LONG-LIFE BAND HEATERS
11⁄2"(4 cm) Wide Two-Piece Band Heaters
U Premium Quality
U Rugged Construction
U Sheath Temperature
to 1200°F
U Barrel Temperature
to 800°F
U Terminal Posts for
Power Connection
HB Series band heaters are used
to heat the barrels and nozzles
of plastic injection molders and
extruders. They are also used on
autoclaves and for heat treating
large diameter piping.
Heater elements are high
temperature, tight fitting, and
provide uniform heat distribution.
These elements are made from a
pair of formed OMEGALUX® PT
series 240V mineral insulated strip
heaters with chrome steel sheath.
Complete firm coverage at all times
is assured by slip proof, stainless
steel clamping bands equipped
with heavy threaded socket bolt;
this allows the pair of elements to
be drawn tight to heated surface.
The hotter it gets the tighter it fits.
Because clamps cannot loosen
or slip off heater, heat transfer is
continuously efficient, adding to
heater life.
Adjacent HB Series heaters of equal
wattage may be wired in series on
480V or connected in multiples of
three of 240 or 480V, 3 phase.
OPTIONAL ACCESSORIES
Terminal Cover–sheet metal box
that fully encloses the terminals and
guards against spillovers, dripping,
grounding, or short circuits. To
order, suffix part number with “/
Terminal Cover” for an additional
cost.
Ceramic post terminal insulators,
one set–Use with insulated wire to
protect against electrical shock...
to wire several heaters where Bx
or conduit is not required. Wires
can leave heater terminals at any
angle. For use with #10-32 thread.
To order, part number H-TP, for an
additional cost.
CAUTION AND WARNING!
Fire and electrical shock may
result if products are used
improperly or installed or used
by non-qualified personnel.
See inside back cover for
additional warnings.
HB Series
Barrel
Dia.
1-1/2"
To Order
11⁄2" (4 cm) Wide, 240V
Wt.
Watts Barrel Dia. In. (cm) Model No. lb (kg)
750 5 (13) HB-5075 1.5 (0.7)
800 5
600 5
1500 5
400 6 (15) HB-6040 2 (0.9)
750 6 (15) HB-6075 2 (0.9)
1000 6
1000 7 (18) HB-7010 2 (0.9)
900 7
1250 7
1500 7
900 8 (20) HB-8013 2 (0.9)
1400 8 (20) HB-8014 2.25 (1)
1565 8
1100 9
1710 9
1300 9
1600 9
1800 10 (25) HB-1018 3 (1.4)
2600 10
1200 10
2025 11 (28) HB-1120 3.25 (1.5)
1200 11
1700 11
1500 12
1800 13
1200 14 (36) HB-1412 3.9 (1.8)
2500 14 (36) HB-1425 3.9 (1.8)
2500 15
2500 17 (43) HB-1725 4.2 (1.9)
2500 17
3000 20 (51) HB-2030 4.5 (2)
Mineral insulated band heaters are available in other sizes and ratings. Mica insulated band
heaters are also available.
Ordering Example: HB-1120, 2025 watts, 240V band heater.
1
⁄4 (13) HB-5080 1.75 (0.8)
1
⁄2 (14) HB-5460 1.75 (0.8)
1
⁄2 (14) HB-5415 1.75 (0.8)
1
⁄2 (17) HB-6410 2 (0.9)
1
⁄2 (19) HB-7490 2.25 (1)
1
⁄2 (19) HB-7412 2.25 (1)
7
⁄8 (20) HB-7715 2.25 (1)
1
⁄2 (22) HB-8415 2.3 (1)
(23) HB-9015 2.5 (1.1)
1
⁄4 (23) HB-9217 2.5 (1.1)
1
⁄2 (24) HB-9413 2.75 (1.2)
1
⁄2 (24) HB-9416 2.75 (1.2)
1
⁄4 (26) HB-10226 3 (1.4)
1
⁄2 (27) HB-10415 3 (1.4)
1
⁄2 (29) HB-11412 3.25 (1.5)
1
⁄2 (29) HB-11417 3.25 (1.5)
1
⁄2 (32) HB-12416 3.5 (1.6)
1
⁄2 (34) HB-13418 3.75 (1.7)
1
⁄2 (39) HB-15425 4 (1.8)
1
⁄2 (44) HB-17425 4.3 (1.9)
