User ’s Guide

LV-510 Series

Single Station Vertical Float

WARRANTY/DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a

period of 13 months from date of purchase. OMEGA Warranty adds an additional one (1) month grace

period to the normal one (1) year product warranty to cover handling and shipping time. This ensures

that OMEGA’s customers receive maximum coverage on each product.

If the unit should malfunction, it must be returned to the factory for evaluation. OMEGA’s Customer Service

Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon

examination by OMEGA, if the unit is found to be defective it will be repaired or replaced at no charge.

OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not

limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unautho-

rized modification. This WARRANTY is VOID if the unit shows evidence of having been tampered with or

shows evidence of being damaged as a result of excessive corrosion; or current, heat, moisture or vibration;

improper specification; misapplication; misuse or other operating conditions outside of OMEGA’s control.

Components which wear are not warranted, including but not limited to contact points, fuses, and triacs.

OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA neither

assumes responsibility for any omissions or errors nor assumes liability for any damages that result

from the use of its products in accordance with information provided by OMEGA, either verbal or writ-

ten. OMEGA warrants only that the parts manufactured by it will be as specified and free of defects.

OMEGA MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATS0EVER,

EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY

WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DIS-

CLAIMED. LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exclusive and the

total liability of OMEGA with respect to this order, whether based on contract, warranty, negligence,

indemnification, strict liability or otherwise, shall not exceed the purchase price of the component

upon which liability is based. In no event shall OMEGA be liable for consequential, incidental or spe-

cial damages.

CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic

Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical

applications or used on humans. Should any Product(s) be used in or with any nuclear installation or activity,

medical application, used on humans, or misused in any way, OMEGAassumes no responsibility as set forth

in our basic WARRANTY/ DISCLAIMER language, and additionally, purchaser will indemnify OMEGA and

hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in

such a manner.

RETURN REQUESTS / INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service

Department. BEFORE RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST

OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FROM OMEGA’S CUSTOMER SERVICE

DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned AR number

should then be marked on the outside of the return package and on any correspondence.

The purchaser is responsible for shipping charges, freight, insurance and proper packaging

to prevent breakage in transit.

FOR WARRANTY RETURNS, please have

the following information available BEFORE

contacting OMEGA:

1. P.O. number under which the product

was PURCHASED,

2. Model and serial number of the product

under warranty, and

3. Repair instructions and/or specific

problems relative to the product.

FOR NON-WARRANTY REPAIRS,

consult

OMEGA for current repair charges. Have

the following information available

BEFORE contacting OMEGA:

1. P.O. number to cover the COST

of the repair,

2. Model and serial number of product, and

3. Repair instructions and/or specific

problems relative to the product.

OMEGA’s policy is to make running changes, not model changes, whenever an improvement is possible.

This affords our customers the latest in technology and engineering.

OMEGA is a registered trademark of OMEGA ENGINEERING, INC.

© Copyright 1996 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied,

photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or

in part, without prior written consent of OMEGA ENGINEERING, INC.

USA

MADE

IN

Servicing North America:

USA: One Omega Drive, Box 4047

ISO 9001 Certified Stamford, CT 06907-0047

Tel: [phone] FAX: [phone]

e-mail: [e-mail]

Canada: 976 Bergar

Laval (Quebec) H7L 5A1

Tel: [phone] FAX: [phone]

e-mail: [e-mail]

For immediate technical or application assistance:

USA and Canada: Sales Service: 1-800-826-6342 / 1-800-TC-OMEGA

SM

Customer Service: 1-800-622-2378 / 1-800-622-BEST

SM

Engineering Service: 1-800-872-9436 / 1-800-USA-WHEN

SM

TELEX: 996404 EASYLINK: 62968934 CABLE: OMEGA

Mexico and

Latin America:

Tel: (95) 800-TC-OMEGA

SM

FAX: [phone]

En Espan˜ol: [phone] ext: 2203 e-mail: [e-mail]

Servicing Europe:

Benelux: Postbus 8034, 1180 LAAmstelveen, The Netherlands

Tel: [phone] FAX: [phone]

Toll Free in Benelux: 06 0993344

e-mail: [e-mail]

Czech Republic: Ostravska 767, 733 01 Karvina

Tel: [phone] FAX: [phone]

e-mail: [e-mail]

France: 9, rue Denis Papin, 78190 Trappes

Tel: [phone] FAX: [phone]

Toll Free in France: 0800-4-06342

e-mail: [e-mail]

Germany/Austria: Daimlerstrasse 26, D-75392 Deckenpfronn, Germany

Tel: [phone] FAX: [phone]

Toll Free in Germany: 0130 11 21 66

e-mail: [e-mail]

United Kingdom: 25 Swannington Road, P.O. Box 7, Omega Drive,

ISO 9002 Certified Broughton Astley, Leicestershire, Irlam, Manchester,

LE9 6TU, England M44 5EX, England

Tel: [phone] Tel: [phone]

FAX: [phone] FAX: [phone]

Toll Free in England: 0800-488-488

e-mail: [e-mail]

OMEGAnet

SM

On-Line Service Internet e-mail

http://www.omega.com [e-mail]

It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly

pursuing certification of its products to the European New Approach Directives. OMEGA will add the CE mark to every

appropriate device upon certification.

