Page 1
User's Guide
Shop online at
omega.com
email: [email protected]
For latest product manuals:
omegamanual.Info
FMG-1000-DLA
Data Logger
Page 2
PAGE 1
Page 3
DL76
Data Logger
Data Port
Active Replace
Battery
GENERAL INFORMATION
The FMG-1000-DLA is a battery-powered data logger that can
be used with most Omega owmeters. It stores pulses for up to 3 years, depending on the user-selected frequency of reading. Indicator lights on the unit ash to indicate when it is functioning and when the battery is low. Housings are rugged cast aluminum, gasketed for environmental protection.
When an FMG-1000-DLA logger is placed into operation, it is
easily set up using a laptop computer. Data is also retrieved
FEATURES
from the FMG-1000-DLA by means of a laptop and can be
analyzed on the laptop or easily loaded on a desktop computer
for analysis. Omega software (ordered separately) is required for the downloading, storing, viewing, graphing, charting and printing of data in several formats. The software requires a PC with Windows 98, NT, 2000, XP, Vista, or Windows 7; CD-Rom drive; 800 x 600 screen resolution; serial port or USB/serial adapter; and an Omega data cable.
Data port connector for Omega data collection
cable
Bright status LEDs ash to indicate logger activity and battery life
Sturdy gasketed cover with potted electronics
Removable foot brackets for remote mounting
(wall mount model only)
SPECIFICATIONS*
Power
Battery Life
Temperature
Rate Units Volume
Time
Total Units
Data Storage Capacity
Maximum Input Frequency
Indicators
Memory Wraparound
Clock Accuracy
Protective data port cap (shown open)
Cable to meter (wall mount only)
3.6 Vdc lithium battery (included)
~3 years (varies with sampling interval)
0˚ to 130˚ F (-18˚ to 54˚C)
mL, liter, gallon, Imperial gallon, cubic foot, cubic meter, million gallon
Seconds, minutes, hours, days
Liter, gallon, Imperial gallon, cubic foot, cubic meter, million gallon, acre-foot, acre-inch, megaliter, thousand-gallon
Capacity at Sampling Interval
11 days at 15 seconds
22 days at 30 seconds
44 days at 60 seconds
6 months at 240 seconds
1 year at 480 seconds
3 years at 1450 seconds
500 Hz
Low battery; Power
Selectable options (Stop or Overwrite)
10 minutes/month (.02%)
*Specifications subject to change.
PAGE 2
Page 4
DIMENSIONS & CONNECTIONS
3.95”
4.52”
3.35”
2.06”
3.95”
DL76
Data Logger
Data Port
Active Replace
Battery
4.90”
3”
16
+
S
-
FMG-1000-DL
Battery
Not
Used
FMG-1000 Cable
Power Supply
7-26 Vdc
at 30 mA max
(see WARNING)
FMG-1000
Blue
Orange
Black
Red
Shielded Direct Burial Cable 22 AWG Stranded
White (-)
Green (+)
(-) (+)
Drain Wire
Do
Not
Use
{
DIMENSIONS
FMG-1000-DLA
CONNECTIONS
To connect the FMG-1000 to the FMG-1000-DLA, remove the four cover screws on the data logger with a 5/32" Allen wrench. Connect the leads as shown in the diagram below.
Replace the cover and tighten the screws evenly, assuring that the gasket on the FMG-1000-DLA is visibly compressed all around.
Data Logger
FMG-1000-DLA
CAUTION: Do not apply external
power to the Data Logger.
The FMG-1000 requires a power source of 7 to 26 Vdc at 30 mA max (see WARNING). The same cable that provides power
also serves as a pulse output if needed for remote reading, data logging, signal conversion, or telemetry.
WARNING: Using an unregulated power supply >18 Vdc may damage the meter due to AC line input voltage uctuation.
FMG-1000 Cable Color Codes
Orange (+) and Blue (-): Serial Output (Do Not Use) Green (+) and White (-): Pulse Output, 30 Vdc max, 10 mA max Red (+) and Black (-): External Power, 7-26 Vdc at 30 mA max Drain: Connect to earth ground (see WARNING)
PAGE 3
Page 5
CONNECTIONS & TROUBLESHOOTING
OPERATION Omega V.2 software is required for operation. Please consult
your manual for instructions in loading the software onto your
FMG-1000-DLA Software Capabilities:
• Manage multiple loggers
• Record up to 3 years of data (depending on sampling interval)
• View current rate and total
• Download les from FMG1000-DLA
to laptop
• Display ow information as a graph
• Display data in preferred units
• Display average and maximum/
minimum ow rate for any selected
time period
• Zoom in to graph any time period
• Show daily ow totals in table format
• Append multiple les
• Print graphs and tables
• Export data to a simple text (.txt) le or to an Excel spreadsheet (.csv) for
analysis
computer, setting up your datalogger for use, downloading, storing, and analyzing your data.
TROUBLESHOOTING
Problem
Laptop screen reads ”No connection” and “Ac­tive” light is NOT blinking
Laptop screen reads ”No connection,” but “Ac­tive” light IS blinking
Flow rate incorrect
No ow rate
Probable Cause Try...
FMG-1000-DLA is transmitting data.
