Handheld
Formaldehyde Meter
HHAQ-108
U Tracks, Calculates
and Displays
Three Cumulative
Formaldehyde Gas
Metrics
U One-Button Calibration
to 0 ppm in Clean Air
U User-Adjustable
High Alarm
U Measures Formaldehyde
ppm, Relative Humidity
(RH) and Temperature
in °F or °C
U Manual Off-Settable
for Temperature and
RH Accuracy
U Min/Max Memory
and Data Hold
U Large Backlit Dual-
Readout LCD
U Low Battery Indication
U Tripod Mount
The HHAQ-108 is ideal for
measuring levels of gaseous
formaldehyde (HCHO) as part
of a workplace indoor air quality
(IAQ) maintenance program,
or to spot-check a residential
environment.
The HHAQ-108 features an
electrochemical sensor which
measures real-time formaldehyde
gas concentration with accuracy
and resolution that meet U.S.
National Institute for Occupational
Safety and Health’s (NIOSH’s)
acceptance criteria. It also tracks,
calculates and displays three
cumulative formaldehyde gas
metrics: 8-hour TWA
(time-weighted average), 1-hour
average, and 15-minute STEL
(short-term exposure limit). The
device is also equipped with a
tripod mount fitting for hands
free monitoring.
Specifications
Formaldehyde Range/Resolution:
0 to 5 ppm/0.01 ppm*
Formaldehyde Accuracy:
±(5% + 0.03 ppm)*
Formaldehyde Sensor Type
Warmup Time: Electrochemical/
1 to 15 minutes
Temperature Range: 0 to 50°C
(0 to 122°F)
Temperature Accuracy/Resolution:
±1°C (1.8°F)/0.1°
RH Range/Accuracy: 10 to 90% RH/
±5% of reading, typical
Display Type/Size: Dual readout
LCD/51 mm (2") diagonal
Auto Power-Off Trigger:
15 minutes of front-panel inactivity
(can be disabled)
Operating Temperature: 0 to 50°C
(32 to 122°F) @ 0 to 95% RH,
non-condensing
Dimensions: 210 L x 60 H x 25 mm D
(8.3 x 2.4 x 1.0")
Weight: 204 g (7.2 oz) (with battery)
Power Source: 4 “AAA” batteries
(included) or optional 110V
AC adaptor (HHB400-AC)
* Meets U.S. National Institute for
Occupational Safety and Health’s
(NIOSH’s) acceptance criteria.
To Order
Model No. Description
HHAQ-108
HHB400-AC
MN2400
Comes complete with soft pouch, 4 “AAA” batteries and operator’s manual.
smaller than actual size.
Handheld formadehyde detector
AC wall adaptor (optional)
Replacement “AAA” batteries 2/pack (2-packs required)
1
HHAQ-108 shown
