary alarm dialouts.
1. Press SET.
2. Press TEMP LIMITS.
3. From the number keys, press a number (from 1 to 8) that
corresponds to the temperature input being programmed.
Chapter 3: Quick Start
°
°
F for low temperature and
to 65
°
The OMA-P1108 responds: “Enter low temper ature
limit.”
4. Using the number keys, enter a value for low temperature
limit. The OMA-P1108 will recite the digits as they are
pressed. If a negative number is required, first press
PAUSE, then enter the number.
19
Page 34
Omegaphone® OMA-P1108 User’s Manual
5. Press ENTER.
The OMA-P1108 responds: “Enter high temperature
limit.”
6. Using the number keys, enter the value for high
temperature limit. The OMA-P1108 will recite the digits
as they are pressed.
7. Press ENTER. The OMA-P1108 responds: “Enter.”
20
This concludes minimum programming to achieve normal
operation of the OMA-P1108. In additon to the programming
just accomplished, default settings for many more features take
effect when the unit is first powered. You will be able to
reprogram most of these factory-set defaults to suit your
application.
For a complete explanation of each feature (with illustrations of
keystrokes), refer to Chapter 4: Communications Programming
and Chapter 5: Alarm Programming.
To gain a basic understanding of how the alarm dial-out feature
works, refer to this chapter, Section 3-4. For extended information regarding dial-out and related programmable parameters,
refer to Chapter 7: Operation.
Page 35
Chapter 3: Quick Start
3.4 Summary of the Alarm Dial-Out Process
Action—Response
1. THE OMA-P1108 DETECTS
AN ALERT CONDITION
An alert condition is not the same as a
valid alarm—the condition must
continue for the programmed time
period, or Reco gnition Time, before it is
recognized as a valid alarm.
2. A VALID ALARM IS CONFIRMED
An audible, on-site alarm message
begins and continues until the alarm is
acknowledged. (If the Mute feature is
turned on, there is no on-site message.)
Call Delay is activated.
3. DIAL-OUT BEGINS
Dial-out begins by calling telephone
number 1 to report an alarm.
If there is no acknowledgment, the
OMA-P1108 waits the programmed
Intercall Time before dialing subsequent
telephone numbers. Dial-out continues
in this manner, cycling through the
remaining telephone numbers, for the
programmed Max Calls.
4. THE ALARM IS
ACKNOWLEDGED
When the alarm is acknowledged, the
dial-out process is cancelled and the
audible, on-site alarm message stops.
Programmable Feature
• Recognition Time
This is the programmed
waiting period to determine if
an alert condition has persisted
long enough to be considered a
valid alarm. If the sensor
returns to normal within
recognition time, then no
alarm will occur.
• Call Delay
This is the programmed
waiting period, before the first
telephone number is called, to
report an alarm.
• Intercall Time
This is the programmed
waiting period, in between
sequential dialing of telephone
numbers, to report an alarm.
•Max Calls
This is the total number of
telephone calls that will be
dialed in response to any valid
alarm. Telephone numbers are
dialed sequentially, and
continue to cycle until the
maximum number of calls is
reached. If no acknowledgment occurs, then at the
completion of Max Calls, all
alarms are automatically
acknowledged.
21
Page 36
Omegaphone® OMA-P1108 User’s Manual
NOTES
22
Page 37
Chapter 4: Communications Programming
Chapter 4: Communications Programming
This chapter explains the keypad commands for
communications programming of the OMA-P1108,
including interrogation and resetting of the following:
• The Unit ID Number
•Dial-out Telephone Numbers
•Tone or Pulse Dialing
• Special Dialing with Pagers, Beepers and Access
Numbers.
•Rings Until Answer and Telephone Answering Device
Compatibility
•Listen-in T ime
• Call Delay
• Local Voice Mute
•Voice Repetitions
•Intercall T ime
• Maximum Number of Calls
• The Clock
• Security Code
4.1 The Unit ID Number
The Unit ID Number is the identification number of the
OMA-P1108. This number may be the same as the telephone
number where the unit is installed, or it may be designated
using any number that best suits your application.
The purpose of the Unit ID Number is to immediately provide
the source of any alarm, especially when using multiple
OMA-P1108 units in a complex monitoring system. When
the OMA-P1108 is called from a remote location, it always
begins its message with the identification number:
“Hello, this is telephone number (Unit ID Number).”
23
Page 38
Omegaphone® OMA-P1108 User’s Manual
4.1.1 Programming the ID Number
To program the ID Number:
1. Press SET.
2. Press ID NUMBER.
3. Using the number keys, enter up to 16 digits for the ID
number. The OMA-P1108 will recite the digits as they are
pressed.
4. Press ENTER. The OMA-P1108 will respond: “Enter.”
4.1.2 Interrogating the ID Number
To interrogate the ID numbers:
1. Press WHAT IS.
2. Press ID NUMBER. The OMA-P1108 will recite the Unit
ID Number programmed.
24
Page 39
Chapter 4: Communications Programming
4.2 Dial-out Telephone Numbers
The OMA-P1108 can store up to eight 32-digit phone numbers.
These are the numbers that will be called during dial-out.
In the event of an alarm, the numbers are dialed sequentially,
1 through 8. Begin programming the first telephone number by
assigning it to the key labeled with the number 1 on the keypad,
and continue to assign any other telephone numbers in
numerical order. A pause, pound or asterisk can be added to an
individual phone number to access different phone and beeper
systems. See Special Dialing, Section 4.4.
4.2.1 Programming Dial-out Telephone Numbers
To program dial-out telephone numbers:
1. Press SET.
2. Press PHONE NUMBER.
3. Select which telephone number to program. Press any
unassigned number key (from 1 to 8) to represent the new
telephone number entry. The OMA-P1108 will respond:
“Enter number.”
4. Enter the complete telephone number using the number
keys.
25
Page 40
Omegaphone® OMA-P1108 User’s Manual
5. Press ENTER. The unit will respond with “Enter.”
6. Repeat above procedure to program up to eight separate
telephone numbers.
4.2.2 Interrogating a Dial-out Telephone Number
To interrogate dial-out telephone numbers:
1. Press WHAT IS.
2. Press PHONE NUMBER.
3. Press a number key (from 1 to 8).
OMA-P1108 will recite the corresponding telephone
number. If there is no number programmed for a
particular key, the unit will respond: “No number.”
4.2.3 Erasing a Telephone Number
To erase a telephone number:
1. Press SET.
26
Page 41
Chapter 4: Communications Programming
2. Press PHONE NUMBER.
3. Press the number key (from 1 to 8) representing the
telephone number you want to erase.
4. Press ENTER. The OMA-P1108 will say “Enter.”
4.3 Tone or Pulse Dialing
The OMA-P1108 can dial out in pulse or Touch Tone™. Select
the type of dialing, in either pulse or tone, depending upon the
type of service provided by your telephone company. The
default is tone.
To program for either pulse or tone:
1. Press the SENSOR ON/OFF key.
2. Press TONE.
The OMA-P1108 will respond: “Off” to indicate that tone
dialing is off and pulse is enabled, or “On” to indicate
that tone dialing is on and pulse is disabled.
3. Repeat key sequence to switch between settings.
27
Page 42
Omegaphone® OMA-P1108 User’s Manual
4.4 Special Dialing
The OMA-P1108 has provisions for special dialing sequences.
Special dialing sequences allow:
•Dialing that requires an access number to connect with
an outside line.
•Dialing that requires the pound (#) or asterisk (*).
•Dialing to a beeper or pager.
4.4.1 Special Dialing Keys
The following designated keys represent special functions when
used with PHONE NUMBER entries:
1. Pause
PAUSE represents a four second pause in dialing. It can
be used when an access number is required before dialing
to an outside line. (For example, in some cases a "9" or
other number, must be dialed first, in order to get a dial
tone for an outside line.) When interrogating telephone
numbers, PAUSE is audibly represented by a “beep.”
28
2. Pound (#)
A pound may be required when calling some phone or
beeper systems. When interrogating telephone numbers,
pound (#) is audibly represented by the word “twelve.”
