COMPACT ULTRASONIC,
SOLID STATE LIQUID LEVEL SWITCH
LVSW-710/LVSW-720
U Easy to Install
U No Moving Parts
U Epoxy-Sealed Integral
Electronics with Sensor
U Low-Cost Replacement
to Mechanical Float
Dimensions: mm (inch)
LVSW-710
HEX 25.4 (1.0)
9.5 (0.375)
¼ NPT
THREAD
(0.150)
ALARM POINT
3.81
Sensor: 316 LSS
Temperature: -29 to 80°C (-20 to 176°F)
Pressure: Up to 250 psig (1724 kPa)
Mounting:
model number)
Relay Output: 1 A SPST (NO, C)
The LVSW-710/720 compact
solid state liquid level switch is a
great replacement for mechanical
float-type liquid level devices. The
switch employs proven ultrasonic
technology and solid state integral
electronics in a small package.
The LVSW-710/720 provides
NO
C
CHASSIS
GROUND
RED
BROWN
WHITE
BLACK
reliable operation in virtually any
liquid, regardless of viscosity. This
eliminates problems of stickiness
and failure rate due to finite
mechanical life inherent in the
mechanical float design. The
combination of fully epoxy-sealed
electronics and ultrasonic sensing
technology will provide years of
maintenance-free service.
RELAY OUTPUT
GROUND (–)
GREEN
+5–30 Vdc
RELAY
OUTPUT
19 (0.75)
47.6
(1.875)
7.6 (0.3)
9.5 (0.375)
SPECIFICATIONS
Repeatability: 2 mm or better
Delay: 0.5 sec
Input Power: 5 to 30 Vdc
Leakage Current: Less than 50 uA
Wire Length: 300 mm (12")
Protection: Transient, reverse polarity
To Order
Model No. Description
K-X
LVSW-710 ¹⁄₄ NPT level switch, 316 LSS SPST NO relay
LVSW-720 ¹⁄₂ NPT level switch, 316 LSS SPST NO relay
Accessory
Model No. Description
PSU-93 Unregulated 24 Vdc power supply
Comes complete with operator’s manual.
LVSW-710, shown
larger than actual size.
LVSW-720
HEX 25.4 (1.0)
19 (0.75)
60
(2.365)
10 (0.40)
16 (0.625)
1
⁄4 or 1⁄2 NPT (depending on
(0.150)
6.35 (0.25)
9.5 (0.375)
½ NPT
THREAD
3.81
ALARM POINT
