Air Temperature
Pt100/
Pt1000
Pt100
Pt100/
Pt1000
RTD Probe
With M12 Connection
PR-25AP Series
ACCURACY
IEC CLASS
(±0.15ºC @ 0ºC)
A
Probe Length
up to 12" long
8
⁄
1
12" and longer
4
±
⁄
1
±
1
" diameter
⁄
4
9
1
" diameter
⁄
16
0.66"
diameter
PR-25AP-A-0600-0-M12
shown smaller
than actual size.
1
⁄
4
PR-25AP-A-0600-1/4-M12
shown smaller
than actual size.
NPT
9
Hex
⁄
16
U Pt100 RTD with Class
A Accuracy Standard
(Tighter Accuracy
Options Available)
U 316L Stainless Steel
Probe and Housing
with Vent Holes
Around Element
U Temperature Range:
-100 to 250°C
(-148 to 500ºF)
U M12, 4-Pin, A-Coded
Plug Connector for
Easy Installation
U Available With or Without
NPT Mounting Threads
U Probe Will Withstand
400 psi (27.6 bar)
Differential Pressure
Between Airstream and
Ambient Conditions
This sensor combines the
usefulness of our ultra-precise air
measurement RTD sensors with
the convenience of our PR-21 M12
enabled RTD sensors. The design
of the probe includes a perforated
sheath over the sensing element
shielding it from debris while
allowing airflow to directly reach
the element. This results in
a sensor which is capable of
providing accurate, fast responding
temperature measurements.
OMEGA also offers a wide variety
of compression fittings, extension
cables and measurement and
control instruments which allow
you to fully customize the system
to best meet your measurement
and control needs.
L
Option 1
Pt100
Option 2
PR-25AP probe tip,
close-up
L-1
Page 2
44.5
(1.75)
Don’t Forget to
Order a M12 Extension
Cable to Easily Connect
Your Sensor to Your
Instrumentation
28.5
(1.125)
32
(1.25)
M12CM-T24SSPC-RF-2
cable, sold separately.
Optional extension cable.
Dimensions: mm (in)
M12CM-T24SSPC-SF-2
cable, sold separately.
PR-25AP-A-1200-0-M12, shown with M12C-SIL-4-R-F-1.5.
To Order
Model Number Probe Diameter Probe Length Mounting Thread
PR-25AP-A-0600-0-M12 ¼" 6" No thread
PR-25AP-A-1200-0-M12 ¼" 12" No thread
PR-25AP-A-1800-0-M12 ¼" 18" No thread
1
PR-25AP-A-0600-1/2-M12 ¼" 6"
PR-25AP-A-1200-1/2-M12 ¼" 12"
PR-25AP-A-1800-1/2-M12 ¼" 18"
PR-25AP-A-0600-3/8-M12 ¼" 6"
PR-25AP-A-1200-3/8-M12 ¼" 12"
PR-25AP-A-1800-3/8-M12 ¼" 18"
PR-25AP-A-0600-1/4-M12 ¼" 6"
PR-25AP-A-1200-1/4-M12 ¼" 12"
PR-25AP-A-1800-1/4-M12 ¼" 18"
Note: option 1 wiring standard.
For option 2 wiring add “-2” to end of model number, no additional charge.
1
For
⁄
DIN accuracy, change “-A-” to “-1/3-” after the “-25AP-” in the model number for an additional cost.
3
1
For
⁄
DIN accuracy, change “-A-” to “-1/10-” after the “-25AP-” in the model; number for an additional cost.
10
A limited selection of Pt1000 elements are available, please consult sales.
Ordering Examples: PR-25AP-A-0600-0-M12, Pt100, Class A RTD sensor with ¼" diameter by 6" long probe, M12 connection with no mounting
threads.
PR-25AP-1/10-1200-1/2-M12, Pt100, Class
1
⁄
DIN RTD sensor with
10
1
" diameter by 12" long probe, M12 connection with
⁄
4
⁄
2 NPT
1
⁄
2 NPT
1
⁄
2 NPT
3
⁄
8 NPT
3
⁄
8 NPT
3
⁄
8 NPT
1
⁄
4 NPT
1
⁄
4 NPT
1
⁄
4 NPT
1
⁄
NPT mounting threads.
2
L-2
