Omega i.BTX-M User Manual

MADE IN
User’s Guide
www.omega.com
e-mail: info@omega.com
For latest product manuals
www.omegamanual.info
Shop on line at
Barometric Pressure
+ Temperature
Pressure/Temp
http://192.168.1.200
Alarm SP1(above)=0095.0 F Alarm SP2(below)=0070.0 F
Temperature
122
9/Div
32
Mon Jul 24 09:42:10 PST 2006
78.3
Pressure/Temp
F
(1 Hour/Div)
1 Day
1 Minute
1 Hour 1 Day 1 Week 1 Month 1 Year
Main Menu
USA
PressureArchives_Inactive
hPa
Tues Jul 25 08:42:10 PST 2006
1000.3
1200
80/Div
400
®
It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing certification of its products to the European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.
The information contained in this document is believed to be correct, but OMEGA Engineering, Inc. accepts no liability for any errors it contains, and reserves the right to alter specifications without notice.
WARNING: These products are not designed for use in, and should not be used for, patient-connected applications.
!
This device is marked with the international caution symbol. It is important to read the Setup Guide before installing or commissioning this device as the guide contains important information relating to safety and EMC.
®
®
OMEGAnet® On-Line Service
www.omega.com
Internet e-mail
info@omega.com
Servicing North America:
USA: One Omega Drive, P.O. Box 4047
ISO 9001 Certified Stamford CT 06907-0047
 TEL: (203) 359-1660 FAX: (203) 359-7700  e-mail: info@omega.com
Canada: 976 Bergar  Laval (Quebec) H7L 5A1  TEL: (514) 856-6928 FAX: (514) 856-6886  e-mail: info@omega.ca
For immediate technical or application assistance:
USA and Canada: Sales Service: 1-800-826-6342 / 1-800-TC-OMEGA
 Customer Service: 1-800-622-2378 / 1-800-622-BEST  Engineering Service: 1-800-872-9436 / 1-800-USA-WHEN
Mexico and TEL: (001)800-TC-OMEGA® FAX: (001) 203-359-7807 Latin American: En Espa
 e-mail: espanol@omega.com
ñol: (001) 203-359-7803
®
®
®
Servicing Europe:
Czech Republic: Frystatska 184, 733 01 Karviná
 TEL: +420 59 6311899 FAX: +420 59 6311114  e-mail: info@omegashop.cz
Germany/Austria: Daimlerstrasse 26, D-75392 Deckenpfronn, Germany  TEL: +49 7056 9398-0 FAX: +49 7056 9398-29  Toll Free in Germany: 0800 639 7678  e-mail: info@omega.de
United Kingdom: One Omega Drive
ISO 9002 Certified River Bend Technology Centre
 Northbank, Irlam Manchester M44 5BD United Kingdom  TEL: +44 161 777 6611 FAX: +44 161 777 6622  Toll Free in England: 0800 488 488  e-mail: sales@omega.co.uk
TABLE OF CONTENTS
Part 1: Introduction
1.1 Safety and EMC Considerations........................................................................2
1.2 Before You Begin ................................................................................................2
1.3 Description ..........................................................................................................2
Part 2: Hardware
2.1 Mounting .............................................................................................................4
2.2 DIP Switches........................................................................................................4
2.3 Parts of iServer Unit ...........................................................................................5
2.4 Disassembly Instruction ....................................................................................6
2.5 Network Communication Interfaces .................................................................7
2.5.1 10Base-T RJ-45 Pinout.........................................................................7
2.5.2 10Base-T Crossover Wiring.................................................................7
2.6 Relay Wiring Connections .................................................................................7
2.7 Running on Battery Power ................................................................................7
Part 3: Network Configuration
3.1 Network Protocols .............................................................................................8
3.2 Ethernet (MAC) Address ....................................................................................8
3.3 DHCP ...............................................................................................................9
3.4 DNS ...............................................................................................................9
3.5 IP Address ...........................................................................................................9
3.5.1 Default IP Address..............................................................................10
3.6 Port Number ......................................................................................................10
Part 4: Operations
4.0 Testing the Connection.....................................................................................11
4.1 iCONNECT Software .........................................................................................12
4.2 Setting a new IP Address over the Network ..................................................13
4.3 Setup and Operation using the iServer Web Page .......................................14
4.3.1 Read Sensor........................................................................................15
4.3.1.1 Java Runtime Environment 1.4 Setup Instructions.............15
4.3.1.2 Java Runtime Environment 1.5 (5.0) Setup Instructions ....16
4.3.1.3 Browser Proxy Selection ........................................................16
4.3.2 Adjustable Chart .................................................................................17
4.3.3 Retrieving Data from Flash ................................................................18
4.3.4 Access Control ..................................................................................19
4.3.5 Configuration ......................................................................................20
4.3.6 Sensor Parameter ...............................................................................26
4.4 Telnet Setup ......................................................................................................27
4.5 HTTPGET Program............................................................................................27
4.5.1 HTTPGET using Port 1000 .................................................................28
4.5.2 HTTPGET and ARP to setup Device IP Address .............................29
4.6 ARP Protocol .....................................................................................................30
4.7 iLOG Software ...................................................................................................31
4.8 Mail Notifier Software .......................................................................................32
4.8.1 Installation...........................................................................................32
4.8.2 Program Options Setup and Configuration ....................................33
4.8.3 Device Setting Setup and Configuration ..........................................34
Part 5: Specifications .............................................................................................................35
Part 6: Factory Preset Values ......................................................................................................36
Appendix A Glossary.............................................................................................................37
Appendix B IP Address ........................................................................................................38
Appendix C IP Netmask.........................................................................................................39
Appendix D ASCII Chart .......................................................................................................40
ASCII Chart Control Codes .............................................................................41
Part 7: Approvals Information
7.1 Electromagnetic Compatibility (EMC) ............................................................42
7.2 FCC ..............................................................................................................42
i
LIST OF FIGURES:
Figure 1.1 iServer and iLD Big Display on the Ethernet Network........................3
Figure 2.1 Mounting ................................................................................................4
Figure 2.2 DIP Switches...........................................................................................4
Figure 2.3 Parts of iServer Unit...............................................................................5
Figure 2.4 Opening the Unit ....................................................................................6
Figure 2.5 RJ45 Pinout ............................................................................................7
Figure 2.6 10Base-T Crossover Cable Wiring .......................................................7
Figure 2.7 Relay Connections ................................................................................7
Figure 3.1 Labeling ..................................................................................................8
Figure 3.2 DIP Switch on Bottom Side of iServer..................................................9
Figure 3.3 Telnet Login into the iServer ...............................................................10
Figure 4.1 Pinging the iServer from MS-DOS Prompt ........................................11
Figure 4.2 Assigning an IP Address using iCONNECT ......................................12
Figure 4.3 Accessing the iServer’s Home Page Menu........................................12
Figure 4.4 Access Control ...................................................................................13
Figure 4.5 iServer Home Page ..............................................................................14
Figure 4.6 Login and Administration Password .................................................14
Figure 4.7 Read Sensor .........................................................................................15
Figure 4.8 Adjustable Chart...................................................................................17
Figure 4.9 iFLASH Download Utility .....................................................................18
Figure 4.10 Access Control ....................................................................................19
Figure 4.11 Configuration ......................................................................................21
Figure 4.12 Sensor Parameter ................................................................................26
Figure 4.13 Remote End Char .................................................................................26
Figure 4.14 ARP Commands and Responses .......................................................30
Figure 4.15 iLOG Software Logging Data ..............................................................31
Figure 4.16 iServer Mail Notifier Main Window......................................................32
Figure 4.17 iServer Mail Notifier Profile Setup ......................................................33
Figure 4.18 iServer Mail Notifier Device Setting ...................................................34
LIST OF TABLES:
Table 2.1 Parts of iServer Unit ..............................................................................5
ii
NOTES, WARNINGS and CAUTIONS
Information that is especially important to note is identified by the following labels:
• NOTE
• WARNING or CAUTION
• IMPORTANT
• TIP
NOTE: Provides you with information that is important to successfully
setup and use the iServer.
CAUTION: Tells you about the risk of electrical shock.
CAUTION: Risk of danger. Tells you of circumstances or practices
that can effect the instrument’s functionality and must refer to accompanying documents.
TIP: Provides you helpful hints.
FEATURES
Virtual Chart Recorder
Web Server
Temperature
Barometric Pressure
Accurate Readings
Password Protection
Email Alarms
Data Logging
Two Relay Alarms
2, 4 or 8M bytes Flash Memory Card
Real-Time Clock
LCD Display
UPS / Stand-alone 9Vdc Battery
1
PART 1
INTRODUCTION
1.1 Safety and EMC Considerations
Refer to the CE Approvals Section.
EMC Considerations
Whenever EMC is an issue, always use shielded cables.
Never run signal and power wires in the same conduit.
Use twisted-pair wires for signal connections.
Install Ferrite Bead(s) on signal wires close to the instrument if EMC problems persist. Failure to follow all instructions and warnings may result in injury!
1.2 Before You Begin Inspecting Your Shipment: Remove the packing slip and verify that you have received
everything listed. Inspect the container and equipment for signs of damage as soon as you receive the shipment. Note any evidence of rough handling in transit. Immediately report any damage to the shipping agent. The carrier will not honor damage claims unless all shipping material is saved for inspection. After examining and removing the contents, save the packing material and carton in the event reshipment is necessary.
Customer Service: If you need assistance, please contact the Customer Service Department nearest you.
Manuals, Software: The latest Operation Manual as well as free software and iServer Mail Notifier are available at the website listed on the cover page of this manual or
on the CD-ROM enclosed with your shipment.
