Omega HHM596C User Manual

OMEGA

HHM596C

Digital Clamp-On Meter

OMEGAnetSM On-Line Service

http://www.omega.com

Internet e-mail

[e-mail]

Servicing North America:

USA: ISO 9001 Certified Canada:

One Omega Drive, Box 4047 976 Bergar

Stamford, CT 06907-0047 Laval (Quebec) H7L5A1

Tel: [phone] Tel: [phone]

FAX: [phone] FAX: [phone]

e-mail: [e-mail] e-mail: [e-mail]

omega.com

TM

For immediate technical or application assistance:

USA and Canada: Mexico and Latin America:

Sales Service: 1-800-826-6342 / 1-800-TC-OMEGA

SM

Tel: (95) 800-TC-OMEGA

SM

Customer Service: 1-800-622-2378 / 1-800-622-BEST

SM

FAX: [phone]

Engineering Service: 1-800-872-9436 / 1-800-USA-WHEN

SM

En Español: [phone]

TELEX: 996404 EASYLINK: 62968934 CABLE: OMEGA e-mail: [e-mail]

Servicing Europe:

Benelux: Germany/Austria:

Postbus 8034, 1180 LA Amstelveen, Daimlerstrasse 26, D-75392

The Netherlands Deckenpfronn, Germany

Tel: [phone] FAX: [phone] Tel: [phone] FAX: [phone]

Toll Free in Benelux: 06 0993344 Toll Free in Germany: 0800 82 66342

e-mail: [e-mail] e-mail: [e-mail]

Czech Republic: United Kingdom: ISO 9002 Certified

ul. Rude armady 1868, 733 01 Karvina- One Omega Drive

Hranice, Czech Repubic Riverbend Technology Centre Northbank, Irlam,

Tel: [phone] FAX: [phone] Manchester, M44 5EX, England

e-mail: [e-mail] Tel: [phone] FAX: [phone]

France:

9, rue Denis Papin, 78190 Trappes Toll Free in England: 0800-488-488

Tel: [phone] FAX: [phone] e-mail: [e-mail]

Toll Free in France: 0800-4-06342

e-mail: [e-mail]

It is the policy of OMEGA to comply with all worldwide safety and EMC/EMI regulations that apply. OMEGA is constantly pursuing cer tification
of its products to the European New Approach Directives. OMEGA will add the CE mark to every appropriate device upon certification.
The information contained in this document is believed to be correct but OMEGA Engineering, Inc. accepts no liability for any errors it contains,
and reserves the right to alter specifications without notice.
WARNING: These products are not designed for use in, and should not be used for, patient connected application.

1

SAFETY INFORMATION

The following safety information must be observed to insure maximum

personal safety during the operation at this meter:

1. Do not use the meter if the meter or test leads look damaged, or if you
suspect that the meter is not operating properly.

2. Use caution when working above 60V dc or 30V ac rms. Such voltages pose
a shock hazard.

3. When Using the probes, keep your fingers behind the finger guards on the
probes.

4. Measuring voltage which exceeds the limits of the clampmeter may damage
the meter and expose the operator to a shock hazard. Always recognize the
meter voltage limits as stated on the front of the meter.

5. If the equipment is used in a manner not specified by the manufacturer, the
protection provided the equipment may be impaired.

2

SPECIFICATIONS

Display: 3¾ digit (4300 counts), and function units sign annunciators.
Polarity: Automatic, positive implied, negative polarity indication.
Overrange: "OL"or"-OL" is displayed.
Low battery indication: the " " is displayed when the battery voltage drops

below the operating level.

Measurement rate: 2.5 times per second, nominal.
Operating Environment: 0°C to 40°C at < 70% relative humidity.
Storage Temperature: -20°C to 60°C, 0 to 80% R.H. with battery removed

from meter.

Accuracy: Stated accuracy at 23°C ± 5°C, <75% relative humidity.
Safety: According to EN61010-1 protection class II overvoltage category

(CAT III 600V) pollution degree 2.

Auto Power off: 30minutes after rotary switch and push button no changes.

(except MAX/MIN function)

Clamp jaw: According to EN61010-2-032 CAT IV 600V.
Power: single standard 9-volt battery.
Battery life: 150 hours typical.
Dimensions: 250mm (H) x 100mm (W) x 46mm (D).
Weight: Approx. 380g including battery.
Accessories: One pair test leads, 9V battery.

