Omega Products HMI06BE User Manual

HMi OPERATOR INTERFACE
Starts at
$
410
l True Analog Touchscreen l Retentive Internal Data Storage l Real Time Trending l Trend Stored Data l Alarming and Alarm Storage l Alarm Frequency l Event Storage (History) l USB Programming l USB Memory Storage l USB Printer l Add I/O l Macro Programming l Multi-Language l Recipe Storage l Auto-Scale Application
from 10 to 4"
l On-Line Simulation l Off-Line Simulation l 10-Level Password Protection
Today’s marketplace is all about how you interface—with customers, suppliers and your machinery. Omega proudly offers a new and easy way to interface, HMi. Available in 4, 6, 8 and 10" models, HMi is a true analog touch screen operator interface with programmable function buttons for the most robust applications. With the ability to store recipes, historical and alarm data, or transfer that data to a USB memory stick, using HMi makes interfacing with your machinery easier than ever.
HMI10CE, 10", $2315, shown smaller than actual size.
HMI08CE, 8",
$1615, shown
smaller than
actual size.
HMI06CE, 6", $875, shown smaller than actual size.
HMI04BU, 4",
$410, shown smaller than
actual size.
Your Application. Your HMi.
With features that allow you to customize the perfect operator interface for your application, HMi is the interface solution you want it to be. HMi models are available in either a blue mode, grayscale or color screen versions. It’s an interface solution designed
to complement your application needs. Because one application doesn’t fit all, you can scale your applications to any size HMi device in a few keystrokes—from 4 to 6" to 8 to 10" and back. If you decide to upgrade or downsize your operator interface, the click of a button resizes your screen image to match another screen size. Once
B-1
you see the features of HMi, you’ll agree it’s the perfect interface device for machines built to different specifications and size requirements. With the ever present need to be connected to your machinery and processes, communications are more important than ever. So, with an expansive
driver list, 3 serial communication ports,
HMi is the answer for communicating on virtually any network, including over 20 brands of PLCs currently on the market. An expansion slot on the back of the unit connects to a Ethernet network or even I/O modules, allowing you to do more with your operator interface than ever before.
HMi simplifies configuring application parameters with features and software that provide added capabilities and make monitoring your system intuitive.
HMi stores your entire application, including images, so editing won’t require original source files. If your computer fails or years from now you need to edit the application, there’s no need to track down old original source files. HMi is the source. Flexibility,
SPECIFICATIONS
MODEL HMI04BU HMI06BE HMI06CE HMI08CE HMI10CE
Display Type STN STN STN TFT-LCD Display Color 8 Blues 8 Blues 256 Colors 65536 Colors Screen Pixels 320 x 240 320 x 240 640 x 480 Back-Light Life About 10,000 About 30,000
Display Size 78.8 x 59.6 mm (3.8") 118.2 x 89.4 mm (5.7") Operation System Real Time OS MCU 32-bit RISC Micro-controller/206.4 MHz Memory
Program 1M 3M 3M 7M 7M History 120K 360K 360K 360K 360K Recipe 64K Alarm 4K 16K 16K 16K 16K
Data Registers (Memory)
Volatile 64K 64K 64K 64K 64K Non-Volatile 1K 1K 1K 1K 1K
Backup Memory (Bytes)
Ext. Memory
Extension Interface USB for Download
(USB Client) USB for Data Storage/
Printer (USB Host) LCD Module (Back Light) LED CCFL CCFL CCFL 2CCFL Safety Approval (Water-
proof for Front Panel) Operating Temp. 0 to 50°C (32 to 122°F) Storage Temp. -20 to 60°C (-4 to 140°F) Ambient Humidity 10 to 90% RH (0 to 40°C), 10 to 55% RH (41 to 50°C) Dimensions: mm (in) 140.8 x 104.8 x 44.8 184.1 x 144.1 x 47
(W x H x D) (5.54 x 4.13 x 1.76) (7.25 x 5.67 x 1.85) Weight: kg (lb) 0.315 (0.69) 0.768 (1.69) 1.147 (2.52) 1.721 (3.79) Backup Battery 3 V Lithium Battery CR2032 x 1/Battery Life: 5 Years Buzzer 85dB Operation Voltage DC +24V (10 to 20%) (Please use isolated power supply) Wattage 2.64 7.2 7.2 14 15
1
Not applicable for HMI08CE and HMI10CE.