1.3 Description View Temperature + Barometric Pressure with a Web Browser. The iServer let’s you
monitor and record Temperature and Barometric Pressure over an Ethernet network or the Internet with no special software except a Web browser. The iServer serves Active Web Pages to display real time readings and display charts of temperature and barometric pressure, or log data in standard data formats for use in a spreadsheet or data acquisition program such as Excel or Visual Basic.
Adjustable Charts. The Java™ Applet chart scales are fully adjustable on the fly. For example, the chart can display one day, one week, one month or one year. Temperature and barometric pressure can be charted across the full span (0-70ºC) or within any narrow range (such as 20-30ºC). Barometric pressure can be displayed in hectopascals (hPa), millimeters of Mercury (mmHg), or inches of Mercury (inHg).
2
Award-winning Technology. The iServer is simple to install and use. It features award winning technology that requires no special software except a Web browser. The iServer connects to an Ethernet Network with a standard RJ45 connector and sends data in standard TCP/IP packets. It is easily configured with a simple menu using a Web browser and can be password protected. From within an Ethernet LAN or over the Internet, the user simply types its IP address or an easy to remember name such as "Cleanroom 5" or "Midwest Server Room" in any Web Browser, and the iServer serves a Web Page with the current readings. The iServer comes complete with one temperature/barometric pressure wand probe, full documentation and software.
Alarms and Email. If temperature and/or barometric pressure exceeds a set limit, the iServer can trigger an alarm that could be sent by email to an Internet enabled pager or cell phone.
A standard web browser can be used to monitor and chart temperature and barometric pressure. The browser can also be used to configure the device’s IP address, passwords for access and overall configuration parameters. An iLD Big Display can display temperature and barometric pressure received from an iServer over the Ethernet or the Internet.
The following example illustrates how you can hookup an iServer and iLD to your network:
Figure 1.1 iServer and iLD Big Display on the Ethernet Network
3
COMPUTER with
Standard Web Browser
COL ON TX RX
4
PART 2 HARDWARE
2.1 Mounting
Position unit where required. Mark and drill holes as required.
If unit is to be mounted on a flat surface, you may take the bottom rubber feet off the unit.
It is recommended that you ground your unit by wrapping a wire around the mounting tab screw and tightening a lock washer so that it embeds itself into the metal of the mounting tab. Or
by connecting a wire to the Return/Ground position of the relay connector, see Figure 2.7.
Figure 2.1 Mounting
Figure 2.2 DIP Switches
2.2 DIP Switches
The iServer is shipped with all DIP switches in "OFF" position.
DIP
Switch Usage
1) N/C - not used
2) To change to default factory settings
3) To enable/disable DHCP
4) N/C - not used
To set the iServer to factory default settings, slide DIP switch #2 to ON position. Power the iServer on and wait about 10 seconds until the iServer fully boots up. Set the DIP switch #2 back to OFF position (it does not matter if the iServer is powered ON or OFF, just make sure that the DIP switch is set to OFF, otherwise, every time the unit is power-cycled the factory settings will take over.
To enable the DHCP, slide DIP switch #3 to ON position and power the unit on. Besides using DIP switch #3 you can enable DHCP by settting the iServer’s IP address to 0.0.0.0. An iServer with IP address of 0.0.0.0 will request an IP address, gateway address, and subnet mask from the DHCP server over the Ethernet.
0.25 [6.4]
3.56 [90.3] 2.00 [50.8]
9.15 [232.3]
1.44 [36.6]
ON
OFF
0.14 [3.6]
1.78 [45.2]
2
1
3.55 [90.2]
3.05 [77.5]
2.42 [61.6]
0.25 [6.4]
0.30 [7.7]
ON
4
3
OFF
4
3
2
1
9-12 Vdc
0.12 [3.0]
5
2.3 Parts of the iServer Unit
Figure 2.3 Parts of the iServer Unit
Table 2.1 Parts of iServer Unit
ETHERNET RJ45 interface for 10BASE-T connection.
iServer RESET Button: Used for power reseting the iServer board (Ethernet connection).
FLASH RESET Button: Used for power reseting the Flash Memory Card/LCD board.
ACTIVITY LED (Red) Blinking: Indicates network activities (receiving or sending packets).
NET LINK LED (Green) Solid: Indicates good network link.
DIAGNOSTICS LED (Yellow) Blinking: Indicates transmitting data from iServer to flash memory card.
When DHCP enabled, it remains solid until DHCP IP address is received. LED (Green) Blinking: Indicates receiving data by the iServer from flash memory card
UNITS
Button: Change display units of measurement from °C to °F
TIME Button: Change display from DATE and TIME to Pressure and Temperature
STBY Button: Will stop the Flash from recording.
BKLT Button: Display Back Light
When using the small push buttons, hold the button until “WAIT” is displayed on the LCD and then release.
RJ45 interface
Side or Bottom Wire Entry for Relay Connector
Removable Plug Connector for Relays under the Cover
iServer
iServer Reset Button
ACTIVITY NETWORK LINK DIAGNOSTICS AND STATUS
1
8
ETHERNET
RESET
iServer LEDs
16 Digit LCD Display
6
1
Flash Memory Card
UNITS STBYTIME BKLT
BAROMETER/TEMPERATURE
Probe Handle Clip
Mounting Tabs
Buttons
Flash Memory Card Reset Button
DB9
Connector
9-12 Vdc
dc Power Input
6
2.4 Disassembly Instruction
You may need to open the unit for one of the following reasons:
To wire relay connector. (Refer to Figure 2.7)
To connect or replace the battery.
To change S5 jumper. In the absence of AC power, and if S5 is installed, the LCD
Backlight and iServer Board will be on and running on the battery power. Refer to Section 2.7.
Disconnect the power supply before proceeding.
Remove Cover as shown.
Figure 2.4 Opening the Unit
COVER
FLASH
CARD
RELAY
CONNECTOR
FLASH RESET
SWITCH
JTAG
S5
TRAY
MOUNTING SCREWS (2)
S5 (WITH LONG PINS)
REMOVE BATTERY CLIP INSULATOR COVER AND STORE WHERE SHOWN WHEN 9V BATTERY IS BEING USED.
KEEP INSULATOR COVER ON BATTERY CLIP WHEN BATTERY IS NOT BEING USED
7
2.5 Network Communication Interfaces
2.5.1 10Base-T RJ-45 Pinout
The 10BASE-T Ethernet network (RJ45) system is used in the iServer for network connectivity. The 10 Mbps twisted-pair Ethernet system operates over two pairs of wires. One pair is used for receiving data signals and the other pair is used for transmitting data signals. This means that four pins of the eight-pin connector are used.
2.5.2 10Base-T Crossover Wiring
When connecting the iServer directly to the computer’s network port, the transmit data pins of the computer should be wired to the receive data pins of the iServer, and vice versa. The 10Base-T crossover cable with pin connection assignments are shown below.
Use straight through cable for connecting the iServer to an Ethernet hub. The ports on the hub are already crossed.
2.6 Relay Wiring Connections
To access the Relay Connector you must remove the cover, refer to Section 2.4.
It is recommended that you ground your unit by connecting a wire to the Ground/Return position of the relay connector. Or
by wrapping a wire around the mounting tab screw and tightening a lock washer so that it embeds itself into the metal of the mounting tab.
2.7 Running on Battery Power
The battery and S5 jumper are installed: if there is a power outage the iServer board will be fully functional including the LCD backlight “ON” for approximately 1 hour. You need to make sure that the LCD/PWR field on the Configuration page of the iServer is set to UPS (see Section 4.3.5.F)
Battery installed and S5 jumper in storage position (Factory Default): if there is a power outage the LCD Backlight and iServer Ethernet board will not run, but
the unit will be
collecting and storing data for approximately 10 days. When you first connect the battery, without the AC power adaptor, the unit will be in “Sleep
Mode”, in order to save power, and the LCD will display “Flash Standby” (provided that S5 jumper is not installed). When battery is installed, plug the AC adaptor into unit and push the Flash Reset Button (refer to Figure 2.3 or Figure 2.4). Unit is now ready to be configured for recording the data. Also, if the AC adaptor is unplugged after configuring the unit, it will be ready for recording data.
If you want to move the unit to a different location, remove AC adaptor and press the Flash Reset button. Repeat the steps in the above paragraph.
Figure 2.7 Relay Connections
Figure 2.6 10Base-T
Crossover Cable Wiring
Pin Name Description
1 +Tx + Transmit Data 2 -Tx - Transmit Data 3 +RX + Receive Data 4 N/C Not Connected 5 N/C Not Connected 6 -Rx - Receive Data 7 N/C Not Connected 8 N/C Not Connected
Figure 2.5 RJ45 Pinout
RELAY 2 RELAY 1
623451
9 Vdc
NO2
COM2
RTN
NO1
COM1
8
PART 3
NETWORK CONFIGURATION
3.1 Network Protocols
The iServer can be connected to the network using standard TCP/IP protocols. It also supports ARP, HTTP (WEB server), DHCP, DNS and Telnet protocols.
3.2 Ethernet (MAC) Address
MAC (Media Access Control) address is your computer's unique hardware number. When you're connected to the LAN from your computer, a correspondence table relates your IP address to your computer's physical (MAC) address. The MAC address can be found on a label attached to your device and contains 6 bytes (12 characters) of hexadecimal numbers XX:XX:XX:XX:XX:XX hex
For example: 0A:0C:3D:0B:0A:0B
Remove the small label with the default IP address and there will be room to put your IP address. See Figure 3.1
Figure 3.1 Labeling
9
3.3 DHCP
DHCP, Dynamic Host Configuration Protocol enables individual computers or devices to extract their IP configurations from a server (DHCP server). If the DHCP is enabled on your iServer, as soon as the iServer is connected to the network, there is an exchange of information between DHCP server and the iServer. During this process the IP address, the Gateway address, and the Subnet Mask will be assigned to the iServer by the DHCP server. Note that the DHCP server must be configured correctly to do such assignment.
If fixed or static IP address is desired, the DHCP must be disabled. The iServer is shipped with DHCP disabled (factory default). The DHCP can be enabled by setting the DIP switch # 3 to the “ON” position (refer to Figure 3.2).
Figure 3.2 DIP Switch on the Bottom Side of iServer
3.4 DNS
DNS, Domain Name System enables individual computers and devices to be recognized over a network based on a specific name instead of an IP address. For example, instead of having to use http://192.168.1.200 (IP address), you would use only http://eis03ec or any eight character name stored as Host Name under the Access Control page in the iServer Home Page. The default DNS name for an iServer is "eis" followed by the last four digits of the MAC address of that particular iServer.
1. It is very important to communicate with the network administrator in order to understand the DHCP and its existing configurations on the host server, before enabling the DHCP on the iServer.
2. The iServers are shipped with a default static IP address of
192.168.1.200 and Subnet Mask of 255.255.255.0.
3. On Novell networks or Windows 2000 Server where the DCHP is an updated function of DNS, this feature may be beneficial since a particular name can be assigned eliminating the need for the IP address, as described in
Section 3.4.
3.5 IP Address
Every active device connected to the TCP/IP network must have a unique IP address. This IP address is used to build a connection to the iServer. Every computer using TCP/IP should have a unique 32-bit address. It is divided into two portions, the network ID and the host ID. For instance, every computer on the same network uses the same network ID. At the same time, all of them have a different host ID. For more details about the IP address see Appendix B.
DIP switch # 3 shown in “ON” position
To enable the DHCP, slide DIP switch #3 to ON position and power the unit on. Besides using DIP switch #3 you can enable DHCP by settting the iServer’s IP address to 0.0.0.0. An iServer with IP address of 0.0.0.0 will request an IP address, gateway address, and subnet mask from the DHCP server over the Ethernet
ON
ON
OFF
4
3
2
1
OFF
4
3
2
1
3.5.1 Default IP Address
The iServer is shipped with a default IP address set to 192.168.1.200 and Subnet Mask of 255.255.255.0. If you are going to use a Web browser or Telnet program to access the iServer using its default IP address, make sure that the PC from which you’re establishing the connection has an IP address that is in the same range as the iServer’s IP address (192.168.1.x, where x can be any number from 1 to 254.
Your PC’s IP address cannot
be the same as the iServer’s IP address).
You also need to make sure that your PC’s Subnet Mask is 255.255.255.0. This is a good way to access the iServer over the network and make any configuration changes needed. If 192.168.1.200 is already in use on your network, use an Ethernet crossover cable between your computer and the iServer to change the IP address or any other settings within the iServer.
3.6 Port Number
All TCP connections are defined by the IP address and a port number. A port number is an internal address that provides an interface between an application running on your computer and the network through the TCP/IP protocol.
There are three default TCP socket port numbers assigned to the iServer:
