Splashproof Portable pH/mV
Measurement Kits
pH and temperature probes
and carrying case included.
U Splashproof Case
U Suitable for Ion Selective Measurements
U Automatic Buffer Recognition and Calibration
U Diagnostic Error Code Displays for Faculty pH Electrode
U Recorder Output
U LCD Meter Display
PHH-257-KIT
Electronics
Only
PHH-257 shown
smaller than
actual size.
The PHH-257-KIT is designed for field and laboratory
measurement of pH. Supplied as a complete kit, the
PHH-257-KIT is perfect for transporting to remote locations,
keeping the equipment organized and ready for future
measurements. Standard features include automatic buffer
recognition and calibration, diagnostic error code display to
indicate defective electrodes or incorrect buffer solution.
The meter has a very precise 0.1 mV resolution, ideal for ion
selective measurements. The PHH-257-KIT comes complete with
meter, epoxy-bodied general purpose pH electrode, temperature
probe, carrying case and user’s manual.
Specifications
Measurement Range:
pH: 0 to 14
mV: ±200, ±2000 (absolute)
Relative mV: ±FS (back-off)
Temperature: -30 to 130°C (-22 to 266°F)
Resolution:
pH: 0.01 pH units
mV: 0.1, 1.0 mV
Temperature: 0.1°C
Accuracy:
pH: ±0.02 pH units
mV: ±0.05 % or 1 digit
Temperature: ±0.3°C
pH Calibration: Automatic (1- or 2-point), compatible with
buffers 4, 7 and 10
Temperature Compensation:
Manual: 0 to 100°C (32 to 212°F)
Automatic: 0 to 100°C (32 to 212°F)
Power Supply: Two 9 V batteries (included)
Instrument Display: 12.7 mm (
1
⁄2") LCD
pH Electrode Connection: BNC
Temperature Probe Connection: 3 pole, 3.5 mm (0.138")
diameter jack
Reference Electrode Connection:4 mm (0.157") diameter
Recorder Output: ±200.0 mV
Meter Dimensions: 145 L x 81 W x 38 mm H (5.7 x 3.2 x 1.5")
Meter Weight (Including Batteries): 363 g (12.7 oz)
To Order
Model No. Description
PHH-257-KIT pH meter with case, pH electrode and
Includes meter, epoxy-bodied general purpose pH electrode, temperature probe,
carrying case and operator’s manual.
Ordering Example: PHH-257-KIT with PHE-4201 replacement electrode.
temperature probe
Accessories
Model No. Description
PHE-4201 Clear, epoxy-bodied, gel-filled combination electrode
ORE-1411 Double junction ORP probe
PHAT-3016 Temperature probe
B-24