3. Asterisk (*)
An asterisk may be required when calling some phone or
beeper systems. When interrogating telephone numbers,
asterisk (*) is audibly represented by the word “eleven.”
Page 43
Chapter 4: Communications Programming
4. Code
CODE instructs the OMA-P1108 to wait until the call is
answered before continuing. When interrogating
telephone numbers, CODE is audibly represented by the
word “fourteen.”
NOTE
Each time a pause, pound (#) or asterisk (*) is
incorporated in a programming sequence, it is
counted as one digit toward the total of 32 digits
allowed.
4.4.2 Incorporating a Pause
Incorporate PAUSE to access an outside telephone line:
1. Press SET.
2. Press PHONE NUMBER.
3. Press any unassigned number key (from 1 to 8) to
represent the new telephone number entry. OMA-P1108
will respond: “Enter number.”
29
Page 44
Omegaphone® OMA-P1108 User’s Manual
4. From the number keys, enter the access digit (i.e., 9).
The OMA-P1108 will recite the digit.
5. Press PAUSE. The OMA-P1108 will “beep.”
6. Enter the complete telephone number (1 + area code)
using the number keys. The OMA-P1108 will recite the
digits as they are pressed.
7. Press ENTER. The OMA-P1108 will say “Enter.”
4.4.3 Incorporating a Pound (#) or Asterisk (*)
Incorporate a pound or asterisk if it is normally included in
telephone number:
1. Press SET.
30
Page 45
Chapter 4: Communications Programming
2. Press PHONE NUMBER.
3. Press any unassigned number key (from 1 to 8) to
represent the new telephone number entry. OMA-P1108
will respond: “Enter number.”
4. Enter the telephone number using the number keys. The
OMA-P1108 will recite the digits as they are pressed.
5. Position the pound (#) or asterisk (*) within the telephone
number where required by pressing SET (where the pound
is located) orWHAT IS (where the asterisk is located).
The OMA-P1108 will beep each time pound or asterisk is
pressed.
–OR–
6. Enter any remaining digits of the telephone number.
7. Press ENTER. The OMA-P1108 will say “Enter.”
4.4.4 Special Dialing to a Beeper or Pager
The following example demonstrates just one solution to
programming the OMA-P1108 for dialing to a beeper or pager.
31
Page 46
Omegaphone® OMA-P1108 User’s Manual
Many other key sequences will also work. Start with steps 1–3
below; next, enter special dialing keys where required for your
beeper or pager service.
To incorporate a pound or asterisk:
1. Press SET.
2. Press PHONE NUMBER.
3. Press any unassigned number key (from 1 to 8) to
represent the new telephone number entry.
32
4. Enter the complete telephone number using the number
keys. The OMA-P1108 will recite the digits as they are
pressed.
5. Press CODE. This instructs the OMA-P1108 to wait for
the telephone call to be answered by the beeper or pager
service. (A voice message will not occur—only digital
tones are used.)
Page 47
Chapter 4: Communications Programming
6. Now press PAUSE once to activate a four second delay.
This assumes the call is answered by a beeper/pager
service that immediately delivers a prerecorded voice
message. PAUSE may be pressed more than once to
program more time for the beeper/pager service to finish
its message. Each press of PAUSE allocates four additional seconds. The OMA-P1108 will “beep” with each
press.
7. Enter a telephone number or custom code number that
will identify the OMA-P1108 as the caller to your beeper
or pager. A code may consist of any number(s) you
designate. Many users find it convenient to use the
telephone number to which the OMA-P1108 is connected.
8. A pound or asterisk may be required in some dialing
situations. If required, position the pound (#) or asterisk
(*) within the telephone number where required by
pressing SET (where the pound is located) or WHAT IS
(where the asterisk is located). The OMA-P1108 will
“beep” each time pound or asterisk is pressed. Enter any
remaining digits of the telephone number.
–OR–
9. Press ENTER. The OMA-P1108 will say “Enter.”
33
Page 48
Omegaphone® OMA-P1108 User’s Manual
4.5 Rings Until Answer
Rings Until Answer is the programmed number of times the
telephone rings before the OMA-P1108 will answer an incoming call. This can be set from 1 to 15 rings. The default value is
4.
4.5.1 Programming Rings Until Answer
To program Rings Until Answer:
1. Press SET.
2. Press RING/TAD. The OMA-P1108 will respond: "Enter
number."
3. Using the number keys, enter a value.
4. Press ENTER. The OMA-P1108 will respond: "Enter."
4.5.2 Interrogating Rings Until Answer -
To interrogate Rings Until Answer:
1. Press WHAT IS.
34
Page 49
Chapter 4: Communications Programming
2. Press RING/TAD.
4.6 TAD (Telephone Answering Device)
The TAD feature is especially useful because it integrates the
operation of the OMA-P1108 with your telephone answering
device in a way that retains the full flexibility of each system.
This allows you to have on-demand telephone access to the
OMA-P1108, for obtaining a Status Report, or for issuing callin commands, while your telephone answering device is set to
receive outside calls. Programming for use with a telephone
answering device (TAD) is always used in conjunction with
Rings Until Answer, detailed in section 4.5.
NOTE
The TAD feature only applies to answering
devices connected to the same telephone line as
the OMA-P1108.
4.6.1 T AD Enable/Disable
To enable/disable the TAD feature:
1. Press SENSOR ON/OFF.
2. Press RING/TAD.
The OMA-P1108 will respond: “On.” (If the OMA-P1108
says “Off,” repeat steps 1 and 2 to reactivate TAD.)
35
Page 50
Omegaphone® OMA-P1108 User’s Manual
4.6.2 Using the TAD Feature
1. Make sure the TAD feature is enabled on the OMAP1108. (The default setting is disabled, so you must
enable it first.)
2. Determine the number of rings your telephone answering
device uses to answer the telephone. (Most answering
devices require 4 rings; others are selectable.)
3. On the OMA-P1108, program Rings Until Answer to a
greater number than the number of rings set on your
answering machine.
Example:
Telephone answering device, rings = 4
OMA-P1108, Rings Until Answer = 6
Using the procedure just outlined, all incoming calls will be
answered by the telephone answering device, allowing it to
operate normally. With the programming just accomplished, the
OMA-P1108 can be accessed remotely, by telephone, to obtain
the Status Report.
1. Dial the telephone number of the OMA-P1108.
2. Let the telephone ring once and then hang up.
3. Wait approximately ten seconds
4. Call the OMA-P1108 back.
It will answer the telephone on the first ring.
Explanation: The pattern of one ring, followed by a second call
(within 30 seconds), signals the OMA-P1108 to answer your
incoming call, excluding the telephone answering device.
36
NOTE
Special Case: If the OMA-P1108 shares the same
line with a telephone answering device, and
during certain time periods, frequent, incoming
calls are expected on that line, then you may
want to temporarily disable the TAD feature. If
you leave the TAD enabled, it will not adversely
affect normal operation, but if two outside
telephone calls are received within the same
30-second time window, the OMA-P1108 will
interpret this pattern as a signal to answer the
telephone. If this occurs, press any key on the
OMA-P1108 to hang up.
Page 51
4.6.3 No TAD In Use
If a telephone answering device is not used on the same
telephone line as the OMA-P1108, make sure that the
TAD feature is disabled, or turned off. Only Rings Until
Answer programming will determine how incoming calls
are answered. For example, if you program Rings Until
Answer to 3, incoming calls will be answered in 3 rings.
4.7 Listen-in Time
The Listen-in Time is the amount of time you can listen to
sounds from the OMA-P1108’s built-in microphone at its
installation site. When you call in for a Status Report, the
OMA-P1108 announces Listen-in Time at the end of its first
round of status readings, saying, “Listen to the sound level for
(programmed time entered).” The programmable range is from
0 to 255 seconds (or up to 4.17 minutes). The default value is
15 seconds.
The microphone is also used to monitor high
sound level. See Chapter 5, Section 5.10 through
Section 5.11.1.
