pH and Temperature Data Logger with LCD Display
OM-CP-PHTEMP2000
Optional
U Large LCD Display
U Works with OMEGA
PHE-4200 Series of pH Probes
®
U Real-Time Operation
U Programmable
Engineering Units
U NIST Traceable Calibration
U Automatic Temperature
Compensation
U Programmable Start-Time
The OM-CP-PHTEMP2000 is a
battery powered, stand alone pH
and temperature data logger with
an LCD.
The OM-CP-PHTEMP2000 will
directly connect to many commonly
used pH, ORP and ISE electrodes
through a female BNC connector
mounted on its side. Temperature
compensation is done automatically
by connecting an RTD to the unit.
The storage medium is non-volatile
solid state memory, providing
maximum data security even if the
battery becomes discharged.
The OM-CP-PHTEMP2000 makes
data retrieval quick and easy. Simply
plug it into an empty com port and our
user-friendly software does the rest.
SPECIFICATIONS
TEMPERATURE
Input: 100Ω Pt RTD
Measurement Range: -40 to 110°C
(-72 to 230°F, 80 to 145 Ω)
Resolution: 0.01°C (0.001 Ω)
Calibrated Accuracy: ±0.15°C
@ 25°C ambient (±0.015 Ω)
Input Connection: Removable
screw terminal; 2-, 3- or 4-wire
interface
PH/ORP/ISE
Input Connection: Female BNC
Measurement Range:
-2.00 to 16.00 pH
Resolution: 0.01 pH (0.001 pH)
pH Accuracy: ±0.01 pH
pH EMI Susceptibility: <0.2 pH @
3V/M, 80 MHz to 1 GHz
ORP/ISE Accuracy: ±0.1 mV
ORP/ISE Susceptibility: <10 mV
@ 3V/M, 80 MHz to 1 GHz
Input Impedance: 1012 Ω typical
Windows
Software shows
data in graphical
format
PHE-4201
general-purpose
OM-CP-PHTEMP2000 shown
smaller than actual size.
RTD probe shown smaller
pH electrode
shown smaller
than actual size.
PR-11-2-100-1/4-6-E
than actual size.
Start Modes: Software
programmable immediate start
or delay start up to six months
in advance
Real-Time Recording: May be
used with PC to monitor
and record data in real time
DOT-MATRIX LCD
Dimensions:
35 H x 63 mm W (1.375 x 2.5")
Text: Configurable channel text size
Indicators: Power, status, memory
Backlight: Configurable w/auto
shut-off and contrast adjustment
Memory: 131,071 readings
per channel
Reading Rate: 1 reading every
2 seconds to 1 every 24 hours
Calibration: Digital calibration
through software
Battery Type: 9V lithium or alkaline
battery (included); user replaceable
Battery Life: 1 year battery life
at 1 minute reading rate with display
off; 30 days typical with continuous
display use; optional AC adaptor
available
Data Format: Date and time
stamped °C, °F, K, R, Ω; pH, V,
mV, engineering units specified
through software
Time Accuracy: ±1 minute/month
(at 25°C; RS232 cable not in use)
Computer Interface: PC serial
or USB (interface cable required);
115,200 baud
Software: XP SP3/Vista/7 and 8
(32-bit and 64-bit)
Operating Environment:
-5 to 50°C (23 to 122°F),
0 to 95% RH (non-condensing)
Dimensions:
84 H x 122 W x 32 mm D
(3.3 x 4.8 x 1.25")
Weight: 440 g (16 oz)
To Order
Model No. Description
OM-CP-PHTEMP2000 pH and temperature data logger with LCD display
OM-CP-PHTEMP2000-CERT pH and temperature data logger with LCD display
OM-CP-IFC200 Windows software and 1.8 m (6') USB
OM-CP-SVP-SYSTEM FDA 21 CFR part 11 compliant IQ/OQ/PQ secure
OM-CP-BAT103 Replacement 9V lithium battery
OM-CP-110-PWR-2000
OM-CP-220-PWR-2000
PHE-4201
PR-11-2-100-1/4-6-E
Operator’s manual and USB cable are included with the OM-CP-IFC200 (software is required
to operate the data logger and is sold separately).
Ordering Example: OM-CP-PHTEMP2000, pH and temperature data logger
and OM-CP-IFC200, Windows software and 1.2 m (4’) USB cable.
General purpose pH electrode
110 Vac power adaptor
220 Vac power adaptor
General purpose 100Ω RTD probe, 6" sheath,
and NIST calibration certificate
interface cable
software validation workbook and software
package (unlimited users, license per computer)
1
⁄4" diameter
