Product Contents
+
VRT400 SERIES
HE_OMEGA_VRT400_V.01.indd 1 2013-01-17 오전 11:28:38
IMPORTANT SAFEGUARDS
Please read carefully before using and follow instructions to avoid
injury.
• To protect against risk of electrical shock or re, do not put motor
base, cord, or plug in water and keep them dry at all times.
• Do not disassemble the base. All repairs should be made only by
authorized personnel.
• Check voltage to be sure that the voltage indicated on the name
plate agrees with your voltage.
• Close adult supervision is necessary when appliance is used by or
near children.
• Unplug the power cord from the wall outlet when the appliance is
not in use.
• Do not operate any appliance with a damaged cord/plug, a
malfunctioning unit, or after the unit is dropped or damaged in
any manner.
• The use of attachments not recommended
may cause damage, re, shock, or injury.
• Keep hands and utensils out of unit when motor is running to
event the possibility of severe personal injury or damage to the
pr
appliance.
• Do not attempt to disassemble any attachments while the motor
is running. Lift appliance with two hands (appliance weight
approximately 14 lbs.)
• Do not put any parts into the dishwasher or use hard scouring
powders and hard implements. Exposure to high heat can cause
damage.
HE_OMEGA_VRT400_V.01.indd 2 2013-01-17 오전 11:28:39
IMPORTANT SAFEGUARDS
Additional usage precautions:
• Do not pre-operate before inputting food. Doing so may cause a
normal squeaking noise.
• Do not attempt to juice any hard materials, large seeds (seeds
which can not be swallowed or chewed), pits, ice, or frozen foods.
• If food gets stuck in the feeding tube, do not use anything other
than the recommended pusher.
• Do not use more than 30 minutes continuously (only meant for
household use).
SAVE THESE INSTRUCTIONS
HE_OMEGA_VRT400_V.01.indd 3 2013-01-17 오전 11:28:39
Omega Juicer Manual For Household Use (Warranty Included)
1 Read “Precautions for safe use (Page 4)” carefully and use the appliance properly.
2 Keep the manual within reach anytime and save it for future reference.
3 Check if the voltage indicated on the base of the appliance corresponds to the local voltage before you connect the appliance.
4 Any quality improvements are subject to change without notice.
CONTENTS
Dear Omega Customers
General description and parts names
Specific terms for parts
Precautions for safe use
Warnings and cautions
Slow Juicer assembly
Slow Juicer assembly in detail
How to use the appliance
Juice Cap and Extraction Packing
When the Screw is stopped during operation (How to use [Reverse/REV] button)
Important safeguards in use
Disassembly, cleaning and care
Bowl disassembly and wash
Sterilization and Easy Cleaning System
Spinning Brush disassembly and wash
Spinning Brush assembly
Bowl Packing assembly
Juice Cap Packing assembly
Troubleshooting
Appliance specifications
Warranty
01
02
03
04
05
08
09
10
11
12
13
14
16
17
18
19
20
21
22
23
24
HE_OMEGA_VRT400_V.01.indd 4 2013-01-17 오전 11:28:39
With Omega’s own Slow Squeezing System and the Juice Cap as an additional mixing function, you can easily make personalized juice in rich tastes and flavors in full preserved valuable
nutrients.
1. Much More Nutrients and Taste: Your own personalized juice
Various mixed juice
Not only enjoying single fruit juice but also adding various ingredients to your taste and health, you can simply make
your own Omega juice.
Omega juice as an alternative meal
Make Omega juice as an alternative meal in rich taste and balanced nutrients by mixing banana, corn or boiled
potato, sweet potato and pumpkin etc. supplementing calories.
Omega baby food
Mixing meat and grain as well as vegetables, you can easily make Omega baby food for growth phases.
Soybean milk and soy juice
Unlike the traditional method that you must put boiled beans and water together, adjusting its portion while the Juice
Cap is closed, anyone can easily make soybean milk and soy juice in desired concentration.
2. Much More Convenient and User Friendly
Opening and closing the juice cap, you can adjust the amount of juice as desired without any drops when you pour
juice into a container.
3. Much More Advanced Easy Cleaning System (Page 17)
Unlike the method rinsing under tap, it is easier and simpler with the Juice Cap. Just fill up the bowl with water while
the Juice Cap is closed and then operate the appliance for easy washing.