Chapter 4: Communications Programming
NOTE
4.7.1 Programming the Listen-in Time
To program the Listen-in Time:
1. Press SET.
2. Press LISTEN TIME. The OMA-P1108 will respond:
“Enter seconds.”
3. Using the number keys, enter the seconds. The OMA-
P1108 will recite the digits as they are pressed.
37
Page 52
Omegaphone® OMA-P1108 User’s Manual
4. Press ENTER. The OMA-P1108 will respond: “Enter.”
4.7.2 Interrogating the Listen-in Time
To interrogate the Listen-in Time:
1. Press WHAT IS.
2. Press LISTEN TIME. The OMA-P1108 will recite the
listen time in seconds programmed.
4.8 Call Delay
Call Delay is the programmed length of time the OMA-P1108
waits, following detection of an alarm, before it begins the dialout sequence. This applies only to the first call. (Delay time
between calls is also programmable: refer to Intercall Time,
Section 4-11.)
The purpose for Call Delay is to allow time for personnel at the
OMA-P1108’s installation site to respond to and cancel an
alarm before dial-out begins. During this time, the OMA-P1108
will audibly repeat its “alert condition” message (unless the
Local Voice Mute feature has been activated—refer to Section
4.9). The default for Call Delay is 30 seconds. Call Delay can
be programmed from 0 seconds to 60 minutes (1 hour).
38
Page 53
Chapter 4: Communications Programming
4.8.1 Programming the Call Delay
To program the Call Delay:
1. Press SET.
2. Press CALL DELAY.
The OMA-P1108 will respond: “Enter minutes.”
3. Using the number keys, enter the minutes.
The OMA-P1108 recites the digits as they are pressed.
4. Press ENTER. The OMA-P1108 responds: “Enter
seconds.”
5. Using the number keys, enter the seconds. The OMA-
P1108 recites the digits as you press them.
6. Press ENTER. The OMA-P1108 responds: “Enter.”
39
Page 54
Omegaphone® OMA-P1108 User’s Manual
4.8.2 Interrogating Call Delay
To interrogate Call Delay:
1. Press WHAT IS.
2. Press CALL DELAY.
The OMA-P1108 will recite the programmed Call Delay.
4.9 Local Voice Mute
When the OMA-P1108 dials out to report an alarm, it also
audibly recites the alarm message at its installation site. The
Local Voice Mute command allows you to turn off the voice at
the OMA-P1108’s site during alarm dialouts and status call-ins.
This feature is used to prevent intruders or unauthorized
persons from hearing the alarm dial-out message or from
hearing the Status Report during an off-site call.
4.9.1 Enable/Disable Local Voice Mute
To enable/disable Local Voice Mute:
1. Press SENSOR ON/OFF.
2. Press MUTE.
The OMA-P1108 will say “On,” to indicate that Local
40
Page 55
Chapter 4: Communications Programming
Voice Mute is enabled, or“Off,” to indicate that it is
disabled.
3. Repeat key sequence to switch between enabled or
disabled Local Voice Mute.
4.10 Voice Repetitions
The Voice Repetitions feature allows programming of the
number of times the alarm message is delivered per phone call
during alarm dial-out.
The maximum repetitions may be set to 10; the default is
3 repetitions.
4.10.1 Programming Voice Repetitions
To program Voice Repetitions:
1. Press SET.
2. Press VOICE REPS.
The OMA-P1108 will respond: “Enter number.”
3. Using the number keys, enter a value from 0 to 10.
4. Press ENTER. The OMA-P1108 will respond: “Enter.”
41
Page 56
Omegaphone® OMA-P1108 User’s Manual
4.10.2 Interrogating Voice Repetitions
To interrogate Voice Repetitions:
1. Press WHAT IS.
2. Press VOICE REPS.
The OMA-P1108 will recite the number programmed.
4.11 Intercall Time
The Intercall Time is the programmable period of time the
OMA-P1108 waits in calling subsequent telephone numbers.
Intercall Time is activated only after alarm dial-out to the first
telephone number fails to be acknowledged. This period can
be programmed from 10 seconds to 60 minutes. The default
intercall time is 1 minute.
If an incoming telephone call is made to the OMA-P1108
during Intercall Time (in between its dialing of subsequent
telephone numbers to report an alarm), it will answer the
incoming call and immediately report any existing alarms. The
manner in which the incoming call is answered depends upon
whether or not TAD is enabled or disabled:
• If TAD (Telephone Answering Device) is enabled,
Rings Until Answer will be 1.
• If TAD is disabled, Rings Until Answer will be 10.
Refer to Section 4.5, Rings Until Answer, and Section 4.6,
TAD (Telephone Answering Device).
4.11.1 Programming Intercall Time
To program Intercall Time:
1. Press SET.
42
Page 57
Chapter 4: Communications Programming
2. Press INTERCALL TIME.
The OMA-P1108 will respond: “Enter minutes.”
3. Using the number keys, enter the minutes.
The OMA-P1108 recites the digits as you press them.
4. Press ENTER. The OMA-P1108 will respond: “Enter
seconds.”
6. Using the number keys, enter the seconds. The OMA-
P1108 recites the digits as you press them.
7. Press ENTER. The OMA-P1108 responds: “Enter.”
4.11.2 Interrogating Intercall Time
To interrogate Intercall Time:
1. Press WHAT IS.
43
Page 58
Omegaphone® OMA-P1108 User’s Manual
2. Press INTERCALL TIME.
The OMA-P1108 will recite the programmed
Intercall Time.
4.12 Maximum Number of Calls (Max Calls)
The Max Calls feature controls the total number of repeated
calling attempts by the OMA-P1108 in the event of an alarm.
When an alarm occurs, the dial-out process begins, and
continues to cycle through your programmed telephone
numbers until a maximum number of calls is reached. The Max
Calls setting regulates the number of calls that will be made as
a result of any alarms; if more than one alarm is detected at
once, or if a second alarm occurs during dial-out on the first
alarm, the Max Calls setting will start the calling process from
zero, until the programmed number of calling attempts are
completed.
The default setting for Max Calls is 16, but it may be
programmed from 0 to 255 calls. Max Calls is cancelled when
an alarm is acknowledged. If the maximum number of calls is
completed and no alarm acknowledgement has occurred, the
OMA-P1108 will automatically acknowledge any alarm and
stop the dial-out.
NOTE
If only one telephone number is programmed, the
OMA-P1108 will dial out a maximum of 15
times to report an alarm.
4.12.1 Programming Max Calls
To program Max Calls:
1. Press SET.
2. Press MAX CALLS.
44
Page 59
Chapter 4: Communications Programming
The OMA-P1108 will respond: “Enter number.”
3. Using the number keys, enter a value. The OMA-P1108
will recite the digits as you press them.
5. Press ENTER. The OMA-P1108 responds: “Enter.”
4.12.2 Interrogating Max Calls
To interrogate Max Calls programmed:
1. Press WHAT IS.
2. Press MAX CALLS.
The OMA-P1108 will recite the value set for Max Calls.
4.13 The Clock
The OMA-P1108 has a built-in clock. The power-up time is
12 AM. The clock will keep time from 12 AM until you
program the current time. It will then keep time from your
programmed time. If the AC power fails, the clock will continue to keep time until the battery back-up fails. It will then
reset to 12 AM when power is restored. An incorrect time is a
45
Page 60
Omegaphone® OMA-P1108 User’s Manual
good indication that the power has failed and the batteries
have been expended.
4.13.1 Setting the Clock
To set the clock:
1. Press SET.
2. Press CLOCK.
3. Using the number keys, enter the correct time. The
OMA-P1108 will recite the digits as they are pressed.
46
4. If the time is AM, press the AM key. The OMA-P1108
will “beep.” (If the time is PM , there is no key to press—
the clock will be automatically set to PM if AM is not set.)
5. Press ENTER. The OMA-P1108 will say “Enter.”
Example: You want to set the clock to 12:45 AM. Press the
following keys in the order shown:
SET…CLOCK…1…2…4…5…AM…ENTER.
Page 61
Chapter 4: Communications Programming
4.13.2 Interrogating for the Current Time
To interrogate the OMA-P1108 for the current time:
1. Press WHAT IS.
2. Press CLOCK. The OMA-P1108 will recite the
programmed time.
