Omega Products LVD-800 Installation Manual

User’s Guide

Shop online at

omega.com

e-mail: [e-mail]

For latest product manuals:

omegamanual.info

LVD-800 SERIES

Dry Material

Rotary Paddle Level Switches



OMEGAnet®Online Service Internet e-mail

omega.com [e-mail]

Servicing North America:

U.S.A.: One Omega Drive, P.O. Box 4047

ISO 9001 Certified Stamford, CT 06907-0047

TEL: [phone] FAX: [phone]
e-mail: [e-mail]

Canada: 976 Bergar

Laval (Quebec) H7L 5A1, Canada
TEL: [phone] FAX: [phone]
e-mail: [e-mail]

For immediate technical or application assistance:

U.S.A. and Canada: Sales Service: 1-800-826-6342 / 1-800-TC-OMEGA

Customer Service: 1-800-622-2378 / 1-800-622-BEST
Engineering Service: 1-800-872-9436 / 1-800-USA-WHEN
TELEX: 996404 EASYLINK: 62968934 CABLE: OMEGA

Mexico: En Espan˜ ol: [phone]-7803 e-mail: [e-mail]

FAX: [phone] [e-mail]

®

®

®

Servicing Europe:

Benelux: Postbus 8034, 1180 LAAmstelveen, The Netherlands

TEL: [phone] FAX: [phone]
Toll Free in Benelux: 0800 0993344
e-mail: [e-mail]

Czech Republic: Frystatska 184, 733 01 Karviná, Czech Republic

TEL: [phone] FAX: [phone]
Toll Free: 0800-1-66342 e-mail: [e-mail]

France: 11, rue Jacques Cartier, 78280 Guyancourt, France

TEL: [phone] FAX: [phone]
Toll Free in France: 0800 466 342
e-mail: [e-mail]

Germany/Austria: Daimlerstrasse 26, D-75392 Deckenpfr

TEL: [phone] FAX: [phone]
Toll Free in Germany: 0800 639 7678
e-mail: [e-mail]

United Kingdom: One Omega Drive, River Bend Technology Centre

ISO 9002 Certified Northbank, Irlam, Manchester

M44 5BD United Kingdom
TEL: [phone] FAX: [phone]
Toll Free in United Kingdom: 0800-488-488
e-mail: [e-mail]

onn, Germany

It is the policy of OMEGA Engineering, Inc. to comply with all worldwide safety and EMC/EMI

egulations that apply

r
Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.

The infor
er

W

mation contained in this document is believed to be cor

rors it contains, and reserves the right to alter specifications without notice.

ARNING:

These pr

. OMEGA is constantly pursuing certification of its products to the European New

rect, but OMEGA accepts no liability for any

oducts are not designed for use in, and should not be used for, human applications.

1

LVD-800 SERIES

This manual contains the information necessary to ensure a safe and
successful installation. Please read and comply with the section on page
9 of this manual pertaining to SAFETY. Doing so will ensure proper oper­ation of the equipment and the safety of all personnel.

Before discarding shipping container, please inspect it thoroughly and
verify that all parts ordered are accounted for. Sometimes smaller parts
become stuck under carton flaps and other packaging materials.

2

PRE-INSTALLATION CONSIDERATIONS

Choosing a Location: (See Figure 1)

1) Material Flow - When selecting a location for any rotary pad-

dle bin monitor, choose a point in the vessel where the paddle
will be out of the direct flow of incoming and outgoing materi­al to prevent any mechanical damage that may be caused by
the pressure of the flow. This is particularly important for
materials with large, lumpy characteristics.
must be positioned at a point where incoming material will
reach and cover the paddle in its normal flow, and when
receding, will flow away from the paddle in an even manner.

2) Vibration Concerns - Mount at a location that is subject to
limited vibration, away from bin vibrators thereby attaining
maximum operational life. Consult the factory when ques­tionable conditions exist.

3) Guard Reinforcement - When using shaft extensions and
guards in top mounted applications, select a location where it
is feasible to reinforce the guard to the vessel wall. See
Mechanical Installation portion of this bulletin for further
details.

