MEDIUM TEMPERATURE HEATING TAPES
SRT
Series
U Maximum Exposure
Temperature up to
230°C (450°F)
U Uniform Heat Distribution
U Moisture and Chemical
Resistant
U Integrally Molded
Separable Plug
U Available with Leads
Same End
OMEGALUX® silicone rubber
extruded heating tapes are lowwatt density electrical resistance
heaters designed for temperature
maintenance in applications
requiring moisture and chemical
resistance. Silicone rubber tapes
are constructed of finely stranded
resistance wires fully insulated with
braided fiberglass and knitted into
flat tape with fiberglass yarn. These
tapes are encapsulated in a voidfree silicone rubber sheath.
†
SPECIFICATIONS
Heating Elements: 36-40 gage finely
stranded resistance wire
Heating Elements Insulation:
Double braided fiberglass yarn
Dielectric Strength: In excess of 2000V
Lead Wires: 16 AWG high temperature
600V silicone rubber insulated lead
wire emerging from opposite ends of
the heating tape into separate sides of
integrally molded separable plug
APPLICATIONS
U Silicone rubber extruded
heating tapes can be used
in direct contact with a
metal or conductive surface
Integrally
molded
separable
plug shown.
SRT051-060
shown smaller
than actual size.
To Order
Watts W/in2 Volts Size cm/m (inch/foot) Model No.
52 4.3 120 1/0.6 (1⁄2/2) SRT051-020
104 4.3 120 1/1.2 (
156 4.3 120 1/1.8 (
209 4.3 120 1/2.4 (
261 4.3 120 1/3 (
313 4.3 120 1/3.7 (
104 4.3 120 2.5/0.6 (1/2) SRT101-020
209 4.3 120 2.5/1.2 (1/4) SRT101-040
313 4.3 120 2.5/1.8 (1/6) SRT101-060
418 4.3 120 2.5/2.4 (1/8) SRT101-080
522 4.3 120 2.5/3 (1/10) SRT101-100
627 4.3 120 2.5/3.7 (1/12) SRT101-120
731 4.3 120 2.5/3.7 (1/12) SRT101-140
836 4.3 120 2.5/4.9 (1/16) SRT101-160
940 4.3 120 2.5/5.5 (1/18) SRT101-180
1045 4.3 120 2.5/6.1 (1/20) SRT101-200
209 4.3 120 5/0.6 (2/2) SRT201-020
418 4.3 120 5/1.2 (2/4) SRT201-040
627 4.3 120 5/1.8 (2/6) SRT201-060
836 4.3 120 5/2.4 (2/8) SRT201-080
1045 4.3 120 5/3 (2/10) SRT201-100
1254 4.3 120 5/3.7 (2/12) SRT201-120
1463 4.3 120 5/4.3 (2/14) SRT201-140*
1672 4.3 120 5/4.9 (2/16) SRT201-160*
1881 4.3 120 5/5.5 (2/18) SRT201-180*
2090 4.3 120 5/6.1 (2/20) SRT201-200*
Does not come with plug.
*
Comes complete with instruction sheet.
† To order heaters with power leads exiting the same end of the tape, add suffix“-LSE” to model
number. Call Sales for pricing. To order 240V version change the “1” before the “-” in model
number to “2”. All 240V versions are supplied without plugs. Call for sales prices.
1
⁄2/4) SRT051-040
1
⁄2/6) SRT051-060
1
⁄2/8) SRT051-080
1
⁄2/10) SRT051-100
1
⁄2/12) SRT051-120
*
28
To Order, Call or Shop Online at omega.com