Wait for “Active” light to blink
Wait two minutes before taking action.
Dead battery in FMG-1000-DLA
Loose cable
Bad cable
K-factor setting is incorrect
Replace battery
Tighten cable
Replace cable
Make sure K-factor in FMG-1000-DLA matches ow sensor
Damaged ow sensor
Mechanical: See if rotor spins freely EX Magmeter: See if “Status LED” indicator is
blinking
Broken wire
Check for ow rate
PAGE 4
Page 6
NOTES
PAGE 5
Page 7
WARRANTY/DISCLAIMER
OMEGA ENGINEERING, INC. warrants this unit to be free of defects in materials and workmanship for a period of 13 months f rom date of purchase. OMEGA’s WARRANTY adds an additional one (1) month grace period to the normal one (1) year product warranty to cover handling and shipping time. This ensures that OMEGA’s customers receive maximum coverage on each product.
If the unit malfunctions, it must be re t u rned to the factory for evaluation. O M E G A’s Customer Serv i c e D e p a rtment will issue an Authorized Return (AR) number immediately upon phone or written re q u e s t . Upon examination by OMEGA, if the unit is found to be defective, it will be re p a i red or replaced at no c h a rge. O M E G A’s WARRANTY does not apply to defects resulting from any action of the purc h a s e r, including but not limited to mishandling, improper interfacing, operation outside of design limits, i m p roper re p a i r, or unauthorized modification. This WARRANTY is VOID if the unit shows evidence of having been tampered with or shows evidence of having been damaged as a result of excessive corro s i o n ; or current, heat, moisture or vibration; improper specification; misapplication; misuse or other operating conditions outside of OMEGA’s c o n t rol. Components in which wear is not warranted, include but are not limited to contact points, fuses, and triacs.
OMEGA is pl eased to offer suggestions on the use of its various p roducts. However, OMEGA neither assumes responsibility for any omissions or errors nor assumes liability for any damages that result from the use of its products in accordance with information provided by OMEGA, either verbal or written. OMEGA warrants only that the parts manufactured by the company will be as specified and free of defects. OMEGA MAKES NO OTHER WARRANTIES OR R E P R E S E N TATIONS OF ANY KIND WHATSOEVER, EXPRESSED OR IMPLIED, EXCEPT THAT OF TITLE, AND ALL IMPLIED WARRANTIES INCLUDING ANY WARRANTY OF MERCHANTA B I L I T Y AND FITNESS FOR A PA RTICULAR PURPOSE ARE HEREBY DISCLAIMED. LIMITATION OF L I A B I L I T Y: The remedies of purchaser set forth herein are exclusive, and the total liability of OMEGA with respect to this ord e r, whether based on contract, warr a n t y, negligence, indemnification, strict liability or otherwise, shall not exceed the purchase price of the compone nt up on wh ic h liabilit y is based . In no even t sha ll OM EGA b e lia ble for consequential, incidental or special damages.
CONDITIONS: Equipment sold by OMEGA is not intended to be used, nor shall it be used: (1) as a “Basic Component” under 10 CFR 21 (NRC), used in or with any nuclear installation or activity; or (2) in medical applications or used on humans. Should any Product(s) be used in or with any nuclear installation or a c t i v i t y, medical application, used on humans, or misused in any way, OMEGA assumes no re s p o n s i b i l i t y as set forth in our basic WA R R A N TY/ D ISCLAIMER language, and, additionally, purchaser will indemnify OMEGA and hold OMEGA h a rmless from any liability or damage whatsoever arising out of the use of the P roduct(s) in such a manner.
RETURN REQUESTS/INQUIRIES
Direct all warranty and repair requests/inquiries to the OMEGA Customer Service Department. BEFORE RETURNING ANY PRODUCT(S) TO OMEGA, PURCHASER MUST OBTAIN AN AUTHORIZED RETURN (AR ) N U MBER F R OM OMEG A’S CUSTO MER SERVIC E D E PA RT MENT (IN ORDER T O AV O I D PROCESSING DELAYS). The assigned AR number should then be marked on the outside of the return package and on any correspondence.
The purchaser is responsible for shipping charges, freight, insurance and proper packaging to prevent breakage in transit.
FOR WARRANTY RETURNS, please have the following information available BEFORE contacting OMEGA:
1 . P u rchase Order number under which the pro d u c t
was PURCHASED,
2. Model and serial number of the product under warranty, and
3. Repair instructions and/or specific problems relative to the product.
FOR NON-WARRANTY REPAIRS,
consult OMEGA for current repair charges. Have the following information available BEFORE contacting OMEGA:
1. Purchase Order number to cover the COST
of the repair,
2. Model and serial number of the product, and
3. Repair instructions and/or specific problems
relative to the product.
OMEGA’s policy is to make running changes, not model changes, whenever an improvement is possible. This affords our customers the latest in technology and engineering.
OMEGA is a registered trademark of OMEGA ENGINEERING, INC. © Copyright 2005 OMEGA ENGINEERING, INC. All rights reserved. This document may not be copied, photocopied,
reproduced, translated, or reduced to any electronic medium or machine-readable form, in whole or in part, without the prior written consent of OMEGA ENGINEERING, INC.
PAGE 6
Page 8