The paddle unit

DIMENSIONS

ARE SHOWN IN INCHES WITH MILLIMETER EQUIVALENT IN BRACKETS

Figure 2

Rotary Paddle Bin Monitor Preparation: (See Figure 3)

1) Mounting Plate Attachment (if applicable)- After using the

2) Flexible Coupling Attachment (if applicable)- Remove lock

3) Extension Attachment (if applicable)- Remove lock pin from

Figure 1

Protective Baffles: (See Figure 2)

The installation of protective baffles for low level monitoring is
recommended for materials that weigh more than 65 lbs/ft

3

(1050

4) Guard Attachment (if applicable)- In applications using a

kg/m3), have a tendency to pack, bridge, arch, or have unusual
flow characteristics. This baffle can be created using a number
of materials including angle iron, welded plates and pipe sec

­tions. This structure will keep the full weight of the material from
damaging the bin monitor. The baffle should be welded to the bin
wall and should not extend more than 6 inches (152 mm) into the

Also, the lowest point of the baf

bin.
6 inches (152 mm) above the top of the paddle arc.

fle should be approximately

5)

mounting plate as a mounting hole template, (See Mechanical
Installation portion of this bulletin), attach the mounting plate
to the rotary paddle bin monitor prior to attaching to vessel.
This is particularly advantageous if the paddle to be used is
not an "insertable" type. Grease the paddle unit's threaded
hub with anti-seize compound and thread the mounting plate
into place until snug.

pin from rotary paddle bin monitor. Screw the flex coupling
into the coupling provided on the paddle unit. Align "through
hole" within the connection and secure with lock pin.

rotary paddle bin monitor or flex coupling. Screw the exten­sion into the coupling provided on the paddle unit, or flex cou­pling. Align "through hole" within the connection and secure
with lock pin. Guards should be used with rigid extensions
greater than 18 inches (457 mm) in length.

mounting plate with a full coupling, slide the 1 1/4" pipe over
the shaft extension and secure to mounting plate coupling.
The shaft extension should protrude from guard a distance of
approximately 4 inches (102 mm). When not using a mount­ing plate, the guard must be connected to paddle unit with a
1-1/4" full coupling and in some cases may require attach­ment after rotary paddle bin monitor installation to vessel.

Paddle

Attachment

(if applicable)- Paddle should be
attached at this time only if variety chosen is an "insertable"
type or if mounting plate is being utilized. Remove lock pin
from applicable connection point (i.e. bin monitor, flex cou­pling, or extension). Screw the paddle into the applicable cou-

Align "through hole" within the connection and secure

pling.
with lock pin.

3

MECHANICAL INSTALLATION

Side Mount /Top Mount:

Coupling Mounting

1)

sponds to the outer diameter of pipe coupling. In side mount
applications, position a half-coupling flush with the inside of
the vessel and weld into place. In top mount applications,
position a full coupling halfway into the vessel and weld into
place. After greasing the mounting threads with anti-seize
compound, thread the rotary paddle bin monitor into the cou­pling and position the conduit entrance to minimize moisture
infiltration. Attach paddle if applicable. (See Figure 2)

2) Plate Mounting - Using the gasket provided with the mount­ing plate as a template, drill six holes at the diameter applica­ble to the attachment method being used. Drill six clearance
holes at 11/32 inch (9 mm) diameter for use with 5/16" bolts.
The bolts may be secured by tack welding the bolt heads to
the vessel, or by an adjoining nut. Cut a hole (suggested size
2-5 inches (50-125 mm)) centered within the bolt circle to
allow an attached paddle to fit within the bin. Attach gasket
and mounting plate to the vessel positioning the conduit
entrance to minimize moisture infiltration. (See Figure 4)

DIMENSIONS ARE SHOWN IN INCHES WITH MILLIMETER EQUIVALENT IN BRACKETS

- Cut a hole into the vessel that corre-

Figure 3

Figure 4

Extension/Guard Installation: (See Figure 5)

1) Typical Configuration - Rigid extensions are recommended

for top mount applications only and should be always accom­panied by a flexible coupling. Shaft guards are recommend­ed whenever extensions are longer than 18 inches (457 mm).

Guard Reinforcement

2)

- Mechanical reinforcement of the
shaft guard should be considered whenever a guard length
greater than 72 inches (1.8 m) is used. The guard should be
anchored to the sidewall with braces to reduce mechanical
stress at the connection point of the guard.