HE_OMEGA_VRT400_V.01.indd 5 2013-01-17 오전 11:28:39
GENERAL DESCRIPTION AND PARTS NAMES
HOPPER
SQUEEZING SCREW
COARSE STRAINER
FINE STRAINER
SPINNING BRUSH
BOWL
PULP CONTAINER
JUICE CONTAINER
CLEANING BRUSH
PUSHER
BASE
02 l
HE_OMEGA_VRT400_V.01.indd 6 2013-01-17 오전 11:28:40
SPECIFIC TERMS FOR PARTS
<FRONT> <REAR>
1. Hopper front
triangle
2. Bowl triangle
3. Pulp outlet
STRAINER
4. Hopper
rear part
5. Operating
switch
6. Juice outlet
7. Juice cap
8. Power cord
9. Grip
*
COARSE STRAINER
The bigger holes in the strainer produce thicker juice when tender and soft fruits are extracted such as strawberries,
kiwis and tomatoes. It is useful to extract more pulpy juice.
FINE STRAINER
The holes of the strainer are small. Use it when making pure juice with hard fruits, beans or higher fibered vegetables. It is useful to extract clearer juice.
NUMBER OF
ATTACHMENT
1 pusher, 1 hopper, 1 screw, 1 fine strainer, 1 coarse strainer, 1 spinning brush, 1 bowl, 1 base, 1 juice container, 1 pulp container,
1 small cleaning brush, 1 cleaning brush, 1 manual
I 03
HE_OMEGA_VRT400_V.01.indd 7 2013-01-17 오전 11:28:40
PRECAUTIONS FOR SAFE USE
All users of this appliance must read and understand this safety precaution before operating.
WARNING Hazards or unsafe practices which could result in serious personal injury or death.
CAUTION Hazards or unsafe practices which could result in minor personal injury or appliance damage.
SIGN EXAMPLES
This sign indicates contents that may cause risk of a fire or an electrical shock.
Specific warnings are written in the sign.
This sign indicates contents that may cause risk of a fire or an electrical shock.
Specific warning is written in the sign.
This sign indicates prohibited acts.
Specific prohibitions are written around or in the sign.
This sign indicates contents of regulating or directing actions.
Specific instructions are written around or in the sign.
04 l
HE_OMEGA_VRT400_V.01.indd 8 2013-01-17 오전 11:28:41
WARNINGS AND CAUTIONS
WARNING Hazards or unsafe practices which could result in serious personal injury or death.
DO NOT PLUG IN OR UNPLUG WITH WET HANDS.
It may cause an electric shock or an injury.
DO NOT USE OTHER THAN 120V AC.
It may cause an electric shock, a fire or an abnormal performance.
If the voltage is different, it may shorten the life of the motor or cause a failure.
PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A WALL SOCKET.
It may cause an electric shock or a fire.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER,
ITS SERVICE OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
If the power cord is damaged, it may cause an electric shock or a fire.
NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMBLE OR REPAIR BY YOURSELF. DO NOT INSERT FINGERS, FOREIGN SUBSTANCES OR OBJECTS SUCH AS PINS
INTO GAPS OR HOLES IN THE BASE. It may cause a fire, an electric shock or a failure.
For any technical support, contact the authorized local Customer Care Center.
DO NOT MOISTEN THE BASE OR SPLASH WATER ON THE BASE.
Be careful not to let any liquids or other substances get into the switch on the appliance.
DO NOT OPERATE THE SWITCH WITH WET HANDS.
It may cause an electric shock or a fire.
WHEN THE POWER CORD, WIRE WAS BROKEN OR DAMAGED OR THE PLUG-IN
PART BECAME LOOSE, DO NOT OPERATE IT.
It may cause an electric shock, a fire or an injury.
FOR SAFETY, MUST DO GROUNDING CONNECTION. ALSO, DO NOT DO THE
GROUNDING ON GAS PIPE, PLASTIC WATER PIPE, TELEPHONE WIRE, ETC.
It could cause an electric shock, a fire, a malfunction and an explosion.
Be sure to use the socket with ground connection.
l 05
HE_OMEGA_VRT400_V.01.indd 9 2013-01-17 오전 11:28:42
WARNINGS AND CAUTIONS
NEVER DISASSEMBLE BOWL SET DURING OPERATION OR INSERT FINGERS,
FOREIGN OBJECTS SUCH AS FORKS, SPOONS ETC. INTO FEEDING TUBE OR JUICE
OUTLET. It may cause an injury, an accident or a failure.