3

DC VOLTS

Ranges: 430mV,4.3V,43V,430V,600V (430mV only manual range)
Resolution: 100µV
Accuracy: ±(0.25%rdg + 1dgt) on 430mV to 430V ranges

±(0.25%rdg + 3dgts) on 600V range

Input impedance: >10MW
Overload protection: 600VDC or AC rms

AC VOLTS (50Hz-500Hz)

Ranges: 4.3V,43V,430V,600V
Resolution: 1mV
Accuracy: ±(1.2%rdg + 4dgts) on 4.3V range

±(0.75%rdg + 4dgts) on other ranges

Input impedance: >10MW
Effect Reading: 100 - 4300
Overload protection: 600VDC or 600VAC rms

RESISTANCE

Ranges: 430W ,4.3KW ,43KW,430KW,4.3MW,43MW
Accuracy: ±(0.5%rdg + 2dgts) on 430W range

±(0.5%rdg + 1dgt) on 4.3KW to 430KW ranges
±(0.8%rdg + 1dgt) on 4.3MW range
±(2.0%rdg + 4dgts) on 43MW range

Open circuit volts: 2.8V on 430W range, 0.7V on 4.3KW range

0.47V on 43KW to 43MW ranges

Overload protection: 600VDC or AC rms

4

CONTINUITY

Audible indication: less than 50W±30W
Overload protection: 600VDC or AC rms

DIODE TEST

Test current: 1.0mA±0.6mA
Accuracy: ±(10.0%rdg + 3dgts)
Open circuit volts: 3.0Vdc typical
Overload protection: 600VDC or AC rms

FREQUENCY

Ranges: 430Hz,4.3KHz
Resolution: 0.1Hz
Accuracy: ±(1.0%rdg + 3dgts)
Sensitivity: 1.0Vrms min
Effect reading: 100-4300
Overload protection: 600VDC or AC rms

DC CURRENT (Put conductor at the center of the jaws)

Ranges: 430A,700A
Resolution: 100mA
Accuracy: ±(1.5%rdg + 5dgts)

*700A to 1200A: ±(2.0%rdg + 5dgts)
Overload protection: 1200Adc max. for 1 minute

AC CURRENT (40Hz-500Hz) (Put conductor at the center of the jaws)

Ranges: 430A,700A
Resolution: 100mA
Accuracy: ±(1.75%rdg + 5dgts) on 50Hz-60Hz

±(3.5%rdg + 5dgts) on 40Hz-500Hz

*700A to 1000A(50Hz/60Hz): ±(2.5%rdg + 5dgts)

Overload protection: 1000Aac max. for 1 minute

TEMPERATURE(K-TYPE)

Ranges: -20°C to 850°C

-4°F to 1562°F

Accuracy: ±(0.5%rdg + 3dgts) on °C range

±(0.5%rdg + 6dgts) on °F range

5

OPERATION

Before taking any measurements, read the Safety Information Section.

Always examine the instrument for damage, contamination (excessive dirt,
grease, etc.) and defects. Examine the test leads for cracked or frayed
insulation. If any abnormal conditions exist do not attempt to make any
measurements.

H Button

In voltage, current, frequency and doide functions, Press " H " button to toggle
in and out of the Auto Hold mode, the " H " annunicator is displayed. In Auto
hold mode, the meter will capture and hold the first stable non-zero(>100
digits) reading after a zero reading(<100 digits). Several consecutive mea­surements can be held and displayed without pressing the (A-H) buttion.
Simply by shorting the test leads together between measurements. In resis­tance, continuity and temperature functions, press " H " button to toggle in and
out of the Data Hold mode, the " H " annunicator is displayed.

PEAK HOLD Button: (only AC functions 40-60Hz)

Press "PEAK" button to toggle in and out of PEAK Hold mode. In the PEAK
Hold mode, the "MAX P " annunciator is displayed. [Accuracy: ±(10% rdg +
10dgts), effect reading: 800~4300]

6

7

MIN / MAX button

Press (MAX/MIN) to enter the MAX MIN AVG Recording mode (manual range
only). The RECORD annunciator turns on and the automatic power-off feature
is disabled.
Push (MAX/MIN) to cycle through the maximum(MAX), minimum(MIN),
average(AVG) and present readings. (AVG) is average last ten times reading
can be displayed. Press and hold down the (MAX/MIN) for 2 seconds to exit
and erase recorded reading.

DD

DD

DZERO Button

In voltage, current, frequency and doide functions, Press (

DD

DD

DZERO) button to

toggle in and out of the Relative mode, the "ZERO" annunciator turn on, zero
the display, and store the displayed reading as a reference value.