3) Guard/Extension Multi-Stage Assemblies - It may be nec­essary to connect multiple short pieces to ultimately achieve
the desired length. In all cases, extensions and guards
should not exceed 144 inches (3.6 m). Shaft extensions can
be simply connected one to another

. Guards must use a

1-1/4" full coupling as an interface between sections.

4) Cable Extensions - Lengths up to 78 inches (2.0 m) are per­mitted. Length can be shortened in the field as required. See
instructions provided with cable extension for details.

4

Figure 5

Hi-Temp Models:

1) Mounting - Carefully handle the hi-temp. gasket provided

with the assembly. Using it as a template, mark the locations
of the six boltholes on the vessel. Drill six holes at the diam­eter applicable to the attachment method being used (i.e.
tapped holes or clearance holes for bolt/nut combination).
For example, drill six clearance holes at 11/32 inch (9 mm)
diameter for use with 5/16" bolts. The bolts may be secured
by tack welding the bolt heads to the vessel, or by an adjoin­ing nut. Cut a hole (suggested size 2-5 inches (50-125 mm))
centered within the bolt circle to allow the paddle when
attached to the bin monitor to fit within the bin. Attach gasket
and hi-temp. paddle unit to the vessel positioning the conduit
entrance in a manner, which restricts moisture infiltration.

2) Extensions/Guards - Use of extensions are permissible on
Hi-Temp units also. (See Extension/Guard Installation sec­tion). Installing guards on Hi-Temp models requires in-field
modifications. Consult Omega for guidance.

Effective Cooling- The Hi-T

3)

ging pipe, which thermally insulates (via lag pipe material and
physical separation) the internal bin temperature from the
paddle unit thereby protecting its critical components. This
technique is very effective but is dependent on careful con­sideration of ambient air temperature surrounding paddle unit,
thermal conductivity of the material being sensed, and the
actual temperature present at the mounting point. The follow­ing chart is intended to provide general guidance for installa­tion. Each application should be evaluated to insure that the
rated temperature of the electronics is not exceeded. In addi­tion, an air connection is provided on the lagged pipe to fur­ther increase the cooling capacity of the system. When appli­cable, connect airline to 1/2" coupling provided on Hi-Temp.
model using only the recommended air pressure, which must
exceed the bin pressure to be effective. The air should be
clean and dry and is required to be continually supplied to the

emp. model to assure cooling.

Hi-T

Internal Temp. Model Air Required CFM

< 250˚F (121˚C) Standard none N/A
250-500˚F (150-260˚C) Hi-Temp none N/A
500-750˚F (260-400˚C) Hi-Temp 0.5 psig 2.14

emp. model includes a steel lag-

ELECTRICAL INSTALLATION

1) Hazardous Location Precautions - (See Safety and
Specifications sections of this manual before starting electri­call installation.) Observe all government regulations
regarding equipment in hazardous locations. In particular, for

approved explosion-proof products, install a conduit

CSA
seal fitting within 2 inches (50 mm) of the rotary paddle bin
monitor. On all models ensure power is disconnected when­ever the cover is removed and upon completion ensure cover
is completely re-attached.

2) Factory Wiring - The LVD-800 Series motor leads are
prewired to the PCB at the designations labeled "M1" and
"M2". DO NOT alter or make additional external connection
to these terminals. Doing so will likely cause damage to the
LVD-800 Series.

3) Permanently Connected Equipment - Disconnecting
devices shall be included in the system installation. In instal­lations were multiple circuits are used, individual disconnects
are required. The disconnects shall be within close proximity
of the equipment, accessible to operators, and marked appro­priately as the disconnect for the associated circuit. Assure
the disconnect ratings are appropriately sized for the circuit
protected (See Specifications).

4) Circuit Separation - Since the LVD-800 single wiring com­partment can not absolutely protect against physical contact
between multiple circuits, it is required that all wiring used
must have an insulation rating of 300v minimum, and a tem­perature rating of 176˚F (80˚C) minimum.

5) Protective Earthing - Each LVD-800 is provided with a
"protective conductor terminal" which shall be terminated
to the local earth ground potential to eliminate shock hazard.
Select wire size that can carry in excess of the sum of all cir­cuit's maximum amperage.