THIS APPLIANCE IS NOT INTENDED FOR USE BY PERSONS (INCLUDING CHILDREN) WITH
REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK OF EXPERIENCE AND
KNOWLEDGE, UNLESS THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
Children should be supervised to ensure that they do not play with the appliance.
CAUTION Hazards or unsafe practices which could result in minor personal injury or appliance damage.
DO NOT OPERATE WITHOUT LOCKING THE HOPPER PROPERLY.
It may cause an injury or a failure.
WHEN DETECTING A GAS LEAK, DO NOT INSERT THE POWER CORD INTO ITS
SLOT. OPEN THE WINDOW TO VENTILATE FULLY AND IMMEDIATELY.
It may cause an injury or a failure.
NEVER PUT A FINGER, A FORK OR A SPOON ETC. INTO JUICE OUTLET.
It may cause an injury or a failure.
IF SCREW ROTATION IS STOPPED IN NORMAL OPERATION, PRESS [REVERSE/REV]
BUTTON AND HOLD FOR 2~3 SECONDS AND THEN AFTER REVERSE OPERATION IS
COMPLETELY STOPPED, PRESS [ON] BUTTON AGAIN. If such a stop event continues during the
operation, the parts may be damaged and performance may be deteriorated due to overheating in a motor.
When the problem continues, immediately stop the appliance and contact the local Customer Care Center.
DURING THE OPERATION, DO NOT ATTEMPT TO MOVE THE BASE, DISASSEMBLE
THE BOWL SET OR PARTS AND TRY TO LOCK THEM.
It may cause an injury or a failure.
Any act of event needed, switch off first and unplug the power cord.
06 l
HE_OMEGA_VRT400_V.01.indd 10 2013-01-17 오전 11:28:43
30minute
WARNINGS AND CAUTIONS
WHEN USING THE APPLIANCE, BE CAREFUL FOR A NECKTIE, LONG NECKLACE,
SCARF ETC. NOT TO BE ENTANGLED INTO FEEDING TUBE.
It may cause an injury, a failure or a breakage.
PLACE THE APPLIANCE ON A FLAT AND STABLE SURFACE.
It may cause an injury or a failure.
DO NOT OPERATE THE APPLIANCE FOR MORE THAN 30 MINUTES AT A TIME.
It may cause a motor failure due to overheating.
Cool it down sufficiently about 5 minutes and operate it again.
WHEN PLACING INGREDIENTS INTO THE FEEDING TUBE, ONLY USE THE PUSHER
PROVIDED.
It may cause an injury or a failure.
DO NOT ALLOW A SEVERE SHOCK TO THE APPLIANCE OR DROP IT.
It may cause an electric shock, a fire or damage.
IF THE APPLIANCE GIVES OFF AN UNPLEASANT SMELL OR EXCESSIVE HEATING,
SMOKE, STOP USING IMMEDIATELY AND CONTACT THE LOCAL CUSTOMER CARE
CENTER.
When using a new appliance, it gives off a smell and the smell disappears naturally over time.
ALWAYS UNPLUG THE APPLIANCE AFTER USE.
WHEN UNPLUGGING THE POWER CORD, MAKE SURE TO HOLD THE POWER CORD.
If holding the wire to unplug, it may cause an electric shock or a fire.
DO NOT WASH AT HIGH TEMPERATURES OF 800C(1760F) OR MORE.
DO NOT PUT THE APPLIANCE IN A DISHWASHER, A DRYER OR A MICROWAVE
ETC. It may cause a failure or parts deformation.
THE APPLIANCE WEIGHS ABOUT 6KG (13.2LB).
WHEN MOVING THE APPLIANCE, ENSURE TO MOVE IT HOLDING GRIPS TIGHTLY
AT THE BASE BOTTOM WITH BOTH HANDS.
If attempting to hold bowl or the edge of the base, the base falls causing an injury or a failure.
l 07
HE_OMEGA_VRT400_V.01.indd 11 2013-01-17 오전 11:28:47
SLOW JUICER ASSEMBLY
OPEN
STEP
STEP
STEP
Align hopper front triangle [ ▼] with bowl triangle
4
[ OPEN ] first and turn it to clockwise until it clicks
so that the hopper triangle [ ] aligned with bowl
triangle [Close ].
