Omega HHM63F User guide

OMEGA

HHM63F

Digital Multimeter

omega. com

TM

OMEGAnetSM On-Line Service

http://www.omega.com

Servicing North America:

USA: ISO 9001 Certified Canada:

One Omega Drive, Box 4047 976 Bergar

Stamford, CT 06907-0047 Laval (Quebec) H7L5A1

Tel: [phone] Tel: [phone]

FAX: [phone] FAX: [phone]

e-mail: [email protected] e-mail: [email protected]

Benelux:

Postbus 8034, 1180 LA Amstelveen,

The Netherlands

Tel: [phone] FAX: [phone]

Toll Free in Benelux: 06 0993344

e-mail: [email protected]

Czech Republic:

ul. Rude armady 1868, 733 01 Karvina-

Hranice, Czech Repubic

Tel: [phone] FAX: 420 (69)

6311114

e-mail: [email protected]

France:

9, rue Denis Papin, 78190 Trappes

Tel: [phone] FAX: [phone]

Toll Free in France: 0800-4-06342

e-mail: [email protected]

Germany/Austria:

Daimlerstrasse 26, D-75392

Deckenpfronn, Germany

Tel: [phone] FAX: [phone]

Toll Free in Germany: 0800 82 66342

e-mail: [email protected]

Internet e-mail

[email protected]

For immediate technical or application assistance:

USA and Canada: Mexico and Latin America:

Sales Service: 1-800-826-6342 / 1-800-TC-OMEGASMTel: (95) 800-TC-OMEGA

Customer Service: 1-800-622-2378 / 1-800-622-BESTSMFAX: (95) 203-359-7807

Engineering Service: 1-800-872-9436 / 1-800-USA-WHENSMEn Español: [phone]

TELEX: 996404 EASYLINK: 62968934 CABLE: OMEGA

e-mail: [email protected]

Servicing Europe:

United Kingdom: ISO 9002 Certified

One Omega Drive

Riverbend Technology Centre Northbank, Irlam,

Manchester, M44 5EX, England

Tel: [phone] FAX: [phone]

Toll Free in England: 0800-488-488

e-mail: [email protected]

SM

SAFETY INFORMATION

The following safety information must be observed to insure maximum

personal safety during the operation at this meter:

1. Do not use the meter if the meter or test leads look damaged, or if you suspect
that the meter is not operating properly.

2. This meter is not recommended for high voltage industrial use; for example,
not for measurements of 440 VAC or 600 VAC industrial power mains. The unit
is intended for use with low energy circuits to 600V AC/DC or high energy
circuit to 250 VAC or DC.

3. Use caution when working above 60V dc or 30V ac rms. Such voltages pose
a shock hazard.

4. When using the probes, keep your fingers behind the finger guards on the
probes.

5. Measuring voltage which exceeds the limits of the meter may cause damage
and expose the operator to a shock hazard. Always respect the voltage limits
as stated on the meter.

6. If the equipment is used in a manner not specified by the manufacturer, the
protection provided by the equipment may be impaired.

1

SPECIFICATIONS

Display: Liquid crystal display (LCD) with a maximum reading of 2500.
Polarity: Automatic, positive implied, negative polarity indication.
Overrange: "OL"or "-OL" is displayed.
Low battery indication: The " " is displayed when the battery voltage drops

below the operating level.

Measurement rate: 2.5 times per second, nominal.
Operating Environment: 32°F to 104°F at < 70% relative humidity.
Storage Temperature: -4°F to 140°F, 0 to 80% R.H. with battery removed from

meter.

Accuracy: Stated accuracy at 73.4°F ± 9°F, <75% relative humidity.
Auto Power off: 30minutes after moving switch and push button no changes.turn

the meter off then on to resume operation.

Safety: According to EN61010-1 protection class II overvoltage category (CAT

II 600V) pollution degree 2.

Power: 4 pcs 1.5V (AAA size).
Battery life: 500 hours typical.
Dimensions: 170mm (H) x 44mm (W) x 40mm (D).
Weight: 140g including batteries.