1. Port (socket) number 1000 when using HTTPGET program.
2. Port (socket) number 2000 when trying to access the sensor (probe) connected to the port of the iServer to receive ASCII data.
3. Port (socket) number 2002 when trying to access the iServer itself for Power Recycling the iServer remotely. This can be done using Windows standard Telnet application.
Power recycling the iServer can also be done through the iServer’s Web Server (see Section 4.2).
Telnet stands for Telecommunications Network, is a protocol that provides a way for users (or clients) to connect to computers (or servers) on a network, whether in the next building or across the world.
Example: C:\>Telnet 192.168.1.200 2002
You will then get the following screen.
Figure 3.3 Telnet Login into the iServer
You can open a Telnet session using other terminal emulation programs like Tera Term Pro (downloadable from the internet), which is a free software for MS-Windows. It supports VT100 emulation, Telnet connection and serial com port connections.
101011
C:\
Type "reset"
to reboot
the server
The default
Telnet 192.168.1.200
Firmware Version x.xx Admin. Password:00000000
Admin. Login Successful reset
The unit will reset in 5 seconds _
Admin. Password
PART 4
OPERATIONS
This iServer can be used and configured in several ways, depending on user’s preference and network setup. It can be configured using a Web browser, like Netscape or Internet Explorer. It can also be configured using NEWPORT’s iCONNECT Configuration Software.
If DHCP and DNS servers are used, the connection is very simple, no need to find the right IP address or watch for network conflicts, these are all done for you by your network DHCP and DNS server. All that is left for you to do, is to enable DHCP on the iServer (see Section 2.2) and use a straight network cable to connect the iServer to a hub and power it up.
If DHCP is not the preferred method, you can configure your PC’s network connection with an IP address of 192.168.1.x that is in the same range as the iServer’s default IP address (192.168.1.200) and connect to the iServer using a cross-over network cable between your PC’s network port and the iServer. After you’re done with configuring the iServer, you can always set your PC back to its original settings.
On your computer, from the MS-DOS Prompt window type "ping 192.168.1.200” and press Enter. If DHCP and DNS servers are used type “ping eisxxxx”, where xxxx are the last four digits of the iServer’s MAC address, located on the back of the device. You should get a reply as shown in Figure 4.1.
4.0 Testing the Connection
Figure 4.1 Pinging the iServer from MS-DOS Prompt
This proves that the connection is proper and you can get into configuration or run mode using the Telnet or Web browser.
C:\>ping eis03ec Pinging eis03ec with 32 bytes of data:
Reply from eis03ec: bytes=32 time=15ms TTL=60 Reply from eis03ec: bytes=32 time=8ms TTL=60 Reply from eis03ec: bytes=32 time=8ms TTL=60 Reply from eis03ec: bytes=32 time=8ms TTL=60
Pinging statistics for eis03ec: Packets: Sent=4, Received=4, Lost=0 (0% loss)
Approximate round trip times in milli-seconds:
Minimum=8ms, Maximum=15ms, Average=9ms
12
4.1 iCONNECT Software
The iServer may also be assigned an IP Address by using the iCONNECT software. a) Download the iCONNECT software from the website listed in this manual. b) Install iCONNECT software on a networked PC. This software is compatible with
Windows 95, NT, 2000, and XP.
c) Use iCONNECT to assign an IP address to the iServer and access its web pages
for configuration. You can also use any standard web browser to access the iServer’s web pages. Consult with your IT department for obtaining an IP address.
Figure 4.2 Assigning an IP Address using iCONNECT
d) To access the iServer for Configuration:
Click on the “View Webpage” button, you will access the iServer’s home page, refer to
Section 4.3 for details.
Figure 4.3 Accessing the iServer’s Home Page Menu
Place the IP address in this box
Take the MAC address from the label attached to the bottom of the iServer and place it in this box
Click here to send the above IP address to the iServer
After the IP address is assigned to the iServer, click here to access it’s web pages
13
4.2 Setting a New IP Address over the Network
Besides using the iCONNECT software, you may use the iServer’s default IP address to access it and assign a new IP address to it.
The iServer is shipped with a default IP address of 192.168.1.200 and Subnet Mask of
255.255.255.0. You can configure your PC’s Network connection with an IP address that is in the same range as the iServer’s IP address (192.168.1.x) and connect to the iServer using a crossover network cable between your PC and the iServer.
With this completed, you can go to the DOS-Prompt and ping 192.168.1.200. If you receive responses back (Figure 4.1), you can go to a Web browser and type in http://192.168.1.200 and it will take you to the iServer’s main web page.
Select
,
button, you’ll be asked for the password. The default LOGIN password is "12345678" and the ADMINISTRATOR password is "00000000", then you should be on the Access Control page were you can simply type in the desired Static IP address, and click Save.
Figure 4.4 Access Control
For the IP address to take effect, the iServer needs to be turned OFF/ON. Clicking the “Power Recycle” button will turn the iServer OFF and ON. Pressing the physical button marked “RESET” on the iServer does the same thing.
You can now connect the iServer to an Ethernet hub using a straight through cable, power it up, and follow the ping routine mentioned in the previous section.
Access Control
Click the following button to activate the new settings.
Access Control
http://192.168.1.200
ACCESS CONTROL
Login Password:
Admin Password:
Host Name: MAC Address: 0A:0B:0C:0D:0E:0F
IP Address:
Gateway Address:
Subnet Mask:
Save Reset
Power Recycle
12345678
00000000
eis0e0f
192.168.1.200
0.0.0.0
255.255.255.0
Main Menu
14
4.3 Setup and Operation using the iServer Web Page
Start your web browser.
From the browser you type http://eisxxxx using the last four-digits from the MAC
address label located on the device if DHCP and DNS are used. If a static IP address is used, then simply type http://x.x.x.x, where x.x.x.x is the iServer’s IP address.
The Home Page, shown in Figure 4.5, will be displayed.
Figure 4.5 iServer Home Page
In order to access certain menu items of the Home Page, users may be prompted for a password, as shown in Figure 4.6.
Figure 4.6 LOGIN and ADMINISTRATOR Passwords
There are 2 different access levels:
1. ADMINISTRA
TOR Password (administrator) allows certain groups and individual users to
access and modify "entire" iServer parameters without any restrictions. The default password is 00000000. This password can be up to 16 alphanumeric case-
sensitive characters.
2. LOGIN Password (operator) allows users to access and modify all of the iServer’s parameters, except “Access Control” which requires an Administrator password. The "Read Sensor" does not require a password.
The default password is 12345678. This password can be up to 16 alphanumeric case-sensitive characters.
iServer Home Page
http://192.168.1.200
iSERVER HOME PAGE
Read Sensor
Access Control
Firmware Version x.x
Chart
Configuration
LOGIN
http://192.168.1.200 http://192.168.1.200
LOGIN
ADMINISTRATOR
ADMINISTRATOR
4.3.1 Read Sensor
• Click on . In a few seconds the following page (Figure 4.7) will appear
with all default values of 100.00. Then the actual readings of Temperature and Barometric Pressure will be displayed.
• This page automatically updates the Temperature and Barometric Pressure values.
• Click on Main Menu to return to Home Page.
While accessing the Read Sensor page, If a blank screen appears without any “java application running” or image of a “Java logo”, please verify you have the latest Java Runtime Environment installed and configured according to the following instructions. If you do not have Java Runtime Environment, you may download it from our website or contact the Customer Service Department nearest you.
Figure 4.7 Read Sensor
4.3.1.1 Java Runtime Environment 1.4 Setup instructions
1. Go to your computer's Control Panel. Open the Java Plug-in
2. Select the "Cache" Tab Un-check the "Enable Caching" box
3. Select the "Proxy" Tab. Follow these Browser Proxy Selection instructions
below. (Generally, un-check the box if accessing iServers on your local network and check the box for access from your internal network to the internet.)
4. Refresh or restart the webpage.
Read Sensor
15
Pressure/Temp
http://192.168.1.200
Pressure/Temp
Temperature
Pressure
79.80
1000.40
o
F
hPa
16
4.3.1.2 Java Runtime Environment 1.5 (5.0) Setup instructions
1. Go to your computer's Control Panel. Open the Java Plug-in
2. Click on "Settings" & "View Applets" in the "General" tab.
3. Select the "Settings" button on the General Tab Un-check the "Enable Caching" box. Then close dialog box to show the General Tab
again
4. Select the "Network Settings" button on the General Tab. Proceed to the Browser tab. Follow the Browser Proxy Selection instructions
below.You should either select the "Use Browser Settings" option or the "Direct Connection" option depending on the network connections between your computer and the iServer product. (Generally, select "Direct Connection" if accessing iServers on your local network and select "Use Browser Settings" option for access from your internal network to the internet.)
5. Refresh or restart the webpage.
4.3.1.3 Browser Proxy Selection Accessing iServer units within your internal network
Usually when the computer and iServer are on an internal network, you will not use Proxy
server access.
You should un-check the "Use Browser Settings" option on the "Proxy" tab. Accessing iServer units using the internet
Often the web browser will use Proxy server access to the internet. In such cases, the
default Java runtime settings on the "Proxy" tab should suffice. The default setting is the "Use Browser Settings" option.
If the default proxy setting doesn't work, then you may have a situation where the proxy settings of the web browser are incorrect.
Diagnostics:
If the web page of the iServer appears, then the HTTP Proxy is working fine. If the data isn't updated on the iServer upon selecting the Read Sensor web page, there may be
a problem with access through a winsock proxy server. In such cases your network administrator will need to provide the winsock proxy server and port #s. (If the administrator requires knowledge of the port # required on the iServer, the value is 2003).
These values should be entered into the Socks line on the "Proxy" tab (of the Java Plugin control panel) or into the "connections" tab on the View,Internet Options dialog and make sure that the Proxy tab shows that the "Use Browser Settings" option is not selected (i.e. when you specify proxy connections in the Java Plugin control panel.
Accessing iServer units over Peer-to-Peer network A simple peer-to-peer network is setup by disconnecting from the main network (as users will
often do when trying to do initial setup of the iServer) and then connecting the iServer to another computer using a ethernet hub, an ethernet switch, or a Cross-over cable connection.
Often when using a peer-to-peer network, the Java plugin and the web browser (such as Internet Explorer) have internet connections configured to connect through proxy servers. In such case, you will need to simply assign the final IP address on this peer to peer network and then view the iServer charts after connecting the iServer into the regular network. Otherwise you can disable the Java plug-in's "Use Browser Settings" temporarily and then reconfigure the Java plug-in settings for regular network access after testing the iServer chart access on your peer­to-peer network.
The "Use Browser Settings" should not be selected. And the HTTP and Socks proxy entries should be blank. Also, setup the internet browser so that proxy servers are disabled.
Java and the Java Coffee Cup Logo are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries."
17
4.3.2 Adjustable Chart
• Click on , the following page (Figure 4.8) should appear. The Java™ Applet
graph displays Temperature and Barometric Pressure and can be charted across the full span (-40 to 123ºC) or within any narrow range (such as 20-30ºC). The time-base can display one minute, one hour, one day, one week, one month or one year.
If a blank screen appears without any “java application running” or image of a “Java logo”, please verify you have the latest Java Runtime Environment installed and configured according to the instructions (refer to Section 4.3.1.1). If you do not have Java Runtime Environment, you may download it from our website or contact the Customer Service Department nearest you.
Figure 4.8 Adjustable Chart
1). If you select an Alarm the degree C or F unit must match your “Sensor Unit” for the Setpoint line to show correctly.
Chart
Pressure/Temp
Main Menu
http://192.168.1.200
Pressure/Temp
(1 Hour/Div)
1 Day
1 Day
1 Week 1 Month 1 Year
1 Minute
1 Hour
Mon Jul 24 05:00:00 PST 2006
32
9/Div
122
400
80/Div
1200
Temperature
78.3
PressureArchives_Inactive
1000.3
F
Tues Jul 28 19:00:00 PST 2006
Alarm SP1(above)=0095.0 F Alarm SP2(below)=0070.0 F
hPa
User selectable time base
1 minute, 1 hour, 1 day,
1 week, 1 month, or 1 year
User selectable
temperature range
User selectable
temperature range
Number of degrees
