User’s Guide

Two-wire Display and Control Unit

Omega TX03 Manual

Manual for 2-wire LCD display and control unit

1. Brief

Omega series universal intelligent 2-wire LCD digital display is fit for all
of the transmitters and converters with 4～20mA 2-wire technique, just as
pressure, differential pressure, temperature, flow, PH, acceleration and so on.
16 Bit ADC MCU inside. Customer can use the three buttons to program the
zero point, Span, unit, decimal point, damping and alarm point etc. instead
of the potentiometer. The actual value will expressed by the schedule.
And it can replace all of the analog indicators in the market

2. feature

1) High accuracy and stability.

2) 16 Bit ADC MCU inside.

3) The scope of the value ca

n be displayed on the LCD is -1.9.9.9.9. ～

9.9.9.9.9.

4) LCD can work at 3mA. Dropout voltage≤3.1V

5) 34 optional units. Many kinds of the value can be displayed, such as
pressure, temperature, PH and so on.

6) Friendly soft interface.

7) The schedule show the value measured in real time, and it will
twinkle to alarm

8)

Two OPTO switch outputs, NPN, PNP output

3. Setting

“ M” menu item for setting
“ ” to move the cursor

“ ”to change the value that the cursor point to and move the decimal

point.

Omega TX03 Manual

3.1 power on

After the digital LCD display was connected to the current circle 4～20mA,

LCD is lighted,the initial screen display the default setting:

3.2 Zero-point (value to be displayed for 4mA)

Press button “M” to enter zero-point setting mode: (Factory default setting is

4.0000mA)

→Press “ ” to move the cursor.

→Press “ ” to change the value that the cursor point to.
→When the cursor move to the first left number, press “ ” again, the

decimal point is twinkling, press “ ” to move the decimal point.

→Press “M” to confirm setting and return to the menu ite

m

3.3 Span (value to be displayed for 20mA)

Press “M” to continue, span setting mode is displayed:

(Factory default setting 20.000mA)

Omega TX03 Manual

→Press “ ” to move the cursor.

→Press “ ” to change the value that the cursor point to.
→When the cursor move to the first left number, press “ ” again, the

decimal point will twinkle, press “ ” to move the decimal point.

→Press “M” to confirm setting and return to the menu item

3.4 Unit setting

Press button “M” to continue, unit setting mode is displayed:

→ Press “ ” or “ ” to select the unit, For example “℃”is selected,

unit

is displayed on the LCD.

Optional units: V, mV, bar, mbar, Pa, KPa, MPa, mH2O, mmH2O, cmH2O,

mmHg, PSI, TOR, kg, g, N, KN, , ℃

o

F, K, RH, VOL, PPM,

LEL, PH, m, cm, mm, INCH, M/S, Ohm, Kohm, %.

3.5 Decimal digits

Press button “M” to continue, decimal digits setting mode is displayed:

Omega TX03 Manual

→Press “ ” or “ ” to select the number of decimal digits, (Valid

number: 0,1,2,3)

3.6 Damping

Press button “M” to continue, damping setting model is displayed:

→Press “ ” to move the cursor.

→Press “ ” to change the value that the cursor point to. Value is increased

and decreased by step 0.1s. (Min=0s, Max=99.9s, step 0.1s)

→ “M” to confirm setting and return to the menu item.

3.7 Alarm

Press button “M” to continue, alarm setting mode is displayed：

Omega TX03 Manual

→ Press “ ” or “ ” to change the setting either “ON” or “OFF”.

“ON” means the setting parameter is available, and the alarm was

expressed by the twinkle of the schedule on the top and the value. “OFF”

means the alarm setting parameter is unavailable.

3.8 The first alarm point.

Press button “M” to continue, first alarm point setting mode is display:

The method of setting is the same as step 3.2

3.9 The second alarm point

Press button “M” to continue, second alarm point setting mode is display:

The method of setting is the same as step 3.2

3.10 The direction of the first alarm pi

nt

Omega TX03 Manual

Press button “M” to continue, the direction of the first alarm point setting mode

is displayed:

Press “ ” or “ ”to change the setting either “UP” or “Down”. “UP”
means alarm while the value is above the alarm parameter, and “Down”

means alarm while value is below the alarm parameter.

3.11 The direction of the first alarm point

Press button “M” to continue, the direction of the first alarm pint setting mode

is displayed:

Other is the same as 3.10.

3.12 The delay

Press button “M” to continue, delay setting mode is display:

→ Setting is the same as 3.6 (Min=0s, Max=

99.9s step 0.1)

Omega TX03 Manual

3.13 Display Mode

Press button “M” to continue, display mode setting is display:

Three display modes are for selection:

Pressure, Current or Percent

4 Dimensions