2

DC VOLTS

Ranges 250mV,2.5V,25V,250V,600V
Resolution 100µV
Accuracy ±(0.25%rdg + 5dgts) on 250mV range

Input impedance >10MW
Overload & protection 600VDC or AC rms

±(0.25%rdg + 1dgt) on other ranges

AC VOLTS (50Hz - 500Hz)

Ranges 2.5V,25V,250V,600V
Resolution 1mV
Accuracy ±(0.75% of reading + 4dgts) on 2.5V to 600V
Input impedance >10MW
Overload & protection 600VDC or AC rms

RESISTANCE

Ranges 250W,2.5KW ,25KW ,250KW ,2.5MW ,25MW
Resolution: 100mW

3

Accuracy: ±(0.3%rdg + 3dgts) on 250W range

Open circuit volts 0.4Vdc
Overload protection 500VDC or AC rms

±(0.3%rdg + 1dgt) on 2.5KW to 2.5MW ranges
±(3.5%rdg + 4dgts) on 25MW range

CONTINUITY

Audible indication <100W
Overload protection 500VDC or AC rms

DIODE TEST

Accuracy ±(3.0%rdg + 3dgts)
Resolution 1mV
Test current 0.25±0.2mA
Test voltage <1.6V

CAPACITANCE (Autoranging)

Ranges 250nF,2.5µF,25µF
Accuracy ±(5.0%rdg + 10dgts)
Overload protection 500VDC or AC rms

4

FREQUENCY (Autoranging)

Ranges 5.000Hz,50.00Hz,500.0Hz,5.000KHz
Resolution 0.001Hz
Accuracy ±(0.05%rdg + 2dgts)
Sensitivity 1.0V rms min

Overload protection 500VDC or AC rms

Alternating Pulse or SINE wave signal on all range

DUTY CYCLE (2Hz to 1kHz)

Ranges 10% to 90%
Resolution 0.1%
Accuracy ±5dgts @ 2Vrms min Alternating Pulse signal
Pulse Width 50µs
Overload protection 500VDC or AC rms

TEMPERATURE (Autoranging)

Ranges -4°F to 2498°F
Resolution 0.1°F or 1°F
Accuracy ±(2.0%rdg + 6°F) on -4°F to 923°F

±(3.0%rdg + 4°F) on 923°F to 2498°F

5

OPERATION

Before taking any measurements, read the Safety Information Section.

Always examine the instrument for damage, contamination (excessive dirt,
grease, etc.) and defects. Examine the test leads for cracked or frayed insulation.
If any abnormal conditions exist do not attempt to make any measurements.

Auto Power-down mode

If unused for about 30 minutes, the tester will power-down automatically. If you
should diseble Auto Power-down mode, press SELECT buttom when you turn on
the meter.

Back-Light and Data-Hold Switch ( >2sec),( H ):

Press this button briefly to activate DATA-HOLD mode. The " H " annunciator is
displayed.
Press this button for 2 seconds to turn the Back-Light on. As this also activates
the DATA-HOLD mode, briefly press the button to return to normal display. To
turn the Back-Light off press again for 2 seconds.

6

SELECT Function Button (DC/AC),(

The SELECT Function button is Yellow in color. Press it to toggle to the alternate
function (AC, Audible continuity, Diode and capacitance) shown in Yellow on the
meter face.

WW

W / / )

WW

Voltage Measurements

1. Connect the red test lead to the "VW" jack and the black test lead to the "COM"
jack.

2. Set the Function/Range switch to the desired voltage function.

3. Connect the test leads to the device or circuit being measured.

4. For dc, a (-) sign is displayed for negative polarity; positive polarity is implied.

Frequency Measurements

1. Set the Function/Range switch to the ACV position, and then press Hz-%
button toggle the voltage/frequency/duty cycle mode.

2. Connect the red test lead to the "VW" jack and the black test lead to the "COM"
jack.

3. Connect the test leads to the point of measurement and read the frequency
from the display.

7

Duty Cycle Measurements

1. Set the Function/Range switch to the ACV position, and then press Hz-%
button toggle the voltage/frequency/duty cycle mode.

