Windows 98/ME/XP Version 1.20/2.0

Driver Installation

For more information, please read the installation notes.

1. Install driver for Windows 98/ME

First install the USB storage device

1. Boot the computer, and plug USB Disk into the USB Port.

2. Windows will detect the new hardware and inform you of “a
new USB storage device”. Click the “next” button to continue.

3. Windows will then ask where the driver is. Click the “browse”
button to locate the driver. Click the “next“ button to continue.

4. For WIN 2000/XP, the product does not require drivers and it is
plug and play.

2. Operation

1. Formatting USB Disk

Run command “Manager.exe”
First, please chose “Full Format”, then click the right “format”
button (Full formatting generally takes several minutes).
After the format is finished, the USB Disk will be useable.

2. Booting the USB Disk

For Win98 only run the “Manager.exe” command, and select
the “boot disk” option. (NOTE: YOU MUST FORMAT THE
USB DISK). Reboot the computer, and set the BIS’s Boot Device
to “SB-ZIP”, the boot will now enable. (NOTE: IF YOU SELECT
THE BOOT DISK, THE “ENCRYPT DISK” OPTION WILL
DISABLE)

3. Set Password and Operation

1. After formatting the USB Disk, run the “Manager.exe”
command again.

2. Select the “set password” option, quit and plug the USB Disk
back in.

3. Click the “My Computer” icon, and select the USB Disk
Option Run command, “Pass Man exe”.

4. After login, the “Pass Man” window will close and you can
use the USB Disk.

4. To Change Password

Run “Change password” and enter your own password in the
“new password” and “confirm password” boxes, then click the
“OK” button. Re-plug the USB Disk.