RANGE Button

Press (RANGE) button to select the Manual Range mode and turn on the "
" annunciator. (The meter selected next range it was in when manual ranging
was selected).
In the Manual Range mode. each time you press (RANGE) button, the range
(and the input range annunciator) increments, and a new value is displayed.
To exit the Manual Range mode and return to autoranging, press and hold
down (RANGE) button for 2 seconds. The "

" annunciator will disappear.

8

Voltage Measurements

1. Connect the red test lead to the "V" jack and the black test lead to the "COM"
jack.

2. Set the Function/Range switch to the desired voltage range (AC or DC). The
meter will automatically select the best voltage range.

3. Connect the test leads to the device or circuit being measured.

4. For dc, a (-) sign is displayed for negative polarity; positive polarity is implied.

Current Measurements

1. Set the Function/Range switch to the desired highest 700A range (AC or
DC). In DC current measurement use

DD

DD

DZERO button, offset the residual

magnetic of the jaws.

2. Press the trigger to open transformer jaws and clamp onto one conductor
only. Read the current directly on the display. It is recommended that the
conductor be placed at the center of the closed jaws for maximum accuracy.

3. When the reading is lower than 430 counts, set the range switch to the next
lower range position. For maximum accuracy, select the lower range
possible without overranging the meter.

Resistance Measurements

1. Set the Function/Range switch to the resistance range.

2. Remove power from the equipment under test.

3. Connect the red test lead to the " + " jack and the black test lead to the "COM"
jack.

4. Touch the probes to the test points. In ohms, the value indicated in the
display is the measured value of resistance.

WARNING

The accuracy of the functions might be slightly affected, when exposed to
a radiated electromagnetic field environment, eg, radio, telephone or
similar.

Continuity Measurements

1. Set the Function/Range switch to the " " position.

2. Remove power from the equipment under test.

3. Connect the red test lead to the " + " jack and the black test lead to the "COM"
jack.

4. Touch the probes to the test points. the beeper sounds continuously, if the
resistance is less than 50W ±30W .

Diode Tests

1. Connect the red test lead to the " + " jack and the black test lead to the "COM"
jack.

2. Set the Function/Range switch to the "

" position.

3. Turn off power to the circuit under test.

4. Touch probes to the diode. A forward-voltage drop is about 0.6V (typical for
a silicon diode).

5. Reverse probes. If the diode is good, "OL" is displayed. If the diode is
shorted, ".000" or another number is displayed.

6. If the diode is open, "OL" is displayed in both directions.

9

10

Frequency Measurements

1. Set the Function/Range switch to the Hz desired range.

2. Connect the red test lead to the " + " jack and the black test lead to the "COM"
jack.

3. Connect the test leads to the point of measurement and read the frequency
from the display.

Temperature Measurements

1. Set the Function/Range switch to the "°C" position.

2. Connect the temperature transition adaptor to the meter and make sure "
+ " and " - " polarity is right position.

3. Connect a type k thermocouple to the jack on the transition adaptor. Place
the probe or thermocouple tip on or in the material to be measured and take
the temperature reading directly from the display.

WARNING

Remove test leads being measured

MAINTENANCE

WARNING

Remove test leads before changing battery

or performing any servicing.

Battery Replacement

Power is supplied by a 9 volt "transistor" battery. (NEDA 1604, IEC 6F22). The
" " appears on the LCD display when replacement is needed. To replace the
battery, remove the two screws from the back of the meter and lift off the
battery cover. Remove the battery from battery contacts.

Cleaning

Periodically wipe the case with a damp cloth and detergent, do not use
abrasives or solvents.

11

WARRANTY / DISCLAIMER

OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months
from date of purchase. OMEGA Warranty adds an additional one (1) month grace period to the normal one (1) year product
warranty to cover handling and shipping time. This ensures that OMEGA's customers receive maximum cover age on each product.If
the unit should malfunction, it must be returned to the factory for evaluation. OMEGA's Customer Service Department will issue an
Authorized Return (AR) number immediately upon phone or written request. Upon examination by OMEGA, if the unit is found to
be defectiv e it will be repaired or replaced at no charge. OMEGA's W ARRANTY does not apply to def ects resulting from any action
of the purchaser, including but not limited to mishandling, improper interfacing, operation outside of design limits, improper repair,
or unauthorized modification. This W ARRANTY is V OID if the unit shows evidence of ha ving been tampered with or shows evidence
of being damaged as a result of excessive corrosion; or current, heat moisture or vibration; improper specification; misapplication;
misuse or other operating conditions outside of OMEGA's control. Components which wear are not warranted, including but not
limited to contact points, fuses, and triacs.