6) Power Input - Verify the intended voltage supply is com­patible with the voltage configuration indicated on the elec­tronics and the external nameplate. Connect power as shown
in Figure 6. The 24 VAC/DC model must be supplied by a
SELV source. Observe polarity when using a VDC source.

7) Sense Output Contacts - The LVD-800 is equipped with a
set of isolated contacts (SPDT) which indicates whether or
not material is being detected within the vessel (See Figures
6-8). This output is also influenced by the selection of the
"fail-safe" switch as described in the "Setup" section of this
manual. The designations on the circuit board relate to the
contact status when the relay is de-energized (e.g. the mate­rial is "not" sensed and the fail-safe switch is in the "low"
mode).

8) Fault Output Contacts - The LVD-800 is equipped with a
set of isolated contacts (SPDT) that indicates whether or not
the unit's self-diagnostics detected successful operation (See
Figures 6-8). The designations on the circuit board relate to
the contact status when the relay is de-energized (e.g. the
power is removed or when an internal error is detected). In
normal operation, the "fault" relay will be energized resulting
in a closed "normally open" contact, and an open "normally
closed" contact. This output can be wired in tandem with the
Sense Output Contacts to provide an output that combines
the material sense and fault detection on a single wire set.

5

Figure 6

SETUP

Sensitivity (Paddle Selection)
Paddle selection determines the sensitivity of the LVD-800
Series.
that the paddle being used for the application corresponds with
the recommendations found in the Material Characteristics
Guide.

Status LEDs (See Figure 6)
Ordinary location models have LEDs located on the circuit board
which are also visible externally through the lens on the center of
the cover. Hazardous models’ LEDs are not viewable externally.

1) Green-flash - "Initialization" in process. For 30 seconds

2) Green-steady - "No material is being sensed" and self-diag-

3) Red-steady - "Material is being sensed" and that self-diag-

4) Red-flash - A "fault" has been detected in the self-diagnos-

There is no sensitivity adjustment within the unit. Insure

(max) after power is applied, the green LED will flash while
self-diagnostics is performed. The "sense" output will indicate
if material is sensed (Note: influenced by "fail-safe" switch
setting). The "fault" output will remain "de-energized".

nostics has passed. The "sense" output will indicate no-mate­rial-sensed (Note: influenced by "fail-safe" switch setting).
The "fault" output will be "energized".

nostics has passed. The "sense" output will indicate material­sensed (Note: influenced by "fail-safe" switch setting). The
"fault" output will be "energized".

tics. The "sense" output will default to the no-material sensed
state (Note: influenced by "fail-safe" switch setting). The
"fault" output will be "de-energized".

Figure 7

Fail-Safe (See Figure 8)

The "fail-safe" switch setting only influences the "sense" output
(never affects the "fault" output). Generally the "fail-safe" switch
is set so in the event of a power failure, the "sense" output will
default to the application’s critical state condition.

1) High Fail-Safe - The "sense" output will de-energize when
material is sensed at high level or with power loss.

2) Low Fail-Safe - The "sense" output will de-energize when
material is below low level or with power loss.

Designations on the electronics refer to the relay contact status
when no material is sensed and the "low" fail-safe is selected
(Relay is de-energized). Contacts are reversed when no materi­al is sensed and high fail-safe is selected (Relay is energized).

Figure 8

6

TROUBLESHOOTING MAINTENANCE

PROBLEM:

CAUSE/SOLUTION:

1) Verify electrical power is connected to the proper termina-

2) Verify motor leads (and only the motor leads) are con-

3) Verify voltage between the M1 and M2 positions. The

4) Verify clutch operation by manually rotating paddle until

5) Verify gap between ring magnet and small encoder PCB.

PROBLEM: The paddle does not rotate when material is

CAUSE/SOLUTION:

1) Verify condition of sensitivity spring. It should not be cut,

2) Verify status of material around shaft and hub of rotary

3) Verify if drive shaft is free to rotate by manually twisting

The LVD-800 Series indicates "fault" via its
relay output and red flashing LED

tions and that it is the proper voltage as depicted on the
cover.

nected to the terminal block locations M1 and M2.

voltage should be 115VAC for 115VAC models, 230VAC
for 230VAC models, and 6VAC for 24VDC/AC models. If
correct voltage is present, motor should rotate. Replace
motor if necessary.

motor mounting plate reaches its stops. Replace clutch
if manual rotation can not cause motor mounting plate to
reach stops.