per division
based on
temperature range
Actual Temperature
User selectable
temperature units: F or C
(See Note 1)
Actual Barometric Pressure
Alarm Type
Title
Archives_Inactive: 1minute or 1hour Archives_Enable: 1Day, 1Week, 1Month, or 1Year Archives_Done: displays after done archiving your selected interval
Start Time
End Time
User selectable Barometric Pressure units: HectoPascals (hPa) / mbar Inches of Mercury (inHg) Millimeters of Mercury (mmHg
User selectable Pressure range
User selectable Pressure range
Setpoint Range (See Note 1)
4.3.3 Retrieving Data from Flash
To retrieve and graph the data that is stored in the Flash Memory, you have two options:
OPTION 1:
You can use the iServer’s WEB interface to chart the data stored in the flash memory.
1. Click on the “Chart” button located on the Server Home Page, see Figure 4.5.
2. Select a time interval of Day, Week, Month or Year (Minute and Hour are not selectable for data retrieval).
3. As soon as the time interval is selected the “Archives_Inactive” button will change to “Archives_Enable”.
4. Click on “Archives_Enable” button to graph the stored data.
OPTION 2:
Download the iServer Download Utility iFlash software from the website listed in this manual and install it on your networked PC. This software is compatible with Windows 95, 98, NT, 2000, and XP operating systems. After the installation is completed, you can run the program to obtain the screen shown in Figure 4.9.
IP Address: Place the IP address of the iServer from which you want to download data, in this window.
Output Filename: Assign the path and the file name in which the downloaded data will be placed, in this window.
Model: Select the iBTX-M option. Latest Data for: This option allows you to download data for the last day, week, or
month. By selecting “Full” you can download the whole data. Output Format: This option
gives the data in either Excel format (check the box) or Text format (uncheck the box). By default, the temperature and barometric pressure values are always provided.
Header Data: You can choose what to appear for the header of the data file either in Excel or Text format.
Scale: This will give you the temperature in either Fahrenheit or Celsius as well as barometric pressure units..
Access Log: The completion of data download will be reported in this window. You can start downloading by clicking on the “Start Download” button.
18
Figure 4.9 iFLASH Download Utility
19
4.3.4 Access Control
This section describes the "Access Control" page of the iServers’s Web interface. This page allows the users to set up the network and security parameters of the iServer.
At the initial entrance to the “Access Control” page you will be prompted for the LOGIN Password (see Figure 4.6) prior to an ADMINISTRATOR Password.
Figure 4.10 Access Control
Login Password: This allows users to access and modify all of the iServer Home Page
menu items, except “Access Control”, which requires an Administrator password. The default Login password is 12345678. This password can be up to 16 alpha-numeric case­sensitive characters. If there is no Login Password assigned (blank box) the iServer will not require a password to access and modify iServer Home page menu items.
Admin (administrator) Password: This allows users to access and modify the "Access Control" page. The default password is 00000000. This password can be up to 16 alpha­numeric case-sensitive characters. If there is no Administrator Password assigned (blank box) the iServer will not require password to access and modify "Access Control" page.
Host Name: Refer to Section 3.4, DNS. MAC Address: This is also called Hardware address or Ethernet address, which is
assigned to the iServer at production. The MAC (Media Access Control) address is the iServer’s unique hardware number and is not changeable.
IP Address: The IP (Internet Protocol) address is a 32-bit number that identifies each sender or receiver of information that is sent in packets across the Ethernet or the Internet. The iServer’s default IP address is 192.168.1.200. The iServer’s IP address should be changed to fit user’s networking environment. Consult with your IT department for obtaining an IP address.
Gateway Address: A gateway is a network point that acts as an entrance to another network. A gateway is often associated with a router, which knows where to direct a given packet of data that arrives at the gateway. If the iServer is sending packets to another network node that is not on the same network on which the iServer is connected, a gateway address needs to be given to the iServer. The gateway address should be the IP address of the router connected to the same LAN to which the iServer is connected. The iServer’s default gateway address is 0.0.0.0. Consult with your IT department for obtaining a gateway address.
Subnet Mask: It is a 32-bit number that is used to determine which part of the IP address is the network portion and which part is the host portion. The iServer’s default subnet mask is 255.255.255.0. Consult with your IT department for obtaining a subnet mask.
Power Recycle: Clicking this button will reset the power on the iServer.
The DHCP can be enabled by setting the dip switch number 3 to ON position.
Changes made in the iServer’s Access Control page can be saved permanently by pressing the Save button and power recycling the iServer.
If you change a field and press Save, this message will appear
Click the following button to activate the new settings.
Access Control
http://192.168.1.200
ACCESS CONTROL
Login Password:
Admin Password:
Host Name: MAC Address: 0A:0B:0C:0D:0E:0F
IP Address:
Gateway Address:
Subnet Mask:
12345678
00000000
eis0e0f
192.168.1.200
0.0.0.0
255.255.255.0
Save Reset
Power Recycle
Main Menu
4.3.5 Configuration
Setting up the Flash Memory Card can be done in the Configuration page. From the Home Page Menu click on to get to the page (see Figure 4.11).
General Description of the Configuration page: There are two general sections “Flash Card Memory” and “Server”. Flash Card Memory consists of the following titles: Real Time Clock (RTC), Title, Alarm Setup, and Flash Recording. Server consists of Terminal Server and Remote Access.
Title and Flash Recording selections can be editted once by selecting “Activation ­StartRecord” and after that, no modification will take place unless recording is stopped (the reason for this is to be compliant with the data logging rules). The remaining parameters can be changed during recording as explained below.
There are several scenarios depending on the state of the Flash Card and the Real Time Clock (RTC):
#1) RTC is not set and Flash Card is empty. All the fields must be updated exactly according to the indicated format, “Adjust RTC
Only” check box must be left unchecked, “Activation” selection must set to “StartRecord” and click the “Update” button. Having done this, it is recommended to select “Configuration” from “Activation” drop down window, click the “Update” button, set the “Activation” to “Status/RTC/Alarm” and click the “Update” button one more time to review/verify that the setup took place as it was intended.
#2) RTC is set, and recording is in progress. The only possible setups are to update “Date” and “Time” of the Real Time Clock
along with checking “Adjust RTC Only” box. Also, alarms can be updated provided that “Activation” is set to “Status/RTC/Alarm”. Otherwise, the recording has to be stopped by selecting “StopRecord” of the “Activation” drop down window prior to modifying the Flash Card setup. An alternative way to stop recording is to push Standby Button (refer to Figure 2.3) of the unit.
#3) RTC is set, recording is stopped, and Flash Card is not empty. This means that a pre-recorded Flash Card is installed, and by activating the chart the
archived data can be viewed (Refer to Figure 4.8). The chart has the following selections:
1 Minute, 1 Day, 1 Week, 1 Month, 1 Year
In other words, they are the last specified selection e.g. 1 Day means the last day of the recorded data. Having done the selection, the “Archives_Enable” button must be clicked, which will then change to “Archives_Done” and the data will be retrieved accordingly. Also, the corresponding Start and End dates will reflect the respective time duration e.g. refer to Figure 4.8 which is the last 1 Day, the dates are:
02/20/2004 09:42:10 to 02/21/2004 09:42:10. #4) RTC is not set and the Flash Card is not empty. This is similiar to item 3) above except that at the power-up the installed Flash Card
was not empty. Or, the Flash Card Reset Button (refer to Figure 2.3) was pushed.
Configuration
20
4.3.5 Configuration (continued)
Figure 4.11 Configuration
Below are the definitions of terms used in the Configuration page.
A) Sensor/Device Setup
Clicking on the No. 1 or 2 allows you to modify the Sensor/Device Parameters (see Section 4.3.6 for more details).
21
http://192.168.1.200
Sensor Name
Temperature
Pressure
Remote Format
T0000.00 P00000.0
Remote End Char (HEX)
0D 0D
Click on Device No. on the left to modify Sensor Parameters.
07/24/2006
Flash Card Pre-Recorded AC Power On
0070.0 nnnn.n0095.0 nnnn.n
07/25/2006
07/28/2006
Sensor Units:
Status/RTC/AlarmWrap
05:00:00
19:00:00
Pressure/Temp F:hPa
Offset
0000.0
0000.0
5Command
B) Real Time Clock
RTC Date and T
ime: The formats are mm/dd/yyyy and hh:mm:ss. The exact formats are
required otherwise an error message will appear in the Title box. Note: time is military time/24 hour based.
Adjust RTC Only
: If checked, the clock will be updated and nothing else, provided that
Activation” is set to “Status/RTC/Alarm”. To verify the clock, set the “Activation” to “Configuration”, click Update button, then set “Activation” to “Status/RTC/Alarm” and click Update button one more time.
T
ime Stamp
: If checked, the Temperature/Barometric Pressure values will be stamped with
time and date using Port 1000 (HTTPget program must be used, see Section 4.5.1).
Secured
Applet: If checked, the LOGIN password is required to open “Read Sensor” and
“Chart” pages.
C) Flash Card Size: Reports the Flash Card density and if it is already recorded, how many
locations are filled.
0-Megabytes: Flash Card is not installed or a bad Flash Card
2-Megabytes, 4-Megabytes, 8-Megabytes: available sizes of Flash Cards.
D) Flash Card Message: Describes RTC setup, listed in the previous 4 scenarios.
Flash Card Module Malfunctional Open Sensor Flash Card Standby Flash Card Recording Stopped Flash Card Pre-Recorded Flash Card Recording Complete Flash Card Recording On Wait Reading Flash Flash Card Module Not Initialized Recording Initialized Flash Card Corrupt Initialization
If the battery is not connected or the voltage is low, the statement “Low Battery” will be added to the above statements. You may also see a statement “Archive Busy” if another client is busy receiving archive data. In this case, refrain from activating the applet, instead keep clicking the Update button and make sure “Activation” is set to “Status/RTC/Alarm” until the “Archive Busy” statement is no longer displayed.
E) Alarm Setup: There are two alarms which can be assigned to temperature or barometric
pressure. Alarm Type: Selection of Temperature (T) or Barometric Pressure (B) and Above
Setpoint (Hi) or Below Setpoint (Lo):
T&T:Hi/Lo T&B:Hi/Lo T&B:Hi/Hi B&B:Hi/Lo T&B:Lo/Hi T&B:Lo/Lo No Alarm
Example: If T&T:Hi/Lo is selected, the temperature will be monitored against these two Hi and Lo values. If temperature goes above Hi value, Relay 1 will be energized, and if temperature goes below Lo value Relay 2 will be energized.
Alarm Enabled:
Selections of “Latched ” or “Unlatch” are available. If “Unlatch” is selected, the relay in the iServer will be turned on (closed) when the temperature and/or barometric pressure values fall outside of Setpoint range. When the temperature and/or barometric pressure values are back within the range, the relay will be turned off (opened).
If “Latched” is selected, the relay in the iServer will be turned on (closed) when the temperature and/or barometric pressure values fall outside of Setpoint range and will remain on until the user turns it off.
SP1 and SP2
: Editable box for Setpoint values. The format is nnn.n, it must be followed
exactly otherwise the modification will not take place for any modified item in the Alarm Setup.
22
F) Flash Recording
T
itle: Editable field with up to 16 characters long. The given name will display as a title on
the Chart and Read Sensor pages either for the real-time data or the stored data.
Sensor Unit:
The unit of temperature either in degree Fahrenheit F or degree Celcius C for
each type of barometric pressure unit hPa, inHg or mmHg..
LCD/PWR
: The selections are “ON ”, “OFF ”, and “UPS”. Selecting “OFF” will cause the
LCD to turn off during a power outage, provided the battery is connected. The current consumption is about 1.5mA or 3mA depending on “OFF ” or “ON ” selection respectively. If recording is “ON “, depending on the recording interval, the LCD will be updated every 10 seconds or 1 minute. Therefore, when the LCD is set to “ON ”, it could take some time before the LCD is turned on. If recording is not “ON “, the LCD will be updated every 10 seconds.
Selecting “UPS” puts the iServer into full operational mode when it’s running on the battery (S5 jumper needs to be installed, see Section 2.4 and 2.7). This means that in case of power outage, sensing, recording, LCD display, and network communication capabilities of the iServer will all operate on the battery. Due to heavy power consumption the battery will not last more than an hour.
