HandHeld Rotating Vane
tHeRMo-aneMoMeteR
HHF143 Series
No Points
Standard
U High Accuracy
(±1.0% of Reading)
U Low Speed Sensitivity
U Wide Temperature
Range -20 to 100°C
(-4 to 212°F)
U Temperature
Measurement Standard
U Minimum and
Maximum Recall
U Analog Voltage Output and
Communication Options
U NIST Calibration Included
HHF143B
shown smaller
than actual size.
70 mm (23⁄4")
dia probe
(included)
The OMEGA® HHF143 rotating
vane anemometer series are
high-quality instruments providing
highly accurate air velocity and
temperature measurements in
harsh environments via a userfriendly and intuitive interface.
Applications include indoor air
quality, process control, flow
hood monitoring, and many other
applications where precise air flow
and temperature measurement
is required.
SPECIFICATIONS
Ranges:
HHF143B: 0.2 to 40.00 MPS
(40 to 7800 FPM)
HHF143A: 1.5 to 35.00 MPS
(300 to 6800 FPM)
Temperature (Using Either
Air Velocity Probe Head):
-20 to 100°C (-4 to 212°F)
Accuracy
Air Velocity: ±1.0% of reading ±1-digit
Temperature: ±(0.3°C + 0.2% of
reading in °C)
Temperature Accuracy Examples:
±0.3°C @ 20°C (±0.5°F @ 68°F)
Resolution
Air Velocity: 0.01 MPS or 1 FPM
Temperature: 0.1°C or °F
Display:
4-digits, with LED backlight
12.7 mm (0.5") LCD,
Operating Temp:
Instrument: 0 to 50°C (32 to 125°F)
Air Probe: -20 to 100°C (-4 to 212°F)
Power Supply: 3 “AA” alkaline
batteries (included)
Battery Life: Approximately 150 hours
Dimensions:
Instrument: 165 x 83 x 38 mm
(6.5 x 3.25 x 1.5")
HHF143A: 25 mm (1") diameter
HHF143B: 70 mm (2.75") diameter
Cable: 1.5 m (5')
To Order
Model No. Description
HHF143A Handheld thermo-anemometer 25 mm (1") dia probe
HHF143B Handheld thermo-anemometer 70 mm (2³⁄₄") dia probe
Accessories
Model No. Description
HHF140B-RP-T Replacement 70 mm (2³⁄₄") vane probe with temp sensor
HHF140A-RP-T Replacement 25 mm (1") vane probe with temp sensor and
MN1500-4 Package of 4 “AA” replacement batteries
Comes complete with vane probe [25 or 70 mm (1 or 2
rods (flexible, straight and with handle), 1.5 m (5') cable, 3 “AA” alkaline batteries, hard
carrying case, NIST calibration certificate and operator’s manual.
For units with a protective boot add suffix “-PB” to model number, for additional cost.
For units with USB communications add suffix “-USB” to model number, for additional cost.
For units with a 0 to 5 Vdc voltage output add suffix “-V” to model number, for additional cost.
Ordering Example: HHF143B, thermo-anemometer with 70 mm (2
1.5 m (5') cable
3
") depending on model], 3 extension
⁄
4
3
") vane.
⁄
4
C-19