4.14 The Security Code
The Security Code is the last step after setting all other programming parameters for the OMA-P1108. The code consists
of a 4-digit number you select and will effectively prevent
unauthorized changes to the OMA-P1108’s programming.
When the Security Code is activated, all keyboard programming is inaccessible. The OMA-P1108 may be interrogated
using the WHAT IS key, but the keyboard must be unlocked,
via the Security Code, before any additional programming is
possible.
4.14.1 Locking the Keypad
To program the Security Code:
1. Press SET.
2. Press CODE.
The OMA-P1108 will say “Enter security code.”
47
Page 62
Omegaphone® OMA-P1108 User’s Manual
3. Using the number keys, enter 4 digits. The OMA-P1108
says, “OK.” The keyboard is now locked.
If unauthorized persons attempt to set a parameter, an
error message, “Error 2,” is returned. Whenever any
operation except WHAT IS takes place without entering
the security code first, this error message occurs.
4.14.2 Unlocking the Keypad
To unlock the keyboard:
1. Press WHAT IS.
48
2. Press CODE.
The OMA-P1108 will say “Enter Security Code.”
3. Using the number keys, enter the digits for the code.
.
If the correct code is entered, the OMA-P1108 will say
“OK.” If the wrong code is entered, the OMA-P1108 will
say “Error 2.”
Page 63
Chapter 5: Alarm Programming
Chapter 5: Alarm Programming
This chapter explains the alarm programming and monitoring
capabilities of the OMA-P1108, with specific instructions for
the following features:
• Configure inputs as dry contact or temperature
• Enable/disable inputs
•Program alarm Recognition Time for each input
•Program high and low temperature limits
•Disable alarm response to high or low temperature
•Program temperature in Fahrenheit or Celsius scale
• Calibrate temperature
• Obtain current temperature
•Program AC power-failure Recognition Time
• Enable/disable AC power monitoring
•Program sound level sensitivity
•Program high sound Recognition Time
•Disable alarm response to high sound
•Use Exit Delay via Status Report
5.1 Input Configuration
In preparing the OMA-P1108 to sense an alert condition, the
inputs must be configured as dry contact (either open or
closed) or as temperature inputs. The default setting for input 1
is temperature; for inputs 2-4, the default is dry contact and
open. To configure input normality, sensors are first wired to
the terminal strip at the back of the unit. (Refer to Chapter 2,
Section 2.9–2.12, for an explanation on wiring inputs.)
The configuration process directs the OMA-P1108 to initialize
the 8 inputs and establish normal settings. Any change in the
status of an input (for example, from a normally open contact
to a suddenly closed contact) is recognized as an alert condi-
tion. In the case of a temperature input, an alert condition is
recognized when established temperature limits are exceeded.
Before starting keyboard commands to configure input
normality on the OMA-P1108, it is very important to
check that the sensors you have wired to the unit are set
in their normal, non-alarm positions.
NOTE
49
Page 64
Omegaphone® OMA-P1108 User’s Manual
For example, if a magnetic reed switch (a normally-closed
sensor used to detect unauthorized entry) has been wired
to the OMA-P1108, make sure that the door or window to
be monitored is shut before configuring the input. If a
motion-detector is wired to the unit, it is advisable to
block all sources of motion from the sensor before and
during configuration.
5.1.1 Programming Input Configuration
1. Press STANDBY to place the OMA-P1108 in
Standby mode.
2. Wire sensors to the inputs to the back of the OMA-P1108
(see Chapter 2, Section 2.10).
3. Press RUN. The red light glows when the OMA-P1108
returns to Run mode.
50
4. Press SET.
5. Press CONFIGURE.
6. The OMA-P1108 audibly recites the configuration for
each of the eight inputs:
• If the input is normally open, the OMA-P1108 recites
the number of the input and says“OK.”
• If the input is normally closed, the OMA-P1108 recites
the number of the input, followed by a “beep”
and“OK.”
Page 65
Chapter 5: Alarm Programming
• If the input is configured as temperature, the
OMA-P1108 recites the number of the input, followed
by “Temperature.”
5.1.2 Verifying Input Configuration
Input configuration can be verified when interrogating the
OMA-P1108 for a complete Status Report. Refer to Chapter 6
for a more detailed description of the Status Report.
5.2 Enable/Disable Inputs
This function allows you to enable or disable an input’s
response to an alert condition. An enabled input will respond to
an alert condition and allow dial-out. A disabled input will
cause dial-out to be suppressed, but any existing alert conditions will be revealed during the Status Report. Enable/disable
programming is useful during wiring of inputs (see Chapter 2)
or when a condition needs to be monitored, but is not critical
enough to be programmed for dial-out reporting. It is important
to verify input status after performing any task that requires
disabling. The default setting for all inputs is enabled (ON).
If an alert condition exists when inputs are re-enabled,
Recognition Time will restart—refer to Section 5.3.
5.2.1 Changing Enabled/Disabled Input Status
1. Press SENSOR ON/OFF.
2. Press the number (1 to 8) of the selected input to enable/
disable. The OMA-P1108 says “Off” to indicate disabled
or “On” to indicate enabled.
51
Page 66
Omegaphone® OMA-P1108 User’s Manual
5.2.2 Verifying Enabled/Disabled Input Status
1. Press WHAT IS.
2. Press STATUS.
The OMA-P1108 audibly recites the current status of every
input. In a Status Report, each input is first identified by its
input number, followed by a report that specifies parameters
currently affecting that input. If an input is disabled, the word
“Off” immediately follows the number recited for that input.
For example, input 3 is configured as a normally open, dry
contact input. During the Status Report:
• If disabled, the OMA-P1108 recites:
“Number 3—Off—OK,” for input 3.
• If enabled, the OMA-P1108 recites:
“Number 3—OK,” for input 3.
In another example, input 2 is configured as a temperature
input. The current temperature is 76 degrees. During a Status
Report:
• If disabled, the OMA-P1108 recites “Number 2—Off—
76 degrees—OK”.
• If enabled, the OMA-P1108 recites “Number 2—
76 degrees—OK”.
5.3 Input Recognition Time
The Input Recognition Time is the length of time an alert
condition must be present before a valid alarm exists and dialout is activated. This time period is programmable, from 0
minutes, 0 seconds (for immediate response) up to a period of
272 minutes, 0 seconds. If an alert condition begins and then
clears within the established Recognition Time, no dial-out will
occur. When an alert condition continues beyond the
52
Page 67
Chapter 5: Alarm Programming
programmed Recognition Time, the OMA-P1108 initiates dialout. The default setting for Input Recognition Time is 0
minutes, 3 seconds.
5.3.1 Programming Input Recognition Time
1. Press SET.
2. Press RECOGNITION TIME.
3. Press the number (1 to 8) of the selected input to be
programmed.
The OMA-P1108 responds: “Enter minutes.”
4. Using the number keys, enter the minutes. For example, to
set a Recognition Time of five minutes, simply press “5”
on the keypad. The OMA-P1108 recites the digits as they
are pressed.
5. Press ENTER. The OMA-P1108 responds: “Enter
seconds.”
53
Page 68
Omegaphone® OMA-P1108 User’s Manual
6. Using the number keys, enter the seconds. The
OMA-P1108 recites the digits as they are pressed.
7. Press ENTER. The OMA-P1108 responds: “Enter.”
5.3.2 Interrogating Input Recognition Time
1. Press WHAT IS.
2. Press RECOGNITION TIME.
3. Press the corresponding input key (1 to 8).
The OMA-P1108 recites the programmed Recognition
Time for that input.
5.4 Establishing High and Low Temperature Limits
High and low temperature limits can be separately programmed
for each input configured as temperature. Limits can range
from
–20° to +150° Fahrenheit, or from –30
When temperature limits exceed high or low settings, the
OMA-P1108 will dial out with an alarm message. Default
54
°
to 65
°
Celsius.
Page 69
Chapter 5: Alarm Programming
settings are: 10
°
F for low temperature and 100
temperature.
