Dew Point/Humidity
Transmitters
HX200 Series
Standard
HX200HD shown
smaller than
actual size.
U High Accuracy with
Certificate of Calibration
U High Temperature
Sensor to 200ºC (392ºF)
(at 0% RH)
U High Pressure Sensor
to 750 psi (51.7 bar)
U Switchable for Dew Point
or Humidity
U Switchable ºC or ºF
Temperature
The HX200 is a high accuracy
calibrated dew point or humidity
transmitter. The remote sensor is
designed to work at temperatures
as high as 200ºC (392ºF). This
high accuracy sensor is also
built to withstand up to 750 psi.
These transmitters are perfect for
applications such as compressed
air, dryers and environmental
chambers.
Specifications
Dew Point: -60 to 40ºC (-76 to 104ºF)
Relative Humidity: 0 to 95% RH
(non-condensing) unit displays
dew point or humidity, as well as
temperature
Maximum Sensor Pressure Rating:
750 psi (51.7 bar)
Sensor Body Material: 304 SS
Maximum Operating Temperature:
200ºC (392ºF) (at 0% RH)
Mesh Filter Top: Stainless Steel
Single Output: 4 to 20 mA
loop powered (relative humidity
or dew point)
Dew Point Accuracy: ±1.0°C from
-20 to 40°C (-4 to 104°F); ±3.0°C
below -20°C (-4°F)
Relative Humidity Accuracy:
±1% RH from 15 to 40°C
(59 to 104°F), 0 to 90% RH
(non-condensing); ±2% RH below
15°C (59°F) or above 40°C (104°F)
Display: 2 line LCD
Resolution: 0.1
Power: 4 to 20 mA loop
powered, 2-wire 24 Vdc (typical)
12 to 28 Vdc
Dimensions (Enclosure):
88.9 L x 63.5 W mm (3.5 x 2.5")
Mounting Center: 78.7 mm (3.1")
Dimensions of Probe:
Length: 10.16 cm (4")
OD: 1.27 cm (0.5") ½ NPT Fitting
Weight: 1.8 kg (4 lb)
OMEGACARESM extended
SM
warranty program is available for
models shown on this page. Ask
your sales representative for full
Extended Warranty
Program
details when placing an order.
OMEGACARE
labor and equivalent loaners.
SM
covers parts,
To Order
Model No. Description
HX200HD
HX200HR
Comes complete with probe, transmittter, user’s manual and NIST calibration certificate [calibration done at -60°C (-76°F)].
Ordering Example: HX200HD dew point transmitter and OCW-1 OMEGACARESM extends standard 1-year warranty to a total of 2 years.
Dew point transmitter, 4 to 20 mA loop powered output
Relative humidity transmitter, 4 to 20 mA loop powered output
