OM-EL-WiFi-TH

WiFi Temperature & Humidity
Data Logging Sensor

FEATURES

• Temperature and humidity data logging sensor

• WiFi capability and integrated display

• Wireless connectivity to PC via WiFi

• Easy sensor set-up using free PC software

• View and analyze multiple sensors using the PC application, including

immediate graphing of historic data

• Measurement range from -20 to +60°C (-4 to +140°F)

• 802.11b compliant

• Capable of logging greater than 500,000 data set entries

• Sensor memory stores all data even if WiFi is temporarily disconected

• IP55

• Rechargeable internal lithium polymer battery

• Congurable high and low alarms with indicator

• Max & Min readings

• Low battery indicator

• WiFi connection indicator

• USB port used for recharging

• Supplied with wall bracket and micro USB lead

ORDERING INFORMATION

WiFi Temperature &
Humidity Data Logging
Sensor

OM-EL-WiFi-TH

The OM-EL-WiFi-TH sensor measures the temperature and humidity of the environment in which it is situated. Data is transmitted wirelessly

via a WiFi network to a PC and viewed using a free software package. During conguration the sensor will search for an existing wireless

network while physically connected to the PC. It can then be placed anywhere within range of the network. If the sensor temporarily loses

connectivity with the network, it will log readings until it is able to communicate again with the PC application (max 60 days at 10 second

sample interval). The range of the sensor can be increased by using WiFi extenders.

This OM-EL-WiFi-TH is a low powered battery device. When congured using typical sampling periods (e.g. once every 60 seconds) the

sensor will operate for over one year. The battery can then be recharged via a PC or USB +5V wall adapter using the USB lead provided.

The battery is safely charged when the unit is operating between 0 to +40°C (+32 to +104°F). It is protected against charging outside this

temperature range. Sensor readings may be inaccurate during battery charging.

The software installed on the PC will allow set-up, data logging and data review. Set-up features will include sensor name, °C/°F, sample

rate, and high/low alarms. Once congured, historic data can be viewed via the graphing tool or exported into Excel. This software is

available for free from www.omega.com.

www.omega.com

Specications liable to change without prior warning Data Sheet - Issue 01 06/2012 S.T.L Applies to OM-EL-WiFi-TH Page 1 of 3

The sensor clips into the bracket.

All OM--EL-WiFi-TH sensors are thoroughly tested pre-release but the sensor may experience compatibility issues with certain WiFi

networks. In this instance we recommend the use of network accessories available on the Omega website.

Battery life

USB supply voltage

Temperature measurement range

Internal resolution

Temperature accuracy (overall error between -10°C and +60°C)

Humidity accuracy (overall error between 20%RH and 80%RH)

Operating temperature range

* Typical but will be less if frequent transmissions

Warning - do not exceed operating temperatures

Minimum Typical Maximum Unit

>1* Year

4.5v 5.5v V d.c.

-20 (-4) +60 (+140) °C (°F)

+/- 0.5 °C

+/- 1.0 °C

+/- 3.0 %RH

Every 10s 30 seconds Every 12hrs Transmisson rate

-20 (-4) +60 (+140) °C (°F)

EXAMPLE OF UNIT WHILE PHYSICALLY CONNECTED TO PC DURING SET-UP

HARDWARE

• Battery: Rechargeable via USB connection.

• ARM MCU.

• 1x microUSB Type B (bottom of unit) for connection of unit to PC. 0.5m USB cable supplied.

PHYSICAL DIMENSIONS

All dimensions in millimetres (mm)

www.omega.com

LCD SCREEN SHOTS

ADDITIONAL FUNCTIONALITY

When the user cycles through to the Recieved Signal Strength Indicator (RSSI) screen the unit automatically transmits a dummy message

every 2 seconds to enable an RSSI reading to be displayed. If there is any outstanding data waiting to be transmitted, this data will be sent

at the same time but if not it’ll just send the dummy message and the next data package will be sent as per the unit conguration.

When on Max or Min screen, holding the button for 3 seconds will clear the stored values.

The sensor can be restarted by holding the button for 10 seconds until the screen blanks and LOW is shown ashing in the top right hand

corner of the display. The sensor will retain all settings but will lose any data that has not been transferred to the PC. The sensor can be

reset to factory state by holding the button for 20 seconds but this will delete all settings and stored data.

Note: neither the restart or the reset will delete data already transferred to your PC.

www.omega.com

Specications liable to change without prior warning Data Sheet - Issue 01 06/2012 S.T.L Applies to OM-EL-WiFi-TH Page 3 of 3

WARRANTY/DISCLAIMER