Make sure to press the screw down into the strainer
3
as in STEP 2. The hopper does not close properly
when the screw does not fit in completely.
Assemble the parts as following order:
2
Bowl>Spinning Brush> Strainer. Make sure bowl
triangle [ OPEN ] aligns with strainer triangle [ ▼].
A spinning brush can be assembled regardless of the
direction.
STEP
08 l
HE_OMEGA_VRT400_V.01.indd 12 2013-01-17 오전 11:28:48
Place the bowl in the base.
1
Open
SLOW JUICER ASSEMBLY IN DETAIL
Align the hopper rear part with base completely as in below.
4
The hopper does not close properly when the parts are not assembled correctly.
Assemble the parts in the order of bowl> spinning brush> strainer> squeezing screw> hopper (or assemble the spinning brush
2,3
into the bowl then fit strainer bump in the bowl inner groove). Make sure all the triangles of bowl [ OPEN ], strainer [ ▼] and
hopper [▼ ] are aligned in a vertical line.
Hopper
Squeezing Screw
Hopper
rear part
Strainer bump
BOTTOM
OF THE
STRAINER
Strainer
Spinning brush
Bowl
Insert extraction packing at the bottom of the bowl hard enough into the pulp outlet.
1
Make sure bowl outer groove aligns with base bump completely.
Extraction
packing
Bowl inner
groove
Base bump
Bowl outer groove
INSIDE
THE BOWL
I 09
HE_OMEGA_VRT400_V.01.indd 13 2013-01-17 오전 11:28:48
HOW TO USE THE APPLIANCE
역회전
REAR VIEW
2
Wash the fruits and/or vegetables and cut
them into pieces that fit into the feeding
tube. Place the suitable pieces into feeding
tube slowly and press with a pusher.
Use fresh fruits and vegetable for juicing as they contain more
juice themselves.
1
OPERATING
작동스위치
SWITCHES
Normal
direction
정회전
역회전
Reverse
direction
Press [On] button to start.
Normal
정회전
direction
역회전
Reverse
direction
누름
Press
OPERATING
작동스위치
SWITCHES
Normal
정회전
direction
Reverse
direction
off(정지)
off (stop)
Normal
정회전
direction
Stop
정지
Reverse
역회전
direction
정지상태
After juicing is completed, click [Reverse/
REV] to stop.
Motor does not stop immediately clicking [Reverse/REV] for
the safety reason and performance. It stops slowly.
3
STOP status
10 l
HE_OMEGA_VRT400_V.01.indd 14 2013-01-17 오전 11:28:49
Open
JUICE CAP AND EXTRACTION PACKING
JUICE CAP
This is the cap of juice outlet in the bowl.
Close the juice cap and fill up with juice in the bowl with various ingredients. You can easily make mixed fruit juice or vegetable juice.
Juice cap
Close juice cap and press [ON] button to start.
1
When juice starts filling up the bowl, you can mix
2
banana, nuts, boiled sweet potato etc. and liquids
such as milk etc. as well as vegetables and fruits
like smoothies.
Juice cap
Juice cap
packing
EXTRACTION PACKING
This is the pulp stopper made of silicone at the bottom of the bowl.
Make sure to close extraction packing always as shown below before use. For cleaning, let extraction packing opened and start washing. (Page 16)
CLOSED
Extraction
packing
Open juice cap to pour out as much as you need
3
and close without any drops.
l 11
HE_OMEGA_VRT400_V.01.indd 15 2013-01-17 오전 11:28:50
WHEN THE SCREW IS STOPPED DURING OPERATION (REVERSE/REV BUTTON)
Reverse
direction
(REV)
Normal
direction
(ON)
Stop
1
2
3
Click [Reverse/REV] button in
operating switches and stop the
appliance.
Press [Reverse/REV] button in
operating switches for 3~5 seconds
and release it. Repeat this process
2~3 times.
Reverse is the button pushing ingredients upward.
Reverse only works while the button is pressed and
held. Once release the button, screw rotation stops.
After the rotation stops completely,
press [ON] button to operate.
Any direction you want to change from either
Normal direction or Reverse direction, make
sure that screw rotation is stopped completely.
Then operate any button you need.
NOTE
If the screw does not work even after the above
process, unplug the power cord from the socket,
disassemble the bowl set, wash and use it again.
