Page 1
User’s Guide
Shop online at
omega.com
e-mail: [email protected]
For latest product manuals:
omegamanual.info
SM
HHSL-101
USB Digital Sound Level
Data Logger
Page 2
omega.com [email protected]
Servicing North America:
U.S.A.: Omega Engineering, Inc., One Omega Drive, P.O. Box 4047
Stamford, CT 06907-0047 USA
Toll-Free: 1-800-826-6342 (USA & Canada only)
Customer Service: 1-800-622-2378 (USA & Canada only)
Engineering Service: 1-800-872-9436 (USA & Canada only)
Tel: (203) 359-1660 Fax: (203) 359-7700
e-mail: [email protected]
For Other Locations Visit omega.com/worldwide
The information contained in this document is believed to be correct, but OMEGA accepts no
liability for any errors it contains, and reserves the right to alter specifications without notice.
Page 3
TABLE OF CONTENTS
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 – 3
Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
What’s in the Package . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setup Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 – 5
Install the Battery . . . . . . . . . . . . . . . . . . . . . 4 – 5
Software, Drivers, Configuration . . . . . . . . . . . . . 5
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . 5 – 6
Deploy the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Button Functions . . . . . . . . . . . . . . . . . . . . . . 5 – 6
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintenance Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
INTRODUCTION
Thank you for purchasing the HHSL-101 USB Digital Sound
Level Data Logger. Please read this user’s manual carefully
and thoroughly before using the instrument.
The HHSL-101 is a low-cost, compact, battery-powered
sound level meter capable of unattended logging (recording)
of the decible level of an environment for days, weeks, or
months. Data logging can be started or stopped by pushing a
button on the unit, eliminating the need to bring a laptop to
the job site.
Windows® 7 and Windows
2
®
XP are registered trademarks of Microsoft Corporation.
Page 4
After a data log has been captured and stored, it can be
uploaded as a .txt file to any PC running the Windows
®
Windows
XP operating system after plugging the HHSL-101
®
7 or
into one of the computer’s USB ports. The HHSL-101’s internal
flash memory is large enough to store up to 32000 data points.
Included with the product—which is slightly larger than a
thumb drive—is a mini-disc with the drivers needed to
interface the unit to the computer, as well as software that
can display a data log file as a table or graph and/or export it
to Microsoft Excel. Exporting to Excel is recommended for
sophisticated trending and analysis of sound level data and
easy detection of unexpected excursions.
KEY FEATURES
• One button starts/stops data logging without a PC
• Plug-and-play USB 2.0 interface; no need for cables,
cradles or docks
• Large storage capacity offers the ability to track, store, and
download 32,000 data points into Excel-Format.
• LCD displays real time sound level
• A/C frequency weighting
• FAST/SLOW time weighting
• MAX/MIN/AVG displays
• High and low alarm limit, selectable sampling time
• Ability to analyze data in graph view using included
software and also print or save the results.
SAFETY INSTRUCTION
Do not use the HHSL-101 in the presence of flammable or
explosive gases.
3
Page 5
WHAT’S IN THE PACKAGE
The HHSL-101 comes in a blister pack containing:
• The instrument (with included “1/2 AA” battery)
• A disc with software drivers for Windows
®
Windows
XP computers, a program for capturing data
®
7 or
logs and displaying them as curves, a software installation
and operation manual, a PDF of this user’s manual
• A stand to mount the instrument
• A USB extension cord
• A hard copy of this user’s manual (inside the fold-over card)
PRODUCT OVERVIEW
Fig. 1 shows the main components, controls, display and
connectors of the HHSL-101.
names and functions before
moving on to the Setup
Instructions.
A
A. Microphone
B. Function button
C. LCD
D. Protective cap
E. Full-size USB plug
Fig. 1
B
D
C
E
SETUP INSTRUCTIONS
INSTALL THE BATTERY
The HHSL-101 uses a 3.6VDC “1/2 AA” Lithium-ion battery
(included).
To open the battey compartment
screwdriver with a fine point to push in the silver flange
4
, use a
Page 6
showing through the small square hole in the rear of the unit.
Push back the cover, insert a fresh battery in the correct
orientation, and replace the cover, pushing it forward until you
feel and hear a click.
Note: If the battery is removed from a unit before it has been
set up from software or while it is recording, the unit must be
reconfigured before it can be reactivated. If it is not
reconfigured, the unit will remain in standby mode.
Replacement “1/2 AA” batteries are available from Omega
(part no. OM-EL-BATT).
SOFTWARE, DRIVERS, CONFIGURATION
Please refer to the software manual on the CD for installation,
configuration and operating instructions.
OPERATING INSTRUCTIONS
DEPLOY THE UNIT
The HHSL-101 is particularly easy to deploy on a job site
because the unit does not need to be plugged into a computer
to be activated (ready to start logging data). The HHSL-101—
with its protective cap on—can be deployed either by laying
it on a horizontal surface or by mounting it onto the stand
provided.
BUTTON FUNCTIONS
To turn on the device, press and hold the unlabeled yellow
Function button (Fig. 1, Callout B) for 3 seconds. If the device
has not yet been activated, this operation will activate the
Log
device and the LCD will display
activated, this operation will deactivate the logger and the
LCD will display
Con
. If the memory is full, the LCD will
. If the device is already
5
Page 7
display
modes which are
the button briefly to switch between these modes.
Normal
Max
Min
Avg
Status
FUL
during recording. The data logger has 5 display
Normal, Max, Avg
: displays current sound level
: displays the maximum reading recorded since activation
of this mode
: displays the minimum reading recorded since activation
of this mode
: displays the average value of readings recorded since
activation of this mode
: displays status of the device
Log
: currently logging data
Con
: inactive; connect to computer to configure for next
data logging session
Ful
: memory is full
---
configured and ready to start logging
and
Status
. Press
SPECIFICATIONS
Range: 30~130dB Resolution: 0.1dB Accuracy: ±1.5dB
Max capacity: 32000 data points Link Protocol: USB 1.0/2.0
Power supply: DC3.6V Li Battery Capacity: 1200mAh
Working current: <1mA
Operating temperature: 32° to 122°F (0° to 50°C)
Operating humidity: 10-90%RH non-condensing
Storage temperature: 14° to 122°F (-10° to 50°C),
5% to 95%RH w/o battery
Dimensions: 7.09 x 1.10 x 1.06 in. (180 x 28 x 27 mm)
Weight: 2.01 oz. (57g) w/o battery
6
Page 8
MAINTENANCE TIPS
• Avoid dropping the unit. Do not subject it to violent shock or
vibration or expose it to strong electromagnetic fields (for
example, near arc welders or induction heaters).
• Keep the unit out of direct sunlight.
• Do not use chemicals or abrasive cloth to clean the display
window or housing.
• Before storing the HHSL-101 for an extended period of time
(several months or more), remove the battery to avoid
having it leak and damage the unit.
7
