OMEGA® GENERAL SERVICE GAUGES
P-Style L Stem Fig. 1
P-Style B Back Fig. 1
P-Style B Flush Fig. 1
TYPE S
PGS Series
PGS-35L-300, shown
actual size.
U 63 and 89 mm
(21⁄2 and 31⁄2") Dials
U Stem and Panel
Mount Styles
U Weather-Resistant
Stainless Steel Case
U 316 SS Wetted Parts
U 1% FS Accuracy
To combat hostile environments,
this general service gauge is
corrosion, weather, and dust
resistant. Mounting versatility,
PGS-25L-160, shown
actual size.
excellent readability, and sustained
accuracy make this stainless steel
design a gauge leader. It can be
stem, surface, or flush mounted.
Sustained accuracy and excellent
readability are especially important
to users of the OMEGA® general
service gauge line. Meeting the
requirements of many industrial
applications, general service gauges
can be used on steam boilers or
other pressurized vessels; on pumps
and compressors; on many types of
industrial machinery; in the chemical,
petrochemical, and allied process
industries; in power plants; and in
pulp and paper mills.
The pressure gauge actuation
system in the OMEGA® general
service gauge line is the standard
316 SS Bourdon tube system, which
is engineered to precise tolerances
for repeatability and consistent
response to pressure fluctuations.
STYLE L
STYLE B
G-55
With Flange Mounting Kit
STYLE B
Page 2
3
1
⁄2"
Lower
and Back Connect
75
(2.95)
11
FLATS
(0.44)
Ø98.8
(3.89)
9.1
(0.36)
31.7
(1.25)
Ø 91.3
(3.59)
21.3
(0.84)
29.4
(1.16)
TYPE S GENERAL SERVICE GAUGES
3
1
⁄2"
Lower
and Back Connect
75
(2.95)
11
FLATS
(0.44)
Ø98.8
(3.89)
10.4
(0.41)
9.1
(0.36)
31.7
(1.25)
Ø 91.3
(3.59)
21.3
(0.84)
29.4
(1.16)
21⁄2" Lower
and Back Connect
(2.39)
Ø 69.9
60.6
(2.75)
11
FLATS
(0.44)
10.4
(0.41)
(0.36)
9.1
Ø 62.3
(2.45)
31.7
(1.25)
21.3
(0.84)
29.4
(1.16)
31⁄2" Back Connect
21.3
(0.84)
2 (1/16) TO 6 (1/4)
PANEL
48
(1.89)
9.1
(0.36)
33.3
(1.31)
22.6
(0.89)
29.4
(1.16)
Ø 91.3
(3.59)
11 (0.44)
FLATS
#8-32 STUDS
& 3/8 HEX NUT
61.1
(2.41)
93 (3.66) ±1 (0.03)
PANEL CUTOUT
6.4
(0.25)
26.4
(1.04)
106.3
(4.18)
Ø3.89
(98.8)
3
1
⁄2"
Lower
and Back Connect
75
(2.95)
11
FLATS
(0.44)
Ø98.8
(3.89)
10.4
(0.41)
9.1
(0.36)
31.7
(1.25)
Ø 91.3
(3.59)
21.3
(0.84)
29.4
(1.16)
21⁄2" Lower
and Back Connect
(2.39)
Ø 69.9
60.6
(2.75)
11
FLATS
(0.44)
10.4
(0.41)
(0.36)
9.1
Ø 62.3
(2.45)
31.7
(1.25)
21.3
(0.84)
29.4
(1.16)
21⁄2" Back Connect
21.3
(0.84)
29.4
(1.16)
9.1
(0.36)
2 (1/16) TO 6 (1/4)
PANEL
Ø 62.3
(2.45)
22.6
(0.89)
33.3
(1.31)
48
(1.89)
11 (0.44)
FLATS
#8-32 STUDS
& 3/8 HEX NUT
49.2
(1.94)
28.4
(1.12)
73.3
(2.88)
6.4
(0.25)
64 (2.53) ±1 (0.03)
PANEL CUTOUT
Ø 69.9
(2.75)
31⁄2" 1009 Back
Connect
Ø4.57
BOLT CIRCLE
(116)
Ø3.89
(98.8)
Ø5.20
(132)
Ø.22
(5.6)
.84
(21.3)
Ø
3.78
(96) MIN
Ø
3.86 (98) MAX
PANEL CUTO UT
1.16
(29.4)
1.25
(31.7)
Ø3.59
(91.3)
.64
(16.2)
.44 (11)
FLATS
31⁄2" Back Connect
