Pre-Cut Front Panels
For DIn Meters anD
Controllers
For neMa 4X FIberglass enClosures
OM-HFPU Series
l Aluminum Hinged Front Panels
l Cut-Outs for
1
⁄4 DIN Size Controllers
l Easy Field-Installed Panel Kit
l Stainless Steel Hardware
l Latch Design Secures Panel
in Place with
1
⁄32, 1⁄16, 1⁄8 and
1
⁄4 Turn
Pre-Cut Panel Kits
These front panels are 2 mm (0.090”) thick
aluminum and are pre-cut for up to 4 DIN
size controllers, depending on the size of the
enclosure. The kits are simple to assemble
requiring drilling three holes with the provided template. All stainless steel hardware
is included along with installation instructions. These kits are available for
two NEMA 4X fiberglass enclosure models,
0.3 H x 0.25 W x 0.15 m D (12 x 10 x 6")
0.40 H x 0.35 W x 0.20 m D (16 x 14 x 8").
sub-panels are also available for mounting
additional electrical components.
and
Rear
Enclosures
OM-AMU series non-metallic fiberglass enclosures are designed to insulate and protect
electrical controls and components in both
indoors and outdoors applications and are
especially well suited for higher temperatures and corrosive environments. These
NEMA 4X (IP66) fiberglass JIC junction
boxes feature clear polycarbonate covers
with a variety of screw or
latching options.
For Complete Details
on CNi Series Controllers
OM-HFPU120-116DIN-2 shown installed in
OM-AMU1206LCCF fiberglass enclosure with two
CNi Series 1⁄16 DIN controllers.
The OM-HFPU Series is ONLY for the panel as pointed out in the photo.
To purchase the full enclosure, please see OM-AMU1206LCCF
OM-HFPU120-116DIN-2 front
panel kit, pre-cut for two 1⁄16 DIN
controllers shown smaller than
actual size.
Visit omega.com/cni_series
Enclosures
1
Page 2
OM-HFPU120-116DIN-2 shown
DIN Rail
and Terminal Blocks
Available, Visit us online!
installed in OM-AMU1206LCCF
fiberglass enclosure with two
CNi Series 1⁄16 DIN controllers,
shown much smaller than
actual size.
FRONT PANELS WITH DIN CUT-OUTS
To Order
MODEL NO. PANEL CUT-OUTS DIN SIZE
FRONT PANELS FOR 0.3 H x 0.25 W x 0.15 m D (12 x 10 x 6") FIBERGLASS ENCLOSURES
OM-HFPU120-132DIN-1 One
OM-HFPU120-132DIN-2 Two
OM-HFPU120-116DIN-1 One
OM-HFPU120-116DIN-2 Two
OM-HFPU120-18DIN-1 One
OM-HFPU120-18DIN-2 Two
OM-HFPU120-14DIN-1 One
FRONT PANELS FOR 0.40 H x 0.35 W x 0.20 m D (16 x 14 x 8") FIBERGLASS ENCLOSURES
OM-HFPU164-132DIN-1 One
OM-HFPU164-132DIN-2 Two
OM-HFPU164-132DIN-3 Three
OM-HFPU164-116DIN-1 One
OM-HFPU164-116DIN-2 Two
OM-HFPU164-116DIN-3 Three
OM-HFPU164-18DIN-1 One
OM-HFPU164-18DIN-2 Two
OM-HFPU164-14DIN-1 One
OM-HFPU164-14DIN-2 Two
1
⁄32
1
⁄32
1
⁄16
1
⁄16
1
⁄8
1
⁄8
1
⁄4
1
⁄32
1
⁄32
1
⁄32
1
⁄16
1
⁄16
1
⁄16
1
⁄8
1
⁄8
1
⁄4
1
⁄4
NEMA 4X FIBERGLASS ELECTRICAL ENCLOSURES
MODEL NO. DESCRIPTION DIMENSIONS
OM-AMU1206CCHF Hinge and screw closure 12 H x 10 W x 6" D
OM-AMU1206LCCF Hinge and snap latch cover 12 H x 10 W x 6" D
OM-AMU1206TCCF Hinge and twist latch cover 12 H x 10 W x 6" D
OM-AMU1648CCHF Hinge and screw closure 16 H x 14 W x 8" D
OM-AMU1648LCCF Hinge and snap latch cover 16 H x 14 W x 8" D
OM-AMU1648TCCF Hinge and twist latch cover 16 H x 14 W x 8" D
ACCESSORIES
MODEL NO. DESCRIPTION
OM-AMPOLEMNT-10 Pole mount kit for 0.25 m (10") wide fiberglass enclosure
OM-AMPOLEMNT-14 Pole mount kit for 0.35 m (14") wide fiberglass enclosure
SCE-12P10 Steel sub-panel (rear) for 0.3 x 0.25 m (12 x 10") enclosure
SCE-16P14 Steel sub-panel (rear) for 0.40 x 0.35 m (16 x 14") enclosure
Comes complete with installation instructions.
Ordering Examples: OM-HFPU120-132DIN-2, front panel with two cut-outs for
NEMA 4X fiberglass enclosure with snap latches, 12 H x 10 W x 6" D.
OM-HFPU164-116DIN-3, front panel with three cut-outs for
with snap latches, 16 H x 14 W x 8" D, and SCE-16P14, rear sub-panel for 0.40 x 0.35 m (16 x 14") enclosure.