5.4.1 Pr ogramming Temperature Limits for a Selected Input
1. Press SET.
2. Press TEMP LIMITS.
3. From the number keys, press a number (from 1 to 8) that
corresponds to the temperature input being programmed.
The OMA-P1108responds: “Enter lo w temperature
limit.”
°
F for high
4. Using the number keys, enter a value for low temperature
limit. The OMA-P1108 will recite the digits as they are
pressed. If a negative number is required, first press
PAUSE, then enter the number.
5. Press ENTER.
55
Page 70
Omegaphone® OMA-P1108 User’s Manual
The OMA-P1108 responds: “Enter high temperature
limit.”
6. Using the number keys, enter the value for high temperature limit. The OMA-P1108 recites the digits as they are
pressed.
7. Press ENTER. The OMA-P1108 responds: “Enter.”
NOTE
Do not set temperature limits too close to normal
room temperature. Minor temperature fluctuations could result in frequent and unnecessary
alarm dialouts.
5.4.2 Disabling Alarm Response to High or Low T emperature
To disable alarm response to either high or low temperature
settings exclusively, enter the maximum temperature limit when
programming the selected input. (The OMA-P1108 will not
respond to temperatures encountered at maximum settings or
beyond.) Begin by following the key sequence shown in
Section 5.4.1, and when prompted to enter the high or low
temperature value:
• Set high temperature to either +150o F or +65o C (high
temperature limit) to prevent the OMA-P1108 from
responding to a high temperature alarm.
• Set low temperature to either -20o F or -30o C to prevent
56
Page 71
Chapter 5: Alarm Programming
the OMA-P1108 from responding to a low temperature
alarm.
5.4.3 Interrogating High and Low Temperature Limits
1. Press WHAT IS.
2. Press TEMP LIMITS.
3. Press the number key corresponding to the selected
temperature input.
5.5 Temperature Scale
Temperature inputs may be set in either Fahrenheit or Celsius
degrees. The default temperature scale is Fahrenheit. To change
to Celsius:
1. Press SENSOR ON/OFF.
2. Press TEMP. The OMA-P1108 responds: “Off,” indicating
Celsius scale has replaced Fahrenheit scale.
3. To return to Fahrenheit scale, repeat the key sequence.
57
Page 72
Omegaphone® OMA-P1108 User’s Manual
The OMA-P1108 responds: “On,” indicating Fahrenheit
scale is in effect.
NOTE
When switching from Fahrenheit to Celsius, or
vice versa, the change applies to all inputs
configured to read temperature. When switching
temperature scales it is important to reset high
and low temperature limits on all temperature
inputs. Refer to Section 5.4.1 to reset
temperature limits.
5.6 Temperature Calibration
To compensate for minor variances in sensor accuracy, an offset
may be programmed for each temperature input. The amount of
offset is measured in degrees Fahrenheit or degrees Celsius.
Adjustments are possible within a range from -10 degrees to
+10 degrees. For example, if input 3 is sensing temperature and
is reading 1 degree too high, then the calibration for input 3 is
set at -1 to obtain an accurate reading.
5.6.1 Programming Temperature Calibration
58
1. Press SET.
2. Press CALIBRATE.
3. Press the number (1 to 8) of the selected temperature
input to be calibrated.
4. Enter the number required to offset the current temperature reading so a correct reading is obtained.
Page 73
Chapter 5: Alarm Programming
•To program a positive offset number (up to +10
degrees), enter the number on the keypad. The
OMA-P1108 recites the digits as they are pressed.
•To program a negative offset number (up to –10
degrees), first press PAUSE. The unit responds with a
“beep.” Next, enter the number on the keypad. The unit
recites the digits as they are pressed.
5. Press ENTER. The OMA-P1108 responds:“Enter.”
NOTE
If you find that your calibration offset exceeds
more than + 5 or – 5 degrees, other complicating
factors could be affecting normal operation of
the OMA-P1108. Call Omega for technical
assistance.
5.6.2 Interrogating Temperature Calibration
1. Press WHAT IS.
2. Press CALIBRATE.
59
Page 74
Omegaphone® OMA-P1108 User’s Manual
3. Press the number key corresponding to the selected
temperature input.
If a “beep” precedes the number as it is recited, then a
negative offset is indicated.
5.7 Obtaining Current Temperature
Current temperature readings for each temperature input may
be accessed at any time. The OMA-P1108 recites the input
number, and the actual temperature detected by the attached
sensor, for all inputs configured as temperature. To obtain
current temperature:
1. Press WHAT IS.
2. Press TEMP.
5.8 AC Power Monitoring Enable/Disable
The OMA-P1108 monitors AC power failure. This command
enables or disables the power failure detection feature.When
enabled, the OMA-P1108 will monitor power and dial out when
AC power failure exceeds a programmable span of time (refer
to AC Power Failure Recognition Time, Section 5.9).
The default setting for AC power monitoring is enabled (on).
When disabled, the OMA-P1108 will not dial-out to report
power failure.
60
Page 75
Chapter 5: Alarm Programming
5.8.1 Enabling/Disabling the AC Power Alarm
1. Press SENSOR ON/OFF.
2. Press POWER.
• The OMA-P1108 will say “Off” to indicate that the
power alarm is disabled, or
• The OMA-P1108 will say “On” to indicate that the
power alarm is enabled.
3. Repeat key sequence to change settings.
5.9 AC Power Failure Recognition Time
The AC Power Failure Recognition Time is the length of time
that AC electric power is off before a valid alarm is recognized
and dial-out begins. The default setting is 5 minutes, 0 seconds,
but is programmable from 0 seconds to a maximum of
272 minutes.
When AC power failure occurs, and throughout the programmed Recognition Time, the OMA-P1108 steadily repeats
the message, “the electricity is off,” at the unit’s installation site.
There is no Call Delay programming available for AC power
failure. Immediately following Recognition Time, the OMAP1108 begins the dial-out process to report power failure.
To cancel the power-failure message locally at the keypad
(during or after Recognition Time) press any key on the
OMA-P1108 keypad. This action also cancels the dial-out
process. The AC power failure alarm may also be cancelled
remotely, by telephone acknowledgment (see Chapter 6,
Section 6.1).
61
Page 76
Omegaphone® OMA-P1108 User’s Manual
5.9.1 Programming Power Failure Recognition Time
1. Press SET.
2. Press RECOGNITION TIME.
3. Press PO WER. The OMA-P1108 responds: “Enter
minutes.”
4. Using the number keys, enter the number of minutes. The
OMA-P1108 will recite the digits as they are pressed.
62
5. Press ENTER. The OMA-P1108 responds: “Enter
seconds.”
6. Using the number keys, enter the number of seconds. The
OMA-P1108 will recite the digits as they are pressed.
Page 77
Chapter 5: Alarm Programming
7. Press ENTER. The OMA-P1108 responds: “OK.”
5.9.2 Interrogating Power Failure Recognition Time
1. Press WHAT IS.
2. Press RECOGNITION TIME.
3. Press POWER.
The OMA-P1108 will recite the power Recognition Time.
5.10 Sound Alarm Monitoring
This feature allows you to program the level and duration of
sound that will cause the OMA-P1108 to respond to an alarm
and dial-out. It may be useful to desensitize the OMA-P1108 to
sound if it is installed in an area with a relatively high noise
level, or where a loud noise occurs frequently but is not
associated with an alarm. In some applications, it may be
desirable to increase sound sensitivity to low sound levels.
5.10.1 Programming Sound Alarm Sensitivity
The sensitivity setting for sound alarm monitoring ranges from
1 to 255. A value of 1 makes the microphone the MOST
sensitive to changes in sound. The value 255 makes the
microphone the LEAST sensitive to sound. The default value
is 32.
63
Page 78
Omegaphone® OMA-P1108 User’s Manual
1. Press SET.
2. Press CALIBRATE.
3. Press SOUND. The OMA-P1108 responds: “Enter
number.”
4. Using the number keys, enter a value for sound sensitivity.
The OMA-P1108 recites the digits as you press them.