21.3
(0.84)
2 (1/16) TO 6 (1/4)
PANEL
48
(1.89)
9.1
(0.36)
33.3
(1.31)
22.6
(0.89)
29.4
(1.16)
Ø 91.3
(3.59)
11 (0.44)
FLATS
#8-32 STUDS
& 3/8 HEX NUT
61.1
(2.41)
93 (3.66) ±1 (0.03)
PANEL CUTOUT
6.4
(0.25)
26.4
(1.04)
106.3
(4.18)
Ø3.89
(98.8)
3
1
⁄2"
Lower
and Back Connect
75
(2.95)
11
FLATS
(0.44)
Ø98.8
(3.89)
10.4
(0.41)
9.1
(0.36)
31.7
(1.25)
Ø 91.3
(3.59)
21.3
(0.84)
29.4
(1.16)
31⁄2" 1009 Back
Connect
Ø4.57
BOLT CIRCLE
(116)
Ø3.89
(98.8)
Ø5.20
(132)
Ø.22
(5.6)
.84
(21.3)
Ø
3.78
(96) MIN
Ø
3.86 (98) MAX
PANEL CUTO UT
1.16
(29.4)
1.25
(31.7)
Ø3.59
(91.3)
.64
(16.2)
.44 (11)
FLATS
31⁄2" Back Connect
21.3
(0.84)
2 (1/16) TO 6 (1/4)
PANEL
48
(1.89)
9.1
(0.36)
33.3
(1.31)
22.6
(0.89)
29.4
(1.16)
Ø 91.3
(3.59)
11 (0.44)
FLATS
#8-32 STUDS
& 3/8 HEX NUT
61.1
(2.41)
93 (3.66) ±1 (0.03)
PANEL CUTOUT
6.4
(0.25)
26.4
(1.04)
106.3
(4.18)
Ø3.89
(98.8)
3
1
⁄2"
Lower
and Back Connect
75
(2.95)
11
FLATS
(0.44)
Ø98.8
(3.89)
10.4
(0.41)
9.1
(0.36)
31.7
(1.25)
Ø 91.3
(3.59)
21.3
(0.84)
29.4
(1.16)
21⁄2" Lower
and Back Connect
Dimensions: mm (inch) ø = diameter
SPECIFICATIONS
Max Operating Temp: 66°C (150°F)
Case: Polished stainless steel
Window: Polycarbonate plastic with
Neoprene sealing gasket
Bourdon Tube: 316 SS
ACCESSORIES FOR TYPE S GAUGES
MODEL NO. DESCRIPTION
UBK-25A U-bracket kit for 2
UBK-35A U-bracket kit for 3
FMK-25A Flange mount kit for 2
FMK-35A Flange mount kit for 3
Dimensions: mm (in) ø = diameter
PGS-25B/PGS-25L PGS-35B/PGS-35L
29.4
(1.16)
21.3
(0.84)
21⁄2" 1009 Back
Connect
PANEL CUTOUT
Ø
Ø
21⁄2" Back Connect
2.53 (64) MIN
2.59 (66) MAX
(62.3)
Ø 2.45
21.3
(0.84)
28.4
(1.12)
11 (0.44)
FLATS
73.3
(2.88)
49.2
(1.94)
PANEL CUTOUT
64 (2.53) ±1 (0.03)
9.1
(0.36)
Ø 62.3
(2.45)
10.4
(0.41)
6.4
(0.25)
29.4
(1.16)
10.6
(0.42)
31.7
(1.25)
#8-32 STUDS
& 3/8 HEX NUT
FMK-25A
31.7
(1.25)
1
⁄2 gauge
1
⁄2 gauge
UBK-25A
48
(1.89)
33.3
(1.31)
22.6
(0.89)
29.4
(1.16)
Ø 62.3
(2.45)
21.3
(0.84)
11 (0.44)
FLATS
Ø 79.5
(3.13)
BOLT CIRCLE
Ø 69.9
(2.75)
Ø 93.7
(3.69)
1
⁄2"
3
Lower
and Back Connect
29.4
1
⁄4 NPT
1
3
⁄2" 1009 Lower and
Back Connect
19.5
(0.77)
G-56
(1.16)
21.3
(0.84)
21.3
(0.84)
Ø 69.9
(2.75)
60.6
(2.39)
11
(0.44)
FLATS
Connection: Back or lower
Fitting: 316 SS,
Dial Size: 63 and 89 mm (2
Mounting: Stem, flange or “U” bracket
Accuracy: 1% full scale
1
⁄2 gauge
1
⁄2 gauge
PANEL
2 (1/16) TO 6 (1/4)
Ø 69.9
(2.75)
9.1
(0.36)
Ø 4.1
(0.16)
1
⁄2 and 31⁄2")
31⁄2" Back Connect
26.4
(1.04)
(0.80)
106.3
(4.18)
(2.41)
20.3
61.1
9.1
(0.36)
31.7
(1.25)
Ø 91.3
(3.59)
10.4
(0.41)
Warning: To prevent misapplication, all
gauge components should be chosen
with an eye to the media and ambient
operating conditions to which they will
be exposed. Improper application
can be detrimental to the gauge,
causing failure and possible personal
injury and property damage.
