[47.63]
DIP SWITCH
SERIES LCT316
Timers
COUNT DOWN DIGITAL TIMER
Quick Installation, Digital Input, Audible Alarm
The Series LCT316 Count Down Digital Timer provides accurate countdown timing
for a variety of applications. The timer can be triggered remotely using the digital input
terminals or locally via the set button. Time intervals can be set up to 999 minutes or
seconds and an internal buzzer will sound when the time interval has expired.
BENEFITS/FEATURES
• 1secondto999minuteeldsettimeinterval
• Audible alarm for status indication
APPLICATIONS
• Commercial cooking equipment
• Commercial dish washers and refrigeration equipment
MODEL CHART
Model Supply Power
LCT316-100
LCT316-200
LCT316-300
LCT316-400
115 VAC
230 VAC
12 VAC/DC
24 VAC/DC
DWYER INSTRUMENTS, LLC | dwyer-inst.com364
1-11/32
[33.99]
3
[76.20]
SPECIFICATIONS
Operating Temperature Range: 32 to 158°F (0 to 70°C).
Control Output Ratings: Relay, SPST NO, 16 A at 250 VAC resistive.
Status Light: LED shows time and operation.
Inputs: Digital input for start and reset.
Supply Voltage: 115 VAC, 230 VAC, 12 VAC/DC, 24 VAC/DC depending on the
model.
Power Consumption: 4 VA.
Weight: 5.6 oz (158.8 g).
Compliance: CE, cURus.
2-7/16
[61.91]
[28.57]
1-1/8