5. Press ENTER. The OMA-P1108 responds: “Enter.”
5.10.2 Interrogating Sound Sensitivity
1. Press WHAT IS.
2. Press CALIBRATE.
64
Page 79
Chapter 5: Alarm Programming
3. Press SOUND. The OMA-P1108 recites the programmed
sound sensitivity level.
5.10.3 Programming High Sound Alarm Recognition Time
The Recognition Time for sound alarm monitoring ranges from
2 seconds to 59 seconds. The default value is 8 seconds.
1. Press SET.
2. Press RECOGNITION TIME.
3. Press SOUND. The OMA-P1108 responds: “Enter
seconds.”
4. Using the number keys, enter the number of seconds. The
OMA-P1108 will recite the digits as they are pressed.
5. Press ENTER. The OMA-P1108 responds: “OK.”
65
Page 80
Omegaphone® OMA-P1108 User’s Manual
5.11High Sound Alarm Enable/Disable
The OMA-P1108 monitors sound through the built-in
microphone. When the sound level suddenly exceeds the
programmed high sound limit, the OMA-P1108 will respond to
an alert condition. The increased sound level must continue
throughout the programmed recognition time. The default for
high sound alarm is enabled (on).
NOTE
The microphone is also used for listening to
on-site sounds. Refer to Chapter 4, Section 4.7.
Disabling the sound alarm does not affect
listen-in capability.
5.11.1Changing Enabled/Disabled High Sound Alarm
1. Press SENSOR ON/OFF.
2. Press SOUND. The OMA-P1108 will say “Off” to
indicate disabled or “On” to indicate enabled.
3. Repeat key sequence to change settings.
5.12 Exit Delay
When tripping an alarm is unavoidable, yet a true alert
condition has not actually occurred, the alarm response,
including dial-out, can be temporarily suppressed.
The OMA-P1108 is able to suppress and then reset its dial-out
function automatically through use of the Status Report. This is
especially convenient when an alert condition is created upon
66
Page 81
Chapter 5: Alarm Programming
exiting a monitored door, and there is no way to cancel from
the local keypad.
Example: You are planning to exit through a monitored door.
Prior to exiting, you initiate a Status Report recitation at the
OMA-P1108 keypad by pressing WHAT IS, followed by
STATUS, (key sequence shown below). This allows you
approximately 30 seconds to exit without activating the
OMA-P1108’s programmed response to an alarm. At the
conclusion of the status report, normal alarm response is
reactivated.
To use exit delay, initiate the Status Report.
1. Press WHAT IS.
2. Press STATUS. The OMA-P1108 recites the full Status
Report; during this time, you are able to exit the
monitored area without tripping an alarm.
67
Page 82
Omegaphone® OMA-P1108 User’s Manual
NOTES
68
Page 83
Chapter 6: Acknowledgment, Status Report, and Remote Access
Chapter 6: Acknowledgment,
Status Report, and
Remote Access
In addition to communication and alarm monitoring
capabilities, the OMA-P1108 will also respond to your
instructions and provide you with access to information on
monitored conditions at all times.
By issuing commands to the unit, either at the installation site
or over standard telephone lines, the following features may be
activated:
• Acknowledgment of existing alarms
• The Status Report on all monitored conditions.
6.1 Alarm Acknowledgment
When the OMA-P1108 dials out with an alarm message, it will
request acknowledgment before hanging up. Acknowledgment
indicates to the unit that the alarm message has been received.
Upon acknowledgment, the OMA-P1108 will cancel the dialout sequence.
There are three ways* that an alarm is acknowledged directly:
• Local Acknowledgment
•Touch-Tone
• Callback Acknowledgment
* A fourth method of alarm acknowledgment is indirect. Refer
to Max Calls, Chapter 4, Section 4.12 for an example of
automatic alarm acknowledgment.
TM
Acknowledgment
6.1.1 Local Acknowledgment
To acknowledge an alarm locally (directly at the installation
site of the OMA-P1108), press any key.
6.1.2 Touch-Tone
This method of remote alarm acknowledgment works with a
Touch-ToneTM telephone.
TM
Acknowledgment
69
Page 84
Omegaphone® OMA-P1108 User’s Manual
Example: You receive a call from the OMA-P1108, reporting
that an alarm exists. The message concludes: “Indicate you
have received warning message.” Now, or at any time during
this call, you may acknowledge the alarm with the code “555”
if you are using a Touch-ToneTM telephone.
•To enter “555,” press the number (5) key on the Touch-
ToneTM phone keypad three times. The OMA-P1108 will
respond: * “Warning message received by telephone
number (last number dialed).” The OMA-P1108 will
hang up and the dial-out sequence, including any further
response to the alarm, will be cancelled.
• If you enter the wrong code or do not enter it within
10 seconds following the conclusion of the message, the
OMA-P1108 will respond: “Dial telephone number
(the programmed unit phone number) within (Intercall
Time).” Then, the OMA-P1108 will hang up. The alarm
is still not acknowledged until you call back. You have a
period equal to the programmed Intercall Time to call
the unit back in order to acknowledge the alarm. Refer
to Callback Acknowledgment, Section 6.1.3, below.
6.1.3 Callback Acknowledgment
This method of remote alarm acknowledgment works with any
telephone: pulse, rotary, or Touch-ToneTM.
Example: The OMA-P1108 calls you with an alarm message.
You answer the call with a rotary or pulse telephone, and do the
following:
•You listen to the message and hang up.
• Then you call the OMA-P1108 back on any telephone.
You must wait for 10 rings—this signals the OMAP1108 to answer your telephone call. (Make sure to call
back within the programmed setting for Intercall
Time—refer to Chapter 4, Section 4.11.)
When the OMA-P1108 answers your return call, it gives a
Status Report (refer to Section 6.2). Then it says:“Warning
message received by ...” and recites the telephone number last
dialed. This indicates that the alarm has been acknowledged.
70
Page 85
Chapter 6: Acknowledgment, Status Report, and Remote Access
NOTE
If you have the TAD feature ( telephone
answering device) enabled, the OMA-P1108 will
answer the telephone on the first ring. If it is
disabled, the telephone must be allowed to ring
10 times. This serves as a precaution against a
random alarm acknowledgment. Refer to
Chapter 4, Section 4.6, for complete information
on using the TAD feature.
6.2 Status Report
The Status Report allows access to complete information on all
monitored conditions either locally, from the keypad, or by
telephone, from any location. The OMA-P1108 will answer an
incoming telephone call following the programmed Rings Until
Answer (refer to Chapter 4, Section 4.5). Included with the
Status Report are messages related to alarm conditions,
AC power, battery backup and sound level. It also provides an
opportunity for listening to on-site sounds (refer to Listen-in
Time, Chapter 4, Section 4.7).
To initiate the Status Report:
1. Press WHAT IS.
2. Press STATUS.
Sections 6.2.1, 6.2.2, and 6.2.3 demonstrate two different Status
Report recitations. The Status Report starts with:
“Hello. This is telephone number 555-1234 (or the
programmed ID).”
“The time is 12:15 PM (or the current time).”
The OMA-P1108 proceeds with a separate report for each
input. Each input identifies itself by reciting the input number.
71
Page 86
Omegaphone® OMA-P1108 User’s Manual
6.2.1 Example: Status Report, No Alarms
Inputs 2, 5, and 6 are configured as dry contact and input 1 is
configured as temperature. No alarms exist. The Status Report
begins by saying, “Hello , this is telephone number 555-1234;
the time is 12:15 PM.” Following this introduction, the report
continues:
“Number 1, 74 degrees, OK.”
“Number 2, OK.”
“Number 5, OK.”
“Number 6, OK.”
“The electricity is ON.” This refers to AC power.
“Battery condition, OK.” Other responses: “Battery condition
low” or “Replace batteries.” (Refer to Section 6.2.4 for
additional information regarding battery condition.)
“Sound level, OK.”
“Listen to the sound level for 10 seconds.” In this case, the
programmed Listen-in Time is set at 10 seconds. (This feature
is not available when obtaining the Status Report on-site,
directly at the keypad.)