#8-32 STUDS
PANEL CUTOUT
93 (3.66) ±1 (0.03)
FMK-35A
41.6
(1.64)
& 3/8 HEX NUT
6.4
(0.25)
116
Ø(4.57)
BOLT
CIRCLE
98.8
Ø(3.89)
(0.44)
FLATS
11
48
(1.89)
(0.89)
29.4
(1.16)
Ø 91.3
(3.59)
21.3
(0.84)
22.6
11 (0.44)
FLATS
33.3
(1.31)
9.1
(0.36)
PANEL
2 (1/16) TO 6 (1/4)
11
(0.44)
FLATS
UBK-35A
(98.8)
Ø3.89
5.6
Ø(0.22)
132
Ø(5.20)
(2.95)
Ø98.8
(3.89)
75
75
(2.95)
PRESSURE
GAUGES
G
Page 3
HOW TO ORDER TYPE S
GENERAL SERVICE GAUGES
Standard Ranges—Type S
Pressure (psi)
DIAL SIZE MODEL NO. CONNECTION
PGS-25L-[*] (to 600 psi) Lower
PGS-25L-[*] (over 600 psi) Lower
21⁄2"
PGS-25B-[*] (to 600 psi) Back
PGS-25B-[*] (over 600 psi) Back
PGS-35L-[*] (to 600 psi) Lower
PGS-35L-[*] (over 600 psi) Lower
1
3
PGS-35B-[*] (to 600 psi) Back
PGS-35B-[*] (over 600 psi) Back
*
Option: “X6B”, oxygen service cleaning.
Ordering Example: PGS-25B-160, pressure gauge, general service type, 21⁄2 " dial,
back connection, 0/160 psi range.
⁄2"
Insert range code from table below. Comes complete with operator’s manual.
Pressure Range: Select a gauge
with a full scale pressure range
of approximately twice the normal
operating pressure. The maximum
operating pressure should not
exceed approximately 75% of the
full scale range. Failure to select a
gauge range within these criteria
may ultimately result in fatigue
failure of the Bourdon tube.
Oil-Filled Gauges Also Available:
Type S gauges are available on
special order filled with silicone oil.
The silicone oil is used to dampen
the internal movement of the gauge
when it is installed on vibrating
equipment. The oil has an operating
range of -40 to 66°C (-40 to 150°F).
The maximum storage temperature
of the gauge is 82°C (180°F).
To Order: Add suffix “F” to
model number for an additional
cost for 63 mm (21⁄2") gauges or an
additional cost for 89 mm
(31⁄2") gauges.
FIGURE MINOR
INTERVAL GRADUATION
RANGE INCHES INCHES
CODE RANGE MERCURY psi MERCURY psi
30V/15 30 inHg vac/0/15 psi 5 3 1 0.5
30V/30 30 inHg vac/0/30 psi 10 5 1 1
30V/60 30 inHg vac/0/60 psi 10 10 2 1
30V/100 30 inHg vac/0/100 psi 10 10 2 1
30V/150 30 inHg vac/0/150 psi 10 20 5 2
30V/300 30 inHg vac/0/300 psi 30 25 5 5
Note: For Type S gauges with oxygen cleaning, gauge fill must be Halocarbon, for additional cost.
Ordering Example: PGS-25B-60-F, pressure gauge, general service type, 63 mm (21⁄2") dial,
0/60 psi range, silicone oil filled.
PGS-25L-160,
shown smaller
than actual size.
PGS-25L-100,
shown smaller
than actual size.
RANGE FIGURE MINOR
CODE RANGE
15 0/15 1 0.2
30 0/30 5 0.5
60 0/60 5 1
100 0/100 10 1
160 0/160 20 2
200 0/200 20 2
300 0/300 30 5
400 0/400 50 6
600 0/600 50 10
800 0/800 100 10
1000 0/1000 100 10
1500 0/1500 200 20
2000 0/2000 200 20
3000 0/3000 300 50
5000 0/5000 500 50
6000 0/6000 1000 100
7500 0/7500 1000 100
10,000 0/10,000 1000 100
VACUUM
30V 30 to 0 5 0.5
inHg inHg inHg
INTERVAL
GRADUATION
G-57
