INTRODUCTION

This instrument is a portable, compact-sized Humidity Temperature Trans­ducer designed for simple one hand operation. Uses Platinum Resistance
Temperature Detector Pt385/1000W (Alpha=0.00385) as temperature sensor,
and uses thin film polymer capacitive type relative humidity sensor as hygrom­eter sensor.

SAFETY INFORMATION

It is recommended that you read the safety and operation instructions before
using the humidity temperature transducer.

• Do not immerse the transducer sensor head into liquids since this
causes permanent damage to the sensor.

• The meter when not in use, please use protective metal cap cover the
sensor head and rotate clockwise it to extend sensors life.

The symbol on the instrument indicates that the operator must refer to an

explanation in this manual.

CAUTION

1

SPECIFICATIONS

GENERAL

Low battery indication: The "Red LED" is displayed when the battery voltage

drops below the operating level.
Accuracy: Stated accuracy at 73.4°F ± 9°F, <75% relative humidity.
Temperature Coefficient: 0.056 times the applicable accuracy specification per

°F from 32°F to 64.4°F and 82.4°F to 122°F.

Operating environment: 32°F to 122°F at <75% relative humidity.
Storage environment: -4°F to 140°F at <80% relative humidity.
Battery: 4 pcs 1.5V (AAA size).
Battery Life: 200 hours typical.
Dimensions: 170mm(H) x 44mm(W) x 40mm(D).
Weight: 7.05oz (including probe and batteries).

2

ELECTRICAL
TEMPERATURE

Temperature Scale: Fahrenheit.
Temperature Sensor: RTD Pt385/1000W.
Measurement Range: -4°F to 140°F.
Temperature Output: 10mV/°F.
Accuracy: ±0.9°F 32°F to 122°F

±1.8°F -4°F to 32°F, 122°F to 140°F

RELATIVE HUMIDITY

Humidity Sensor: Electronic capacitance polymer film sensor. (The sensor is

unaffected by water condensate, is immune to most reagent vapors)

Measurement Range: 0% to 100%RH.
Relative Humidity Output: 10mV/%RH.
Accuracy: ±2.5%RH (10% to 90%RH)

Sensor Response Time for 90% of Total Range: 60sec typical.
Sensor Stability: ±2%RH, 2 years typical.

±5%RH (<10%, > 90%RH)

3

Sensor Hysteresis (excursion of 10% to 90% to 10% RH): ±1%RH typical.
Sensor Temperature Dependence: Negligible between 32°F to 122°F.

OPERATON

1. Plug the humidity temperature transducer test leads into the Vdc input jack and

common or ground input jack on the DMM. Observe polarity.

2. Set the DMM to the 200mV range.

3. Rotate counter clockwise to remove the protective metal cap.

4. Set the power switch to the desired %RH or °F range.

5. If the DMM display is over-range. Set the DMM to the 2V range.

6. Read the DMM display. (10mV/°F, 10mV/%RH)

7. Cover sensor head to extend sensor life when not in use.

4

SPECIAL CONSIDERATIONS

• Before a reliable measurement can be made, the measuring hygrometer and

medium to be measured must be in temperature and humidity eguilibrium.

• Temperature measurement errors

Due to too short measurement time, sunshine during the measurement,

heating, cold outer walls, air draft (e.g. fans), radiating hand and / or body heat

etc.

• Humidity measurement errors

Due to steam, water splashes, dripping water or condensation (not water

condensate) on the sensor etc. However, repeatability and long-term stability

are not impaired by this.

• Contamination

By dust in the air or measurements in powdery substances. This can be largely

avoided by using a corresponding filter. The filter must be cleaned or replaced

periodically depending upon the degree of contamination of the measuring

site.

5

OPERATOR MAINTENANCE

Battery Replacement

Power is supplied by four 1.5V (AAA size) batteries. The "LOW BATT" red LED
lighted when replacement is needed. To replace the batteries, remove the screw
from the back of the meter and lift off the battery cover. Remove the batteries from
battery contacts.

Cleaning

Periodically wipe the case with a damp cloth and detergent, do not use abrasives
or solvents.

6
