OM-EL-CC-1 RANGE
Cold Chain Data Logging Solutions
Page 2
omega.com [email protected]
Servicing North America:
U.S.A. Omega Engineering, Inc.
Headquarters: Toll-Free: 1-800-826-6342 (USA & Canada only)
Customer Service: 1-800-622-2378 (USA & Canada only)
Engineering Service: 1-800-872-9436 (USA & Canada only)
Tel: (203) 359-1660 Fax: (203) 359-7700
e-mail: [email protected]
For Other Locations Visit omega.com/worldwide
The information contained in this document is believed to be correct, but OMEGA accepts no liability for any errors it contains, and reserves
the right to alter specifications without notice.
Page 3
OM-EL-CC-1 Range
Cold Chain Data Logging Solutions
M-5665/0717
Shop online at omega.comSM e-mail: [email protected]
For latest product manuals: omegamanual.info
1
2
Your new logger comes ready to go.
Simply press and hold the buon unl the green LED lights up to start logging.
Push to start
Preset high and
low alarm levels
Status LEDs
Now place your logger in the locaon you want to monitor.
Once logging, pressing the buon will light up an LED to give a quick indicaon of the
status. It will also add a marker to the data to show that you have checked it.
No alarms will be triggered in the rst 30 minutes to allow the logger to sele at the
monitored temperature.
Green single ash
The data logger is currently logging
No alarm has been triggered
Red single ash
The data logger is currently logging
An alarm has been triggered!
Green double ash
The data logger’s memory is full
No alarm was triggered
Red double ash
The data logger’s memory is full
An alarm was triggered!
No LEDs ash
The data logger is stopped or the baery is at
No acon required
Check alarm condion in PC soware
Plug your logger in to a PC, download
your readings and start a new session
Plug your logger in to a PC, download
your readings, check alarm condion
and start a new session
Check the logger’s status using the PC
soware
Page 4
When you are ready to view the recorded data on your logger, the rst thing you
3
need to do is download the free soware.
Visit www.omega.com and click on the download link.
Double click on the downloaded .exe le, and follow the on screen prompts.
To save your data, remove the logger from the plasc sleeve and connect it to a USB port.
4
Open the soware and click on Save Data.
This will automacally open up your readings in the soware, where you can view
your data or export it in various formats.
To start your logger for the next session, click on Prime Logger.
5
Your data logger is now primed and ready to go. Place your logger in locaon ready
for the next session. To start it logging again, press and hold the buon unl the
green LED lights up.
The OM-EL-CC-1
Range
ALARMS:
HIGH
8°C
2°C
STATUS:
CHILLED GOODS
LOW
OM-EL-CC-1-001
Chilled Goods
High Alarm 8°C
Low Alarm 2°C
ALARMS:
HIGH
-16°C
-20°C
STATUS:
FROZEN GOODS
LOW
OM-EL-CC-1-002
Frozen Goods
High Alarm -16°C
Low Alarm -20°C
ALARMS:
HIGH
14°C
RIPENING GOODS
LOW
12°C
STATUS:
OM-EL-CC-1-003
Ripening Goods
High Alarm 14°C
Low Alarm 12°C
Page 5
OM-EL-CC-1-Range
Cold Chain Data Logging Soluons
• 3 data loggers for monitoring Chilled Goods, Frozen Goods
and Ripening Goods.
• No set-up required. One buon press-to-start logging.
• Pre-congured with appropriate sample rates and alarm thresholds
for each applicaon.
• Reusable with 12+ months baery life.
• Various export opons including PDF, Microso Excel and JPEG.
Each of the three Cold Chain loggers comes pre-congured for use in your
parcular applicaon – simply press the buon to start logging. During a
logging session, pressing the buon will light up the status LEDs to give a quick
indicaon as to whether the temperature has exceeded an alarm condion at any
point. Once your session has been completed, tear open the IP67-rated plasc
wallet to reveal the USB connector and plug it in to your PC. Use the free soware
for Windows to download and graph the data, and then prime your logger for its
next use.
Omega CC Soware
The simple-to-use soware allows you to view the data
graphically, in a table or export it in various formats for use
in further reporng.
Download the latest version of the soware free of
charge from www.omega.com
YOUR OM-EL-CC-1
Start / Status buon
1
Status LEDs
2
USB connector
3
Tear to open
4
Mounng point
5
Model type
6
1
6
2
67 mm (2.6”)
5
3
4
SPECIFICATIONS
Measurement range -30 to +60°C (-22 to +140°F)
48 mm (1.8”)
Accuracy (overall error) ±0.5°C maximum (±1°F)
Resoluon 0.1°C (0.1°F)
Baery Life 12 months (minimum)
IP Rang IP67*
Readings 32,600
* The data logger is protected against moisture to IP67 standard when
housed in an OM-EL-CC-BAG or equivalent.
MODEL SPECIFIC
High Alarm Level
Low Alarm Level
Logging Interval
Part Number
This unit can be quickly customized for use in mulple markets. If you have a specic monitoring applicaon, that requires dierent
sample rates or alarm thresholds, call us today.
Chilled Goods Frozen Goods Ripening Goods
8°C -16°C 14°C
2°C -20°C 12°C
10 minutes (220 days) 10 minutes (220 days) 10 minutes (220 days)
OM-EL-CC-1-001 OM-EL-CC-1-002 OM-EL-CC-1-003
ACCESSORIES
OM-EL-CC-BAG: Pack of 5 waterproof bags for data logger during use.
