COMPACT ULTRASONIC,
SOLID STATE LIQUID LEVEL SWITCH
LVU-A710 Series
U Easy to Install
U No Moving Parts
U Epoxy-Sealed Integral
Electronics with Sensor
U Low-Cost Replacement
to Mechanical Float
The LVU-A710 Series compact
solid state liquid level switch is a
great replacement for mechanical
float-type liquid level devices. The
switch employs proven ultrasonic
technology and solid state integral
electronics in a small package.
The LVU-A710 Series provides
reliable operation in virtually any
liquid, regardless of viscosity. This
eliminates problems of stickiness
and failure rate due to finite
mechanical life inherent in the
mechanical float design. The
combination of fully epoxy-sealed
electronics and ultrasonic sensing
technology will provide years of
maintenance-free service.
SOURCE OUTPUT
+5–30 Vdc
SOURCE
GROUND (–)
GREEN
SINK OUTPUT
GROUND (–)
GREEN
RELAY OUTPUT
GROUND (–)
GREEN
CHASSIS
GROUND
+5–30 Vdc
+5–30 Vdc
RELAY
OUTPUT
RED
WHITE
BROWN
BLACK
JUMPER WHITE WIRE
TO RED WIRE (+)
RED
WHITE
SINK
CHASSIS
GROUND
CHASSIS
BROWN
BLACK
JUMPER BROWN WIRE
TO BLACK WIRE (-)
RED
BROWN
NO
WHITE
C
BLACK
SPECIFICATIONS
Repeatability: 2 mm or better
Delay: 0.5 sec
Input Power: 5 to 30 Vdc
Leakage Current: Less than 50 uA
Outputs:
Source: 100 mA max
Sink: 100 mA max
Relay Output: 1 A SPST (NO, C)
Dimensions: mm (inch)
LVU-A711, 712, 713
HEX 25.4 (1.0)
9.5 (0.375)
¼ NPT
THREAD
3.81
(0.150)
ALARM POINT
19 (0.75)
47.6
(1.875)
To Order Visit omega.com/lvu-a710_series for Pricing and Details
Model No. Description
LVU-A711 ¹⁄₄ NPT level switch, 316 LSS sinking output
LVU-A712 ¹⁄₄ NPT level switch, 316 LSS sourcing output
LVU-A713 ¹⁄₄ NPT level switch, 316 LSS SPST NO relay
7.6 (0.3)
9.5 (0.375)
LVU-A714 ¹⁄₂ NPT level switch, 316 LSS sinking output
LVU-A715 ¹⁄₂ NPT level switch, 316 LSS sourcing output
LVU-A716 ¹⁄₂ NPT level switch, 316 LSS SPST NO relay
Accessory
Model No. Description
PSU-93 Unregulated 24 Vdc power supply
Comes complete with operator’s manual.
Ordering Examples: LVU-A713, 316 LSS,
LVU-A716, 316 LSS,
1
⁄2 NPT, 1A SPST relay ultrasonic switch.
K-31
Protection: Transient, reverse polarity
Sensor: 316 LSS
Temperature: -29 to 80°C (-20 to 176°F)
Pressure: Up to 1000 psig (6895 kPa)
Mounting:
model number)
1
⁄4 NPT, 1A SPST relay ultrasonic switch.
60
(2.365)
LVU-A713, shown
larger than actual size.
1
⁄4 or 1⁄2 NPT (depending on
LVU-A714, 715, 716
HEX 25.4 (1.0)
19 (0.75)
3.81
(0.150)
6.35 (0.25)
10 (0.40)
16 (0.625)
ALARM POINT
9.5 (0.375)
½ NPT
THREAD
