Omega XW-EDA, XW-ED, XW-ED-PRO, XW-EDA-PRO User guide

Page 1

Discrete I/O Connector (PRO Version Only)

Note: Only PRO versions of the transmier support Discrete

I/O. Opons for these appear in the Output Tab in Omega Sync. Please refer to the User’s Manual for more details on how to congure I/O.

Pin 1 I/O 1

Pin 2 I/O 2

Pin 3 Ground 2

Pin 4 Ground 1

The XW-ED and XW-EDA-PRO versions support 2 Discrete Open Drain Digital Inputs / Outputs on the 4-pin M12 Male connector. To connect an input or output, a standard M12 4-pin cable can be used. Omega also oers an oponal eld installable M12 connector.

Figure 10

Input To use a pin as an input make sure it is set to Acve Low (default) in the Output

Conguraon Tab in Omega Sync. The Input can then be set as Acve High or Low in the Input Tab.

Each pin has an internal pull-up but in order to save power, the internal pull-up is only acve when unit takes a reading.

The state of both pins is always shown on the ZW-REC as the last input. Refer to the following table to decode the input state.

Input 1 Input 0 Reading

Inacve Inacve 0

Inacve Acve 1

Acve Inacve 2

Acve Acve 3

Output

Output opons are set in the Output Conguraon Tab of Omega Sync. Each output can be congured as either Acve High or Acve low.

To use a pin as an output rst set up the Output Opons and assign the output to an Alarm using Omega Sync. Please see the full User’s Manual for an in depth descripon on how to assign the output to an alarm.

What’s Next?

You may now navigate to the ZW-REC webpage. Your XW Transmier and the data it is reading will now appear on the ZW-REC webpage.

For addional informaon on the features of the XW Transmier or the ZW-REC, refer to the following User’s Manuals.

•XW Transmier:

hps://assets.omega.com/manuals/M5745.pdf

• ZW-REC:

hps://assets.omega.com/manuals/M5546.pdf

For long-term data logging and OPC integraon, consider using the Omega Gateway Enterprise soware downloadable at:

hps://www.omega.com/en-us/oeg

XW-ED Input Connector

Frequency Pulse Width

Duty Cycle Counter

Pin 1

Pin 2 Enable Clock B Direcon Input 3 Proc Input 1

Pin 3 Clock Clock A Clock Input 1 Proc Input 2

Pin 4 Reset Reset Reset Input 2 N/C

Pin 5 Shield

Pin 6 NC

Pin 7 GND

Pin 8 3.3V Output

Delay

XW-EDA Input Connector

Thermocouple Voltage Current

Pin 1 TC 2 Negave Input 1 Input 1

Pin 2 TC 1 Posive Input 2 Input 2

Pin 3 TC 1 Negave Ground 2 Ground 2

Pin 4 TC 2 Posive Ground 1 Ground 1

RTD 4 Wire Opon 1 RTD 4 Wire Opon 2

RTD 3 Wire RTD 2 Wire

Up/Down

Counter

Digital

Input

Process

Input

WARRANTY/DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months from date of purchase. OMEGA’s WARRANTY adds an additional one (1) month grace period to the normal one (1) year product warranty to cover handling and shipping time. This ensures that OMEGA’s customers receive maximum coverage on each product. If the unit malfunctions, it must be returned to the factory for evaluation. OMEGA’s Customer Service Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification. This WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence of having been damaged as a result of excessive corrosion; or current, heat, moisture or vibration; improper specification; misapplication; misuse or other operating conditions outside of OMEGA’s control. Components in which wear is not warranted, include but are not limited to contact points, fuses, and triacs.

OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA neither assumes responsibility for any omissions or errors nor assumes liability for any damages that result from the use if its products in accordance with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by the company will be as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exclusive, and the total liability of OMEGA with respect to this order, whether based on contract, warranty, negligence, indemnification, strict liability or otherwise, shall not exceed the purchase price of the component upon which liability is based. In no event shall OMEGA be liable for consequential, incidental or special damages.

CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any Product(s) be used in or with any nuclear installation or activity, medical application, used on humans, or misused in any way, OMEGA assumes no responsibility as set forth in our basic WARRANTY/DISCLAIMER language, and, additionally, purchaser will indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in such a manner.

RETURN REQUESTS/INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FROM OMEGA’S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return package and on any correspondence.

FOR WARRANTY RETURNS, please have the following information available BEFORE contacting OMEGA:

1. Purchase Order number under which the product was PURCHASED,

2. Model and serial number of the product under warranty, and

3. Repair instructions and/or specific problems relative to the product.

OMEGA’s policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest in technology and engineering. OMEGA is a trademark of OMEGA ENGINEERING, INC. © Copyright 2019 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of OMEGA ENGINEERING, INC.

MQS5811/0720

FOR NON-WARRANTY REPAIRS, consult OMEGA for current repair charges. Have the following information available BEFORE contacting OMEGA:

1. Purchase Order number to cover the COST of the repair or calibration,

2. Model and serial number of the

product, and

3. Repair instructions and/or specific problems relative to the product.

XW-ED, XW-ED-PRO, XW-EDA,

XW-EDA-PRO

XW Series Transmitter

omega.com [email protected]

U.S.A. Omega Engineering, Inc. Headquarters: 800 Connecticut Ave. Suite 5N01, Norwalk, CT 06854 Toll-Free: 1-800-826-6342 (USA & Canada only)

Customer Service: 1-800-622-2378 (USA & Canada only) Engineering Service: 1-800-872-9436 (USA & Canada only) Tel: (203) 359-1660 Fax: (203) 359-7700 e-mail: [email protected]

For Other Locations Visit omega.com/worldwide

The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.