Gap to be roughly 1/16". Significant misalignment will
require factory evaluation and repair.

absent and the sensor is in "sense" mode

broken or excessively stretched to the point that is loses
its ability to retract motor to "no sense" condition.
Replace if necessary.

paddle bin monitor. Excessive buildup may restrict shaft
from returning to "no sense" condition. Clean material
buildup.

paddle. If rotation is restricted, replace the outer seal
and the two internal bearings.

Fuse Replacement

The fuses incorporated into the LVD-800 PCBs are intended for
factory replacement only
return of L

Cleaning Requirements

The hazardous and environmental protection techniques are
functional only when the cover is completely installed on to the
housing. If necessary, clean the cover/housing threads to per­mit complete thread engagement. Do not alter the threads and
ensure O-ring is in place and free of contaminants.

Motor Replacement: (See Figure 9)

1) Disconnect power source from SafePoint.

2) Disconnect motor leads that protrude from center of PCB

3) Remove the four screws securing the PCB to the chassis.

4) Remove the two screws holding the motor to the plastic

5) Install new motor and retain with two screws.

6) Pass the motor leads through the grommet in the center of

7) Fasten motors leads to "M1" and "M2" terminals on the PCB.

8) Reconnect the power source to the LVD-800.

VD-800, or for additional technical information.

and attach to "M1" and "M2" terminals.

Pull motor leads through the grommet in the PCB. Leave
power and output connections in place and drape the PCB
over the side of the housing so the motor is completely
accessible.

mounting/actuator plate.

the PCB. Re-attach PCB to the chassis with the four
screws.

Pull all excess wire up through the grommet on the PCB.

. If failure occurs, consult Omega for

PROBLEM: The paddle rotates but material is not sensed

when the paddle is covered.

CAUSE/SOLUTION:

1) Verify that the paddle being used in the application fol-

lows the guidelines outlined in the Material
Characteristics Guide. Change paddle to one capable of
sensing lighter material.

2) Verify that motor mounting plate rotates freely between
its two mechanical stops. Insure spring extends uniform-

without binding. Replace spring if necessary

ly

3) Verify gap between motor mounting plate and small
encoder PCB. Gap to be roughly 1/16". Significant mis­alignment will require factory evaluation and repair.

.

7

Figure 9

DIMENSIONS

MECHANICALS

ARE SHOWN IN INCHES WITH MILLIMETER EQUIVALENT IN BRACKETS

Paddles

Mounting Plate

Flexible coupling

Extensions and guards

8

SAFETY

General:

General Safety

CAUTION:

to ensure proper operation of the equipment and safety of operating
personnel. Use of equipment not specified herein, may impair protec­tion provided by equipment. The use of this symbol is used throughout
manual to highlight important safety issues.

Certain LVD-800 bin monitors are powered with HIGH VOLTAGE. No
operator serviceable parts are inside.
by qualified personnel. Each
conductor terminal" which shall be terminated to earth ground poten­tial (see Electrical Installation). This product's design complies with
EN61010-1 installation category II and pollution degree 2.

Certain LVD-800 bin monitors can be used in Hazardous Locations
(See specifications). These models shall only be used in applications
covered by stated ratings or those considered non-hazardous. Failure
to comply could result in damage to personnel and property. The fol­lowing must be maintained to assure safe operation:

Electromagnetic Compatibility (EMC)
The
ed below. The
mercial environments. Compliance to the EMC standards was demon­strated using the following installation methods.

It is essential that all instructions in this manual be followed

Electrical Shock Caution:

All servicing is to be performed

LVD-800 is provided with a "protective

Hazardous Location Caution

1) Enclosure integrity - The LVD-800 is manufactured from alu-

minum and stainless steel with nitrile rubber seals. The user or
installer should consider the performance of these materials
with regard to attack by aggressive substances that may be
present in a hazardous location. The dimensions of the hou­sing, cover or drive-shaft shall not be altered.