2
Recipe memory uses program memory.
SM Card ⻬⻬ ⻬⻬ USB Disk
plus the security of password protection, makes HMi the perfect operator interface for any user. A feature called Picture Bank uploads/downloads images from HMi to a personal computer. Save pictures and use them in other documents, and easily upload pictures and applications to new HMi units.
Its easy-to-use macro ability, with the strength to handle even the most complicated applications, allows HMi to
From simple math, storing and manipulating trends, data, and communications, to sending data from one PLC to another, macros make HMi the easiest interface on the market.
help you manage your machine more efficiently than ever.
hours at 25°C
2
128K 128K 128K 128K
About 50,000 hours at 25°C
162.2 x 121.7 mm (8.0")
hours at 25°C
215.2 x 162.4 mm (104")
128K 512K 512K
⻬⻬
⻬⻬ ⻬⻬
1 Client Ver. 1.1
⻬⻬
IP65/NEMA 4X/CE/UL/cUL/C-Tick
243.1 x 178.1 x 52.4 297.1 x 222.1 x 51.1 (9.57 x 7.01 x 2.06) (11.70 x 8.74 x 2.01)
1
B-4
HMi04
184.1 (7.25)
F1
39.0
(1.54)
144.1 (5.67)
6.1
(0.24)
Ty p .
132.4
(5.21)
172.4 (6.79)
F2
F3
F4
SYS
POWER
Cut-Out Dimensions
243.1 (9.57)
F1
44.4
(1.75)
178.1 (7.01)
Typ.
166.4 (6.55)
231.4
(9.11)
Cut-Out Dimensions
F2
F3
F4
F5
F6
SYS
POWER
297.1
(11.70)
F1
43.1
(1.70)
222.1
(8.74)
6.1
(0.24)
3.0 (0.12) R Ty p .
210.2 (8.27)
285.2
(11.22)
Cut-Out Dimensions
F2
F3
F4
F5
F6
F7
SYS
POWER
140.8 (5.54)
F1
36.7
(1.44)
104.8 (4.13)
Typ.
91.8
(3.61)
117.8 (4.64)
POWER
Cut-Out Dimensions
F2
F3
F4
SYS
1.6 - 3.0
(0.06 - 0.12)
6.1
(0.24)
1.6 - 3.0
(0.06 - 0.12)
3.0 (0.12) R
3.0 (0.12) R
1.6 - 3.0
(0.06 - 0.12)
1.6 - 3.0
(0.06 - 0.12)
3.0 (0.12) R
HMi06
HMi08CE
HMi10C
Dimensions: mm (in)
To Order (Specify Model Number)
AVAILABLE FOR FAST DELIVERY!
MODEL NO. PRICE DESCRIPTION HMI04BU $410 HMi 4" blue mode touchscreen HMI06BE 565 HMi 6" blue mode with expansion slot HMI06CE 875 HMi 6" color mode with expansion slot HMI08CE 1615 HMi 8" color mode with expansion slot HMI10CE 2315 HMi 10" color mode with expansion slot
Ordering Example: HMI06BE, HMi 6" blue mode with expansion slot, $565.
B-5
HMISOFT PROGRAMMING
SOFTWARE
HMISOFT
$
257
l Simulate an Application
On-Line or Off-Line
l Built-In Picture Library l Create Your Own
Picture Library
l Screen Manager l 70 On-Screen Objects l Easy Object Setup l Monitor All States
of Objects
l Macro Editing l Scale Application
from 10 to 4"
l Upload/Download
Applications Over USB
For use with the HMi series of touchscreens, this software supports all of the features of HMi. This easy to use Windows based software can run on Windows 2000 and XP with a minimum CPU of Pentium III 500 Mhz, 256 MB RAM, 100 MB free hard disk space and mouse.
To Order (Specify Model Number)
MODEL NO. PRICE DESCRIPTION HMISOFT $257 HMi programming software
Ordering Example: HMISOFT, HMi programming software, $257.
AVAILABLE FOR FAST DELIVERY!
B-6
