EMI Protection Hardware
with Nickel-Zinc Ferrite Cores
Cable Clamps for Standard and Miniature Connectors
PCLM Series
Patented
PCLM-FT ferrite core
and cable clamp,
standard size.
PCLM-FT
ferrite cable
clamp attaches
to standard
connectors to
provide EMI
protection.
Ferrite core
included.
Ferrite Cable Clamp
To Order
Compatible
Connectors
Model No.
PCLM-FT
(for standard
connectors)
PCLM-SMP-FT
(for miniature
connectors)
PCLM-SMP-RSC-FT
(for miniature
connectors)
Ordering Example: PCLM-SMP-FT, ferrite cable clamp for subminiature connector.
by Type
OST, OSTW, HST,
HSTW, OGP, HGST,
OTP
SMP, SMPW,
GMP, HGMP, HMP,
HMPW, MTP
SMP, SMPW,
GMP, HGMP, HMP,
HMPW, MTP
Maximum
Wire Gage for
Duplex Wire
14 AWG 120 225 Ferrite cable clamp,
22 AWG 105 155 Ferrite cable clamp,
22 AWG 105 155 Ferrite cable clamp,
Impedance (Ω) @±20%
PCLM-SMP-FT ferrite
core and cable clamp,
miniature size.
U Helps Reduce
EMI/RFI Noise in
Measurement Circuit
For twisted shielded wire
@25 Mhz @100 Mhz
Both models
shown larger
than actual size.
visit us online.
Description
standard size.
miniature size.
miniature size use with
RSC cable.