12 l
HE_OMEGA_VRT400_V.01.indd 16 2013-01-17 오전 11:28:50
30minute
IMPORTANT SAFEGUARDS IN USE
∙ Fruits with pits, hard seeds such as nectarines, peaches, mangos, apricots, plums and cherries must be pitted before juicing.
∙ Cut fibrous ingredients (water parsleys etc.) in small size like 3~4cm (1.5 inch) and place to the feeding tube.
∙ Drink the fruit juice or green vegetable juice immediately after you have extracted. If it is exposed to air sometime,
the juice will lose its taste and natural value.
∙ Do not use the appliance for grinding the dry ingredients such as grains, coffee beans, etc. It may cause a part damaged or a failure.
∙ Do not squeeze the leftovers again which already come out from pulp outlet.
∙ Do not operate the appliance when the bowl is empty.
DO NOT USE IT FOR MORE THAN 30 MINUTES CONTINUOUSLY.
It may cause a failure due to overheating in a motor.
But, when using continuously, stop and cool it down about 5 minutes for each use.
NEVER INSERT A FINGER, A FORK OR A SPOON, ETC. INTO JUICE OUTLET
DURING OPERATION.
If inserting a fork etc. into juice outlet during operation, it is stuck in spinning brush and causes a part damaged.
ONLY USE THE PUSHER TO PRESS DOWN THE INGREDIENTS.
Using other object, it is stuck in the screw and causes a part damaged, an injury or a failure.
DO NOT PLACE GRAINS, FRUIT WITH HARD SEED OR NUTS WITH HARD SHELL
SUCH AS WALNUTS.
It may cause damage or a failure of bowl, screw, squeezing strainer,etc.
Fruits with pits, hard seeds such as nectarines, peaches, mangos, apricots, plums and cherries must be pitted before juicing.
DO NOT OPERATE SWITCHES WITH WET HANDS.
It may cause an electric shock, an electric leakage or a fire.
Do not stain any foreign substances around switches.
DO NOT PUT SEAFOOD AND MEAT.
It may cause abnormal performances or a failure.
DO NOT PUT FRUIT PRESERVED IN SUGAR, HONEY, ALCOHOL, ETC.
(GRAPES, APRICOT, BERRIES, ETC.).
It may cause the hopper unopened.
NOTE
Frozen fruit or withered ingredients stored in the refrigerator for a long time may produce less juice or it is even hard to squeeze them.
l 13
HE_OMEGA_VRT400_V.01.indd 17 2013-01-17 오전 11:28:51
DISASSEMBLY, CLEANING AND CARE
FIGURE IN ORDER
Juice outlet
1
2
3
14 l
HE_OMEGA_VRT400_V.01.indd 18 2013-01-17 오전 11:28:52
DISASSEMBLY, CLEANING AND CARE
4 5
1. Ensure the motor stops completely and unplug the power cord.
When unplugging the power cord, hold the head part of the power cord and unplug it.
Do not touch the power cord with wet hands.
2. Hold the juice outlet and the hopper with both hands and lift them up from the base.
3. Disassemble the parts in reverse as below:
1) Unlock the bowl twisting to counterclockwise.
2) Take the screw out.
3) Remove the strainer.
4) Take the spinning brush out and disassemble the silicone brush.
4. Rinse each parts with cleaning brush and brush the inside and outside under running water.
Never use scouring pads, abrasive cleaning agent, aggressive liquids or sharp cleaning tools.
Do not wash them in a dishwasher or a dish dryer.
5. Wipe the stain on the base with soft damp cloth or wrung towel and dry it thoroughly.
Do not immerse the base unit in water or any other liquid, nor rinse it under tap.
6. After each cleaning, allow them to air-dry completely and store them in a clean and safe place.
Always wash the bowl set immediately after each use. Without wash-up, remained pulps get dried up and stuck onto it. It makes difficult
to disassemble or wash them. Also, it may cause degradation in performance.
l 15
HE_OMEGA_VRT400_V.01.indd 19 2013-01-17 오전 11:28:52
BOWL DISASSEMBLY AND WASH
juice cap
packing
Remove Juice Cap packing and bowl packing.
1
Open juice cap first. Hold the bowl and juice cap with one hand and remove juice cap packing with the other hand like
taking it off. When removing it, be careful not to drop the juice cap and bowl. It may cause damage to the juice cap.
Remove the bowl packing like pinching and twisting it with two fingers.
bowl packing
Extraction
Packing
Open the extraction packing at the bot-
2
tom of the bowl.