2. Connect the red test lead to the "VW " jack and the black test lead to the "COM"
jack.

3. Connect the test leads to the point of measurement. The display will indicate
10% to 90% of the frequency duty cycle.

Resistance Measurements

1. Set the Function/Range switch to

2. Remove power from the equipment under test.

3. Connect the red test lead to the "VW " jack and the black test lead to the "COM"
jack.

4. Touch the probes to the test points. In ohms, the value indicated in the display
is the measured value of resistance.

WARNING

The accuracy of the functions might be slightly affected, when exposed to a
radiated electromagnetic field environment, eg, radio, telephone or similar.

WW

W/ / position.

WW

8

Diode Tests

1. Set the Function/Range switch to

2. Remove power from the equipment under test.

3. To toggle the W/continity/diode/capacitance modes, press SELECT switch.

4. Touch probes to the diode. A forward-voltage drop is about 0.6V (typical for
a silicon diode).

5. Reverse probes. If the diode is good, "OL" is displayed. If the diode is shorted,
".000" or another number is displayed.

6. If the diode is open, "OL" is displayed, in both directions.

7. If the junction is measured in a circuit and a low reading is obtained with both
lead connections, the junction may be shunted by a resistance of less than
1kW . In this case the diode must be disconnected from the circuit for accurate
testing.

WW

W/ / position.

WW

Continuity Measurements

1. Set the Function/Range switch to

2. Remove power from the equipment under test.

3. To toggle the W/continity/diode/capacitance modes, press SELECT switch.

4. Connect the test leads to the two points at which continuity is to be tested. The
buzzer will sound if the resistance is less than approximately 100W .

WW

W/ / position.

WW

9

Capacitance Measurements

1. Set the Function/Range switch to

2. Remove power from the equipment under test.

3. To toggle the W /continity/diode/capacitance modes, press SELECT switch.

4. Dischange capacitors before trying to measure it.

5. Connect the "+" lead to the "VW " jack and the "-" lead to the "COM" jack.

6. Read the capacitance directly from the display.

WW

W/ / position.

WW

Temperature M easurements

Remove test leads being measured

1. Set the Function/Range switch to the "°F" position, and then press °F button
toggle the ohm/°F mode.

2. Connect a type k thermocouple to the jack on the instrument. Place the probe
or thermocouple tip on or in the material to be measured and take the
temperature reading directly from the display.

WARNING

10

MAINTENANCE

Remove test leads before changing batteries or fuse

or performing any servicing.

Battery Replacement

Power is supplied by four 1.5V (AAA size) batteries. The " " appears on the LCD
display when replacement is needed.To replace the batteries, remove the screw
from the back of the meter and lift off the battery cover case. Remove the
batteries from battery contacts.

Cleaning

Periodically wipe the case with a damp cloth and detergent, do not use abrasives
or solvents.

WARNING

11

OMEGA warrants this unit to be free of defects in materials and workmanship and to give satisfactory service for a
period of 13 months from date of purchase. OMEGA Warranty adds an additional one (1) month grace period to the
normal one (1) year product warranty to cover handling and shipping time. This ensures that OMEGA's customers
receive maximum coverage on each product. If the unit should malfunction, it must be returned to the factory for
evaluation. OMEGA's Customer Service Department will issue an Authorized Return (AR) number immediately
upon phone or written request. Upon examination by OMEGA, if the unit is found to be def ective it will be repaired or
replaced at no charge. However, this WARRANTY is VOID if the unit shows e vidence of having been tampered with
or shows evidence of being damaged as a result of excessive corrosion; or current, heat moisture or vibration;
improper specification; misapplication; misuse or other operating conditions outside of OMEGA's control. Components
which wear or which are damaged by misuse are not warranted. This includes contact points, fuses, and triacs.

OMEGA is glad to offer suggestions on the of use of its various products. Nevertheless, OMEGA only warrants
that the parts manufactured by it will be as specified and free of defects

OMEGA MAKES NO OTHER WARRANTIES OR REPRESENTATIONS OF ANY KIND WHATSOEVER,
EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE AND ALL IMPLIED WARRANTIES INCLUDING ANY
WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY
DISCLAIMED.

