INTRODUCTION

This instrument is a portable compact-sized temperature transducer designed
to use external K-type thermocouple and a digital Multimetrer(DMM). The
temperature transducer accepts the output of any K-type thermocouple and
converts it to 1 millivolt per degree Celsius. Temperature indication follows
Reference Temperature/Voltage Tables N.I.S.T. Monograph 175 Revised to
ITS-90 for K-type thermocouples. One K-type thermocouple is supplied with the
thermometer.

SAFETY INFORMATION

It is recommended that you read the safety and operation instructions before
using the temperature transducer.

To avoid electrical shock, do not use this instrument when voltages at the

measurement surface exceed 24V AC or DC.

WARNING

1

To avoid damage or burns, do not make temperature measurement in

WARNING

microwave ovens.

Repeated sharp flexing can break the thermocouple leads. To prolong lead

life, avoid sharp bends in the leads, especially near the connector.

The symbol on the instrument indicates that the operator must refer to an
explanation in this manual.

CAUTION

2

SPECIFICATIONS

ELECTRICAL

Temperature Scale: Celsius.
Measurement Range: -50°C to 1300°C.
Output: 1mV/1°C.
Accuracy: Accuracy is specified for operating temperatures over the range of

18°C to 28°C, for 1 year, not including thermocouple error.

±(0.3%rdg + 1°C) -50°C to 1000°C

±(0.5%rdg + 1°C) 1000°C to 1300°C
Temperature Coefficient: 0.1 times the applicable accuracy specification per

°C from 0°C to 18°C and 28°C to 50°C.
Input Protection: 24V dc or 24V ac rms maximum input voltage on any

combination of input pins.
Input Connector: Accepts standard miniature thermocouple connectors.

3

ENVIRONMENTAL

Ambient Operating Ranges: 0°C to 50°C <80% R.H.
Storage Temperature: -20°C to 60°C <70% R.H.

GENERAL

Battery: 4 pcs 1.5V (AAA size).
Battery Life: 200 hours typical.
Dimensions: 170mm(H) x 44mm(W) x 40mm(D).
Weight: 140g.

4

OPERATING INSTRUCTIONS

1. Plug the temperature transducer test leads into the dc volts input of the

Multimeter. Observe polarity.

2. Set the multimeter to the 200mV range.

3. Use the 2V range for higher temperatures. Ignore the decimal point.

4. Plug the K-type thermocouple into the temperature transducer thermocouple

input connector.

5. Turn on the temperature transducer and the multimeter. Temperature trans-

ducer Green LED Lighted.

6. Read the temperature on the multimeter.

5

OPERATOR MAINTENANCE

To avoid possible electrical shock, disconnect the thermocouple connectors

from the thermometer before removing the cover.

Battery Replacement

Power is supplied by four 1.5V (AAA size) batteries. The red LED Lighted when
replacement is needed. To replace the batteries, remove the screw from the back
of the meter and lift off the battery cover. Remove the batteries from battery
contacts.

WARNING

6
