3-Prong Miniature Connectors
5.8
OMEGA
G
+ –
OMEGA
G
+
–
3.3 DIA.
TYP.
23.1
12.7
2.3
7.9
3.0
7.9
0.8
3.0
7.9
26.9
10.4
7.9
23.6
MALE FEMALE
(0.13)
(0.23)
(0.09)
(0.31)
(0.12)
(0.31)
(0.91)
(0.50)
(1.06)
(0.41)
(0.03)
(0.12)
(0.31)
(0.93)
(0.31)
4.93 (0.19'') WIRE
ACCESS HOLE
U
W
U
For Thermocouples, RTD’s and 3-Wire Thermistors
MTP Series
U Supplied with Shielded Wire
Copper Connection Pin
U Heavy Duty Construction
U Color-Coded
U Accepts Stranded or Solid
Wire up to Size 20 AWG
U Combination Phillips/
Slot Screws
U Glass-Filled Nylon
Rated from -29 to 180°C
(-20 to 356°F)
Note: Minor discoloration of connector may occur between 150°C (302°F)
and 180°C (356°F). Electrical properties are not affected.
We make running changes
when technical advances allow.
Check at time of ordering
for additional features.
Miniature uncompensated
version male and female
shown actual size.
Maximum wire
diameter is
3 mm (0.125").
Discount Schedule
1-10 ..................................................... Net
11-49 ....................................................5%
50-99 ..................................................10%
100-999 ..............................................15%
1000-4999 ..........................................20%
5000 and over.....................................25%
For OMEGA’s
Selection of Connector
Accessories
Visit Us Online
G
Also Available!
Transmitters and Ferrite Cores for EMI Protection
SPRTX, 2-wire RTD connector/
transmitter.
PCLM-SMP -FT
cable clamp
with ferrite core
for EMI protection.
Connector sold
separately.
To Order
Dimensions: mm (inch)
PATENTED
Compensating Alloy Model No.
Type of Thermocouple Used in Connector ANSI
Alloy Used with Shell Color
Code
†
CHROMEGA
Copper-Constantan Copper Constantan Copper Blue MTP-T-(*)
Connector + – G Color Code
®
-ALOMEGA® CHROMEGA ALOMEGA Copper Yellow MTP-K-(*)
Iron-Constantan Iron Constantan Copper Black MTP-J-(*)
CHROMEGA-Constantan CHROMEGA Constantan Copper Purple MTP-E-(*)
Uncompensated Copper Copper Copper White MTP-U-(*)
†
K, T, J, E, R, S and B are ANSI designations.
*To order, specify “M” for male connector only, or “F” for female connector only.
OMEGALLOY Type N is generically known as Nicrosil-Nisil.
OMEGA’s subminiature connectors are molded of high performance glass-filled nylon. Connectors will accommodate protection tubes from
0.25 mm to 3.17 mm (0.010" to 1⁄8") O.D. Bushings can be purchased for an additional cost; order BB-SMP-1.
OMEGALLOY
®
OMEGA-P® OMEGA-N® Copper Orange MTP-N-(*)