LIMITATION OF LIABILITY: The remedies of purchaser set forth herein are exc lusive and the total liability of
OMEGA with respect to this order, whether based on contract warranty, negligence, indemnification, strict
liability or otherwise, shall not exceed the purchase price of the component upon which liability is based. In
no event shall OMEGA be liable for consequential, incidental or special damages.

Every precaution for accuracy has been taken in the preparation of this manual; ho we v er, OMEGA ENGINEERING,
INC. neither assumes responsibility for any omissions or errors that ma y appear nor assumes liability for any damages
that result from the use of the products in accordance with the information contained in the manual.

SPECIAL CONDITION: Should this equipment be used in or with any nuclear installation or activity, purchaser will
indemnity OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the
equipment in such a manner.

WARRANTY

It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is
constantly pursuing certification of its products to the European New Approach Directives. OMEGA will add the CE
mark to every appropriate device upon certification.
The information contained in this document is believed to be correct but OMEGA Engineering, Inc. accepts no
liability for any errors it contains, and reserves the right to alter specifications without notice.
WARNING: These products are not designed for use in, and should not be used for, patient connected application.

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING
ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FR OM
OMEGA'S CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned
AR number should then be marked on the outside of the return package and on any correspondence.
The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prev ent breakage in
transit.

FOR WARRANTY RETURNS, please have the following

information available BEFORE contacting OMEGA:

1. P.O. number under which the product was

PURCHASED.

2. Model and serial number of the product under

warranty, and

3. Repair instructions and/or specific problems relative

to the product.

OMEGA's policy is to make running changes, not model changes, whenever an improvement is possible. This
affords our customers the latest in technology and engineering. OMEGA is a registered trademark of OMEGA
ENGINEERING, INC. © Copyright 1999 OMEGA ENGINEERING, INC. All rights reserved. This document may not
be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable from, in
whole or in part, without prior written consent of OMEGA ENGINEERING, INC.

RETURN REQUESTS / INQUIRIES

FOR NON-WARRANTY REPAIRS, consult OMEGA for

current repair charges. Hav e the f ollo wing inf ormation
available BEFORE contacting OMEGA:

1. P.O. number to cover the COST of the repair.

2. Model and serial number of product , and

3. Repair instructions and/or specific problems relative
to the product.

Where Do I Find Everything I Need for

Process Measurement and Control?

HEATERS

þ Heating Cable

þ Cartridge & Strip Heaters

þ Immersion & Band Heaters

þ Flexible Heaters

þ Laboratory Heaters

PRESSURE/STRAIN AND FORCE

þ Transducers & Strain Gauges

þ Load Cells & Pressure Gauges

þ Displacement Transducers

þ Instrumentation & Accessories

FLOW/LEVEL

þ Rotameters, Gas Mass

Flowmeters & Flow Computers

þ Air Velocity Indicators

þ Turbine/Paddlewheel Systems

þ Totalizers & Batch Controllers

M-2896/0799

OMEGA...Of Course!

TEMPERATURE

þ

Thermocouple, RTD & Thermistor

Probes, Connectors, Panels &

Assemblies

þ Wire: Thermocouple, RTD &

Thermistor

þ

Calibrators & Ice Point References

þ

Recorders, Controllers & Process

Monitors

þ Infrared Pyrometers

ENVIRONMENTAL
MONITORING AND CONTROL

þ

Metering & Control Instrumentation

þ Refractometers

þ Pumps & Tubing

þ Air, Soil & Water Monitors

þ Industrial Water & Wastewater

Treatment

þ pH, Conductivity & Dissolved

Oxygen Instruments

pH/CONDUCTIVITY

þ pH Electrodes, Testers &

Accessories

þ Benchtop/Laboratory Meters

þ Controllers, Calibrators,

Simulators & Pumps

þ Industrial pH & Conductivity

Equipment

DATA ACQUISITION

þ Data Acquisition & Engineering

Software

þ Communications-Based

Acquisition Systems

þ Plug-in Cards for Apple, IBM

& Compatibles

þ Datalogging Systems

þ Recorders, Printers & Plotters