16 l
HE_OMEGA_VRT400_V.01.indd 20 2013-01-17 오전 11:28:53
Wash the bowl and all the packings.
3
Wash bowl and bowl packing with cleaning brush
under the running water.
Open
STERILIZATION AND EASY CLEANING SYSTEM
STERILIZATION
For sterilization, use baking soda or natural wash-up liquids only.
You can thoroughly wash them immersing in the water diluted with one or two drops of baking soda or natural wash-up liquids for
about 30 minutes.
EASY CLEANING SYSTEM
After closing the juice cap, pour the water
1
into feeding tube and operate the appliance.
Whenever changing the ingredient, it is not necessary to disassemble and wash the bowl.
After juicing, make sure to disassemble and wash the bowl set.
HE_OMEGA_VRT400_V.01.indd 21 2013-01-17 오전 11:28:53
After a while, open the juice cap and
2
discharge the water.
l 17
SPINNING BRUSH DISASSEMBLY AND WASH
Spinning brush
Silicone brush
1
2
3
Remove the spinning brush from
strainer.
Detach the silicone brush from spinning brush.
As shown to the left, hold the outer part of silicone
brush with your fingers and pull it out to the arrow
direction. It is recommendable to remove it
according to the above method. If pulling it by
force, silicone brush may be torn or spinning brush
may be damaged.
With cleaning brush, wash inside and
outside of spinning brush like brushing under the running water.
Wash silicone brush in the same way under the
running water.
Cleaning brush
18 l
HE_OMEGA_VRT400_V.01.indd 22 2013-01-17 오전 11:28:53
SPINNING BRUSH ASSEMBLY
SPINNING BRUSH SILICONE BRUSH
1
Inner
wing
Brush
groove
Down
(shorter part)
1
2
1
Up
(longer part)
2
Outer wing
2
3
Check the groove of the spinning brush
and the direction of silicone brush.
There are grooves to insert silicone brush in the
spinning brush.
Silicone brush has inner wing ▼ and outer wing
▼ .
2
As shown to the left, let ‘inner wing’ face the spinning
brush.
1
Insert the silicone brush into the
spinning brush.
According to the No. 1 above, let the longer part
of inner wing ▼ face upward.
Hold the outer wing ▼ of silicone brush with
your thumb and index finger and insert the inner
wing into the groove of spinning brush.
1
2
Pull the inner wing tight enough.
Push silicone brush from the outer side of spinning
brush and pull ‘inner wing’ in the direction of inside
of the spinning brush with the other hand as shown
to the left.
Pull it until you cannot pull it any longer.
If units are operating without fully assembled, there is
a risk of breakage.
Hold up and down of ‘outer wing’ and pull it tight
enough.
l 19
HE_OMEGA_VRT400_V.01.indd 23 2013-01-17 오전 11:28:54
BOWL PACKING ASSEMBLY
Bowl packing
1
2
Hold the bowl packing like pinching.
As shown to the left in a dotted circle, let the protrusion part on the bowl packing face upward and hold
it like pinching with your thumb and index finger.
Insert the bowl packing into the bowl
hole.
Insert the bottom of the bowl packing into the bowl
hole and fully press it down.
Do not insert whole part of bowl packing.
The upper part of the bowl packing must be shown.
3
20 l
HE_OMEGA_VRT400_V.01.indd 24 2013-01-17 오전 11:28:54
Turn over the bowl and organize the
bowl packing in place.
If the bowl packing at the bottom of the bowl is not
fully inserted and bent, organize it with the rotating
attractor of the cleaning brush.
JUICE CAP PACKING ASSEMBLY
Juice cap packing
1
2
3
Hold juice cap packing as shown to
the left.
As shown to the left in a dotted circle, the hole must
be visible when you hold.
Open the juice cap and insert the juice
cap packing in.
Insert it in from the top to the juice cap.
Be careful not to drop the bowl.
Organize the packing to seal off
completely.
If the packing is not completely sealed, it may
cause juice leaking.
l 21
HE_OMEGA_VRT400_V.01.indd 25 2013-01-17 오전 11:28:54
TROUBLESHOOTING
Check the details below before contacting Technical Support for repair or service.
If you need information or if you have a problem, please contact the local Customer Care Center.
When applying for after sales service, check the manufacturer’s serial number or bar code.
THE APPLIANCE DOES NOT WORK.
Make sure the power cord is properly plugged in.