OMEGA is pleased to offer suggestions on the use of its various products. However , OMEGA neither assumes responsibility
for any omissions or err or s nor assumes liability for any damages that result from the use of its products in accordance
with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by it
will be as specified and free of defects. OMEGA MAKES NO O THER WARRANTIES OR REPRESENT ATIONS OF ANY KIND
WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE AND ALL IMPLIED WARRANTIES INCLUDING ANY
WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE HEREBY DISCLAIMED.
LIMITA TION OF LIABILITY: The remedies of purchaser set forth herein are exclusive and the total liability of OMEGA with
respect to this order , whether based on contract, warranty, negligence, indemnification, strict liability or otherwise, shall
not exceed the purchase price of the component upon which liability is based. In no event shall OMEGA be liable for
consequential, incidental or special damages.

CONDITIONS: Equipment sold b y OMEGA is not intended to be used, nor shall it be used: (1) as a "Basic Component" under 10
CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any
Product(s) be used in or with any nuclear installation or activity, medical application, used on humans, or misused in any way,
OMEGA assumes no responsibility as set forth in our basic W ARRANTY / DISCLAIMER language, and additionally, purchaser will
indemnify OMEGA and hold OMEGA harmless from any liability or damage whatsoever arising out of the use of the Product(s) in
such a manner.

RETURN REQUESTS / INQUIRIES

Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING ANY
PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR) NUMBER FROM OMEGA'S
CUSTOMER SERVICE DEPARTMENT (IN ORDER TO AVOID PROCESSING DELAYS). The assigned AR number should then
be marked on the outside of the return package and on any correspondence.
The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent breakage in transit.

FOR WARRANTY RETURNS, please ha ve the following

information available BEFORE contacting OMEGA:

1. P.O. number under which the product was PURCHASED.

2. Model and serial number of the product under warranty, and

3. Repair instructions and/or specific problems relative to the

product.

FOR NON-WARRANTY REPAIRS, consult OMEGA for

current repair charges. Have the following information
available BEFORE contacting OMEGA:

1. P.O. number to cover the COST of the repair.

2. Model and serial number of product , and

3. Repair instructions and/or specific problems relative to the
product.

OMEGA's policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest
in technology and engineering. OMEGA is a registered trademark of OMEGA ENGINEERING, INC. © Copyright 1999 OMEGA ENGINEERING,
INC. All rights reserved. This document may not be copied, photocopied, reproduced, translated, or reduced to any electronic medium or
machine-readable from, in whole or in part, without prior written consent of OMEGA ENGINEERING, INC.

M-2880/0799

Where Do I Find Everything I Need for

Process Measurement and Control?

OMEGA...Of Course!

TEMPERATURE

þ Thermocouple, RTD & Thermistor

Probes, Connectors, Panels & Assemblies

þ Wire: Thermocouple, RTD & Thermistor

þ Calibrators & Ice Point References

þ Recorders, Controllers & Process Monitors

þ Infrared Pyrometers

PRESSURE/STRAIN AND FORCE

þ Transducers & Strain Gauges

þ Load Cells & Pressure Gauges

þ Displacement Transducers

þ Instrumentation & Accessories

FLOW/LEVEL

þ Rotameters, Gas Mass Flowmeters

& Flow Computers

þ Air Velocity Indicators

þ Turbine/Paddlewheel Systems

þ Totalizers & Batch Controllers

pH/CONDUCTIVITY

þ pH Electrodes, Testers & Accessories

þ Benchtop/Laboratory Meters

þ Controllers, Calibrators, Simulators

& Pumps

þ Industrial pH & Conductivity Equipment

DATA ACQUISITION

þ Data Acquisition &

Engineering Software

þ Communications-Based

Acquisition Systems

þ Plug-in Cards for Apple, IBM

& Compatibles

þ Datalogging Systems

þ Recorders, Printers & Plotters

HEATERS

þ Heating Cable

þ Cartridge & Strip Heaters

þ Immersion & Band Heaters

þ Flexible Heaters

þ Laboratory Heaters

ENVIRONMENTAL
MONITORING AND CONTROL

þ Metering & Control Instrumentation

þ Refractometers

þ Pumps & Tubing

þ Air, Soil & Water Monitors

þ Industrial Water & Wastewater

Treatment

þ pH, Conductivity & Dissolved Oxygen

Instruments
