Heating tapes witH Built-in
adjustaBle tHermostat
HTWAT Series
U Adjustable Thermostat
Control Sets Up to
218°C (425°F)
U No Additional
Control Needed
U Moisture and
Chemical Resistant
U Suitable for Electrically
Conductive Surfaces
U Rapid Heat Up
HTWAT051-002
shown smaller
than actual size.
The HTWAT Series of silicone
rubber heating tapes with adjustable
thermostat control are designed for
process temperature control, freeze
protection, and supplemental heat.
Applications include valves, pipe
lines, bearings, filter housings,
actuators, and more. Simply wrap
the flexible heating tape around
the desired object you want to
heat, set the temperature, and
it will maintain heat at the set
temperature.
SPECIFICATIONS
Adjustable Thermostat:
10 to 218°C (50 to 425°F)
Maximum Exposure Temperature:
232°C (450°F)
Nominal Watt Density:
6.0 Watts/in V (0.009 Watts/mm V)
Minimum Bend Radius:
12.7 mm (0.5")
Outer Sheath:
Extruded silicone rubber
Construction:
Fiberglass, knitted and braided
Power Cord: 1.8 m (6') with plug
on 120V models, stripped lead
ends on 240V models
Power: 120 or 240 Vac
To Order
120 Vac Power
Model No.
HTWAT051-002 HTWAT052-002
HTWAT051-004 HTWAT052-004
HTWAT051-006 HTWAT052-006
HTWAT051-008 HTWAT052-008
HTWAT051-010 HTWAT052-010
HTWAT101-002 HTWAT102-002
HTWAT101-004 HTWAT102-004
HTWAT101-006 HTWAT102-006
HTWAT101-008 HTWAT102-008
HTWAT101-010 HTWAT102-010
HTWAT201-002 HTWAT202-002
HTWAT201-004 HTWAT202-004
HTWAT201-006 HTWAT202-006
HTWAT201-008 HTWAT202-008
HTWAT201-010 HTWAT202-010
HTWAT301-002 HTWAT302-002
HTWAT301-004 HTWAT302-004
HTWAT301-006 HTWAT302-006
HTWAT301-008 HTWAT302-008
HTWAT301-010 HTWAT302-010
240V version is 1800 W.
*
Comes complete with user’s manual. 240V versions are supplied without plugs.
Ordering Examples: HTWAT201-002, heating tape, 2" x 2', 120V, 288 W, with integral
adjustable thermostat.
HTWAT051-002, heating tape,
240 Vac Power
Model No. Power
1
" x 2', 120V, 72 W, with integral adjustable thermostat.
⁄
2
J-26
mm x m (inch x foot)
72 W 12.7 x 0.6 (
144 W 12.7 x 1.2 (
216 W 12.7 x 1.8 (
288 W 12.7 x 2.4 (
360 W 12.7 x 3.0 (
144 W 25.4 x 0.6 (1 x 2)
288 W 25.4 x 1.2 (1 x 4)
432 W 25.4 x 1.8 (1 x 6)
576 W 25.4 x 2.4 (1 x 8)
720 W 25.4 x 3.0 (1 x 10)
288 W 50.8 x 0.6 (2 x 2)
576 W 50.8 x 1.2 (2 x 4)
864 W 50.8 x 1.8 (2 x 6)
1152 W 50.8 x 2.4 (2 x 8)
1440 W 50.8 x 3.0 (2 x 10)
432 W 76.2 x 0.6 (3 x 2)
864 W 76.2 x 1.2 (3 x 4)
1296 W 76.2 x 1.8 (3 x 6)
1440 W 76.2 x 2.4 (3 x 8)
1440 W* 76.2 x 3.0 (3 x 10)
Size
1
⁄2 x 2)
1
⁄2 x 4)
1
⁄2 x 6)
1
⁄2 x 8)
1
⁄2 x 10)
J