T
ype
: The selections are: “Limited”, “Wrap”, or “Nonwrap”.
Limited: You must define the Start Date and Time, and End Date and Time in which
you need the recording to be done. Wrap: You only need to define the Start Date and Time. The iServer will record data
until the Flash is full, then the iServer will continue to record and overwrite the existing data.
Nonwrap: You only need to define the Start Date and Time. The iServer will record data until the Flash is full, then the iServer will stop recording.
Interval
: The recording interval at which the temperature or barometric pressure is being
stored into the Flash Card. The selections are “10 seconds“ and “1 minute“.
Activation:
The selections are “Status/RTC/Alarm”, “StartRecord ”, “Configuration”, and
StopRecord ”. Refer to previous scenarios #1 and #2 at the beginning of this Section
4.3.5 for more details.
Status/RTC/Alarm: Select “Configuration” and “Status/RTC/Alarm”, each followed by
clicking the Update button to retrieve the latest recording settings. By selecting “Status/RTC/Alarm” only, followed by clicking the “Update” button the iServer will report back all the settings, but the “Recording” settings.
StartRecord: Select to initiate a recording. Configuration: Select to retrieve the latest recording settings, followed by
Status/RTC/Alarm” option.
StopRecord: Select to stop an ongoing recording. Reset: Selecting this option will reset the flash memory, LCD, recording sections, and
the Ethernet connection to a fresh start. It is suggested to select “Reset ” followed by clicking the “Update” button if you experience recording problems.
Start Date, T
ime: Starting date and time for recording. The format is mm/dd/yyyy and
hh:mm:ss, it must be followed exactly. Entry is required for all Types of Flash Recording. End Date, Time: Ending date and time for recording. The format is mm/dd/yyyy and
hh:mm:ss, it must be followed exactly. Entry is required for Limited Type of Flash
Recording only. NOTE 1: While the recording is in progress, the first letter of the measurement unit (“h”P, “i”Hg or
“m”Hg), located on the LCD screen blinks continuously.
23
NOTE 2: Downloading data and recording can not be done at the same time. While downloading data, the writing process to the flash memory will be internally disabled while the data is being read from the memory flash. For small amounts of data to be retrieved (1 Day or 1 Week), this is not a significant interruption in the recording data. However, for large amounts of data (1 Month or 1 Year) it may take 4 to 8 minutes to download the data. In “Archives_Enabled “ mode, charting remains static, while data download is taking place.
NOTE 3: The number of barometric pressure/temperature values that can be recorded depends on the memory flash capacity (2 Mbytes, 4 Mbytes or 8 Mbytes) and number of barometric pressure / temperature values (540,540, 1,081,212 and 2,162,556). The time to fill the memory flash depends on the recording interval time, e.g. 1 minute interval for 4 Mbytes is 1,081,212 minutes or 750 days. If the flash is busy sending data to the applet to chart the archive, the iServer will refuse to initiate a call to provide archived data to the second applet until it has finished with the first one.
NOTE 4: If there is a loss of power while recording the data, the number of data logged can not be stored, therefore having restored the power the logged data will be read from Flash Memory and the number of recorded data will be stored for future use. During this process the LCD will display “Reading Flash”, and if you connect through a web browser the Configuration page will display “Wait Reading Flash”.
NOTE 5: After you “StartRecord” the flash recording followed by clicking the “Update button, if you then need to make any changes in the Flash Recording section you must either select “StopRecord” followed by clicking the “Update” button or push the reset button on the side of the iServer and reconfigure the Flash Recording section again.
NOTE 6: If you stop the recording prematurely, when you download the data, you will lose the last 256 bytes of the data that was left in the buffer and was not transferred into the flash card. Therefore, we strongly suggest downloading the data while the recording is still on and then stop the recording if desired.
G) Terminal Server
TCP/UDP*
: The iServer supports TCP and UDP protocols (default is TCP). If UDP is
selected, it can be configured either for Broadcast UDP or Directed UDP. In case of Broadcast UDP, the iServer will transmit the data to every node on the network. This can be accomplished if the Remote IP Address is set to 255.255.255.255.
The Broadcast UDP is a practical solution when one iServer needs to communicate with multiple nodes over the network. In the case of directed UDP, the iServer will transmit the data to a specific node on the network. This can be accomplished if the Remote IP Address is set to the IP address of that specific node.
Server T
ype: Continuous mode sends the temperature and barometric pressure to the
Ethernet every two seconds. It is mainly used to send readings to a remote display. Command mode needs a command to query the iServer to send the reponse back to querying device.
In order to change from one type to another, make sure to close any TCP connections to the sensor. The unit could get locked up if changing the type while the TCP socket is still open to the sensor. Reseting the power will correct the problem.
Number of Connections
: The range is from 0 to 5. If 0 is selected, the Terminal Server
feature is disabled. This means that no network connection can be made to the iServer’s sensor. If 1 is selected, only one network connection can be made to the sensor. Any number more than 1 would allow that number of network hosts to read from the iServer simultaneously (default is 5).
24
Port: (default 2000) is the default TCP port number for the port to which the sensor is connected. Ports 1000 (used for HTTPget, refer to Section 4.5), 2002, 2003, and 2004 are reserved for internal use.
Terminal Server usually describes a device that exchanges data between Ethernet/TCPIP networks and RS-232/RS-485 systems. With this iServer, the data is obtained digitally from the sensor (irrelevant to RS-232 or RS-485 interface) and can be accessed from anywhere on the network.
A computer program, such as NEWPORT’s Mail Notifier, OPC Server, iLOG, iFLASH or httpget can send TCP requests and obtain readings using the Terminal Server feature.
H) Remote Access
Remote IP Address: iServer can establish a connection to a remote device (e.g. an
iLD Remote Display with an Ethernet iServer embedded board) with this IP. Remote Port: (default 2000) the remote port number for the connection. Ports 1000
(used for HTTPget, refer to Section 4.5), 2002, 2003, and 2004 are reserved for internal use.
Remote
Access:** Remote Access can be enabled and disabled. If enabled, the
iServer can send its data to a remote node on the same network (the “Remote IP address” and “Remote Port” must be entered).
*TCP/UDP: when UDP mode is selected, Remote Access should be disabled and Remote IP and Port are the UDP remote listening IP and Port. If the Remote IP is set to 255.255.255.255, the UDP packet becomes a broadcasting packet which will allow any device listening to the Remote port to receive the packet.
**If Remote Access is enabled, Terminal Server is automatically disabled.
25
26
4.3.6 Sensor Parameters
• In the first column of Configuration page (Figure 4.11), click on No. 1 to view and modify the Sensor Parameters page for Temperature.
Figure 4.12 Sensor Parameters
Below are some definitions of terms used in the Sensor Parameters page. Device Name: is a text field and can take up to 16 alphanumeric characters, it shows on
the “Configuration” and the “Read Sensor” page. Remote Display Format: Remote display format is used for Terminal Server continuous
mode. P0000.0mbar in barometric pressure setting, displays P and 0000.0mbar is the
barometric pressure value displayed. Example: if the barometric pressure is 1014.4, then P1014.4mbar will be seen in the
remote display. If no format is specified (blank), there is no reading sent out. If temperature is 76.25 and 00.0F is used in temperature setting, the remote site will show
76.2F. This format setup is originally based on iLD Remote Display, which has four or six LEDs.
For six LEDs, T00.00F format, and for four LEDs, 00.0F formats are appropriate.
Remote End Char
: The default value is 0D (Hex representation of <CR>). This means
that the iServer sends <CR> after each temperature and barometric pressure value. This will be done only in Continuous mode.
This is how the data will appear on the host with OD assigned:
T75.7F P1014.9mbar
If the end character, for instance, is 20 (Hex representation of space), the data will then appear as: T75.7F P1014.9mbar
If nothing is set for the “Remote End Char” field, the iServer will then forward the data to the LAN with no characters followed.
Offset: Since the sensing probe is solid state electronics, there is no need for calibration. If it’s determined that the readings are slightly off, the user can manually assign numerical values (including negative) to adjust the readings for temperature and barometric pressure. For temperature offset, the unit must be in degree C, for barometric pressure the unit must be in hPa. The Offset can be changed while recording is on.
Figure 4.13
Remote End Char
You may type any
ASCII characters in the first three boxes, but you must delete the leading spaces.
Sensor Parameter
http://192.168.1.200
SENSOR PARAMETER
Device No. 1
Device Name:
Remote Display Format: Remote End Char (HEX) 0X: Offset:
Temperature
0000.0
C
Update Reset
Cancel
Main Menu
T0000.00
0D
Tera Term - 192.168.1.200 VT
File Edit Setup Control Window Help
T75.7F P1014.8mbar T75.6F P1014.7mbar T75.5F P1014.7mbar T75.4F P1014.6mbar T75.2F P1014.6mbar T75.0F P1014.5mbar
27
4.4 Telnet Setup
Set the Number of Connections to 1-5 other than 0, using telnet simulation program connect to iServer. In continuous mode, the telnet teminal will receive continuous messages from the iServer. In command mode, the command can be sent to query the iServer and get a response back. Refer to Figure 3.3
Send remote reset: Telnet port 2002 will bring a terminal for admin password. After typing the password and following with the end character, the message Admin. Login Successful will be showed on the terminal. Now type "reset" following with return character to reset the iServer. If no character is received within 20 seconds, the terminal will be closed automatically.
Initiating the archive chart while Telnet is active will halt Telnet until the archive chart is done.
4.5 HTTPGET Program
The Httpget software is used to send a single HTTP or TCP request to an iServer product. In contrast, the telnet or Hyperterminal programs allow a continuous connection with multiple requests to be sent to the iServer product.
Generally httpget is used for simply programming an IP address to the iServer or for quickly obtaining a reading of from a device.
The iServer product must be configured from the configuration web page so that the "Server Type" value is set to "Command" (This is positioned under the heading of Terminal Server). Also the Number of Connections may need to be set to "0" to enable Port 1000 (Port 1000 is for access in a non-standard terminal mode). To use Port 2000 access (where "2000" is the value stored in "Port"), the Number of Connections should be set to "2" for general usage. The value of 2 can later be changed to a value from 1 to 5 depending on needs for secure access or fault tolerance.
Whenever Terminal Server service (using Port 2000 by default) is required, the Number of Connections must be set to a value from 1 to 5. The Terminal Server mode is the recommended mode for the most reliable connection when operating with NEWPORT software or with other programs supporting TCPIP communications. The Port 1000 access can be used with NEWPORT software and may be needed with some iServer products when you need to view readings from the web page while simultaneously collecting data through TCPIP communications.
28
4.5.1 HTTPGET using Port 1000
You can setup and read the information from the iServer by using the HTTPGET program. The following program can be used to read data from the embedded server firmware by using TCP port 1000. The command string is sent to this TCP port, then the response can be read back from the same socket.
The Httpget.exe file is used to setup and read information from the iServer. This file will be automatically installed when you install the MailNotifier software available on our website and CD.
Notes on using Httpget : The Httpget.exe program is installed to the windows directory (usually c:\winnt or
c:\windows) when installing the Mail Notifier software.
1. Open up a command window (or have a DOS window) a) Click on start menu b) Click on "Run" c) In the dialog box that appears, type "cmd" or "command" and click on "OK" button. d) A command window should now appear.
2. If you now type "httpget" and press the "enter" key, the program options should be displayed.
3. Next run httpget with the options displayed below
httpget -r -S “*SRTC\r” 192.168.1.200:1000
where:
-r –S are parameters needed for the command string
*SRT is the command as the following:
*SRTC Read the temperature in C *SRTF Read the temperature in F *SRHb Read the pressure in mbar / hPa. *SRHi Read the pressure in inHg (Mercury). *SRHm Read the pressure in mmHg (Mercury). *SRA Read the SP1 and SP2 *SRB Read the temperature and barometric pressure *SRYS Indicate Power to be on AC or DC *SRYRST Reset Power on iServer
\r is the carriage return termination character
192.168.1.200 is an IP address
1000 is a socket port number
Response:
076.6 (in Deg.F format)
29
4.5.2 HTTPGET and ARP to setup Device IP Address
Use the iCONNECT software, which may be downloaded from our website, to do these IP changes whenever possible.
Use ARP first to assign the mac address to a static IP address in computer arp table by this command:
apr –s 192.168.1.200 00-03-34-00-00-06-b6
Then use the following command to assign new IP to the device:
Httpget –r –S "00000000" 192.168.1.200:1
where:
00000000” is admin. password. If the password is wrong, the unit will ignore the new IP. If the new IP is taken, you will get the message " New IP is Assigned" after the httpget command. The device will reset automatically.
192.168.1.200” is an example of an IP addresss. It is replaced with an IP address suitable for your network
00-03-34-00-00-06-b6” is replaced with your iServer product MAC address.
30
4.6 ARP Protocol
ARP is the Internet layer protocol responsible for matching or obtaining the MAC (hardware) address that corresponds to a particular IP address. The ARP command allows the user to view the current contents of the ARP cache of the local computer (residing on the same network). Microsoft includes the ARP.EXE utility for viewing and modifying the ARP cache with its Windows products. The following ARP commands can be used to view cache entries:
arp –a Use this command to view all ARP cache entries.
arp –a plus IP address Use this command to view ARP cache entries associated
with one particular interface on a network with multiple adapters.
arp –g Same as arp –a.
arp –N Use this command to display ARP entries for specific network interface.
arp – s plus IP address plus Physical address Use this command to manually add
a permanent static entry to the ARP cache.
arp –d Use this command to manually delete a static entry.
Ping the destination computer using IP address first before using the arp -a command.
The following window shows examples of arp commands and responses.
• Your computer has an IP address of 192.168.1.118
• The destination computer has an IP address of 192.168.1.96
Figure 4.14 ARP Commands and Responses
C:\>arp - 192.168.1.96 No ARP Entries Found C:\>ping 192.168.1.96 Pinging 192.168.1.96 with 32 bytes of data:
Reply from 192.168.1.96=bytes=32 time=5ms TTL=32 Reply from 192.168.1.96=bytes=32 time=3ms TTL=32 Reply from 192.168.1.96=bytes=32 time=3ms TTL=32 Reply from 192.168.1.96=bytes=32 time=4ms TTL=32
C:\>arp -a 192.168.1.96 Interface: 192.168.1.118 Internet Address Physical Addresss Type
192.168.1.96 00-03-34-00-00-23 dynamic C:\>arp -s 192.168.1.96 00-03-34-00-00-23 C:\>arp -a 192.168.1.96 Interface: 192.168.1.118 Internet Address Physical Addresss Type
192.168.1.96 00-03-34-00-00-23 static C:\>arp -d 192.168.1.96 C:\>arp -a 192.168.1.96 No ARP Entries Found C:\>
4.7 iLOG Software
The iLOG software can be used only with NEWPORT Electronics instruments. This is an Excel application software that can log temperature and barometric pressure from an iServer over the Ethernet or the internet.
a) Download the iLOG software from the website listed in this manual. b) Install iLOG software on a networked PC. This software is compatible with Windows
95, 98, NT, 2000, and XP.
c) For complete information of how to use the iLOG software, click on the HELP button.
Figure 4.15 iLOG Software Logging Data
31
4.8 Mail Notifier Software
The Mail Notifier Software can be used only with NEWPORT Electronics instruments. For complete information of how to use the Mail Notifier software, click on the Help menu
of the main window. The Mail Notifier software generates email notifications for alarm conditions. Users can
be notified automatically of alarm conditions monitored via internet connections throughout the world. By use of the email forwarding of alarm conditions, alarm conditions can be monitored on a network isolated from the internet and forwarded to connections on the Internet.
The Mail Notifier utility operates under Windows 98, NT 4.0, 2000, and XP in conjunction with existing email that supports the MAPI messaging interface. If MS Outlook has been loaded, the MAPI support should be available.
4.8.1 Installation
The Mail Notifier must be loaded on a computer running Microsoft Windows (versions specified earlier) using an email program that provides MAPI access. Network access must be available between this computer and the iServer. Network access must also be available from this computer to the appropriate email server and from the email server to the recipient’s email server.
Figure 4.16 iServer Mail Notifier Main Window
32
33
4.8.2 Program Options Setup and Configuration
Complete program setup requires:
Entering a recipient for the email
Specifying connection details to MAPI services.
Defining alarms for devices, and selecting how and when the email will be active.
Figure 4.17 iServer Mail Notifier Profile Setup
The “Send To” tab contains a field to specify an email address to which alarm notifications will be sent (i.e. the recipient). Only one entry is permitted, in the address field. Additional addresses can be placed into “More Addresses” list.
Email Connection (MAPI Access)
The following instructions work with some versions of Microsoft Outlook. Note though that some email systems may prevent the use of Mail Notifier due to security constraints.
The simplest way to obtain a connection the the Email services is as follows:
1. Configure the Mail Notifier to connect to the email by displaying a Login Box. This option is found by selecting View, Options from the Mail Notifier's menubar. Select the "Email Setup" tab, mark the checkbox for "Use Login Box"
2. After Mail Notifier is configured to use the login box, the Mail Notifier can be started without user intervention if your MS Outlook program is running beforehand. Otherwise, the Mail Notifier will display a Login Box that should display the necessary User Profile.
34
4.8.3 Device Setting and Configuration
Device setup requires:
• Entering the IP
address for iServer device (for example 192.168.1.200).
• Specifying Socket number
(1000 or 2000 depending on iServer settings).
• Defining RS485 Unit # interface address (1 to 199). Enter "0" for RS232 interface
or for iServer.
• Entering Reading command
. Normally set to SRT to obtain reading from the
devices.If you want to change this setting, refer to HTTPget Section 4.5.
• Defining the Alarm setup
(High/Low, High value, or Low value).
• Specifying Pause Interval. It determines how many seconds each subsequential alarm
notification will be sent.
• Determining Monitor interval
. It establishes the interval or time resolution in seconds
for which readings will be obtained from the device.
Figure 4.18 iServer Mail Notifier Device Setting
35
PART 5 SPECIFICATIONS
SENSOR SPECIFICATIONS BAROMETRIC PRESSURE (B) Accuracy/Range:
±2.0 mbar / 0-1100 mbar (0-110 KPa)
Resolution: 0.1 mbar
TEMPERATURE (T) Range*: 0°C to 70°C (32°F to 158°F) Accuracy*:
± 0.8°C @ 20°C (± 1.5°F @ 68°F) ± 2°C for -40 to 125°C (± 3.6°F for -40 to 257°F) *Note: extended temperature range is for
Industrial Probe only, the iServer’s operating temperature is 0 to 70°C.
Response Time: 5 seconds (63% slowly moving air)
Repeatability: ±0.1°C Resolution: 0.01°C, 14bit
PROBE PHYSICAL DIMENSIONS Wand Probe:
159 mm lg x 19 mm dia (6.25” x 0.75")
Cable with DB9 connector:
152 mm long (6")
Cable operating temp:
0 to 80°C (32 to 176°F)
Industrial Probe:
137mm lg x 16mm dia (5” x 0.63")
Cable with DB9 or stripped leads:
6.1m long (20’)
Cable operating temp:
0 to 105°C (32 to 221°F)
iSERVER SPECIFICATIONS INTERFACE Ethernet: 10Base-T (RJ45) Sensor: Digital 4-wire (DB-9) Supported Protocols:
TCP/IP, UDP/IP, ARP, ICMP, DHCP, DNS, HTTP, and Telnet
LED Indicators: Network Activity, Network Link, and Diagnostics
LCD Display: 16 digits, 6mm (0.23”)
Processor: Enhanced 8051, 22 MHz Memory: 512 Kbytes Flash, 16 Kbytes
SRAM Memory Data Flash Card: 2 Mbytes or
2 months of data storage at 10 second logging intervals, or 1 year at 1 minute logging intervals. Atmel# AT45DCB002
Optional Flash Cards:
4 Mbyte (2 years at 1 minute intervals) 8 Mbyte (4 years at 1 minute intervals)
Relay Outputs:
Two relays 1.5A @ 30Vdc Management: Device configuration and
monitoring through embedded WEB server
Embedded WEB Server: Serves WEB pages containing real-time data and live updated charts within definable time intervals.
Agency Approvals: FCC-B, CE Software: Field firmware upgradeable.
Including an Excel program for automatic data logging within definable time intervals, compatible with all Windows operating systems.
POWER Power Input: 9-12 Vdc Consumption: 2.5 W max. Safety Qualified ac Power Adapter
Nominal Output: 9 Vdc @ 0.5 A Input: 100-240 Vac, 50/60Hz
Battery: 9 Vdc, alkaline
approximately 650 mA hours
ENVIRONMENTAL Operating Temperature:
0 to 70°C (32 to 158°F)
Storage Temperature:
-40 to 125°C (-40 to 257°F)
PACKAGING Material: Metal case with flange mount iServer Housing Dimensions:
36.6H x 62W x 90Dmm (1.44 x 2.93 x 3.56 “)
Weight: 298 g (0.8 lbs.)
PART 6
FACTORY PRESET VALUES
PRESET PARAMETERS FACTORY DEFAULTS
Network Interface:
IP Address 192.168.1.200 Gateway Address 0.0.0.0 Subnet Mask 255.255.255.0 Device Host Name eis and Last 4 digits from the MAC address Login Password 12345678 Admin Password 00000000 DHCP Disabled Flow Control None End Character 0D (Hex) (Carridge Return)
Terminal Server:
Server Type Command Number of Connections 5 Port # 2000 Server Mode Disable
Remote Access (Tunneling):
Remote Access Disable Remote Port 2000 Remote IP Address 0.0.0.0
LCD Backlight On
36
APPENDIX A GLOSSARY
User of this manual should be familiar with following definitions: ARP (Address Resolution Protocol) is a protocol for mapping an Internet Protocol
address (IP address) to a physical machine address that is recognized in the local network. For example, the IP address in use today is an address that is 32-bits long. In an Ethernet local area network, however, addresses for attached devices are 48-bits long. (The physical machine address is also known as a Media Access Control or MAC address.) A table, usually called the ARP cache, is used to maintain a correlation between each MAC address and its corresponding IP address. ARP provides the protocol rules for making this correlation and providing address conversion in both directions.
Ethernet is a network protocol defined by the IEEE 802.3 standard. Ethernet-based networks use MAC Address rather then IP Address to exchange data between computers. By using ARP and adding TCP/IP support, Ethernet devices may be connected as part of the Internet. An Ethernet LAN typically uses coaxial cable or special grades of twisted pair wires. The most commonly installed Ethernet systems are called 10BASE-T and provide transmission speeds up to 10 Mbps. Devices are connected to the cable and compete for access using a Carrier Sense Multiple Access with Collision Detection (CSMA/CD) protocol.
IP (Internet Protocol) is the method or protocol by which data is sent from one computer to another on the Internet.
IP address (Internet Protocol address) is a 32-bit number that identifies each sender or receiver of information that is sent in packets across the Internet.
IP Netmask is a 32-bit pattern of bits used to determine which part of the IP address is the network portion and which part is the host portion.
MAC (Media Access Control) Address is your computer's unique hardware number. When you're connected to the Internet from your computer, a correspondence table relates your IP address to your computer's physical (MAC) address on the LAN.
Ping is a utility that tests the network connectivity. It is used to determine if the host is capable of exchanging information with another host.
Port number/Socket number is a way to identify a specific process to which an Internet or other network message is to be forwarded when it arrives at a server. It is a predefined address that serves as a route from the application to the Transport layer or from the Transport layer to the application of the TCP/IP system.
Sockets are a method for communication between a client program and a server program in a network and defined as "the endpoint in a connection." Information transferred across the Internet primarily occurs between sockets.
TCP/IP (Transmission Control Protocol/Internet Protocol) is the basic communication language or protocol of the Internet. When you are set up with direct access to the Internet, your computer is provided with a copy of the TCP/IP program just as every other computer that you may send messages to or get information from also has a copy of TCP/IP. TCP/IP often is used as a general term to indicate generic access to the Internet.
UDP/IP (User Datagram Protocol/Internet Protocol) is the TCP/IP standard protocol that allows an application program on one machine to send a datagram to an application program on another. The UDP can be either in Broadcast or Directed form. The Broadcast UDP transmits data to every node on the same network. The Directed UDP transmits data to one node only.