2) Maintenance - Power to all circuits must be disconnected
before conducting any investigation, setup or maintenance.

LVD-800 was tested and found to comply with the standards list-

LVD-800 should not be used in the residential or com-

1) LVD-800 enclosure was connected to protective earth ground.

2) No specific wiring convention was used to supply power or to

retrieve output signal from the

LVD-800.

Power Requirements: 115 VAC (+/- 15%); 9 VA; 50/60 Hz

Altitude: 6562 ft (2000 m) max
Relative Humidity: Suitable for outdoors
Installation Category: II
Pollution Degree: 4 (Reduced to 2 via enclosure)
Ambient Operating Temp: -40˚F (-40˚C) to +150˚F (65˚C)

*Internal Bin Temp:

Conduit Connection: Two(2) 3/4” NPT
Outputs:

Maximum Pressure: 30 PSI (2 bar)
Sensitivity: 5 lb./ft

Indicators:

Housing: Die cast alum, NEMA 4, IP66
Housing Finish: Powder coating
Mounting Connection: 1-1/4" NPT
Weight: Approx. 8-1/2 lb. (3.9 kg)

Materials of construction/accessories:

Flexible Couplings: 304 stainless steel
Mounting Plates: Carbon steel or 304 stainless steel
All Paddles except Ex-Flex: 304 SS
Ex-Flex Belt: 304 SS coupling, rubber/fabric blend belt
Flexible Cable Extension: 304 SS 1/4” diameter

Listings/Approvals: CSA

*Influenced by mounting, material thermal conductivity and ambient temp.

SPECIFICATIONS

230 VAC (+/- 15%); 9 VA; 50/60 Hz
24 VAC/DC (+/- 15%); 11 VA

Standard Unit: to +250˚F (+121˚C)
Hi-Temp Unit: to +750˚F (+399˚C)

Material Sense: One SPDT; 5A @ 250 VAC, 30 VDC max
Unit Status (Fault): One SPDT; 5A @ 250 VAC, 30 VDC max

3

(80 kg/m3)minimum material density
(when using large 3-vane paddle)
Red and green high intensity LEDs indicate
material sense and unit status conditions
(Ordinary Location unit only)

: Ordinary Locations; Class I, Div. 1&2,

US/C

Groups C, D; Class II, Div. 1&2, Groups E, F, G
CE Mark

EMC Emissions:

Meets EN 61326-1 Electrical Equipment for Control Use, EMC

EN 55011 Radiated and conducted emissions

EN 61000-3 Fluctuations/Flicker

Meets FCC Part 15B: RF Devices, Unintentional Radiators

CISPR 1

EMC Immunity:

Meets EN 61326-1 Electrical Equipment for Control Use, EMC

IEC 1000-4-2
IEC 1000-4-3 RF radiated EM fields (industrial)
IEC 1000-4-4 Electrical fast transients (industrial)
IEC 1000-4-5
IEC 1000-4-6
IEC 1000-4-8
IEC 1000-4-11 Source voltage deviation

(Class A- industrial)

Radiated and conducted emissions

1

(Class A- industrial)

Electrostatic discharge (industrial)

Electrical surges (industrial)
RF conducted EM energy (industrial)
Power frequency magnetic fields (industrial)

U.S. Patent 6,696,965 B2

9

WARRANTY/DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a
period of
grace period to the normal
ensures that OMEGA’s customers receive maximum coverage on each product.

If the unit malfunctions, it must be returned to the factory for evaluation. OMEGA’s Customer Service
Department will issue an Authorized Return (AR) number immediately upon phone or written request.
Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no
charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, includ­ing but not limited to mishandling, improper interfacing, operation outside of design limits,
improper repair, or unauthorized modification. This WARRANTY is VOID if the unit shows evidence of
having been tampered with or shows evidence of having been damaged as a result of excessive corrosion;
or current, heat, moisture or vibration; improper specification; misapplication; misuse or other operating
conditions outside of OMEGA’s control. Components in which wear is not warranted, include but are not
limited to contact points, fuses, and triacs.