Check the hopper is assembled properly. If the hopper has not been properly locked in place, the appliance does not work for safety reason.
Check if the appliance has been assembled according to the manual in an ordinary manner.
See the assembly in the manual or consult with the local Customer Care Center for help.
THE HOPPER DOES NOT OPEN.
Are there lots of pulps left inside the bowl? Press [ON ] button to discharge internal pulp somehow.
Have you placed any foreign substances or solid object such as hard seeds?
Press the [Reverse/REV] button to make foreign substances come up again toward the feeding tube.
Do not attempt to open it by force or with too much pressure. Still it does not work following by the above process, contact the local
Customer Care Center.
IT STOPS DURING NORMAL OPERATION.
Have you put heavy loads of ingredient or thick/big ingredient? Read the manual Page 12 and follow Reverse/REV button guideline.
Still the problem has not been solved, contact the local Customer Care Center.
THERE ARE THE GATE MARKS (FORMING MARK) RESULTING FROM THE MOLDING PROCESS.
It is a normal part and there is no problem for use.
WHAT IS THE DIFFERENCE BETWEEN FINE STRAINER AND COARSE STRAINER?
Use fine strainer with ‘small holes’ if you want somewhat clear juice.
Use the coarse strainer with ‘bigger holes’ if you want more pulpy juice or thicker juice.
Regarding strainer selection for suitable ingredients, read the manual Page 3.
JUICE LEAKS OVER THE BASE.
Is Extraction packing properly inserted in?
Juice could leak when the extraction packing is not properly inserted in. Please push the extraction packing tight enough.
Juice is still leaking even though the extraction packing was inserted properly? Did you put heavy loads?
If an amount of input ingredient is too much compared to the size of pulp outlet, the packing may be slightly pushed out and juice may leak through the
gap. Do not process heavy loads at a time and squeeze little by little.
THE BOWL SHAKES WHEN SQUEEZING.
Slight shaking may be occurred due to motor movement.
Large or small movements occur depending on the pulp texture of ingredients (hard or tough).
It is normal when the screw is rotating. Please note that it is not malfunction.
Hard ingredients (e.g: carrots/potatoes/radishes/beetroots etc.) may shake the bowl more than soft and juicy ingredient.
22 l
HE_OMEGA_VRT400_V.01.indd 26 2013-01-17 오전 11:28:54
APPLIANCE SPECIFICATIONS
APPLIANCE STANDARDS
PRODUCT NAME
MODEL NAME
RATED VOLTAGE
RATED FREQUENCY
RATED POWER
CONSUMPTION
RPM (REVOLUTIONS
PER MINUTE)
CORD LENGTH
MOTOR
FUSE
WEIGHT
OUTWARD
DIMENSIONS
RATED
OPERATING HOUR
Omega Slow Juicer
VRT400 Series
120 V
60 Hz
150 W
80 RPM
1.4 m▼▼
Single-phase induction motor
250 V 10 A
6.01 KG (13.2 LB)
Width 160 mm
Length 218 mm
Height 405 mm
Less than 30 minutes
l 23
HE_OMEGA_VRT400_V.01.indd 27 2013-01-17 오전 11:28:54
WARRANTY
Product name
Manufacture’s
serial number
Supplier
Model name
Date of purchase
Customer name
Address
Important: To better protect your purchase, fill out and mail this form to a local distributor where you have purchased,
and keep the original receipt.
This certifies that the Omega Slow Juicer is warranted by Omega to be free from defects in material construction and
workmanship.
The motor warranted for five (5) years and other parts are warranted for one (1) year from the date of purchase to the
original purchaser.
This warranty does not apply to damages caused by accident, misuse, abuse, commercial use, alteration, failure to
follow operating instructions, or damage caused by parts or service unauthorized by Omega Damages caused by
transportation must be claimed with carrier.
Omega disclaims all responsibilities for consequential damages from incidental losses caused by use of this appliance.
If service should be necessary, please contact our local Customer Care Center for technical difficulty.
24 l
HE_OMEGA_VRT400_V.01.indd 28 2013-01-17 오전 11:28:55
MEMO
l 25
HE_OMEGA_VRT400_V.01.indd 29 2013-01-17 오전 11:28:55
V.01
Copyright© All Rights Reserved by HUROM
HE_OMEGA_VRT400_V.01.indd 30 2013-01-17 오전 11:28:55
Loading...
