OMEGABOND® OB-300
HIGH TEMPERATURE AIR SET CEMENT
INSTRUCTION
SHEET
GENERAL DESCRIPTION
The OMEGA®OB-300 High Temperature Air Cement is a sodium silicate base, one-part ceramic cement which has many exceptional characteristics including:
• Resists temperatures to 982°C (1800°F)
• Resists oil, solvents and most acids (except hydrofluoric)
• Heat conductive and thermal shock resistant
• Excellent electrical insulator
• Adheres to metals, ceramics, glass, porcelain and most other nonplastic surfaces
• Excellent mechanical bonding characteristics
• Ceramic-like body
OMEGA’s OB-300 cement is used for assembling, insulating, heat treating, and cementing porcelain, glass, metal, and other materials. It is also used as a replacement for sealing wax, bolts, nuts, screws, and mica since it adheres quite readily to practically any non-plastic surface which is clean and free from oil and grease.
HANDLING INFORMATION
CAUTION
• Avoid prolonged breathing of vapors - work in well­ventilated area
• Protect skin against contamination
• Protect eyes against contamination
• Do not take internally
OMEGABOND®OB-300 Powder is a harmful dust. Avoid breathing dust by using respirators. Avoid contact with eyes or skin by wearing gloves and goggles or a face shield. Wash thoroughly with soap and water after handling. Keep containers closed.
SHELF LIFE
OMEGABOND®OB-300 Powder has a shelf life of (6) months when stored in unopened, tightly sealed containers in a dry location at 21°C (70°F).
SOLVENT
A 10% caustic or alkaline solution such as 10% NaOH (Sodium Hydroxide) will break down the OB-300 after it has cured. However, care should be exercised as far as the compatibility of the caustic solution with any other components involved in the application, such as the material or surface that the cured cement has been applied to.
DIRECTIONS FOR USE
OMEGA’s OB-300 Cement is a one-part cement and is supplied as a powder. Just mix the powder with water to a smooth, uniform consistency. Avoid using excess liquid as this will reduce mechanical strength, increase shrinkage and delay the set time. Surfaces to which the cement will be
applied should be clean and free of dirt or grease. Apply several coats where heavier layers are desired, allowing each coat to dry before application of the next coat. Do not apply OB-300 in thickness greater than 1/4". OMEGA’s OB-300 cement can be applied by brushing, dipping and spraying.
Porous substrates should be dampened with OMEGABOND
Thinning Liquid (Part No. OB-TL), prior to application of the mixed cement.
CURING
OMEGA’s OB-300 cures at room temperature by air drying in 18-24 hours, depending upon thickness and consistency. Cure time can be accelerated by low temperature oven drying at 82°C (180°F). If the cement is to be exposed to elevated temperatures, cure for 18-24 hours at ambient temperature, then oven dry for 4 hours at 82°C (180°F) and for an additional 4 hours at 104°C (220°F). This helps to prevent flaking and chipping.
PHYSICAL PROPERTIES*
Maximum Service Temperature: 982°C (800°F) Thermal Conductivity: 4-6 Btu-in/sq.ft./-hr-°F Color: Off white Coefficient of Thermal Expansion: 6.2 x 10-6in/in°F Dielectric Constant: 3.5-6.0 Dielectric Strength:
At 21°C (70°F): 12.5 to 51.0 volts/mil At 399°CF (750°): 15.0 volts/mil
At 801°C (1475°F): 1.3 volts/mil Compressive Strength: 3900 PSI Tensile Strength: 410 PSI Shear Strength: 710 PSI Modulus of Rupture: 460 PSI Volume Resistivity:
At 21°C (70°F): 108-109ohm-cm
At 399°C (750°F): 10
4
-105ohm-cm
At 801°C (1475°F): 10
2
-103ohm-cm
*Determined under laboratory conditions using applicable ASTM procedures. Actual field data may vary. Do not use Physical Properties for specifications.
NOTE
The Material Safety Data Sheet (MSDS) for the OMEGA
OB-300 cement is shipped with the product. Additional copies can be obtained by contacting OMEGA Engineering and asking for MSDS-0136.