OMEGA is pleased to offer suggestions on the use of its various products. However,
OMEGA neither assumes responsibility for any omissions or errors nor assumes liability for any
damages that result from the use of its products in accordance with information provided by
OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by the
company will be as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR
REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF
TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF
LIABILITY: The remedies of purchaser set forth herein are exclusive, and the total liability of
OMEGA with respect to this order, whether based on contract, warranty, negligence,
indemnification, strict liability or otherwise, shall not exceed the purchase price of the
component upon which liability is based. In no event shall OMEGA be liable for
consequential, incidental or special damages.

CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic
Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical
applications or used on humans. Should any Product(s) be used in or with any nuclear installation or
activity, medical application, used on humans, or misused in any way, OMEGA assumes no responsibility
as set forth in our basic WARRANTY/DISCLAIMER language, and, additionally, purchaser will indemnify
OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the
Product(s) in such a manner.

13 months fr

om date of purchase. OMEGA’s WARRANTY adds an additional one (1) month

one (1) year product warranty to cover handling and shipping time. This

RETURN REQUESTS/INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE
RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN
(AR) NUMBER FROM OMEGA’S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID
PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return

espondence.

package and on any cor
The pur

chaser is r

breakage in transit.

FOR

WARRANTY RETURNS, please have the

following infor

mation available BEFORE

contacting OMEGA:

chase Order number under which the prod-

Pur

1.
uct was PURCHASED,

2. Model and serial number of the product under
warranty, and

3. Repair instructions and/or specific problems
relative to the product.

s policy is to make r

OMEGA
customers the latest in technology and engineering.

OMEGA is a registered trademark of OMEGA ENGINEERING, INC.
© Copyright 2005 OMEGA ENGINEERING, INC. All rights r

duced, translated, or r
written consent of OMEGA ENGINEERING, INC.

’

r

esponsible for shipping char

ges, freight, insurance and proper packaging to prevent

FOR NON-W
for cur
information available BEFORE contacting OMEGA:

1. Purchase Order number to cover the COST
of the repair,

2. Model and serial number of the product, and

3. Repair instructions and/or specific problems
relative to the product.

unning changes, not model changes, whenever an impr

ved. This document may not be copied, photocopied,

educed to any electr

onic medium or machine-r

eser

ARRANTY

ent repair charges. Have the following

r

ovement is possible. This af

eadable form, in whole or in part, without the prior

REP

AIRS,

consult OMEGA

for

ds our

epr

r

-

o

10

Where Do I Find Everything I Need for

Process Measurement and Control?

OMEGA…Of Course!

Shop online at omega.com

TEMPERATURE

MU

Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies

MU

Wire: Thermocouple, RTD & Thermistor

MU

Calibrators & Ice Point References

MU

Recorders, Controllers & Process Monitors

MU

Infrared Pyrometers

PRESSURE, STRAIN AND FORCE

MU

Transducers & Strain Gages

MU

Load Cells & Pressure Gages

MU

Displacement Transducers

MU

Instrumentation & Accessories

FLOW/LEVEL

MU

Rotameters, Gas Mass Flowmeters & Flow Computers

MU

Air Velocity Indicators

MU

Turbine/Paddlewheel Systems

MU

Totalizers & Batch Controllers

pH/CONDUCTIVITY

MU

pH Electrodes, Testers & Accessories

MU

Benchtop/Laboratory Meters

MU

Controllers, Calibrators, Simulators & Pumps

MU

Industrial pH & Conductivity Equipment

DATA ACQUISITION

MU

Data Acquisition & Engineering Software

MU

Communications-Based Acquisition Systems

MU

Plug-in Cards for Apple, IBM & Compatibles

MU

Datalogging Systems

MU

Recorders, Printers & Plotters

HEATERS

MU

Heating Cable

U

M

Cartridge & Strip Heaters

MU

Immersion & Band Heaters

MU

Flexible Heaters

MU

Laboratory Heaters

ENVIRONMENTAL
MONITORING AND CONTROL

U

M

Metering & Control Instrumentation

U

M

Refractometers

MU

Pumps & Tubing

MU

, Soil & W

Air

MU

Industrial Water & Wastewater Treatment

MU

pH, Conductivity & Dissolved Oxygen Instr

ater Monitors

uments

M-4170/0405