72
The Status Report repeats once more and the OMA-P1108
concludes the call, saying: “Have a good day.” (The Status
Report will not repeat if obtained at the keypad; “Have a good
day,” is also not recited.)
The phrase “no number” at the end of a Status Report
indicates that no dial-out phone numbers have been
programmed.
Page 87
Chapter 6: Acknowledgment, Status Report, and Remote Access
6.2.2 Example: Status Report, Existing Alarms
Inputs 2, 3,and 8 are configured as dry contact and input 1 is
configured as temperature. An emergency situation is at hand:
a fire in a greenhouse has tripped a smoke alarm and electrical
power has been disrupted. In addition to high sound and AC
power alarms, separate alarms exist on inputs 1, 2, 3, and 4. You
happen to call in for the Status Report, which begins with,
“Hello, this is telephone number 555-1234; the time is
12:15 PM.” Following this introduction, the report continues:
“Number 1, 110 degrees, HIGH.”
“Number 2, EXISTS.”
“Number 3, EXISTS.”
“Number 8, EXISTS.”
“The electricity is OFF.”
“Battery condition, OK.”
“Sound level, HIGH.”
“Warning message received by ...(last telephone number
dialed*).”
“Listen to the sound level for 10 seconds.”
The Status Report repeats once more and the OMA-P1108
concludes the call, saying: “Have a good day.”
* The “last telephone number dialed” refers to any one of the
programmed, dial-out telephone numbers through which the
OMA-P1108 was able to receive alarm acknowledgment, prior
to your call for a Status Report; this could also refer to the
OMA-P1108’s I.D. Number (identification number), if the
alarms are acknowledged at the keypad by someone present at
the site.
73
Page 88
Omegaphone® OMA-P1108 User’s Manual
6.2.3 Example: Status Report, Disabled Inputs
If an input is disabled, the dial-out feature for that input is
deactivated, but all other programmed parameters remain in
effect. In the example below, all 4 inputs are disabled, although
inputs 1 and 3 are detecting alarms. AC power and Sound Level
is also disabled for dial-out. (Note that to indicate disabled
status, only AC power will return two audible “beeps,” rather
than the word “OFF.”) When y ou call the OMA-P1108 for a
Status Report, you hear the following:
“Hello, this is telephone number 555-1234.
“The time is 12:15 PM.”
“Number 1, OFF, 96 degrees, HIGH.”
“Number 2, OFF, 74 degrees, OK.”
“Number 3, OFF, EXISTS.”
“Number 4, OFF, OK.”
“The electricity is (beep, beep), ON.” If the electricity is off,
or the AC adaptor is disconnected, you will hear:
“The electricity is (beep, beep), OFF.”
74
“Battery condition, OK.”
“Sound level, OFF, OK.” If the sound level is high you will
hear: “Sound level, OFF, HIGH.”
“Listen to the sound level for 10 seconds.”
The Status Report repeats once more and the OMA-P1108
concludes the call, saying: “Have a good day.”
Page 89
Chapter 6: Acknowledgment, Status Report, and Remote Access
6.2.4 Battery Condition
During a Status Report, you may hear one of three possible
messages regarding battery power. The OMA-P1108
determines the appropriate message by measuring battery
voltage. Depending upon the remaining voltage, it may
respond:
• “Battery Condition , OK,” if over 8.2 Volts.
• “Battery Condition , low,” if between 7.2 and 8.2 Volts.
• “Replace batteries,” if below 7.2 Volts.
6.2.5 Remote Access by Touch-Tone™ Telephone
Calling the OMA-P1108 for a Status Report provides the
opportunity to access other functions, using Touch Tone™ pushbutton commands. Remote telephone commands include:
•Disabling/enabling any input.
•Disabling/enabling High Sound Alarm monitoring.
•Disabling/enabling AC Power monitoring.
• Activation of Listen-In Time.
• Activation of the Status Report.
To issue commands by telephone, first dial the number of the
OMA-P1108 to access the Status Report. The Status Report
will be followed by the programmed Listen-In Time. If you
remain on the telephone, the Status Report will be repeated,
followed by a 10 second waiting period and hang-up. During
this
10 second waiting period, or at any time during the call, other
commands may by accessed by pressing any push button on
the telephone.
If a Security Code is in effect, the OMA-P1108 will prompt
you with: “Enter Security Code.” If no Security Code is set,
then it will say “O.K.”
• Enter your Security Code (4 digits) with the telephone
push buttons. If the code you enter is correct, the
OMA-P1108 will respond: “OK.”
• If you enter the wrong Security Code, the OMA-P1108
says,“Error. Have a good day,” and hangs up.
75
Page 90
Omegaphone® OMA-P1108 User’s Manual
Disabling/enabling inputs – If an input is set to detect an alert
condition, it can be disabled to prevent the OMA-P1108 from
dialing out, or re-enabled at any time.
This feature allows the convenience of disabling an input, even
if you are away from the site of the OMA-P1108. One such
application may involve an input programmed to detect
unauthorized entry. You are in another locale, but must allow
someone else temporary access to the area monitored by the
OMA-P1108. Using a Touch Tone
the appropriate input (thereby disabling any alarm dial-out
response). The input remains disabled until you issue the same
command, which effectively returns it to its former, enabled
state.
Press the following push-buttons on the Touch ToneTM telephone to execute the desired command:
* (asterisk), 1
...equal to Sensor On/Off, for input 1. To re-enable the
input, repeat the same Touch-ToneTM button sequence
used for disabling.
* (asterisk), 2
...equal to Sensor On/Off for input 2, and so on, for
inputs up to 8. To re-enable the input, repeat the same
Touch-ToneTM button sequence used for disabling.
TM
telephone, you can disable
76
Disabling/enabling High Sound Monitoring –
* (asterisk), 9
...equal to SENSOR ON/OFF for High Sound Alarm
monitoring. To re-enable High Sound Alarm, repeat the
command.
Disabling/enabling A C P ower –
* (asterisk), 0
...equal to Sensor On/Off for AC Power monitoring. To
re-enable AC Power monitoring , repeat the command.
Page 91
Chapter 6: Acknowledgment, Status Report, and Remote Access
Activating Listen-In Time –
# (pound), 1
...initiates Listen-In Time for listening to on-site sounds
for the programmed time available.
Activating Status Report –
# (pound), 2
...initiates a full recitation of the Status Report.
Exiting –
# (pound), # (pound)
...forces exit. The 1108 says, “Have a good day,” and
hangs up.
77
Page 92
Omegaphone® OMA-P1108 User’s Manual
NOTES
78
Page 93
Chapter 7: Operation
Chapter 7: Operation
After installation and programming is completed, the
OMA-P1108 is fully operational. This chapter explains the
sequence of events that occur during an alarm dialout to
illustrate how the OMA-P1108 operates.
7.1 Alarm Detection, Dial-out and Acknowledgment
Generally, an alarm event is structured in the following manner:
I. The OMA-P1108 detects an alert condition due to a
change at the sensor.
II. A valid alarm is recognized.
III. Dial-out begins.
IV. The alarm is acknowledged.
Often, an alarm does not proceed through all stages: either an
alert condition does not persist long enough to be considered
valid, or a valid alarm is cancelled.
The table on the following page explains the alarm detection,
dial-out and acknowledgment features and lists important
variable factors affecting their operation.
79
Page 94
Omegaphone® OMA-P1108 User’s Manual
I. OMA-P1104 Detects a Change at the Sensor
• OMA-P1108 detects a change in the
monitored condition (from the sensor
wired to one of the 8 inputs). This is
considered an alert condition, and does
not qualify as a valid alarm at this point.
• The condition continues throughout the
programmed Recognition Time. If the
condition (or sensor) reverts to its
normal state before the Recognition
Time is reached, no alarm will occur.
• The condition must persist long enough
to meet or exceed the programmed
Recognition Time. When Recognition
Time has expired, but the alert condition
continues, the OMA-P1108 will
determine that a valid alarm exists.
• When a valid alarm is determined, Call
Delay is activated, forcing the
OMA-P1108 to wait for a programmed
period of time before starting the dialout process. Call Delay applies to the
period just prior to dial-out, before the
first telephone call is made.