37
Appendix B IP Address
An IP address is a unique 32-bit address assigned to a computer and includes:
• A network ID number identifying a network.
• A host ID number identifying a computer on the network.
All IP addresses have been divided into three smaller groups (classes) A, B and C
Class A addresses have 8-bits of network ID and 24-bits of host ID. They can support a large number of hosts, approximately 2 = 16,777,216 computers per network.
The IP addresses range in binary from 00000001.xxxxxxxx.xxxxxxxx.xxxxxxxx
to 01111111.xxxxxxxx.xxxxxxxx.xxxxxxxx
The IP addresses range in decimal from 1.x.x.x to 127.x.x.x
Class A network ID’s support a very large number of hosts.
Class B addresses have 16-bits of network ID and 16-bits of host ID. They can support approximately 216= 65,536 computers per network.
The IP addresses range in binary from 10000000 00000000.xxxxxxxx.xxxxxxxx
to 10111111 11111111.xxxxxxxx.xxxxxxxx
The IP addresses range in decimal from 128.0.x.x TO 191.255.xxx.xxx
Class B network ID’s support a medium number of hosts.
Class C addresses have 24-bits of network ID and 8-bits of host ID. They can support approximately 28= 256 computers per network.
The IP addresses range in binary from 11000000.00000000.00000000.xxxxxxxx
to 11011111.11111111. 11111111.xxxxxxxx
The IP addresses range in decimal from 192.0.0.xxx to 223.255.255.xxx
Class C network ID’s support a small number of hosts.
The rest of the addresses are divided into two classes, D and E. Class D networks are not assigned to the host. They are used for multicasting. The address range from 224.x.x.x to 239.x.x.x
Class E networks are experimental or reserved addresses. The address range from 240.x.x.x to 247.x.x.x
38
Appendix C IP Netmask
IP Netmask or Subnet Mask is a 32-bit pattern of ones and zeros used to determine network portion of an IP address from the host portion of the IP address. Subnet mask is a network ID that is created by borrowing bits from host portion of IP address and using them as part of a network ID. The table below shows a default subnet mask for address Classes A, B, and C. Each bit that is set to "1" in the subnet mask corresponds to the bit in the IP address that is to be used as the network ID. Each bit that is set to "0" in the subnet mask corresponds to a bit in the IP address that is to be used as the host ID.
Address Class Mask Binary Value Mask Decimal Value
or Dotted Notation
Class A 255.0.0.0 Class B 255.255.0.0 Class C 255.255.255.0
If your network requires more network ID’s, you can extend the default subnet mask to include additional bits from the host ID. This allows for additional network ID’s within the network. The table below shows some examples of subnet masks and bits moved from the hosts ID to create a new subnet.
Mask Dotted Notation Mask Binary Mask Bits
Class A
255.0.0.0 (Default) 0
255.192.0.0 2
255.224.0.0 3
255.240.0.0 4
255.248.0.0 5
255.252.0.0 6
255.254.0.0 7
255.255.0.0 8
255.255.128.0 9
255.255.192.0.0 10
……………......... .
255.255.255.252 22
Class B
255.255.0.0 (Default) 0
255.255.192.0 2
……………......... .
255.255.255.252 14
Class C
255.255.255.0 (Default) 0
255.255.255.192 2 …………………. .
255.255.255.254 6
To determine the number of valid hosts ID’s remaining after subnetting, use the following equation: 2n– 2, where n is the number of octet digits left after the subnet mask.
39
11111111 11111111 11111111
00000000 11111111 11111111
00000000 00000000 11111111
00000000 00000000 00000000
11111111 11111111 11111111 11111111 11111111 11111111 11111111 11111111 11111111 11111111
........
11111111
00000000 11000000 11100000 11110000 11111000 11111100 11111110 11111111 11111111 11111111
........
11111111
00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000 10000000 11000000
........
11111111
00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000 00000000
........
11111100
11111111 11111111
........
11111111
11111111 11111111
........
11111111
00000000 11000000
........
11111111
00000000 00000000
........
11111100
11111111 11111111
........
11111111
11111111 11111111
........
11111111
11111111 11111111
........
11111111
00000000 11000000
........
11111100
Appendix D ASCII Chart
ASCII Dec Hex Binary ASCII Dec Hex Binary
Char No Parity Char No parity
NUL 00 00 00000000 @ 64 40 01000000 SOH 01 01 00000001 A 65 41 01000000
STX 02 02 00000010 B 66 42 01000010 ETX 03 03 00000011 C 67 43 01000011
EOT 04 04 00000100 D 68 44 01000100 ENQ 05 05 00000101 E 69 45 01000101 ACK 06 06 00000110 F 70 46 01000110
BEL 07 07 00000111 G 71 47 01000111
BS 08 08 00001000 H 72 48 01001000 HT 09 09 00001001 I 73 49 01001001
LF 10 0A 00001010 J 74 4A 01001010 VT 11 0B 00001011 K 75 4B 01001011 FF 12 0C 00001100 L 76 4C 01001100
CR 13 0D 00001101 M 77 4D 01001101 SO 14 0E 00001110 N 78 4E 01001110
SI 15 0F 00001111 O 79 4 F 01001111
DLE 16 10 00010000 P 80 50 01010000 DC1 17 11 00010001 Q 81 51 01010001 DC2 18 12 00010010 R 82 52 01010010 DC3 19 13 00010011 S 83 53 01010011 DC4 20 14 00010100 T 84 54 01010100 NAK 21 15 00010101 U 85 55 01010101 SYN 22 16 00010110 V 86 56 01010110
ETB 23 17 00010111 W 87 57 01010111 CAN 24 18 00011000 X 88 58 01011000
EM 25 19 00011001 Y 89 59 01011001 SUB 26 1A 00011010 Z 90 5A 01011010 ESC 27 1B 00011011 [ 91 5B 01011011
FS 28 1C 00011100 \ 92 5C 01011100
GS 29 1D 00011101 ] 93 5D 01011101
RS 30 1E 00 011110 ^ 94 5E 010 11110 US 31 1F 00 011111
_
95 5F 0 1011111
SP 32 20 00100000
`
96 60 01100000 ! 33 21 00100001 a 97 61 01100001 " 34 22 00100010 b 98 62 01100010
# 35 23 00100011 c 99 63 01100011 $ 36 24 00100100 d 100 64 01100100
% 37 25 00100101 e 101 65 01100101
& 38 26 00100110 f 102 66 01100110
39 27 00100111 g 103 67 01100111 ( 40 28 00101000 h 104 68 01101000 ) 41 29 00101001 I 105 69 01101001 * 42 2A 00101010 j 106 6A 01101010
+ 43 2B 00101011 k 107 6B 01101011
, 44 2C 00101100 l 108 6C 01101100
- 45 2D 00101101 m 109 6D 01101101 . 46 2E 00101110 n 110 6E 01101110
40
Appendix D ASCII Chart Continuation
/ 47 2F 00101111 o 111 6F 01101111
0 48 30 00110000
p
112 70 01110000
1 49 31 00110001
q
113 71 01110001 2 50 32 00110010 r 114 72 01110010 3 51 33 00110011 s 115 73 01110011 4 52 34 00110100 t 116 74 01110100 5 53 35 00110101 u 117 75 01110101 6 54 36 00110110 v 118 76 01110110 7 55 37 00110111 w 119 77 01110111 8 56 38 00111000 x 120 78 01111000 9 57 39 00111001
y
121 79 01111001
: 58 3A 00111010 z 122 7A 01111010 ; 59 3B 00111011
{
123 7B 01111011 < 60 3C 00111100
|
124 7C 01111100 = 61 3D 00111101
}
125 7D 01111101 > 6 2 3 E 00 111110 ~ 1 26 7E 01111110 ? 63 3F 00111111 D EL 1 27 7F 01111111
ASCII Control Codes
ASCII Dec Hex Ctrl Key Definition ASCII Dec Hex Ctrl Key Definition
Char Equiv. Char Equiv.
NUL 00 00 Crtl @ Null Character DC1 17 11 Crtl Q Data Control 1
- XON
SOH 01 01 Crtl A Start of DC2 18 12 Crtl R Data Control 2
Header
STX 02 02 Crtl B Start of Text DC3 19 13 Crtl S Data Control 3
- XOFF
ETX 03 03 Crtl C End of Text DC4 20 14 Crtl T Data Control 4
EOT 04 04 Crtl D End of NAK 21 15 Crtl U Negative
Transmission Acknowledge
ENQ 05 05 Crtl E Inquiry SYN 22 16 Crtl V Synchronous
Idle
ACK 06 06 Crtl F Acknowledge ETB 23 17 Crtl W End of Trans
Block
BEL 07 07 Crtl G Bell CAN 24 18 Crtl X Cancel
BS 08 08 Crtl H Back Space EM 25 19 Crtl Y End of Medium HT 09 09 Crtl I Horizontal SUB 26 1A Crtl Z Substitute
Tabulation
LF 10 0A Crtl J Line Feed ESC 27 1B Crtl [ Escape
VT 11 0B Crtl K Vertical FS 28 1C Crtl \ File Separator
Tabulation
FF 12 0C Crtl L Form Feed GS 29 1D Crtl ] Group
Separator
CR 13 0D Crtl M Carriage RS 30 1E Crtl | Record
Return Separator
SO 14 0E Crtl N Shift Out US 31 1F Crtl_Unit Separator
SI 15 0F Crtl O Shift In SP 32 20 Space
DLE 16 10 Crtl P Data Link
Escape
41 42
PART 7
APPROVALS INFORMATION
7.1 CE APPROVAL
This product conforms to the EMC directive 89/336/EEC amended by 93/68/EEC, and with the European Low Voltage Directive 72/23/EEC.
Electrical Safety EN61010-1:2001
Safety requirements for electrical equipment for measurement, control and laboratory.
Basic Insulation Pollution Degree 2 Dielectric withstand Test per 1 min
Input Power to Sensor Metal Body: none
Input Power to Ethernet Output: 1500Vac
Input Power to Relays: 1500Vac
Ethernet Output to Relays: 1500Vac
Measurement Category I
Category I are measurements performed on circuits not directly connected to the Mains Supply (power). Unit measures Air Temperature and Barometric Pressure.
Transients Overvoltage Surge (1.2/50uS Pulse)
Input Power: 500V Transients Overvoltage
Ethernet: 1500V Transients Overvoltage
Note: The ac/dc power adaptor must have Safety Qualified Agency Approvals
for CE with Double Insulation rating. The ac/dc power adaptor is 9Vdc. The minimum output current rating is 500mA.
EMC EN61000-6-1:2001 (Immunity) and EN61000-6-3:2001 (Emmissions)
Immunity requirements for residential, commercial and light-industrial environments
EMC Emissions Table 1, Class B
EMC Immunity Table 1: Enclosure
Table 2: Signal Lines Ports Table 3: Dc input/Dc output Ports
EMC EN61326:1997 + and A1:1998 + A2:2001
Immunity and Emissions requirements for electrical equipment for measurement, control and laboratory.
EMC Emissions Table 4, Class B of EN61326
EMC Immunity Table 1 of EN61326
Note: I/O lines / sensor cables require shielded cables and these cables must be located
on conductive cable trays or in conduits.
Refer to the EMC and Safety installation considerations (Guidelines) of this manual for additional information.
7.2 FCC
This device complies with Part 15, Subpart B, Class B of the FCC rules.
WARRANTY/DISCLAIMER
OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of one (1) year from the date of purchase. In addition to OMEGA’s standard warranty period, OMEGA Engineering will extend the warranty period for one (1) additional year if the warranty card enclosed with each instrument is returned to OMEGA.
If the unit malfunctions, it must be returned to the factory for evaluation. OMEGA’s Customer Service Department will issue an Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to be defective, it will be repaired or replaced at no charge. OMEGA’s WARRANTY does not apply to defects resulting from any action of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair, or unauthorized modification. This WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence of having been damaged as a result of excessive corrosion; or current, heat, moisture or vibration; improper specification; misapplication; misuse or other operating conditions outside of OMEGA’s control. Components which wear are not warranted, including but not limited to contact points, fuses, and triacs.
OMEGA is pleased to offer suggestions on the use of its various products. However, OMEGA neither assumes responsibility for any omissions or errors nor assumes liability for any damages that result from the use of its products in accordance with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by it will be as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATSOEVER, EXPRESS OR IMPLIED, EXCEPT THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exclusive, and the total liability of OMEGA with respect to this order, whether based on contract, warranty, negligence, indemnification, strict liability or otherwise, shall not exceed the purchase price of the component upon which liability is based. In no event shall OMEGA be liable for consequential, incidental or special damages.
CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any Product(s) be used in or with any nuclear installation or activity, medical application, used on humans, or misused in any way, OMEGA assumes no responsibility as set forth in our basic WARRANTY/DISCLAIMER language, and, additionally, purchaser will indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in such a manner.
RETURN REQUESTS/INQUIRIES
Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FROM OMEGA’S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return package and on any correspondence.
The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent breakage in transit.
FOR WARRANTY RETURNS, please have the following information available BEFORE contacting OMEGA:
1. Purchase Order number under which the product was PURCHASED,
2. Model and serial number of the product under warranty, and
3. Repair instructions and/or specific problems relative to the product.
FOR NON-WARRANTY REPAIRS,
consult OMEGA for current repair charges. Have the following information available BEFORE contacting OMEGA:
1. Purchase Order number to cover the COST of the repair,
2. Model and serial number of product, and
3. Repair instructions and/or specific problems relative to the
product.
OMEGA’s policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest in technology and engineering.
© Copyright 2006 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of OMEGA ENGINEERING, INC.
TRADEMARK NOTICE:
®
, omega.com
®
, , and ® are Trademarks of OMEGA ENGINEERING, INC.
PATENT NOTICE: This product is covered by one or more of the following patents: U.S. Pat. No. Des. 336,895; 5,274,577/ CANADA 2052599; 2052600 / ITALY 1249456; 1250938 / FRANCE BREVET No. 91 12756 / SPAIN 2039150; 2048066 / UK PATENT No. GB2 249 837; GB2 248 954 / GERMANY DE 41 34398 C2. Other US and International Patents pending or applied for.
®
M4223/0806
Where Do I Find Everything I Need for
Process Measurement and Control?
OMEGA…Of Course!
Shop on line at omega.com
TEMPERATURE

Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies

Wire: Thermocouple, RTD & Thermistor

Calibrators & Ice Point References

Recorders, Controllers & Process Monitors

Infrared Pyrometers
PRESSURE, STRAIN AND FORCE

Transducers & Strain Gauges

Load Cells & Pressure Gauges

Displacement Transducers

Instrumentation & Accessories
FLOW/LEVEL

Rotameters, Gas Mass Flowmeters & Flow Computers

Air Velocity Indicators

Turbine/Paddlewheel Systems

Totalizers & Batch Controllers
pH/CONDUCTIVITY

pH Electrodes, Testers & Accessories

Benchtop/Laboratory Meters

Controllers, Calibrators, Simulators & Pumps

Industrial pH & Conductivity Equipment
DATA ACQUISITION

Data Acquisition & Engineering Software

Communications-Based Acquisition Systems

Plug-in Cards for Apple, IBM & Compatibles

Datalogging Systems

Recorders, Printers & Plotters
HEATERS

Heating Cable

Cartridge & Strip Heaters

Immersion & Band Heaters

Flexible Heaters

Laboratory Heaters
ENVIRONMENTAL MONITORING AND CONTROL

Metering & Control Instrumentation

Refractometers

Pumps & Tubing

Air, Soil & Water Monitors

Industrial Water & Wastewater Treatment

pH, Conductivity & Dissolved Oxygen Instruments
Loading...