The information contained in this document is believed to be correct but OMEGA Engineering, Inc. accepts no liability for any errors it con-

tains, and reserves the right to alter specifications without notice.

WARNING: These products are not designed for use in, and should not be used for, patient connected applications.

OMEGA

®

TM

omega.com

Step One

SPECIFICATIONS

Specifications:

Accuracy: ± 5 mm in water
Repeatability: ± 2 mm in water
Extreme orientation: ±20° from vertical
Specific Gravity Range: 0.8 - 1.2
Reed type: Dry contact, SPST
Reed rating: 120 VAC, 120 VDC @ 50 VA

(CE: 30 Vrms and 42.2 Vpeak or 60 Vdc)
Reed output: NO or NC
Temperature range: F: -40° to 194°

C: -40° to 90°
Pressure: 10 psi (0.7 bar) max.
Sensor material: Polypropylene (PP) or

Polyvinylidene Fluoride (PVDF)
Mounting threads: 1/8" NPT (1/8” BSP)
Cable type: 2 ft. (61 cm), 2-wire
CE compliance: EN 50082-2 immunity

EN 55011 emission

Part Number Information:

Part # Material Thread

LV-510 PP 1/8" NPT
LV-511 PVDF 1/8" NPT

Float Orientation:

Orientation Mark on Top of the FLoat

Switch Closed Switch Open

Switch Open Switch Closed

Orientation Mark on Top of the FLoat

Dimensions:

About This Manual:

PLEASE READ THE ENTIRE INSTRUCTION SHEET PRIOR TO
INSTALLING OR USING THIS PRODUCT. This Instruction sheet
includes information on all models of Vertical Mini-Floats from Omega:
LV-510 series. Please refer to the part number located on the sensor label
to verify the exact model which you have purchased.

User's Responsibility for Safety:

Omega manufactures a wide range of liquid level sensors and technolo­gies. While each of these sensors is designed to operate in a wide variety
of applications, it is the user's responsibility to select a sensor model that
is appropriate for the application, install it properly, perform tests of the
installed system, and maintain all components. The failure to do so could
result in property damage or serious injury.

Proper Installation and Handling:

Because this is an electrically operated device, only properly trained staff
should install and/or repair this product. Use a proper sealant with all instal­lations. Never overtighten the sensor within the fitting, beyond being hand
tight. Always check for leaks prior to system startup.

Material Compatibility:

The LV-510 series is available in two different wetted materials. Models LV­510 are made of Polypropylene (PP, a polyolefin). Models LV-511 are made
of Polyvinylodene Fluoride (PVDF). A Nylon C-ring is also used to secure
the float. Make sure that the model which you have selected is compatible
with the application liquids. T o determine the chemical compatibility between
the sensor and its application liquids, refer to the Compass Corrosion Guide,
available from Compass Publications (phone [phone]).

Wiring and Electrical:

The Vertical Mini-Float features a two-wire design with a SPST dry con­tact closure. Electrical wiring of the sensor should be performed in accor­dance with all applicable national, state, and local codes.

Normally Open/Normally Closed:

The orientation position of the float determines whether the switch is Open
or Closed. The top of the float has two concentric circles on each edge of the
cylinder. When the float is orientated up, the switch is open when the float is
away from the threads and is closed when the float is next to the threads.
When the float is orientated down, the switch is closed when the float is
away from the threads and is open when the float is next to the threads.

Flammable, Explosive and Hazardous Applications:

The LV-510 series should not be used within flammable or explosive applica­tions. In hazardous applications, use redundant measurement and control points,
each having a different sensing technology . Refer to the National Electric Code
(NEC) for all applicable installation requirements in hazardous locations.

About Single Station Sensing

Omega's L V-510 series use a magnetic float which rides up and down a stem
containing the reed switch. The only moving part is the float. No bearings,
packing glands, bellows or electronic gadgets are used. The Vertical Mini­Floats are built rugged to resist shock and vibration. The LV-510 series uti­lize a low cost, flexible design which allows for vertical mounting at the top
or bottom of a tank. The Vertical Mini-Floats can be mounted up, down or
up to 20 degrees off vertical.
