OMEGAFLEX
®
SAntOprEnE FLEXibLE rubbEr tubinG
TYSP Series
By Individual
Model No.
†
U Broad Operating
Temperature Range
-59 to 135°C (-75 to 275°F)
U Available in Shore A
Hardness of 55, 64 and 73
U Suitable for Many
Peristaltic Pumps
Santoprene thermoplastic rubber
tubing is offered with Shore A
hardness of 55A (TYSP5), 64A
(TYSP6), and 73A (TYSP7). The
tubing resists fatigue. The regular
black santoprene also resists
exposure to ozone and
ultraviolet radiation.
† Visit omega.com/rohs to determine
specific RoHS compliance.
SPECIFICATIONS**
TYSP5 TYSP6 TYSP7
Hardness, Shore A 55A 64A 73A
Specific Gravity 0.97 0.97 0.97
Tensile Strength, PSI 640 950 1100
Elongation at Break, % 330 400 410
Heat Distortion Temp. 135°C (275°F) 135°C (275°F) 135°C (275°F)
Low Temp. Flexibility Below 60°C (140°F)
To Order
Regular Tubing (Black) Dimensions
Model No. 55A 64A 73A OD ID Wall
TYSP(*)-18116-50 U – –
TYSP(*)-316116-50 – U U
TYSP(*)-1418-50 – U U
TYSP(*)-3818-50 – U –
TYSP(*)-516316-50 U U U
TYSP(*)-12316-50 – – –
TYSP(*)-38316-50 – U –
TYSP(*)-916316-50 U U –
TYSP(*)-3814-50 – U U
TYSP(*)-71614-50 U U –
TYSP(*)-1214-50 U U U
TYSP(*)-5814-50 U U U
TYSP(*)-716516-50 – U U
TYSP(*)-12516-50 – U –
TYSP(*)-1316516-50 – U –
TYSP(*)-1238-50 – U U
TYSP(*)-91638-50 – U –
TYSP(*)-5838-50 – U U
TYSP(*)-138-50 – – – 1"
TYSP(*)-916716-50 – U U
TYSP(*)-5812-50 – U –
TYSP(*)-111612-50 – U U
TYSP(*)-3412-50 – U U
TYSP(*)-7858-50 – U U
TYSP(*)-134-50 – U – 1"
Specify durometer: 5 (for 55A), 6 (for 64A), or 7 (for 73A).
*
required to find the actual operating specifications in a given application.
Ordering Examples: TYSP6-38316-50, specifies a 50' spool, 64A durometer,
TYSP7F-1238-50, 50 feet of tubing, 73A durometer,
