Omega OMB-NET6000 User Manual
Includes:
ENCORE SOFTWARE
FOR OMB-NET6000 SERIES
Ethernet-Based Temperature,
Voltage and Strain
Measurement Modules
e-mail: info@omega.com
For latest product manuals:
omegamanual.info
Shop online at
omega.com
®
User’s Guide
®
Documentation on CD
System Requirements:
Windows® 7/Vista/XP SP2 (32-bit)
/2000 SP4
®
Encore Software
For OMB-NET6000 Series
Rev. 1.1
®
,ENGINEERING INC.
®
800-DAS-IEEE (800-327-4333)
© COPYRIGHT 2012 OMEGA ENGINEERING, INC.
Table of Contents
Introduction ........................................................................................................................................................ 3
System Requirements ......................................................................................................................................... 3
PC ..................................................................................................................................................................................... 3
Operating system .............................................................................................................................................................. 3
Installing Encore software .................................................................................................................................. 3
Installing OMB-NET6000 Series hardware........................................................................................................ 3
Adding a device to an Encore project ................................................................................................................. 4
Encore user interface .......................................................................................................................................... 6
Acquiring and logging data ................................................................................................................................ 7
Playing back data ................................................................................................................................................ 7
Performing computations on logged data ........................................................................................................... 8
Exporting data to Microsoft® Excel® .................................................................................................................. 9
Encore Help file .................................................................................................................................................. 9
Contact Omega Engineering ............................................................................................................................... 9
2
Encore Software for the OMB-NET6000 Series
Introduction
Encore is interactive measurement software designed for acquiring, analyzing, logging, and viewing data from
Omega Engineering OMB-NET6000 Series data acquisition devices. No programming is required. This
document shows you how to perform the following tasks with Encore software:
Acquire data from an analog input channel
Log the data
Play back the logged data
Analyze the signal
Export the data
System Requirements
The system requirements are based on acquiring and logging data from all 12 channels of an OMB-NET6220
device that is running at 100 kHz (1.2 MS/s).
PC
Minimum Requirements:
o CPU: Intel® Pentium® 4, 3.0 GHz or equivalent
o RAM: 1 GB
o Monitor: 1024 by 768 screen resolution
Recommended Requirements:
o CPU: Intel CoreTM 2 Duo Family
o RAM: 2+ GB
o Monitor: 1024 by 768 screen resolution
Operating system
The following Windows operating systems are supported:
Windows 7 (32-bit or 64-bit)
Windows Vista (32-bit or 64-bit)
Windows XP SP2 (32-bit)
Windows 2000 SP4
Installing Encore software
Complete the following steps to install Encore software:
1. Close all running applications on the host PC.
2. Insert the Encore CD into your CD drive and wait for the installation program to start.
If the installation program does not start automatically, navigate to the root of the CD and double-click
Install.exe.
3. Follow the instructions on the installation dialog boxes.
In addition to Encore software, the installation CD includes the Encore Help file, readme, and hardware user's
guides for OMB-NET6000 Series device.
Installing OMB-NET6000 Series hardware
Refer to the Quick Start booklet that shipped with your OMB-NET6000 Series device or to the hardware user’s
guide for information about connecting the hardware to your system.
3