• Call Delay provides the opportunity to
cancel a valid alarm at the
OMA-P1108’s installation site, before
dial-out occurs. An audible voice
message indicates which of the inputs is
in alarm. If on-site personnel acknowledge the alarm within the Call Delay
time, the
OMA-P1108 will not dial out. (Local
Voice Mute is disabled, so that alarm
messages can be heard at the site.)
Variable Factors
Input Type: (1) An
open circuit closes,
(2) a closed circuit
opens, or
(3) temperature
limits are exceeded.
Recognition Time:
Activated
Variable FactorsII. A Valid Alarm Is Recognized
Recognition Time:
Expired
Valid Alarm:
Exists
Call Delay:
Activated
Alarm Message:
Audible, On-site
Activated
Local Voice Mute:
Disabled
80
Page 95
Chapter 7: Operation
III. Dial-out Begins Variable Factors
• The dial-out process is activated as soon
as the Call Delay time expires (if the
alarm has not been cancelled at the
OMA-P1108’s installation site.) The
dial-out begins with telephone number 1
and proceeds sequentially, through the
remaining telephone numbers.
• If the alarm is not acknowledged with
the first dial-out telephone call, the
OMA-P1108 waits the duration of
Intercall Time before dialing the next
telephone number. Intercall Time is the
programmed waiting period in between
each dial-out telephone call.
• When the telephone is answered, the
programmed Voice Repetitions
determine the number of times per call
the OMA-P1108 recites the alarm
message.
• Call Progress, an automatic feature,
enables the OMA-P1108 to detect
whether or not the telephone call is
answered. After 8 rings, or if a busy
signal is encountered, the OMA-P1108
will hang up, wait the programmed
Intercall Time, and proceed to dial the
next telephone number.
• If no telephone calls are answered, the
OMA-P1108 dials out sequentially,
through the remaining telephone
numbers and continues to cycle until the
programmed Maximum Number of
Calls is reached.
• When the telephone is answered, the
OMA-P1108 will immediately begin
reciting a message that indicates which
of the inputs is in alarm. At the same
time, the alarm message is repeating at
the OMA-P1108’s installation site. The
OMA-P1108 will request acknowledgment, if it has not yet occurred.
Call Delay:
Expired
Intercall Time:
Activated
Voice Repetitions:
Activated
Call Progress:
Activated
Max Calls:
Activated
Alarm Messages:
By Telephone
and
On-site
81
Page 96
Omegaphone® OMA-P1108 User’s Manual
Variable FactorsIV. The Alarm is Acknowledged
• At any time after a valid alarm is
determined, the alarm may be acknowledged at the OMA-P1108’s installation
site, by pressing any key.
• When the OMA-P1108 dials out and the
call is answered via Touch-Tone
telephone, any alarm may be instantly
acknowledged by pressing “555.”
• If the alarm message repeats for the
number of programmed Voice Repetitions, and “555” has not been entered,
the OMA-P1108 will say:
“Indicate that you have received warning
message.”
The OMA-P1108 waits 10 seconds for
the Touch-Tone code “555” to be
entered. If the code is entered within 10
seconds, it responds:
“Warning message received by telephone
number...(the Unit ID Number).”
The alarm is considered acknowledged
and the dialout concludes.
• If the OMA-P1108 does not receive the
Touch-Tone code within 10 seconds, it
recites the following and then hangs up:
“Dial telephone number (gives the Unit ID Number)
within...(the programmed Intercall Time.)”
Local, On-site
Acknowledgment
Touch-Tone
Acknowledgment:
Fast Code 555
Touch-Tone
Acknowledgment:
Normal Code 555
Tone or Pulse
Callback
Acknowledgment:
Within Intercall Time
82
The recipient of this message must call
the OMA-P1108 back within the period
programmed for Intercall Time, in order
to acknowledge the alarm. If Local
Voice Mute is off, the unit will beep at
the installation site while waiting for
this call.
• Callback: The OMA-P1108 waits 10
rings before answering to guard against
random acknowledgment. If an
answering device is connected to the
Page 97
Chapter 7: Operation
IV. The Alarm is Acknowledged
same line as the OMA-P1108 (and
TAD is enabled), the OMA-P1108 will
answer on the first ring. First, it recites
the Status Report, followed by:
“Warning message received by telephone
number...(the number of your present location).”
“Have a good day.”
When the OMA-P1108 hangs up, the
alarm is acknowledged and dial-out
stops.
• If calls remain unanswered, or if they
are received by an answering machine
or FAX, the OMA-P1108 continues the
dialout sequence; it waits the Intercall
Time and proceeds to dial the next
telephone number. Telephone numbers
are dialed sequentially, and this cycle
continues for the number of Max Calls
programmed. If no acknowledgment
occurs, then at the completion of Max
Calls, the alarm is automatically
acknowledged and the dial-out process
is terminated.
Variable Factors
Tone or Pulse
Callback
Acknowledgment:
TAD Enabled
Max Calls
Acknowledgment
NOTE
Acknowledging the alarm does not correct the
situation! The alarm condition will still exist
until the sensor is restored to its normal state.
83
Page 98
Omegaphone® OMA-P1108 User’s Manual
7.2 Example: A Dial-out Telephone Call
The following parameters are selected for demonstration
purposes:
• OMA-P1108 Unit ID Number is set to 555-5674.
It is currently installed at your place of business.
•Dial-out Telephone Number 1 is programmed
to 555-1234, your home telephone number.
• Voice Repetitions are set to 4.
The OMA-P1104 is detecting an alarm on input 2.
The telephone rings at 555-1234, your home number.
You answer the telephone and hear the following message:
“Hello, this is telephone number 555-5674. The time is 8.30 p.m.
Alert condition two exists.”
(4-seconds to hear on-site sound from unit’s microphone.)
“Hello, this is telephone number 555-5674. The time is 8.30 p.m.
Alert condition two exists.”
(4-seconds to hear on-site sound from unit’s microphone.)
“Hello, this is telephone number 555-5674. The time is 8.30 p.m.
Alert condition two exists.”
(4-seconds to hear on-site sound from unit’s microphone.)
84
“Hello, this is telephone number 555-5674. The time is 8.30 p.m.
Alert condition two exists.”
(4-seconds to hear on-site sound from unit’s microphone.)
“Indicate you have received warning message.”
NOTE
It is important that your dial-out telephone
numbers be answered by you or other authorized
personnel in order to ensure adequate response to
an alarm.
Page 99
Appendix A: Tr oubleshooting
Appendix A: Troubleshooting
In the event that a problem is encountered, this section will assist
you in determining the cause, so you can return the unit to its usual
monitoring routine with minimal interruption.
Most problems with the OMA-P1108 are easy to identify and
quickly corrected, and are found under the following general
headings:
• Communications/dial-out functions
•Temperature monitoring
• Sound level monitoring
•Other monitoring functions
If you have tried the solutions outlined in this section and are not
satisfied with the results, call Omega Customer Service.
79
Page 100
Omegaphone® OMA-P1108 User’s Manual
Solution
Recheck programming steps, Refer to
Chapter 4, Section 4.2.1.
incorrectly programmed.
Cause
a) The telephone number may be
Switch from the current setting: from tone to
pulse, or from pulse to tone. Refer to
Chapter 4, Section 4.3.
le with the
rent dialing
telephone line on which the OMA-
method) is not compatib
b) Tone or pulse (the cur
Reprogram Recognition Time. Set the
Recognition Time to the minimum duration
required to create a valid alarm. If possible,
condition does not remain in effect long
P1108 is installed.
enough to become a valid alarm.
c) Recognition Time is too long. An alert
an alert condition. Refer to Chapter 5,
Section 5.3.
test the new setting by deliberately creating
Reprogram Max Calls. It is a good idea to
set your Max Calls to at least equal the
number of dial-out telephone numbers
programmed. Refer to Chapter 4,
Section 4.12.1.
d) Max Calls is set to zero.
Problem
Communications / Dial-out:
1. The OMA-P1108 fails to dial out.
80
