POINT LEVEL SENSORS
Drum Level Indicators
LV-110 Series
Vertical Mount Typical
U Compatible with Most
Liquids and Chemicals
U Models Rated to
Maximum 750 psi
U Drum Level Indicators
Require No Electricity
The LV-110 Series drum level
indicators are compact,
self-contained liquid-level indicators
designed for use in 55-gallon
drums. A magnet-equipped float
senses level, and the user can
obtain a readout by removing the
protective cap and reading the
indicator measuring tape.
LV-110 units can be used in either
horizontal or vertical drums.
LV-113 shown
smaller than
actual size.
SPECIFICATIONS
Temperature Range:
316 SS: -40 to 149°C (-40 to 300°F)
Brass/Buna: To 82°C (180°F) in
water, -40 to 110°C (-40 to 230°F)
in oil
Pressure Rating: 750 psi for 316 SS
float; 300 psi for Buna floats
Mounting: 2 NPT
Tube/Fitting Size:
Mounting Attitude: Vertical ±30°
1
⁄2" OD tube
To Order
Length (L) Float Specific
Model No. Drum Position (inch) Stem/Float Gravity
LV-110 22 horizontal Brass/Buna 0.48
LV-111 22 horizontal 316 SS 0.64
LV-112 33 vertical Brass/Buna 0.48
LV-113 33 vertical 316 SS 0.64
LV-115 33 vertical PVC 0.8
Ordering Example: LV-113, 316 SS drum level indicator, 33" vertical.
K-35