Servicing North America:

Page 2

START HERE

Introducon

Use this Quick Start Guide to set up your XW Transmier. For addional informaon on all setup opons, refer to the User’s Manual available on the Omega website.

Transmier Versions Descripon

XW-ED 8-Pin Digital Probes, Timer/Totalizer, Process

XW-ED-PRO

8-Pin Digital Probes, Timer/Totalizer, Process, Discrete I/O

XW-EDA TC, RTD, Process

XW-EDA-PRO TC, RTD, Process, Discrete I/O

Materials

Included with your XW Transmier

•2.4 GHz Antenna

•Mounng Kit

•CR2032 Coin Cell Baery (Pre-Installed)

•2x C-Cell Baeries

•Micro USB Cable

•Quick Start Guide

Addional Materials Needed

•Computer/Laptop with Windows OS

•Omega Sync soware (Downloadable on the Omega website)

•ZW-REC

•Micro USB Cable

Note: A second Micro USB cable is needed to connect the ZW-REC

to your computer.

Safety and Regulatory Compliance

Safety:

EN 61010-1 3rd Edion

EMC:

EN61326-1: 2013

Radio:

EN 301 489-17 V3.3.1 EN 300 328 V2.1.1:2016-11

CE:

The product herewith complies with the essenal requirements and other relevant provisions of the Radio Equipment Direcve 2014/53/EU, the EMC Direcve 2014/30/EU, and the Low Voltage Direcve 2014/35/EU, and carries the CE-Marking accordingly.

Before You Start

To setup your XW Transmier, ensure the Omega Sync soware is downloaded, setup, and running before connuing.

Connecng Your ZW-REC

Before connuing, make sure your ZW-REC is setup. Follow these direcons to ensure your ZW-REC is properly connected.

Note: For a complete guide on how to set up your ZW-REC, refer to

the Quick Start Guide available on the Omega website.

Step 1: Plug in your ZW-REC to your computer with a Micro USB cable. Omega

Sync will then auto-detect the ZW-REC and pull the following informaon from the ZW-REC to ensure proper communicaon between the receiver and the transmier:

•IP Address

•Network Mask

•Gateway

•PAN ID

Note: If the auto-detect feature is unsuccessful, click the

buon on Omega Sync to search for connected devices.

Figure 1

Seng Up Your XW Transmier

Step 1: Connect the antenna to the XW Transmier.

Note: 8-pin digital probes, including Omega Smart Probes, can

be plugged in at this point. Digital I/O or Analog connecons should be made aer the XW Transmier is setup.

Step 2: Remove the pull-tab from the coin cell. See Figure 2.

Step 3: Install the baeries or plug in the oponal AC Adaptor. See Figure 2.

Note: Take note of the baery orientaon of the device as

displayed in Figure 2.

The blue LED will illuminate immediately and begin ashing, indicang the device is on.

Connecng to Omega Sync

Step 1: Ensure the XW Transmier is powered on.

Step 2: Connect the XW Transmier to your computer using a Micro USB cable.

Figure 3

You should now have your ZW-REC and your XW Transmier connected to the computer running Omega Sync. See Figure 4.

Note: Omega Sync will auto detect your XW Transmier. If the

auto-detect feature is unsuccessful, click the buon on Omega Sync to search for connected devices.

Step 2: Omega Sync will detect the Network ID of the connected ZW-REC. See

Figure 5. Click Next to accept network ID.

Note: The default Network ID for the ZW-REC is set to 0. You may

manually enter the Network ID of a dierent ZW-REC if the receiver you wish to connect to is not available.

Step 3: Assign a unique Device ID and a name to your device. Click Next to

proceed. See Figure 6.

Figure 6

Step 4: Review your selecons and click Finish. Record your network ID selecon

on the back of the transmier.

If you are using a Digital or Smart Probe, setup is now complete. Please proceed to the next secon to customize inputs.

Figure 7

Customizing Inputs

Click Inputs from the Conguraon Tabs to begin customizing your transmier. See Figure 8.

Select the desired type from the Input Type drop-down menu. See Figure 8.

Figure 8

The desired Input (Figure 8) and the Conguraon Panel (Figure 9) will appear below the drop down menu once it has been selected.

Note: If your transmier supports mulple inputs, click on the

one you wish to congure.

The following CE Mark is axed to this equipment. The CE declaraon is available at the website listed on the cover page of this quick start guide.

FCC/IC:

Part 15C, Class DTS Internaonal radiator Contains TX FCC ID: TYOJN5168M5 Contains Industry Canada ID IC: 7438A-CYO5168M5

FCC Radiaon Exposure Statement:

This portable equipment with its antenna complies with FCC’s RF radiaon exposure limits set forth for an uncontrolled environment. To maintain compliance, follow the instrucons below:

1. This transmier must not be co-located or operang in conjuncon with any other antenna or transmier.

2. Avoid direct contact to the antenna or keep it to a minimum while using this equipment.

Figure 2

Figure 4

Onboarding the XW Transmier

Step 1: Once the XW Transmier is auto-detected, Omega Sync will guide you

through an Onboarding sequence.

Figure 5

Figure 9

You may use the conguraon panel to customize the available inputs on your XW Transmier. For more details on the inputs available on your XW Transmier, see the User’s Manual available on the Omega website.

Refer to the wiring diagrams in Secon 6 to connect your input.
